PWG Semantic Model (PWG SM) Work items of interest 1 04/01/06 Zehler Logistics Date/Time: Agenda: April 6 2006 9:00 - 9:15: 9am 1pm eastern Convene Dial-In 9:15 - 9:30: Tele-Con Number:

slide-1
SLIDE 1

04/01/06 Zehler 1

PWG Semantic Model (PWG SM)

Work items of interest

slide-2
SLIDE 2

04/01/06 Zehler 2

Logistics

  • Date/Time:

–April 6 2006 –9am – 1pm eastern

  • Dial-In

–Tele-Con Number:

  • 1-866-365-4406

–PassCode:

  • 2635888
  • WebEx Meeting Details

(http://www.mymeetings.com) :

–Meeting Number: 747275324 – Meeting Passcode: PwgSm –Meeting Host: Peter Zehler

–http://www.mymeetings.com/xerox/nc/j

  • in.php?i=747275324&p=PwgSm&t=c
  • Enter the required fields.
  • Indicate that you have read the

Privacy Policy.

  • Click on Proceed.
  • Agenda:

–9:00 - 9:15:

  • Convene

–9:15 - 9:30:

  • Intros
  • Agenda bashing

–9:30 - 10:30

  • Presentation slides

and discussion

–10:30 - 10:45

  • Break

–10:45 – 11:30

  • JDF Office

discussion

–11:30 – 1:00

  • Decide on priority &

dates

  • Detailed discussion
slide-3
SLIDE 3

04/01/06 Zehler 3

Current Status

  • The PWG SM Working Group has been on

hiatus since the publishing of the PWG SM and associated Schema.

  • There is work from other PWG work groups that

could to be incorporated in an update to the PWG SM (e.g. WIMS, Counters).

  • The PWG SM deals only with a data model and

not with specific application use or a protocol

  • mapping. However an XML schema is included.
slide-4
SLIDE 4

04/01/06 Zehler 4

Current PWG SM

slide-5
SLIDE 5

04/01/06 Zehler 5

Print Service Element

slide-6
SLIDE 6

04/01/06 Zehler 6

Print Job Element

slide-7
SLIDE 7

04/01/06 Zehler 7

Print Document Element

slide-8
SLIDE 8

04/01/06 Zehler 8

Inclusion of Subunit semantics

  • There is currently no access to subunits of

a print device since the SM describes a print service

  • The PWG has modeled the subunits of a

printer device in the Printer MIB.

  • Should the PWG SM Model be extended

to include the subunits?

slide-9
SLIDE 9

04/01/06 Zehler 9

Top level Subunits

slide-10
SLIDE 10

04/01/06 Zehler 10

Extension to MultiFunction Devices

  • The PWG SM currently only covers a

printer service.

  • We would like to incorporate other services

that are available in a MultiFunction Device in the SM

  • The WIMS Working Group has modeled a

Multifunction Device

  • Should we extend the PWG SM for

MultiFunction Devices?

slide-11
SLIDE 11

04/01/06 Zehler 11

MultiFunction Device Services

slide-12
SLIDE 12

04/01/06 Zehler 12

Inclusion of Usage Counters

  • The PWG SM currently only covers a

printer service. We would like to incorporate other services that are available in a MultiFunction Device in the SM

slide-13
SLIDE 13

04/01/06 Zehler 13

Counter classes

slide-14
SLIDE 14

04/01/06 Zehler 14

Counter classes

slide-15
SLIDE 15

04/01/06 Zehler 15

Media used

slide-16
SLIDE 16

04/01/06 Zehler 16

Monitoring

slide-17
SLIDE 17

04/01/06 Zehler 17

Availability

slide-18
SLIDE 18

04/01/06 Zehler 18

Abstract Job Definition

  • The PWG SM definition of a Job is Print

Service Specific

  • The PWG SM may be extended to

MultiFunction Devices

  • Should a superclass of the print job be

defined?

  • Should subclasses of the abstract job be

defined for each service?

slide-19
SLIDE 19

04/01/06 Zehler 19

PWG SM and Management Using Web Services (MUWS) (e.g. WSDM, WS-Management)

  • Currently the PWG is working with the

DMTF to align CIM and the PWG MIBs and PWG SM.

  • Will a PWG defined “Dialect” be able to be

directly used in a MUWS environment?

  • Should we be working directly with

WSDM/WS-Management/W3C to adapt the PWG SM to those environments?

slide-20
SLIDE 20

04/01/06 Zehler 20

RDF Schema for PWG SM vocabulary

  • In a MultiFunction Device there is no way to

describe the relationships/dependencies between the services and subunits or between individual services.

  • RDF provides a simple way to make statements

about resources (Subject, Predicate, Object)

  • Web Ontology Language (OWL) provides a way to

provide richer semantics of resources (e.g. cardinality, keys, unions, intersection, instance equality)

  • Should we be looking at an RDF/OWL mapping of

the PWG SM?

slide-21
SLIDE 21

04/01/06 Zehler 21

JDF Office alignment

  • JDF Office Printing is a subgroup of JDF Digital Print

– JDF Digital Print focused on the needs of Print on Demand and borrowed from the PWG SM (IPP) – Digital Print has a work item for an Application Note for a mapping of IPP to JDF

  • Office Printing is targeted at black and white and limited

color digital networked printing systems typically used within an office environment.

  • JDF job tickets sent from the applications to the device are

complete and do not require further processing before execution – and do not require an intermediate controller

  • Covers messaging format an subset of Digital Print, and IPP,

that covers submission and simple finishings (e.g. staple collate)

slide-22
SLIDE 22

04/01/06 Zehler 22

Priority Discussion

  • Subunits
  • MultiFunction Device
  • Usage Counters
  • Abstract Job
  • PWG SM and MUWS
  • PWG SM and RDF/OWL
  • JDF Office
