Rattray Marsh Restoration Phase 2 Public Information Session Green - PowerPoint PPT Presentation

Nov 25, 2023 •183 likes •363 views

Rattray Marsh Restoration Phase 2 Public Information Session Green Glade Public shcool May 5,2015 Phasing & Removals Plan -Revised original site plans -Omitted areas of continued deposition -Included a formal pumping plan this year -

  1. Rattray Marsh Restoration Phase 2 Public Information Session Green Glade Public shcool May 5,2015

  2. Phasing & Removals Plan -Revised original site plans -Omitted areas of continued deposition -Included a formal pumping plan this year - Emphasis on grading and sediment volumes to combat invasive species concerns

  3. Site Preparation -Wildlife exclusion fencing -Fast fence to contain site -Phragmites & Cattail shearing -Sediment fence around access road & mudflat

  4. Access Road Diversion -Gain access to the Phase 2 area -Floating road construction

  5. Sheridan Creek Crossing

  6. Excavation

  8. Before After

  9. Organic Soils

  10. Trucking -253 trucks for sediment -25 trucks/day max -15 days for sediment removal -4 days of gravel removal

  11. Phragmites Control -Create physical conditions to limit the spread -BMP is 1.5-2m depth over 6 week period -Depth determined in consultation with Ontario Phragmites working group

  12. Habitat Features Sunning Logs Tern Nesting Rafts Perching Stump

  13. Access Road Removal -Crushed stone reused by contractor -Minor spring time cleanup -Cattail regeneration

  14. What’s Next? Invasive Species Control Carp Control Aquatic Planting Sediment Deposition Monitoring

  15. Great Lakes Restoration Initiative Monitoring

  16. Project Partners
