Supporting Munitions Safety

Probabilistic Modeling of Initiation due to Fragment Impact

• Dr. Ernie Baker

Warheads Technology TSO e.baker@msiac.nato.int Christiaan Leibbrandt

IMEMTS 2019

Martijn van der Voort Transport and Storage TSO m.vanderVoort@msiac.nato.int

Supporting Munitions Safety

Overview

• Fragment Impact Testing
• Jacobs-Roslund Initiation Model
• Deterministic initiation response model
• Augmenting deterministic initiation

response model

– Algebraic model: Geometrical aspects of fragment impact – Validation – Implementation in deterministic model

• Probabilistic initiation response model
• Conclusions and recommendations

Supporting Munitions Safety

Fragment Impact Gun Testing

➢ NATO STANAG 4496, Ed. 1 ➢ Standard test: 253090 m/s

• Alternate test of 183060 m/s

➢ Standard fragment (projectile) geometry ➢ Several loosely defined and undefined characteristics that can affect the test item response

• Velocity variation
• Aim point variation
• Projectile tilt upon impact
• Fragment material characteristics

➢ Develop a probabilistic model that accounts for these variations and conduct an associated case study

Supporting Munitions Safety

Typical FI Test Setup

NSWC Dahlgren

4.5 meters 3 meters

Test Item Support Table Sabot Stripper Plate TOA Screens ➢ The test item is as close to gun as possible without causing damage to the gun in order to reduce aim point variability. ➢ Fragment velocities are measured using either make/break screens or photographic techniques. ➢ Majority of testing is completed using single stage powder guns Gun

Redstone Test Center

Supporting Munitions Safety

FI Testing Variation

Velocity, projectile tilt and impact point variation are common ➢ Gun barrel wear ➢ Gun powder variation ➢ Ignition anomalies ➢ Sabot release ➢ Measurement error

GD-OTS USA DGA/EM France

Sabots

AFRL Eglin AFB GD-OTS

High Speed Framing Images

Supporting Munitions Safety Supporting Munitions Safety

JACOBS-ROSLUND MODEL

𝑊

𝐷𝑠𝑗𝑢𝑗𝑑𝑏𝑚 = 𝐵

𝑒0.5 ∗ 1 + 𝐶 ∗ 1 + 𝐷 𝑢 𝑒

Deterministic initiation response model VImpact < VCritical : No detonation VImpact > VCritical : Detonation

Symbol Definition Unit VCritical Critical impact velocity for warhead detonation [m/s] Fragment d Fragment critical dimension or diameter [m] B Projectile shape coefficient [-] Warhead t Warhead cover thickness [m] A Explosive sensitivity coefficient [m3/2s-1] C Cover plate protection coefficient [-]

Supporting Munitions Safety Supporting Munitions Safety

RESEARCH QUESTION

Bron: MSIAC, NATO

• How can tilted and off-centre fragment

impact variation be implemented in a response model for probabilistic prediction of munitions initiation response?

Supporting Munitions Safety Supporting Munitions Safety

INITIATION MODEL DEVELOPMENT

Augment the Jacobs-Roslund model

• Velocity variation: can already account for it
• Aim point variation: match pressure histories with a reduced velocity based on oblique impact
• Projectile tilt upon impact: match pressure histories with a reduced velocity based on oblique

impact

Use previous 3D hydrocode modeling as data set

• 1-D GODLAG hydrocode within Temper for impact velocity and impactor thickness studies
• Use 1-D results to infer new velocity relationships for impact point offset and projectile tilt

Baker et al., “Insensitive Munitions Fragment Impact Gun Testing Technology Challenges” Propellants, Explosives, Pyrotechnics 10.1002/prep.201600045, 2016.

Supporting Munitions Safety Supporting Munitions Safety

APPARENT VELOCITY CONCEPT MODEL 𝑊

1 = 𝑊 0 ∗ cos 𝜄 + 𝛾

𝜄 = tan−1(− 𝑌 𝑆2 − 𝑌2)

GEOMETRICAL ASPECTS OF FRAGMENT IMPACT

(β clockwise is negative)

Θ+β

Supporting Munitions Safety Supporting Munitions Safety

𝑊

1 = 𝑊 0 ∗ cos 𝜄 + 𝛾

MODEL VALIDATION USING HYDROCODE CALCULATIONS

• Reproduce 3-D pressure histories in 1-D
• Use resulting 1-D impact velocities for

apparent velocity quantification and validation

Supporting Munitions Safety Supporting Munitions Safety

MODEL VALIDATION

0,00 2,00 4,00 6,00 8,00 10,00 12,00 0,00 1,00 2,00 3,00 4,00 5,00 6,00 7,00 8,00 9,00 10,00

Pressure [GPa] Time [μs]

3-D and 1-D model pressure histories for -10° tilted impact

1-D model with v=2342 m/s 1-D model with v=2074 m/s 1-D model with v=1699 m/s 3-D model -10° tilt and 0mm off-centre 3-D model -10° tilt and 12.5mm off-centre 3-D model -10° tilt and 25mm off-centre

Supporting Munitions Safety Supporting Munitions Safety

MODEL VALIDATION

1500 1700 1900 2100 2300 2500 2700

Velocity [m/s] Fragment orientation

Average 1-D hydrocode velocities for different fragment impact orientation

Supporting Munitions Safety Supporting Munitions Safety

MODEL VALIDATION

1400 1600 1800 2000 2200 2400 2600

Model velocities (V1) and hydrocode velocities

V,hydrocode,avg Model

𝑊

1 = 𝑊 0 ∗ cos 𝜄 + 𝛾

Impact Velocity (m/s)

Supporting Munitions Safety Supporting Munitions Safety

MODEL VALIDATION

𝑊

1 = 𝑊 0 ∗ (cos 𝜄 + 𝛾 )3.832

1400 1600 1800 2000 2200 2400 2600

Model velocities (V1) and hydrocode velocities

V,hydrocode,avg Model λ=3,832 (SSD first 8 data points)

𝑊

1 = 𝑊 0 ∗ cos 𝜄 + 𝛾

𝑊

1 = 𝑊 0 ∗ (cos 𝜄 + 𝛾 )λ

Impact Velocity (m/s)

Supporting Munitions Safety Supporting Munitions Safety

OFFSET & TILT MODIFIED JACOBS-ROSLUND

𝑊

𝐷𝑠𝑗𝑢𝑗𝑑𝑏𝑚 =

𝐵 𝑒0.5 ∗ ) (co s( 𝜄 + 𝛾) 𝜇 ∗ 1 + 𝐶 ∗ 1 + 𝐷 𝑢 𝑒

(JR Leibbrandt Model)

Symbol Definition Unit VCritical Critical impact velocity for warhead detonation [m/s] Fragment d Fragment critical dimension or diameter [m] θ Angle of tangent at impact point [°] β Fragment’s angle of tilt [°] λ Leibbrandt-coefficient [-] B Projectile shape coefficient [-] Warhead t Warhead cover thickness [mm] A Explosive sensitivity coefficient [m3/2s-1] C Cover plate protection coefficient [-]

MODEL IMPLEMENTATION

Supporting Munitions Safety Supporting Munitions Safety

PROBABILISTIC ANALYSIS

Supporting Munitions Safety

• Input parameters:
• Target explosive: PBXN-9
• Target cover thickness (t): 8.6mm
• Fragment shape (NATO standard cone)
• Fragment critical dimension (d)
• Variables
• Fragment impact velocity (V)
• Fragment tilt
• Fragment aimpoint
• Output
• Critical impact velocity for detonation (Vc)
• Detonation likely or not?

FI Case Study

Example: 155 mm projectile

Supporting Munitions Safety Supporting Munitions Safety

• VCritical = 1859 m/s (Deterministic)
• VImpact = 1900 m/s, σ = 30 m/s, no tilt or offset

X (off-centre) [mm] Detonation [%] Center Aimpoint σ = 2,5 73.3 Center Aimpoint σ = 12,5 41.6 Center Aimpoint σ = 25 25.9

PROBABILISTIC INITIATION CASE STUDY

• Now add tilt (β = 0°, σ = 4°) and offset impact position
• Deterministic prediction: 100% Detonation
• Probabalistic prediction: 91% of time detonation

Supporting Munitions Safety Supporting Munitions Safety

• VCritical = 1859 m/s (Deterministic)
• VImpact = 1830 m/s, σ = 30 m/s, no tilt or offset

Off-center Impact [mm] Detonation [%] Center Aimpoint σ = 2.5 8.9 Center Aimpoint σ = 12.5 4.2 Center Amipoint σ = 25 2.1

• Deterministic prediction: 0% Detonation
• Probabalistic prediction: 16.6% of time detonation
• Now add tilt (β = 0°, σ = 4°) and offset impact position

PROBABILISTIC INITIATION CASE STUDY

Supporting Munitions Safety Supporting Munitions Safety

CONCLUSIONS AND RECOMMENDATIONS

• Tilt and off-centre have influence on munitions response to fragment impact

– Commonly observed angle of tilt during FI testing has some influence – Commonly observed off-centre distance during FI testing has a large influence

• It is possible that munitions “pass” fragment impact tests unjustly due to

testing variation and a small number of tests – Perhaps tilt and off-center impact should be accounted for when reviewing test results

• STANAG 4496 updated March 2019 (STANAG 4496 Ed. 2, AOP-4496 Ed. A)

– Tilt: ±10° tilt recommendation – Off-center distance: Aimpoint accuracy diameter to be defined before testing

Supporting Munitions Safety Supporting Munitions Safety

QUESTIONS?
