Relational Data Hierarchies CSC444 Why hierarchies? http://www.sci.utah.edu/~miriah/cs6630/lectures/L13-trees-graphs.pdf Scatterplots; dot plots; line charts, etc. Until now, our data points were independent of one another In

slide-1
SLIDE 1

Relational Data Hierarchies

CSC444

slide-2
SLIDE 2

Why hierarchies?

http://www.sci.utah.edu/~miriah/cs6630/lectures/L13-trees-graphs.pdf

slide-3
SLIDE 3

Until now, our data points were “independent of one another” Scatterplots; dot plots; line charts, etc.

slide-4
SLIDE 4

In “relational data”, it’s the relationship between points that matters

slide-5
SLIDE 5
  • The reports-to relationship in an organization
slide-6
SLIDE 6
  • The “tree of life”
  • evolution of species creates branching

mechanism and “ancestor-of” relationship

slide-7
SLIDE 7

What do we want our drawings to show?

  • Who reports to whom
  • … and who doesn’t
  • How big are “sub-organizations”
  • …?
slide-8
SLIDE 8

Many different ways to visualize trees

slide-9
SLIDE 9

http://homes.cs.washington.edu/~jheer/files/zoo/ex/hierarchies/tree.html

slide-10
SLIDE 10

Treemaps

  • Represent hierarchy by containment,
  • … and sizes by areas
  • Let’s work out a simple algo!
slide-11
SLIDE 11

Squarified Treemaps

  • A little harder, tries to make square shapes
slide-12
SLIDE 12

Reingold-Tilford tree drawing

  • All of the before, plus:
  • Don’t waste horizontal space
  • If tree is symmetric, so should be the drawing

http://hci.stanford.edu/courses/cs448b/f11/lectures/ CS448B-20111110-GraphsAndTrees.pdf

slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38
slide-39
SLIDE 39
slide-40
SLIDE 40
slide-41
SLIDE 41
slide-42
SLIDE 42

Reingold-Tilford Algorithm

  • Bottom-up tree traversal
  • y-coord is the depth of the node, x-coords are “locally defined” (so

first is arbitrary)

  • merge trees
  • push right tree as close as possible to left tree (this is where the

contour comes in)

  • position shifts saved at each node
  • parent nodes are centered above direct children
  • Final top-down pass to convert shifts to positions
slide-43
SLIDE 43

Not all Hierarchies are Trees

slide-44
SLIDE 44

Given what we know about tree drawing, how do we draw a DAG?

slide-45
SLIDE 45

The evolution of UNIX

http://www.graphviz.org/Gallery/directed/unix.svg

slide-46
SLIDE 46

The evolution of UNIX

http://www.graphviz.org/Gallery/directed/unix.svg

slide-47
SLIDE 47

Directed, Acyclic Graphs

  • Like a hierarchy, but “direct ancestor” is not unique
slide-48
SLIDE 48

Let’s draw a DAG

  • Compute rank: height of node
  • Requirement: if aRb, height(a) > height(b)
  • Order nodes of same rank to minimize crossings
  • This is known as a “Sugiyama layout” for its

inventor

  • Gansner et al., A Technique for Drawing Directed
  • Graphs. http://ieeexplore.ieee.org/stamp/stamp.jsp?tp=&arnumber=221135
slide-49
SLIDE 49

Let’s draw a DAG

  • Gansner et al., A Technique for Drawing Directed
  • Graphs. http://ieeexplore.ieee.org/stamp/stamp.jsp?tp=&arnumber=221135
slide-50
SLIDE 50

Given what we know about treemaps, can we draw a DAG?

slide-51
SLIDE 51

Euler Diagrams (Venn Diagrams)

slide-52
SLIDE 52

Euler Diagrams

  • Represent relationship by

containment

  • Algorithms are very

complicated, tend to produce bad shapes

slide-53
SLIDE 53

Euler Diagrams

  • Doesn’t scale to large

diagrams

http://raweb.inria.fr/rapportsactivite/RA2009/gravite/3.png

slide-54
SLIDE 54

Euler Diagrams

  • Doesn’t scale to “large”

diagrams

64 regions 16 regions

slide-55
SLIDE 55

Recap

Not a Hierarchy Hierarchy Not a Tree NEXT Sugiyama’s algorithm Euler Diagrams A Tree NEXT Reingold-Tilford Treemaps
