Presented by:

Hettrick, Cyr & Associates Inc. Safety & Risk Control Services www.hettrickcyr.com 888-805-0300

No No Fal all Pr l Protec ection tion – 12 Pit itch

Pr Pres esen entation tation Goa

• als

ls

 Review common faults with personal fall arrest

systems

 Learn key terminology and methods of

implementing personal fall arrest systems

 Review of lesser known fall protection products

available to assist the roofing industry

 Implementing effective training as part of a Fall

Protection Program

Takea eaways ys

 Participants will have understanding of many

common faults in PFAS systems

 Knowledge on key PFAS terminology and

concepts such as “fall restraint”, “calculating fall distance”, “cross-arm straps”, & mobile fall protection.

 Handouts on equipment inspections & hands-on

practical examination tool.

 Falls are the leading cause of

fatalities in construction. Approximately 1 person dies from a fall in the construction industry every workday

 Vast majority of falls under 6’ are not

fatal

 Federal law mandates fall protection

when 6’ and greater above lower level

 Most roofs are greater than 6’ high

Undi Undisput puted ed Tru ruths

If Fall Protection is “Required”, Why are e th there ere so ma many Falls? ls?

Something’s Missing

Ho How B w Bad d is it it?

Co Compl plete e La Lack ck of Fal all Pr Protection ection

No No Fal all l Pr Protecti ection

• n

& Ca Carrying ying Ma Mater erial al Up Up th the e Lad adder der

Improper Tie Off

Poorly Fastened Roof Anchors

No Fall Protection Skylight Exposure

Failu lure re to

• Inspect

ect

Pos

• ssi

sibl ble e Rea eason

• ns

s for

• r Fall

lls

 Lack of training / knowledge.  Lack of fear. “It won’t happen to me”.  Failure to inspect.  Human error.  Lack of enforcement.

A

• 1. Anchor Point
• 2. Life Line
• 3. Rope Grab
• 4. Shock

Absorbing Lanyard

• 5. Full Body Harness

Personal Fall Arrest System (PFAS) Components

Co Componen ponents ts & K & Key y Term erms

 Anchor Point  Fall Arrest  Fall Restraint  Swing Fall Hazard  Harness  Lanyard  Vertical Lifelines  Fall Clearance  Rope Grab  Mobile Fall Protection Carts

FALL ARREST ANCHORS

Pen enetr tratin ating g vs

• vs. Non
• n-Penetr

enetratin ating

• Fall Arrest Systems;

–

Suspend worker in the event of a fall

–

Anchors must withstand 5K pounds.

• Fall Restraint Systems;
• Used as a leash to prevent worker

from reaching the fall hazard.

• Fall restraint anchors need to

support only 1,000 lbs. Differs from

• Providing rope kept tight enough so

roofer can never fall, compliance is

• btained.

Fall ll Res estrai traint nt vs.

• s. Fall

ll Arrest rest

Fall arrest anchor must be installed (in most cases) into substrate per manufacturers requirements to ensure 5000lbs Fall restraint anchors may be installed atop roof system providing competent person ensures it can support 1,000lbs

FALL RESTRAINT VS. FALL ARREST

Co Common

• n An

Anch chor

• rs

 Cross Arm Straps aka Beam Straps-  Good for 1 person to tie off to  Must be wrapped around something capable

• f supporting 5000 pounds for Fall Arrest

Follo low w Ma Manuf nufacturer acturers s Instructions nstructions

• Many types of roof anchors on the market.
• They may look similar, however they are

NOT the same.

• Critically important to follow the

manufacturers instructions when utilizing in fall arrest.

PFAS Components – The Anchor

Anchor Points Not Properly Fastened

Pr Prop

• perly

erly Install talled ed An Anch chor

• r

Cannot be Folded, Must be Into Substrate Directly for Fall Arrest

3 Vertical Lifelines Attached?!?!

Properly Installed Anchor

Great tie-off on steep slope

Rea eall lly? y?

Properly Installed and used PFAS

Hi Hitchclip tchclip An Anch chor

• r

Doo

• or

r Ja Jam An Anch chor

• r

Sta tandin ding g Sea eam R Roo

• of

f An Anch chor

• rs

Always follow manufacturers instructions for installation

PF PFAS AS Co Components ponents – The e Ha Harnes ness

Fall Pr Protection ection Eq Equipmen uipment t Harness ness Ins nspections pections

Co Componen ponents ts of

• f a PF

a PFAS AS

 Lanyard-  Shock Absorber Connected to D-ring  Never tie lanyard in a knot  Never connect one snaphook to another

snaphook Inspection Demonstration

INSP SPECT ECT!

Dragged on roof surface, frayed and damaged.

Proper way to take equipment

• ut of service. Tag out and/or

render inoperable.

Co Common mmon Retrac tractab table e La Lanya yard d Fail il Poin ints ts

 Broken self-closing

springs and fall indicators are common fail points during self-retracting lifeline inspections.

Common mmon Faults lts wi with Lanyards ds / Connect nnector

• rs

Too

• o Much

ch Sla lack ck

Lanyards/Lifelines cannot be connected back to themselves. A cross arm strap should be

• used. The vent pipe also may

not be of adequate strength for fall protection.

GOOD USE OF CROSS ARM STRAP

Impr Improper

• per

Con

• nnections

nections

Single-action carabiner – not acceptable for fall protection

??

200 lb. Worker falling 6 feet = 9,000+ lbs. of energy.

The Six Foot Fall

Impor portance tance of De Dece celeration leration De Device vice

 A.K.A. - “shock absorber”  In a 3’ or 6’ lanyard, this pack will

typically have 3.5 feet of additionally woven material.

 Stitched in precise manner to

significantly reduce fall forces.

○ Construction requires forces be

reduced to 1,800lbs or less. Most equipment designed to reduce forces below 900lbs.

KNOW WHAT YOU’RE BUYING “Everything the Roofer Needs for Fall Protection”

Improper Tie-Off – Will my Deceleration Device Deploy Properly?

Pr Proper per way y to connect nnect a La Lanyar ard

INCORRECT Shock absorber end of the lanyard is placed on the lifeline away from the

• body. Falling over the roof edge may

put force on the lanyard and impede the shock absorbers deployment. CORRECT The shock absorber should be as close to the body as possible. Minimize the chance of it getting disturbed during fall, maximize potential for proper deployment.

Co Componen ponents ts of

• f a PF

a PFAS AS

 Vertical Lifelines and Rope Grabs-  Arrow on Rope Grab always points towards the anchor

point

 Never tie lifeline in a knot  Never use fall protection components to hoist material.

Pr Proper per way y to connect nnect a Rope pe Gra rab

 Arrow Must always face your anchor

point

How w to pr

• prop
• perly

erly con

• nnect

nect to y

• you
• ur

anch nchor

• r po

point nt

WRONG Never wrap your lanyard or lifeline back around and clip to itself. CORRECT Use a cross arm (aka beam strap) to wrap a suitable structure and clip your lanyard/lifeline to the o-ring provided on the cross arm strap.

How w to pr

• prop
• perly

erly con

• nnect

nect to y

• you
• ur

anch nchor

• r po

point nt

CORRECT Image depicts proper tie off. This is for demonstration purposes only. Cross arm strap must be anchored to something substantial enough to support 5,000lbs in the event of a fall (fall arrest forces), or 1,000lbs to prevent from reaching the fall hazard (fall restraint forces)

Swi wing ng Fall ll Hazar zard

Minimize swing falls:

 Work directly below

the anchor.

 Do not extend your

work zone more than 30o from the anchor.

 Manage the slack in

the rope.

PEN ENDUL DULUM/S UM/SWING ING FALL LL HAZARD ZARD

Also improper anchor installation

Swi wing F g Fall ll Ha Haza zard, d, co cont. t.

 On most homes,

multiple anchor points will be required to manage swing-fall hazards.

 It is also important to

locate anchor points at a height that prevents striking a lower level should a fall occur.

Swing Fall Hazard

Ca Calc lcul ulating ating Fall ll Cl Clea earanc rance

 Distance from D-ring to

your feet

 5-6 Feet  Length of Lanyard  6 Feet  Shock absorber length  3.5 Feet

 Harness Stretch / D-ring

Movement

 1 Foot  Safety Factor  1-2 Feet

Ca Calc lcul ulating ating Fall ll Cl Clea earanc rance

 Whenever possible

connect to an anchor point located above your shoulders.

 Tie-offs below your

shoulders or at your feet increase your fall distance.

 When tie off below

shoulders is necessary, you must tie off behind you and keep lifelines tight at the roof edge to prevent more than a 6’ free fall.

Mo Mobile ile Fall ll Protection ection

Mo Mobile ile Fal all Pr Protection ection / B / Bad ad De Decking cking

3 anchors for fall arrest 2 anchors for fall restraint ONLY

Roo

• om for
• r Improvem

ement ent

• Four retractable lanyards in

use on a cart that only permits two.

• Would pendulum into the

ground before system caught them.

MA MAKING ING PF PFAS AS W WORK RK

Always think, “What will happen if I fall?”

PRE - PLANNING

Roo

• of

f Rep epairs

 Use of chicken

ladders & “slator” roof anchor for fall protection.

 Invest in the “competent person”

○ Capable of identifying existing and predictable hazards ○ Authorization to take prompt corrective measures

 Utilize your vendors  Training (not just an OSHA 10-hour card)

○ Initial ○ On-the-job ○ Refresher – tool box talks ○ Recurrent – annual

 Evaluation & Enforcement

○ Front Line, Middle and Upper Management ○ Recommend documenting / photographs for training ○ Helps in evaluating the effectiveness of training

Ma Maki king g PF PFAS AS Work

• rk

1926.503(b)

"Certification of training.“

1926.503(b)(1)

The employer shall verify compliance with paragraph (a) of this section by preparing a written certification record…

1926.503(b)(2)

The latest training certification shall be maintained.

1926.503(c)

"Retraining." When the employer has reason to believe that any affected employee who has already been trained does not have the understanding and skill required by paragraph (a) of this section, the employer shall retrain each such employee. Circumstances where retraining is required include, but are not limited to, situations where:

1926.503(c)(1)

Changes in the workplace render previous training obsolete; or

1926.503(c)(2)

Changes in the types of fall protection systems or equipment to be used render previous training obsolete; or

1926.503(c)(3)

Inadequacies in an affected employee's knowledge or use of fall protection systems or equipment indicate that the employee has not retained the requisite understanding or skill.

Investing esting in in th the e Compet petent ent Per erson son

 PFAS requires a great

deal of knowledge.

 Provide thorough

training for key personnel.

 3rd parties can assist.

Vendors have great training schools

 Not just a one and

• done. Refresher

training needed, continuous education.

Capital Safety 4.5 Day Competent Person Trainer Class

Effec ecti tive e Tra raining ng - Evalu luate

Mock up created to permit for hands-on installation of roof anchors during training

• Employees learn in different ways
• Effective training should include:
• Classroom training
• Written test
• Hands-on training
• Practical examination
• Certification
• Tool Box Talk Program
• Annual Refresher ALL

employees

• Ensure compliance with routine

Jobsite Safety Inspection Program

Resources

 NRCA

○ Videos ○ Written Material ○ Online resources ○ Webinars ○ Formal Training

 OSHA new website material

○ www.osha.gov/stopfalls

 Fall Protection Vendors  State OSHA Consultation Services  Private Safety Consultants

Hettrick, Cyr and Associates Inc. www.Hettrickcyr.com 1-888-805-0300

Presenters:

Peter Shackford & Justin Miller Safety & Risk Control
