Proving linearizability & lock-freedom

Viktor Vafeiadis

MPI-SWS

Michael & Scott non-blocking queue

null

X 1 3 2 head tail

CAS – compare & swap

CAS (address, expectedValue, newValue) { atomic { if ( *address == expectedValue ) { *address = newValue; return true; } else { return false; } } }

• A single hardware instruction on x86

Michael & Scott non-blocking queue

null

X 1 3 2 head tail

Michael & Scott non-blocking queue

null

X 1 3 2 head tail 4

null

Michael & Scott non-blocking queue

X 1 3 2 head tail 4

null

Michael & Scott non-blocking queue

X 1 3 2 head tail 4

null

Michael & Scott non-blocking queue

X 1 3 2 head tail 4

null

Enqueue & dequeue

enqueue(v) { m = new Node(); m→val = v; m→next = null; while (true) { t = Q→tail; n = tail→next; if (Q→tail ≠ tail) continue; if (n == null) { if (CAS(&t→next,n,m)) break; } else { CAS(&Q→tail,t,n); } } CAS(&Q→tail,t,n); }

dequeue () { while (true) { h = Q→head; t = Q→tail; n = h→next; if (Q→tail ≠ t) continue; if (h == t) { if (n == null) return EMPTY; CAS(&Q→tail,t,n); } else { if (CAS(&Q→head,h,n)) return n→val; } } }

Don’t read the code!

RGSep actions (pre-/postcondition pairs)

• Summarize the shared state updates

A B

null

head tail A B head tail A B head tail A

null

head tail A B head tail A B head tail Enqueue Dequeue Advance tail pointer

The actions of enqueue & dequeue

enqueue(v) { m = new Node(); m→val = v; m→next = null; while (true) { t = Q→tail; n = tail→next; if (Q→tail ≠ t) continue; if (n == null) { if (CAS(&t→next,n,m)) break; } else { CAS(&Q→tail,t,n); } } CAS(&Q→tail,t,n); }

dequeue () { while (true) { h = Q→head; t = Q→tail; n = h→next; if (Q→tail ≠ t) continue; if (h == t) { if (n == null) return EMPTY; CAS(&Q→tail,t,n); } else { if (CAS(&Q→head,h,n)) return n→val; } } }

ENQUEUE DEQUEUE

• ADV. TAIL
• ADV. TAIL
• ADV. TAIL

Local updates

Length (first attempt)

length() { num = 0; curr = Q→head→next; while (curr ≠ null) { num++; curr = curr→next; } return num; }

X 1 3 4

null

2 head tail

length() { num = 0; while (true) { t = Q→tail; n = tail→next; if (n == null) break; CAS(&Q→tail,t,n); } curr = Q→head→next; while (curr ≠ null) { num++; if (curr == t) break; curr = curr→next; } return num; }

Length (second attempt)

Read Q→tail, and ensure that Q→tail→next == null

length() { num = 0; do { h = Q→head; while (true) { t = Q→tail; n = tail→next; if (n == null) break; CAS(&Q→tail,t,n); } } while (h ≠ Q→head); curr = h→next; while (curr ≠ null) { num++; if (curr == t) break; curr = curr→next; } return num; }

Length (third attempt)

Get a snapshot of Q→head and Q→tail and ensure that Q→tail→next==null.

Verification challenge

Functional correctness (linearizability): Every method executes ‘atomically’ and obeys a high-level specification Liveness properties, e.g. lock-freedom: At all times, some outstanding method call is guaranteed to terminate.

VMCAI ’09

CAV ’10

POPL ’09

Linearizability

Every method executes ‘atomically’ & obeys a functional correctness specification Shared variable: AQ

AQ := append(singleton(v), AQ); return 0; if (AQ == empty) { return EMPTY; } else { r := hd(AQ); AQ := tl(AQ); return r; } dequeue() spec enqueue(v) spec

Linearizability & forward simulation

Linearizability: The implementation (of every method) is a refinement

• f an atomic specification.

Standard proof technique: forward simulation Abstract (spec) Concrete (impl)

Sconc S’conc Sabs S’abs

Linearization points

The implementation is a refinement of an atomic specification.

abstract execution concrete execution

linearization point (LP)

Linearization point of enqueue

• Lin. Point

(provided CAS succeeds)

enqueue(v) { m := new Node(); m→val := v; m→next := null; while (true) { t := Q→tail; n := tail→next; if (Q→tail ≠ tail) continue; if (n == null) { if (CAS(&t→next,n,m)) break; } else { CAS(&Q→tail,t,n); } } CAS(&Q→tail,t,n); }

Proof search for the LP ?

• For each execution path of each method,

choose a candidate LP

• Check whether it is a valid LP

Does this work ?

Proof search for the LP ?

• For each execution path of each method,

choose a candidate LP

• Check whether it is a valid LP

Does this work ? Not quite.

• 1. LPs can be conditional
• 2. LPs can be in the code of another thread

LP of dequeue, when it returns EMPTY

LP provided

this test fails, and the h==t test succeeds the n==null test succeeds

Condition:

¬prophecy(Q→tail ≠ t)

∧ h == t ∧ n == null dequeue () { while (true) { h := Q→head; t := Q→tail; n := h→next; if (Q→tail ≠ t) continue; if (h == t) { if (n == null) return EMPTY; CAS(&Q→tail,t,n); } else { if (CAS(&Q→head,h,n)) return n→val; } } }

Key observation

• Method executions that logically modify the

state have a simple LP.

• Method executions that do not logically

modify the state often have a complex LP.

So: Treat these two cases differently.

• Search for LPs of executions that logically

modify the state;

• Do a non-constructive proof for executions

that do not logically modify the state.

Basic LP validation

Auxiliary variable: lres

• 1. At the entry to the function:

lres := UNDEF;

• 2. At the candidate efgectful LPs:

assert(lres==UNDEF); lres := method_spec();

• 3. At the return points, check

res == lres concrete result abstract result

Auxiliary variable: can_return

• 1. At the entry to the function:

∀i. can_return[i] := false;

• 2. At every point, add a pure ‘LP checker’:

if (abs_method() has no side-efgects) can_return[abs_method()] := true;

• 3. At the return points, check

can_return[res] == true

Validating pure executions

concrete result

For example...

if (AQ == empty) { return EMPTY; } else { r := hd(AQ); AQ := tl(AQ); return r; } if (AQ == empty) { can_return[EMPTY] := true; } dequeue spec pure lin. checker

Auxiliary variables: lres, can_return

• 1. At the entry to the function:

lres := UNDEF; ∀i. can_return[i] := false;

• 2. At the candidate efgectful LPs:

assert(lres==UNDEF); lres := abs_method()

• 3. Add pure checkers at every program point:

assign can_return[i] := true if method_spec returns i & has no side-efgects.

• 4. At the return points, check

(res==lres) ∨ (lres==UNDEF ∧ can_return[res])

Enhanced LP validation

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 3

null

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 3

null

c

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 3

null

c

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 3

null

c

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 3 5

null

c

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 5 3

null

c

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 3 5

null

c

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

LPs in other threads

add (e) { ... } remove (e) { ... } contains (e) { c := H; while (c→val < e) c := c→next; return (c→val == e); }

1 7 3 5

null

c

• INF

contains(5) || add(5); remove(3); remove(5)

+INF

Auxiliary variables: lres, can_return

• 1. At the entry to the function:

lres := UNDEF; ∀i. can_return[i] := false;

• 2. At the candidate efgectful LPs:

assert(lres==UNDEF); lres := abs_method()

• 3. Add pure checkers at every program point

(incl. program points in other threads)

• 4. At the return points, check

(res==lres) ∨ (lres==UNDEF ∧ can_return[res])

Enhanced LP validation

CAVE: Concurrent Algorithm VErifier

http://www.mpi-sws.org/~viktor/cave

Implementation

• RGSep action inference

[VMCAI 2010]

• Shape-value abstract domain

[VMCAI 2009]

• Algorithm for proving linearizability

[CAV 2010]

Experiments (linearizability)

Algorithm Lines Ops Efg Pure LpO Time (s) DCAS stack 100 8 4 5 0.3 Treiber stack 100 8 4 5 0.3 M&S two-lock queue 85 4 3 2 16.5 M&S non-blocking queue 127 4 3 2 4.9 DGLM non-blocking queue 126 4 3 2 7.6 Pessimistic set 100 3 2 3 247.8 V&Y DCAS-based set 101 3 2 3 51.0 ORVYY lazy set 94 3 2 3 1 521.5

Lines: lines of code: excluding comments & specs Ops: # methods Efg: # efgectful methods Pure: # methods with a pure execution path LpO: # linearization points in other threads

Non-blocking liveness properties

Proving that non-blocking algorithms don’t block [Gotsman, Cook, Parkinson, Vafeiadis, POPL’09]

Non-blocking liveness properties

• Wait-freedom:

Every thread is guaranteed to complete its operation.

• Lock-freedom:

[Provided that there is at least one thread scheduled,] some thread is guaranteed to complete its operation.

• Obstruction-freedom:

Every thread is guaranteed to complete its operation, provided it eventually executes in isolation. (No assumptions about the scheduler.)

Lock-freedom reduces to termination

A library is lock-free ifg init(); ‖n { if(?) enqueue(?) else if(?) dequeue() else length() } terminates when n(=the number of threads) is bounded.

Reminder: enqueue & dequeue

enqueue(v) { m = new Node(); m→val = v; m→next = null; while (true) { t = Q→tail; n = tail→next; if (Q→tail ≠ t) continue; if (n == null) { if (CAS(&t→next,n,m)) break; } else { CAS(&Q→tail,t,n); } } CAS(&Q→tail,t,n); }

dequeue () { while (true) { h = Q→head; t = Q→tail; n = h→next; if (Q→tail ≠ t) continue; if (h == t) { if (n == null) return EMPTY; CAS(&Q→tail,t,n); } else { if (CAS(&Q→head,h,n)) return n→val; } } }

ENQUEUE DEQUEUE

• ADV. TAIL
• ADV. TAIL
• ADV. TAIL

Guarantee-strengthening

I don’t execute ENQUEUE or DEQUEUE infinitely often I don’t execute ENQUEUE, DEQUEUE, or ADV.TAIL infinitely often I don’t execute ENQUEUE or DEQUEUE infinitely often I don’t execute ENQUEUE, DEQUEUE, or ADV.TAIL infinitely often

I terminate I terminate

Guarantee-strengthening

First, do action inference Then, iteratively eliminate actions

Guarantee-strengthening

First, do action inference Then, iteratively eliminate actions □(ENQUEUE ∨ DEQUEUE ∨ ADV.TAIL)

Guarantee-strengthening

First, do action inference Then, iteratively eliminate actions

¬□◊ENQUEUE

Terminates

¬□◊DEQUEUE ¬□◊ADV.TAIL

□(ENQUEUE ∨ DEQUEUE ∨ ADV.TAIL)

Guarantee-strengthening

First, do action inference Then, iteratively eliminate actions

   

¬□◊ENQUEUE

Terminates

¬□◊DEQUEUE ¬□◊ADV.TAIL

□(ENQUEUE ∨ DEQUEUE ∨ ADV.TAIL)

Guarantee-strengthening

First, do action inference Then, iteratively eliminate actions

       

¬□◊ENQUEUE

Terminates

¬□◊DEQUEUE ¬□◊ADV.TAIL ¬□◊ENQUEUE ¬□◊DEQUEUE ¬□◊ADV.TAIL

Terminates

□(ENQUEUE ∨ DEQUEUE ∨ ADV.TAIL)

Guarantee-strengthening

First, do action inference Then, iteratively eliminate actions

           

¬□◊ENQUEUE

Terminates

¬□◊DEQUEUE ¬□◊ADV.TAIL ¬□◊ENQUEUE ¬□◊DEQUEUE ¬□◊ADV.TAIL

Terminates

¬□◊ENQUEUE ¬□◊DEQUEUE ¬□◊ADV.TAIL

Terminates

□(ENQUEUE ∨ DEQUEUE ∨ ADV.TAIL)
