SLIDE 1
Silicon Valley AI Lab
Exploring Sparsity in Recurrent Neural Networks
Sharan Narang
May 9, 2017
Speech Recognition with Deep Learning
English
Recurrent Neural Networks Sharan Narang May 9, 2017 Silicon Valley - - PowerPoint PPT Presentation
Recurrent Neural Networks Sharan Narang May 9, 2017 Silicon Valley - - PowerPoint PPT Presentation
Exploring Sparsity in Recurrent Neural Networks Sharan Narang May 9, 2017 Silicon Valley AI Lab Speech Recognition with Deep Learning English Scaling with Data Compa paris rison on of Spe peech Recogni gnition tion App pproac roaches
SLIDE 2
SLIDE 3
Scaling with Data
Accuracy Data + Model Size (Speed)
Compa paris rison
- n of Spe
peech Recogni gnition tion App pproac roaches hes Title
Deep Learning Traditional methods
SLIDE 4
Model Sizes
8.14 67.70 115.47 32.56 270.79 461.87
0.00 100.00 200.00 300.00 400.00 500.00
Deep Speech 1 Deep Speech 2 (RNN) Deep Speech 2 (GRU) Baidu du Speec ech h Models els Number of Parameters (in millions) Size (in MB)
SLIDE 5
Future Vision
SLIDE 6
Sparse Neural Networks
SLIDE 7
Pruning Weights
Epochs Dense Initial Network Start of Training Pruning Weights During Training Sparse Final Network End of Training
SLIDE 8
Pruning Approach
0.1 0.2 0.3 0.4 0.5
5 10 15 20 Prune Threshold Epoch Recurrent Linear
SLIDE 9
Pruning Layers
70% 75% 80% 85% 90% 95% 100%
1 2 3 4 5 6 7 8 9 10 11 12 13 14 Sparsity Layers Pruned Percent
SLIDE 10
Results
Model Layer Size # of Params CER Relative Perf RNN Dense 1760 67 million 10.67 0.0% RNN Sparse 1760 8.3 million 12.88
- 20.71%
RNN Sparse 2560 11.1 million 10.59 0.75% RNN Sparse 3072 16.7 million 10.25 3.95% GRU Dense 2560 115 million 9.55 0.0% GRU Sparse 2560 13 million 10.87
- 13.82%
GRU Sparse 3568 17.8 million 9.76
- 2.2%
SLIDE 11
Equal Parameter Networks
20 25 30 35 40 45 50 55 60
5 10 15 20 CTC Cost Epoch Number
small_dense_train small_dense_dev0 large_sparse_train large_sparse_dev0
SLIDE 12
Sparsity v/s Accuracy
- 70%
- 60%
- 50%
- 40%
- 30%
- 20%
- 10%
0% 10%
0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
Relative Accuracy Sparsity
10.89 CER 17.4 CER 13.0 CER
Baseline line
SLIDE 13
Models don’t need to be retrained
SLIDE 14
Compression
8.11 6.06 4.04
2 4 6 8 10
1760 Sparse 2560 Sparse 3072 Sparse Compression Sparse se Models els
RNN Model
SLIDE 15
Speedup
2.90 1.93 1.16 10 5.33 3.89
2 4 6 8 10 12
1760 Sparse 2560 Sparse 3072 Sparse Sparse se Models els Measured Speedup Expected Speedup
SLIDE 16
Conclusion
- Sparse Neural Networks can achieve good accuracy while
significantly reducing the number of parameters
- Threshold based approach works for fully connected layers,
recurrent layers and GRU layers
- Improvements in Sparse Matrix Vector libraries can result in
higher speedup for Sparse Neural Networks
SLIDE 17
Thank You!
SLIDE 18
Sharan Narang sharan@baidu.com http://research.baidu.com
Silicon Valley AI Lab
