Red Storm / Cray XT4: A Superior Architecture for Scalability Mahesh Rajan, Doug Doerfler, Courtenay Vaughan Sandia National Laboratories, Albuquerque, NM Cray User Group Atlanta, GA; May 4-9, 2009 Sandia is a multi-program laboratory


slide-1
SLIDE 1

Red Storm / Cray XT4: A Superior Architecture for Scalability

Mahesh Rajan, Doug Doerfler, Courtenay Vaughan Sandia National Laboratories, Albuquerque, NM Cray User Group Atlanta, GA; May 4-9, 2009

Sandia is a multi-program laboratory operated by Sandia Corporation, a Lockheed Martin Company, for the United States Department of Energy’s National Nuclear Security Administration under contract DE-AC04-94AL85000.

1 Rajan, Doerfler, Vaughan

slide-2
SLIDE 2

MOTIVATION

  • Major trend in HPC system architecture: use of commodity multi-socket

multi-core nodes with InfiniBand Interconnect

  • DOE under the ASC Tri-Lab Linux Capacity Cluster (TLCC) program has

purchased 21 “Scalable Units” (SUs). Each SU consists of 144 four-socket, quad-core AMD Opteron (Barcelona) nodes, using DDR InfiniBand as the high speed interconnect

  • Red Storm/Cray XT4 at Sandia was recently upgraded: the 6240 nodes in

the ‘center section’ were upgraded to a similar AMD Opteron quad-core processor (Budapest)

  • Comparison of performance between Red Storm and TLCC reveals a

wealth of information about HPC architectural balance characteristics on application scalability

  • The best TLCC performance used for comparisons; Often required

NUMACTL

  • The benefits of the superior architectural features of Cray/XT4 are

analyzed through several benchmarks and applications

slide-3
SLIDE 3

Presentation Outline

Rajan, Doerfler, Vaughan 3

  • Overview of current Red Storm/Cray XT4 system at Sandia
  • Overview of the Tri-Lab Linux Capacity Cluster -TLCC
  • Architectural similarities and differences between the two systems
  • Architectural balance ratios
  • Micro-benchmarks
  • Memory latency
  • Memory bandwidth
  • MPI Ping-Pong
  • MPI Random and Bucket-Brigade
  • Mini-Applications
  • Mantevo-HPCCG
  • Mantevo-phdMesh
  • SNL Applications
  • CTH – Shock hydrodynamics
  • SIERRA/Presto – Explicit Lagrangian mechanics with contact
  • SIERRA/Fuego – Implicit multi-physics Eulerian mechanics
  • LAMMPS – Molecular dynamics
slide-4
SLIDE 4

Red Storm Architecture

Rajan, Doerfler, Vaughan 4 284.16 TeraFLOPs theoretical peak performance 135 compute node cabinets, 20 service and I/O node cabinets, and 20 Red/Black switch cabinets 640 dual-core service and I/O nodes (320 for red, 320 for black) 12,960 compute nodes (dual-core and quad-core nodes) = 38,400 compute cores 6720 Dual-Core nodes with AMD Opteron™ processor 280 2.4 GHz 4 GB of DDR-400 RAM 64 KB L1 instruction and data caches on chip 1 MB L2 shared (Data and Instruction) cache on chip Integrated Hyper Transport2 Interfaces 6240 Quad-Core nodes with AMD Opteron™ processor Budapest 2.2 GHz 8 GB of DDR2-800 RAM 64 KB L1 instruction and 64KB L1 data caches on chip per core 512 KB L2 Cache per core 2 MB L3 shared (Data and Instruction) cache on chip Integrated Hyper Transport3 Interfaces

slide-5
SLIDE 5

TLCC Overview

Rajan, Doerfler, Vaughan 5

SNL ‘s TLCC 38 TeraFLOPs theoretical peak performance 2 Scalable Units (SUs) 288 total nodes 272 quad-socket, quad-core compute nodes 4,352 compute cores 2.2 GHz AMD Opteron Barcelona 32 GB DDR2 -667 RAM per node 9.2 TB total RAM 64 KB L1 instruction and 64KB L1 data caches on chip per core 512 KB L2 Cache per core 2 MB L3 shared (Data and Instruction) cache on chip Integrated dual DDR memory controllers Integrated Hyper Transport3 Interfaces Interconnect: InfiniBand with OFED stack InfiniBand card: Mellanox ConnectX HCA

slide-6
SLIDE 6

Architectural Comparison

Rajan, Doerfler, Vaughan 6 Name Cores/Node Networlk/Topo logy Total nodes(N) Clock (GHz) Mem/core & Speed MPI Inter Node Latency (usec) MPI Inter Node BW (GB/ s) Stream BW (GB/s/No de) Memory Latency (clocks)

Red Storm (dual) 2 Mesh/ Z Torus 6,720 2.4 2GB; DDR- 400MHz 4.8 2.04 4.576 119 Red Storm (quad) 4 Mesh/ Z Torus 6, 240 2.2 2GB; DDR2- 800MHz 4.8 1.82 8.774 90 TLCC 16 Fat-tree 272 2.4 2GB; DDR2- 667 MHz 1.0 1.3 15.1 157

slide-7
SLIDE 7

Node Balance Ratio Comparison

Rajan, Doerfler, Vaughan 7

MAX Bytes-to- FLOPS Memory MAX Bytes-to- FLOPS Interconnect MIN Bytes-to- FLOPS Memory MIN Bytes-to- FLOPS Interconnect Red Storm (dual) 0.824 0.379 0.477 0.190 Red Storm (quad) 0.756 0.232 0.249 0.058 TLCC 0.508 0.148 0.107 0.009 Ratio: Quad/ TLCC 1.49 1.57 2.33 6.28 Bytes-to-FLOPS Memory = Stream BW (Mbytes/sec)/ Peak MFLOPS Bytes-to-FLOPS Interconnect = Ping-Pong BW (Mbytes/sec)/ Peak MFLOPS MAX = using single core on node MIN = using all cores on a node

slide-8
SLIDE 8

Micro-Benchmark: Memory Latency- single thread

Rajan, Doerfler, Vaughan 8

50 100 150 200 250 300 350 1.00E+05 1.00E+06 1.00E+07 1.00E+08 Latency, Clock Cycles Array Size, Bytes

Memory Access Latency

Red Storm Dual Red Storm Quad TLCC

3 cycles L1 (64k) 15 cycles L2(512k) 45 cycles shared L3(2MB) 90+ cycles RAM

slide-9
SLIDE 9

Micro-Benchmark: STREAMS Memory Bandwidth -MBytes/sec

Rajan, Doerfler, Vaughan 9

2000 4000 6000 8000 10000 12000 14000 16000 One MPI task two MPI tasks Four MPI tasks Two MPI tasks, Two sockets on a node Four MPI tasks, Two sockets on a node Eight MPI tasks, Two sockets on a node Red Storm Dual Red Storm Quad TLCC

slide-10
SLIDE 10

Micro-Benchmark: MPI Ping-Pong

Rajan, Doerfler, Vaughan 10

500 1,000 1,500 2,000 2,500 1.E+00 1.E+01 1.E+02 1.E+03 1.E+04 1.E+05 1.E+06 1.E+07 1.E+08

Bandwidth, Mbytes/sec Message Size, Bytes

Red Storm - Dual Red Storm - Quad TLCC

slide-11
SLIDE 11

Micro-Benchmark: MPI Ping-Pong

Rajan, Doerfler, Vaughan 11

0.001 0.01 0.1 1 1 10 100 1,000 10,000 Time in milliseconds Number of MPI Tasks

MPI Allreduce 8 Bytes Time

Red Storm Dual Red Storm Quad TLCC MVAPICH

slide-12
SLIDE 12

MPI Random and Bucket-Brigade Benchmark Bandwidths in MBytes/sec

Random Message (RM) Sizes = 100 to 1K Bytes; Bucket Brigade Small (BBS) size = 8 bytes; Bucket Brigade Large (BBL) size= 1MB

Rajan, Doerfler, Vaughan 12

RM - 1024 RM- 256 RM- 64 BBS- 1024 BBS- 256 BBS- 64 BBL- 1024 BBL- 256 BBL- 64

Red Storm Dual

67.7 71.9 75.3 1.19 1.19 1.20 1100.2 1116.1 1132.4

Red Storm Quad

41.6 45.0 46.9 0.86 0.86 0.86 654.7 647.6 632.2

TLCC

0.43 1.59 3.64 1.77 3.37 3.42 275.47 314.3 344.1 Note Big Difference between Red Storm and TLCC for Random Messaging Benchmark Random BW Ratio Quad/TLCC @1024 = 97; Random BW Ratio Quad/TLCC @64 = 13

slide-13
SLIDE 13

Mini-Application: Mantevo HPCCG

Illustrates Node Memory Architectural Impact

Rajan, Doerfler, Vaughan 13

10 20 30 40 50 60 70 1 10 100 1000 10000 Wall Time, secs Number of MPI Tasks

Mini-Application HPCCG; Wall Times, secs

Red Storm Dual Red Storm Quad TLCC

  • Mike Heroux’s Conjugate

Gradient mini-application

  • Coefficient matrix stored in

sparse matrix format

  • Most of the time dominated by

sparse matrix vector multiplication

  • Parallel overhead small fraction
  • TLCC-16ppn runs show strong

benefit of using numactl to set process and memory affinity bindings

  • Once best performance within a

node is achieved weak scaling curve is near perfect

  • TLCC 2 to 4 MPI tasks 37% loss; 8

to 16 MPI tasks another 44% loss

  • 1.7 X slower TLCC performance;

This ratio approaches worst Quad/TLCC byte-to-FLOPS ratio of 2.3 discussed earlier

slide-14
SLIDE 14

Mini-Application – Mantevo: phdMesh

Rajan, Doerfler, Vaughan 14 0.02 0.04 0.06 0.08 0.1 0.12 1 10 100 1000 Search time/Step ( seconds) Number of MPI Tasks

phdMesh Oct-tree geometric search wall time, secs

Red Storm Dual Red Storm Quad TLCC

  • Benchmark used for

research in contact detection algorithms

  • Figure shows a weak scaling

analysis using a grid of counter rotating gears: 4x3x1 on 2 PEs, 4x3x2 on 4 PEs, etc

  • Search time / step of an oct-

tree geometric proximity search detection algorithm is shown.

  • TLCC shows quite good

performance except at scale at 512 cores where it is about 1.4X slower than Red Storm Quad.

slide-15
SLIDE 15

Red Storm, TLCC Application Performance Comparison

TLCC/Red Storm Wall Time Ratio Ratio = 1, runs take the same time Ratio =2, TLCC takes twice as long

Rajan, Doerfler, Vaughan 15

1 2 3 4 5 6 7 8 9 64 MPI tasks 256 MPI Tasks 1024 MPI Tasks

slide-16
SLIDE 16

CTH – Weak Scaling

Rajan, Doerfler, Vaughan 16

  • CTH is used for two- and three-

dimensional problems involving high- speed hydrodynamic flow and the dynamic deformation of solid materials

  • Model: shaped-charge; cylindrical

container filled with high explosive capped with a copper liner.

  • Weak scaling analysis with

80x192x80 computational cells per processor.

  • Processor exchanges information

with up to six other processors in the

  • domain. These messages occur several

times per time step and are fairly large since a face can consist of several thousand cells

  • Modest communication overhead

with nearest neighbor exchanges

  • At 16 cores Red Storm Quad is

1.23X faster than TLCC; at 512 cores to 1.32X; This is close to the memory speed ratio of 800/667=1.2

  • CTH does not greatly stress the

interconnect 200 400 600 800 1000 1200 1400 1600 1800 2000 1 10 100 1000 10000 Wall Time, secs Number of MPI Tasks CTH Shape Charge: Wall Time for 100 time Steps: Weak Scaling with 80x192x80 Cells/core Red Storm Dual Red Storm Quad TLCC

slide-17
SLIDE 17

SIERRA/Presto – Weak Scaling

Rajan, Doerfler, Vaughan 17

  • Explicit Lagrangian mechanics

with contact

  • Model: Two sets of brick-walls

colliding

  • Weak scaling analysis with 80

bricks/PE, each discretized with 4x4x8 elements

  • Contact algorithm

communications dominates the run time

  • The rapid increase in run time

after 64 processors on TLCC can be directly related to the poor performance on TLCC for random small-to-medium size messages

  • TLCC/Quad run time ratio at

1024 is 4X.

0:00:00 0:07:12 0:14:24 0:21:36 0:28:48 0:36:00 0:43:12

1 10 100 1000 10000 Wall Clock Time, hr:mi:sec

Number of MPI Tasks

PRESTO: Walls Collision Weak Scaling 10,240 Eelemnts/task; 596 Time Steps

Red Storm Dual Red Storm Quad TLCC

slide-18
SLIDE 18

CTH, Presto(using Pronto)scaling analysis with cray_pat Message density in Mosaic explains Red Storm, TLCC Scaling

Rajan, Doerfler, Vaughan 18

CTH

CTH Mosaic shows # of calls; regular nearest neighbor large message communications CTH Trace: One cycle between the two MPI_bcast ( Green vertical lines)

PRONTO

Pronto uses the same algorithms as Presto but was easier to profile. Pronto Mosaic shows # of calls; Random small message communications Pronto Trace: One cycle shows large communication to computation time ratio

slide-19
SLIDE 19

SIERRA/Fuego – Weak Scaling

Rajan, Doerfler, Vaughan 19

0:00:00 0:14:24 0:28:48 0:43:12 0:57:36 1:12:00 1:26:24 1:40:48 1 10 100 1000 10000 Wall Clock Time, hr:mi:sec Number of MPI Tasks

FUEGO: Methanol EDC Weak Scaling; 2.56M nodes Model

Red Storm Dual Red Storm Quad TLCC

  • Fluids, heat transfer,

participating media radiation, multi-physics code

  • Model: Methanol EDC,

single Fluids mesh

  • Strong scaling analysis
  • Scaling dominated by

implicit fluid solves ( ML)

  • at 64, 128, 256 PEs the

TLCC performance is very good

  • at 512 PEs and above

performance degrades; 3X slower performance on TLCC at 2048

slide-20
SLIDE 20

LAMMPS – Strong Scaling

Rajan, Doerfler, Vaughan 20

  • Classical molecular dynamics
  • Model: RhodoSpin benchmark
  • Strong scaling analysis with 32,000

atoms for 100 time steps

  • LAMMPS divides the

computational domain into three dimensional sub-volumes, and makes the sub-volumes as cubic as possible, The amount of data exchanged is proportional to the surface area of the sub-volume.

  • Little sensitivity to memory

performance; Very good performance on TLCC till 128 PEs

  • This example illustrates how even

if the application does not stress the memory or the interconnect, Red Storm shows superior scalability

1 10 100 1000 1 10 100 1000 Wall Time, Secs Number of MPI Tasks

LAMMPS: RhodoSpin Strong Scaling

Red Storm Dual:VN2 Red Storm Quad:VN4 TLCC

slide-21
SLIDE 21

Conclusions

Rajan, Doerfler, Vaughan 21

 The superior architecture of the Red Storm is evident from the variety of benchmarks and applications presented. The node architecture (minimizing memory contention), the Interconnect architecture (maximizing BW for unstructured, random messages), and the LWK at compute nodes (minimizing OS overheads) are all absolutely necessary to achieve scalability  For 256 or fewer MPI processes similar performance was observed on TLCC and Red Storm for many applications when using all the cores on a node  But for some applications like Presto, there is a need for architecture like the Red Storm as the scaling results demonstrate  Although the four socket node on TLCC has cost advantages, our MPI applications show potential 2X performance penalty due to memory contention  The Red Storm Quad node core has close to 2X peak FLOPS compared to the Red Storm Dual node core. But the run time are close because most applications could not take advantage of the four FLOPS/clock. The inevitable cost pressures to increase core counts on a node might be detrimental in that no improvements in run time may result.
