SLIDE 1
Relating and Visualising CSP , VCR and Structural Traces
Neil Brown1 Marc Smith2
1Computing Laboratory, University of Kent, UK 2Department of Computer Science, Vassar College, NY, USA
Motivation
Relating and Visualising CSP , VCR and Structural Traces Neil Brown - - PowerPoint PPT Presentation
Relating and Visualising CSP , VCR and Structural Traces Neil Brown - - PowerPoint PPT Presentation
Relating and Visualising CSP , VCR and Structural Traces Neil Brown 1 Marc Smith 2 1 Computing Laboratory, University of Kent, UK 2 Department of Computer Science, Vassar College, NY, USA 2 November 2009 Motivation Dining Philosophers
SLIDE 2
SLIDE 3
Motivation
Starving Dining Philosophers
SLIDE 4
Background
Visualization: Strings and Beads
Consider the CSP system: P ||
{a,f}
Q where P = a → b → c → f → SKIP Q = a → d → e → f → SKIP
a b d f c e P Q
SLIDE 5
Background
Visualization: Strings and Beads
Consider the CSP system: P ||
{a,f}
Q where P = a → b → c → f → SKIP Q = a → d → e → f → SKIP
a b d f c e P Q
SLIDE 6
Background
Visualization: Strings and Beads
Consider the CSP system: P ||
{a,f}
Q where P = a → b → c → f → SKIP Q = a → d → e → f → SKIP
a b d f c e P Q
SLIDE 7
Background
Visualization: Strings and Beads
Consider the CSP system: P ||
{a,f}
Q where P = a → b → c → f → SKIP Q = a → d → e → f → SKIP
a b d f c e P Q
SLIDE 8
Background
CSP Observer
SLIDE 9
Background
CSP Observer
SLIDE 10
Background
CSP Observer
a b d f c e P Q a b d f c e P Q a b d f c e P Q a b d f c e P Q
a, b, c, d, e, f a, b, d, c, e, f a, b, d, e, c, f a, d, b, c, e, f a, d, e, b, c, f a, d, b, e, c, f
SLIDE 11
Background
VCR Observer(s)
SLIDE 12
Background
VCR Observer(s)
a b d f c e P Q a b d f c e P Q a b d f c e P Q a b d f c e P Q
{a}, {b, d}, {c, e}, {f} {a}, {b}, {c, d}, {e}, {f} {a}, {d}, {b, e}, {c}, {f}
SLIDE 13
Background
Structural Observers
SLIDE 14
Background
Structural Observers
a b d f c e P Q a b d f c e P Q a b d f c e P Q a b d f c e P Q
(a → b → c → f) || (a → d → e → f)
SLIDE 15
Background
Traces
Three types of traces:
1 CSP traces
A sequence of individual events, recorded by the observer; events observed simultaneously are interleaved abstracts away time and space
2 VCR Traces
A sequence of event multisets; multiple observers account for different views preserves time independence; abstracts away space
3 Structural Traces
Sequential and parallel composition of the trace reflects the program’s structure preserves time independence and space
SLIDE 16
Background
Space and Mobility
logger c
SLIDE 17
Background
Space and Mobility
logger c logger!42 logger?42
SLIDE 18
Background
Space and Mobility
logger c logger!42
- > c!logger
logger?42 c?logger
SLIDE 19
Background
Space and Mobility
logger c logger!42
- > c!logger
logger?42
- > logger?43
c?logger
- > logger!43
SLIDE 20
Background
Space and Mobility
logger c logger!42
- > c!logger
logger?42
- > logger?43
c?logger
- > logger!43
(logger!42 → c!logger) || (c?logger → logger!43) || (logger?42 → logger?43)
SLIDE 21
Conversion
Conversion Example
CSP: P = (AB o
9 AB) ||
{b}
(b → b → SKIP) where AB = (a → SKIP) ||| (b → SKIP)
SLIDE 22
Conversion
Conversion Example
CSP: P = (AB o
9 AB) ||
{b}
(b → b → SKIP) where AB = (a → SKIP) ||| (b → SKIP) Structural Trace Visualisation:
a b a b b b
SLIDE 23
Conversion
Conversion Example
CSP: P = (AB o
9 AB) ||
{b}
(b → b → SKIP) where AB = (a → SKIP) ||| (b → SKIP) Structural Trace Conversion Algorithm:
a b a b b b
SLIDE 24
Conversion
Conversion Example
Structural Trace Conversion Algorithm:
a b a b b b
VCR Trace Visualisation:
a b a b
SLIDE 25
Conversion
Conversion Example
VCR Trace Visualisation:
a b a b
SLIDE 26
Conversion
Conversion Example
VCR Trace Visualisation:
a b a b
CSP Trace Visualisation:
a b a b b a a b a b b a b a b a
SLIDE 27
Example
Starving CHP Philosophers
SLIDE 28
Example
Starving CHP Philosophers Trace
philosopher eatChicken = forever (syncBarrier eatChicken) chef a b c = forever ((syncBarrier a <&> syncBarrier b) <-> (syncBarrier b <&> syncBarrier c) <-> (syncBarrier a <&> syncBarrier c))
SLIDE 29
Example
Starving CHP Philosophers Trace
philosopher eatChicken = forever (syncBarrier eatChicken) chef a b c = forever ((syncBarrier a <&> syncBarrier b) <-> (syncBarrier b <&> syncBarrier c) <-> (syncBarrier a <&> syncBarrier c))
chicken.0 chicken.1 chicken.2 ... (Chef) chicken.0 chicken.0 chicken.2 chicken.2 chicken.2
SLIDE 30
Summary
Summary
Traces are useful for diagnostics and observing run-time behaviour Structural traces
Most straightforward and efficient to record Useful for observing mobility
Conversion algorithms
One Structural trace converts to many VCR traces One VCR trace converts to many CSP traces
Visualisation
Graphs to represent CSP , VCR and Structural traces Tool support will be beneficial
SLIDE 31
Future Work
Tools to Explore Traces
prefix delta succ b c a numbers recorder d 42*(b? -> (c! || d!)) || (42*(b! -> a?) -> b!) || 42*(c! -> a?)
SLIDE 32
Future Work
Tools to Explore Traces
prefix delta succ b c a numbers recorder d 42*(b? -> (c! || d!))
SLIDE 33
Future Work
Challenge: Structural traces and UTP
a c b a c d b d e a g f c
Figure: Concatenation, quotient and healthiness conditions
