Lecture 10: Recurrent Neural Networks CS109B Data Science 2 Pavlos - - PowerPoint PPT Presentation

CS109B Data Science 2

Pavlos Protopapas and Mark Glickman

Lecture 10: Recurrent Neural Networks

CS109B, PROTOPAPAS, GLICKMAN

Sequence Modeling: Handwritten Text Translation

2

• Input : Image
• Output: Text

https://towardsdatascience.com/build-a-handwritten-text-recognition-system-using-tensorflow- 2326a3487cd5

CS109B, PROTOPAPAS, GLICKMAN

Sequence Modeling: Text-to-Speech

3

• Input : Audio
• Output: Text

CS109B, PROTOPAPAS, GLICKMAN

Sequence Modeling: Machine Translation

4

• Input : Text
• Output: Translated Text

CS109B, PROTOPAPAS, GLICKMAN

Rapping-neural-network

5

https://github.com/robbiebarrat/rapping-neural-network

CS109B, PROTOPAPAS, GLICKMAN

Outline

Why RNNs Main Concept of RNNs More Details of RNNs RNN training Gated RNN

6

CS109B, PROTOPAPAS, GLICKMAN

Outline

Why RNNs Main Concept of RNNs More Details of RNNs RNN training Gated RNN

7

CS109B, PROTOPAPAS, GLICKMAN

What can my NN do?

8

NN [George, Mary, Tom, Suzie]

Training: Present to the NN examples and learn from them.

CS109B, PROTOPAPAS, GLICKMAN

What can my NN do?

9

NN George NN Mary

Prediction: Given an example

CS109B, PROTOPAPAS, GLICKMAN

What my NN can NOT do?

10

WHO IS IT?

?

CS109B, PROTOPAPAS, GLICKMAN

Learn from previous examples

11

Time

CS109B, PROTOPAPAS, GLICKMAN

Recurrent Neural Network (RNN)

12

NN George

CS109B, PROTOPAPAS, GLICKMAN

Recurrent Neural Network (RNN)

13

NN George I have seen George moving in this way before. RNNs recognize the data's sequential characteristics and use patterns to predict the next likely scenario.

CS109B, PROTOPAPAS, GLICKMAN

Recurrent Neural Network (RNN)

Our model requires context - or contextual information - to understand the subject (he) and the direct object (it) in the sentence.

14

WHO IS HE?

I do not know. I need to know who said that and what he said before. Can you tell me more? He told me I could have it

CS109B, PROTOPAPAS, GLICKMAN

RNN – Another Example with Text

After providing sequential information, the model understood the subject (Joe’s brother) and the direct object (sweater) in the sentence .

15

WHO IS HE?

I see what you mean now! The noun “he” stands for Joe’s brother while ”it” for the sweater.

• Hellen: Nice sweater Joe.
• Joe: Thanks, Hellen. It used

to belong to my brother and he told me I could have it.

CS109B, PROTOPAPAS, GLICKMAN

Sequences

• We want a machine learning model to understand sequences, not isolated

samples.

• Can MLP do this?
• Assume we have a sequence of temperature measurements and we want to take 3

sequential measurements and predict the next one

16

35 32 45 48 41 39 36 … 1 2 3 4 5 6 7 … features samples

CS109B, PROTOPAPAS, GLICKMAN

Sequences

• We want a machine learning model to understand sequences, not isolated

samples.

• Can MLP do this?
• Assume we have a sequence of temperature measurements and we want to take 3

sequential measurements and predict the next one

17

35 32 45 48 41 39 36 … 1 2 3 4 5 6 7 … features samples 35 32 45 48 1 2 3 4

CS109B, PROTOPAPAS, GLICKMAN

Sequences

• We want a machine learning model to understand sequences, not isolated

samples.

• Can MLP do this?
• Assume we have a sequence of temperature measurements and we want to take 3

sequential measurements and predict the next one

18

35 32 45 48 41 39 36 … 1 2 3 4 5 6 7 … features samples 35 32 45 48 1 2 3 4 32 45 48 41 2 3 4 5

CS109B, PROTOPAPAS, GLICKMAN

Sequences

• We want a machine learning model to understand sequences, not isolated

samples.

• Can MLP do this?
• Assume we have a sequence of temperature measurements and we want to take 3

sequential measurements and predict the next one

19

35 32 45 48 41 39 36 … 1 2 3 4 5 6 7 … features samples 35 32 45 48 1 2 3 4 32 45 48 41 2 3 4 5 45 48 41 39 3 4 5 6

CS109B, PROTOPAPAS, GLICKMAN

Sequences

• We want a machine learning model to understand sequences, not isolated

samples.

• Can MLP do this?
• Assume we have a sequence of temperature measurements and we want to take 3

sequential measurements and predict the next one

20

35 32 45 48 41 39 36 … 1 2 3 4 5 6 7 … features samples 35 32 45 48 1 2 3 4 32 45 48 41 2 3 4 5 45 48 41 39 3 4 5 6

CS109B, PROTOPAPAS, GLICKMAN

Windowed dataset

This is called overlapping windowed dataset, since we’re windowing observations to create new. We can easily do using a MLS:

21

3 1

10 ReLU 10 ReLU 1 ReLU 45 35 32 3 1 2 4 32 48 45 2 4 3 5 41 48 45 5 4 3 6

will produce the same results But re-arranging the order of the inputs like:

CS109B, PROTOPAPAS, GLICKMAN

Why not CNNs or MLPs?

22

1. MLPs/CNNs require fixed input and output size

• 2. MLPs/CNNs can’t classify inputs in multiple places

CS109B, PROTOPAPAS, GLICKMAN

Windowed dataset

What follows after: ‘I got in the car and’ ? drove away What follows after: ‘In car the and I’ ? Not obvious it should be ‘drove away’ The order of words matters. This is true for most sequential data. A fully connected network will not distinguish the order and therefore missing some information.

23

CS109B, PROTOPAPAS, GLICKMAN

Outline

Why RNNs Main Concept of RNNs More Details of RNNs RNN training Gated RNN

24

CS109B, PROTOPAPAS, GLICKMAN

Memory

Somehow the computational unit should remember what it has seen before.

25

Unit 𝑌" 𝑍

"

Should remember 𝑌$ … 𝑌"&'

CS109B, PROTOPAPAS, GLICKMAN

Memory

Somehow the computational unit should remember what it has seen before.

26

Unit Internal memory

𝑌" 𝑍

"

CS109B, PROTOPAPAS, GLICKMAN

Memory

Somehow the computational unit should remember what it has seen before. We’ll call the information the unit’s state.

27

RNN Internal memory

𝑌" 𝑍

"

CS109B, PROTOPAPAS, GLICKMAN

Memory

In neural networks, once training is over, the weights do not change. This means that the network is done learning and done changing. Then, we feed in values, and it simply applies the operations that make up the network, using the values it has learned. But the RNN units are able to remember new information after training has completed. That is, they’re able to keep changing after training is over.

28

CS109B, PROTOPAPAS, GLICKMAN

Memory

Question: How can we do this? How can build a unit that remembers the past? The memory or state can be written to a file but in RNNs, we keep it inside the recurrent unit. In an array or in a vector! Work with an example: Anna Sofia said her shoes are too ugly. Her here means Anna Sofia. Nikolas put his keys on the table. His here means Nikolas

29

CS109B, PROTOPAPAS, GLICKMAN

Memory

Question: How can we do this? How can build a unit that remembers the past? The memory or state can be written to a file but in RNNs, we keep it inside the recurrent unit. In an array or in a vector!

30

RNN

𝑌" (𝑓. 𝑕. ℎ𝑗𝑡) Memory

RNN

𝑍

" (𝑓. 𝑕. 𝑂𝑗𝑙𝑝𝑚𝑏𝑡)

Memory

CS109B, PROTOPAPAS, GLICKMAN

Building an RNN

31

RNN

𝑍

"

Memory 𝑌" Memory

RNN

𝑍

"

Memory

𝑌"

Memory

RNN

𝑍

"6'

Memory

𝑌"6'

RNN

𝑍

"67

Memory

𝑌"67

RNN

𝑍

"68

Memory

𝑌"68

CS109B, PROTOPAPAS, GLICKMAN

Outline

Why RNNs Main Concept of RNNs More Details of RNNs RNN training Gated RNN

32

CS109B, PROTOPAPAS, GLICKMAN

Structure of an RNN cell

33

RNN

𝑍

"

State 𝑌"

RNN

𝑍

"

State 𝑌"

• utput

weight update weight input weight

CS109B, PROTOPAPAS, GLICKMAN

Image taken from A. Glassner, Deep Learning, Vol. 2: From Basics to Practice 34

CS109B, PROTOPAPAS, GLICKMAN

Outline

Why RNNs Main Concept of RNNs More Details of RNNs RNN training Gated RNN

35

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

• For each input, unfold network for the sequence length T
• Back-propagation: apply forward and backward pass on unfolded

network

• Memory cost: O(T)

36

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

37

RNN

𝑍

"

State 𝑌"

• utput

weight update weight input weight

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

38

RNN

𝑍

"

State 𝑌"

• utput

weight update weight

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

39

RNN

𝑍

"

State 𝑌" Update Weights: U Output Weights: W Input Weights: V

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

40

You have two activation functions 𝑕9 which serves as the activation for the hidden state and 𝑕: which is the activation of the output. In the example shown before 𝑕: was the identity.

ℎ"&7 𝑌"&7 V U W ℎ"&' 𝑌"&' V U W ℎ" 𝑌" V U W 𝑧 <t-2 𝑧 <t-1 𝑧 <t

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

41

ℎ"&7 𝑌"&7 V U W ℎ"&' 𝑌"&' V U W ℎ" 𝑌" V U W 𝑧 <t-2 𝑧 <t-1 𝑧 <t

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

42

𝜖𝑧 <" 𝜖𝑋 = 𝑕:′ℎ"

𝑀 = B 𝑀"

• "

𝑒𝑀 𝑒𝑋 = B 𝑒𝑀" 𝑒𝑋

• "

= B 𝜖𝑀" 𝜖𝑧 <" 𝜖𝑧 <" 𝜖𝑋

• "

𝑀" = 𝑀"(𝑧 <")

𝑧 <" = 𝑕: 𝑋ℎ" + 𝑐

CS109B, PROTOPAPAS, GLICKMAN

43

CS109B, PROTOPAPAS, GLICKMAN

Backprop Through Time

44

𝑒𝑀 𝑒𝑉 = B 𝜖𝑀" 𝜖𝑧 <" 𝜖𝑧 <" 𝜖ℎ" 𝜖ℎ" 𝜖𝑉

• "

𝑧 <" = 𝑕: 𝑋ℎ" + 𝑐

𝑀 = B 𝑀"

• "

𝑀" = 𝑀"(𝑧 <")

ℎ" = 𝑕9 𝑊𝑦" + 𝑉ℎ"&' + 𝑐J

𝑧 <" = 𝑕:(𝑋𝑕9 𝑊𝑦" + 𝑉ℎ"&' + 𝑐J + 𝑐) K9L KM=∑ K9L K9O K9O KM " PQ' 𝜖𝑀" 𝜖𝑉 = 𝜖𝑀" 𝜖𝑧 <" 𝜖𝑧 <" 𝜖ℎ" (𝑒ℎ" 𝑒𝑉 + 𝑒ℎ" 𝑒ℎ"&' 𝑒ℎ"&' 𝑒𝑉 + 𝑒ℎ" 𝑒ℎ"&' 𝑒ℎ"&' 𝑒ℎ"&7 𝑒ℎ"&7 𝑒𝑉 + ⋯ ) K9L K9O= K9L K9LST K9LST K9LSU … K9OVT K9O = ∏ K9X K9XST " YQP6' 𝜖ℎY 𝜖ℎY&' = g[

J U

CS109B, PROTOPAPAS, GLICKMAN

Gradient Clipping

Prevents exploding gradients Clip the norm of gradient before update. For some derivative 𝑕, and some threshold u

45

if 𝑕 > 𝑣 𝑕 ⟵ 𝑕𝑣 𝑕

CS109B, PROTOPAPAS, GLICKMAN

Gradient Clipping

46

CS109B, PROTOPAPAS, GLICKMAN

Outline

Why RNNs Main Concept of RNNs More Details of RNNs RNN training Gated RNN

47

CS109B, PROTOPAPAS, GLICKMAN

Long-term Dependencies

Unfolded networks can be very deep Long-term interactions are given exponentially smaller weights than small-term interactions Gradients tend to either vanish or explode

48

CS109B, PROTOPAPAS, GLICKMAN

Long Short-Term Memory

Handles long-term dependencies Leaky units where weight on self-loop α is context-dependent Allow network to decide whether to accumulate or forget past info

49

CS109B, PROTOPAPAS, GLICKMAN

Notation

Using conventional and convenient notation

50

𝑍

"

𝑌"

CS109B, PROTOPAPAS, GLICKMAN

Simple RNN again

51

State V + W σ σ U 𝑌" 𝑍

"

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Simple RNN again

52

State V + W σ σ U 𝑌" 𝑍

"

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Simple RNN again: Memories

State V + W σ σ U 𝑌" 𝑍

"

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Simple RNN again: Memories - Forgetting

State V + W σ σ U 𝑌" 𝑍

"

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Simple RNN again: New Events

State V + W σ σ U 𝑌" 𝑍

"

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Simple RNN again: New Events Weighted

State V + W σ σ U 𝑌" 𝑍

"

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Simple RNN again: Updated memories

State V + W σ σ U 𝑌" 𝑍

"

ℎ"

CS109B, PROTOPAPAS, GLICKMAN

Ref

• [Chen17b] Qiming Chen, Ren Wu, “CNN Is All You Need”, arXiv 1712.09662, 2017.

https://arxiv.org/abs/1712.09662

• [Chu17] Hang Chu, Raquel Urtasun, Sanja Fidler, “Song From PI: A Musically Plausible

Network for Pop Music Generation”, arXiv preprint, 2017. https://arxiv.org/abs/1611.03477

• [Johnson17] Daniel Johnson, “Composing Music with Recurrent Neural Networks”,

Heahedria, 2017. http://www.hexahedria.com/2015/08/03/ composing-music-with- recurrent-neural-networks/

• [Deutsch16b] Max Deutsch, “Silicon Valley: A New Episode Written by AI”, Deep

Writing blog post, 2017. https://medium.com/deep-writing/ silicon-valley-a-new- episode-written-by-ai-a8f832645bc2

• [Fan16] Bo Fan, Lijuan Wang, Frank K. Soong, Lei Xie “Photo-Real Talking Head with

Deep Bidirectional LSTM”, Multimedia Tools and Applications, 75(9), 2016. https://www.microsoft.com/en-us/research/wp- content/uploads/2015/04/icassp2015_fanbo_1009.pdf

58

CS109B, PROTOPAPAS, GLICKMAN

59

Continue on Wednesday

CS109B, PROTOPAPAS, GLICKMAN

RNN

RNN

0.3 dog barking

• dog barking
• RNN

0.1 white shirt

dog barking white shirt

RNN

0.1 apple pie

white shirt apple pie

RNN

0.4 knee hurts

apple pie knee hurts

RNN

0.6 get dark

Is it raining? We build an RNN to the probability if it is raining:

CS109B, PROTOPAPAS, GLICKMAN

RNN + Memory

RNN

0.3

RNN

0.1

RNN

0.1

RNN

0.4

RNN

0.6

RNN

0.3

• RNN

0.1

RNN

0.1

RNN

0.6

RNN

0.9 dog barking white shirt apple pie knee hurts get dark dog barking white shirt apple pie knee hurts get dark

• dog barking

dog barking white shirt white shirt apple pie apple pie knee hurts

• dog barking

dog barking white shirt dog barking apple pie dog barking knee hurts

CS109B, PROTOPAPAS, GLICKMAN

RNN + Memory + Output

dog barking white shirt apple pie knee hurts get dark

RNN

0.3

• RNN

0.1

RNN

0.1

RNN

0.6

RNN

0.9

• dog barking

dog barking apple pie dog barking white shirt dog barking knee hurts

CS109B, PROTOPAPAS, GLICKMAN

63

LSTM: Long short term memory

CS109B, PROTOPAPAS, GLICKMAN

64

Before to really understand LSTM lets see the big picture …

Forget Gate Input Gate Cell State Output Gate

CS109B, PROTOPAPAS, GLICKMAN

65

1.

LSTM are recurrent neural network with a cell and a hidden state, boths of these are updated in each step and can be thought as memories.

2.

Cell states work as a long term memory and the updates depends on the relation between the hidden state in t -1 and the input.

3.

The hidden state of the next step is a transformation of the cell state and the

• utput (which is the section that is in general

used to calculate our loss, ie information that we want in a short memory).

Before to really understand LSTM lets see the big picture …

CS109B, PROTOPAPAS, GLICKMAN

66

Let's think about my cell state

Let's predict if i will help you in the homework in time t

CS109B, PROTOPAPAS, GLICKMAN

67

Forget Gate Erase everything!

The forget gate tries to estimate what features of the cell state should be forgotten.

CS109B, PROTOPAPAS, GLICKMAN

68

Input Gate

The input gate layer works in a similar way that the forget layer, the input gate layer estimate the degree of confidence of and is a new estimation of the cell state. Let’s say that my input gate estimation is:

CS109B, PROTOPAPAS, GLICKMAN

Cell state

After the calculation of forget gate and input gate we can update our cell state.

69

CS109B, PROTOPAPAS, GLICKMAN

70

Output gate

• The output gate layer is calculated using the

information of the input x in time t and hidden state

• f the last step.
• It is important to notice that hidden state used in

the next step is obtained using the output gate layer which is usually the function that we optimize.

CS109B, PROTOPAPAS, GLICKMAN

71

To optimize my parameters i basically need to do: Let’s calculate all the derivatives in some time t! wcct! = we can calculate this!

wcct! wcct! wcct! wcct!

So… every derivative is wrt the cell state or the hidden state

CS109B, PROTOPAPAS, GLICKMAN

72

Let’s calculate the cell state and the hidden state

CS109B, PROTOPAPAS, GLICKMAN

RNN Structures

73

𝑍

"

𝑌"

• ne to one
• The one to one structure is useless.
• It takes a single input and it produces a single
• utput.
• Not useful because the RNN cell is making little

use of its unique ability to remember things about its input sequence

CS109B, PROTOPAPAS, GLICKMAN

RNN Structures (cont)

74

𝑌"&7 many to one 𝑌"&' 𝑍

"

𝑌"

The many to one structure reads in a sequence and gives us back a single value. Example: Sentiment analysis, where the network is given a piece of text and then reports

• n some quality inherent in the
• writing. A common example is

to look at a movie review and determine if it was positive or negative.

CS109B, PROTOPAPAS, GLICKMAN

RNN Structures (cont)

75

𝑍

"&7

𝑌"&7

• ne to many

𝑍

"&'

𝑍

"

The one to many takes in a single piece of data and produces a sequence. For example we give it the starting note for a song, and the network produces the rest of the melody for us.

CS109B, PROTOPAPAS, GLICKMAN

RNN Structures (cont)

76

𝑍

"&7

𝑌"&7 many to many 𝑍

"&'

𝑌"&' 𝑍

"

𝑌"

The many to many structures are in some ways the most interesting. used for machine translation. Example: Predict if it will rain given some inputs.

CS109B, PROTOPAPAS, GLICKMAN

RNN Structures (cont)

77

𝑌"&7 many to many 𝑍

"&'

𝑌"&' 𝑍

"

This form of many to many can be used for machine translation. For example, the English sentence: “The black dog jumped over the cat” In Italian as: “Il cane nero saltò sopra il gatto” In the Italia, the adjective “nero” (black) follows the noun “cane” (dog), so we need to have some kind of buffer so we can produce the words in their proper English.

CS109B, PROTOPAPAS, GLICKMAN

Bidirectional

LSTM and RNN are designed to analyze sequence of values. For example: Patrick said he needs a vacation. he here means Patrick and we know this because Patrick was before the word he. However consider the following sentence: He needs to work more, Pavlos said about Patrick. Bidirectional RNN or BRNN or bidirectional LSTM or BLSTM when using LSTM units.

78

CS109B, PROTOPAPAS, GLICKMAN

Bidirectional (cond)

79

𝑍

"&7

𝑍

"&'

𝑍

"

𝑌"&7 𝑌"&' 𝑌" previous state previous state 𝑍

"

𝑌" symbol for a BRNN

CS109B, PROTOPAPAS, GLICKMAN

Deep RNN

LSTM units can be arranged in layers, so that each the output of each unit is the input to the other units. This is called a deep RNN, where the adjective “deep” refers to these multiple layers.

• Each layer feeds the LSTM on the next layer
• First time step of a feature is fed to the first LSTM, which processes

that data and produces an output (and a new state for itself).

• That output is fed to the next LSTM, which does the same thing, and

the next, and so on.

• Then the second time step arrives at the first LSTM, and the process

repeats.

80

CS109B, PROTOPAPAS, GLICKMAN

Deep RNN

81

𝑌"&7 𝑌"&' 𝑌" 𝑌"6' 𝑌"67 𝑍

"&7

𝑍

"&'

𝑍

"

𝑍

"6'

𝑍

"67

𝑌 𝑍

CS109B, PROTOPAPAS, GLICKMAN

Skip Connections

Add additional connections between units d time steps apart Creating paths through time where gradients neither vanish or explode

82

t-1 t t+1

CS109B, PROTOPAPAS, GLICKMAN

Leaky Units

Linear self-connections Maintain cell state: running average of past hidden activations

83

CS109B, PROTOPAPAS, GLICKMAN

Standard RNN

84

C(t) = tanh(Wh(t−1) + Ux(t−1)) h(t) = C(t) C(t)

colah.github.io

CS109B, PROTOPAPAS, GLICKMAN

Leaky Unit

85

✕

C(t) = tanh(Wh(t−1) + Ux(t−1)) h(t) = αh(t−1) + (1-α)C(t) C(t)

colah.github.io
