Recommender System in KKBOX

Attribute Based Collaborative Filtering Embedding Representation Ranking Model based Context Aware Persona Aware Simple Complex

#Item x #users x #attributes

Precision Diversity Serendipity/Novelty

Collaborative Filtering

Matrix Factorization

Word2Vec - “The results, to our own surprise, show that the buzz is fully justified, as the context-predicting models obtain a thorough and resounding victory against their count-based counterparts.” - Marco et al.

“You should know the word by the company it keeps” (Firth J.R.)

CBOW CBOW Skip-gram

DeepWalk (Bryan Perozzi, Rami Al-Rfou& Steven Skiena, 2014 ) Random Walk Word2Vec

青花瓷

珊瑚海 我不配 給我一首歌的時 間

黃金甲

珊瑚海 雙截棍 天地一鬥

(#item + #users) x log(#Item + #users) x #hidden nodes x window_size

Cold start ?

Learn the relationships between laten factors and audio signals

We got features - And ranking is another problem

User Understaning Content Understanding

Learn to Rank

• Embedding
• Classification
• Topic Mining
• User Profiling
• Embedding

Click/Play Prediction

• Regression
• Classification

買菜送蔥 Building a pipeline

Data pre-processing Feature extraction Model fitting Validation stages → → → → ETL Job Numerical/ Categorical... Logistic Regression/GBDT Cross Validation

Challenges

• Big data
• Heterogeneous sources
• Various formatting
• Data versioning
• Data quality
• Data freshness
• Cost
• Coding is hard, debugging is harder

Logs: Parquet, Json, Tsv, Text, …... Databases: Songs, Members, …...

External Datasets / Logs: Genre, BPM, Artist DB Mixpanel, App Annie …...

ETL

• Data cleaning, normalization
• Pre aggregation / join

Parquet files in S3, partitioned by date and service region if needed.

ETL Data (Parquet files on S3) Thrift (or Protobuf, Avro) Hive Table Schema Presto (or Amazon Athena)

DB Replication

• Apache Spark (Scala)

○ From files on S3 to RDD / Dataframe ○ Use JDBC Driver from Presto

• Python / R

○ Read file from S3, deserialize parquet ○ Use JDBC/ODBC driver from Presto

Example

Challenges

• Big data = EC2 + Spark + Hadoop Family + Presto
• Heterogeneous sources = ETL
• Various formatting = ETL
• Data versioning = ETL
• Data quality = ETL
• Data freshness = DB Replication, Data Streaming
• Cost = EC2, Good Tool Chain
• Coding is hard, debugging is harder - Good Design

Case Study

Nearest Neighbors of Songs

• 1. Build a weighted bipartite graph of users and songs from logs
• Terebytes of data, billions of nodes and edges
• Spark cluster on EC2. (On-demand, hundreds of cores, I/O optimized)
• 2. Put each song on a vector space
• Random walks
• An embedded model (We use

word2vec)

• In an very very large instance with a

lot of memory and cores.

• 3. Find K-NN for each song
• O(n^2) is impossible
• Approximation. For example,

Locality-Sensitive Hashing

• Using a spark cluster on EC2, the

worker nodes are cpu optimized. All middle results are in parquet format on S3, so we can inpect them with Presto.

Songs a User Like to Listen Again

• 1. Extract features from logs, databases, and external data set
• Join billions of transactions.
• Spark cluster on EC2. (On-demand, hundreds of cores)
• 2. Train a model
• Spark MLlib (EX: GBDT)
• Deep learning frameworks

(TensorFlow)

• 3. Repeat - feature selection,

parameter tuning

• 4. Predict from recent logs

Define the Problem Inspect the Data Hypothesis Train and Verify the Model Deploy and A/B Testing

Life cycle of ML-related features

References

• Apache Spark
• Apache Parquet
• Apache Thrift
• Apache Hive
• Presto
• Amazon Elastic Compute Clould
