SLIDE 1 Presentation to NBCC
2
Presentation to NBCC April 18, 2015 Biltech Building Elements - - PowerPoint PPT Presentation
Presentation to NBCC April 18, 2015 Biltech Building Elements - - PowerPoint PPT Presentation
Presentation to NBCC April 18, 2015 Biltech Building Elements Limited Biltech Building Elements Ltd. Avantha Group is one of Indias leading business conglomerates. Its successful entities include : BILT Paper & Pulp Crompton
SLIDE 2
SLIDE 3
3
Biltech Building Elements Ltd.
Corporate Video
SLIDE 4
4
Biltech Painting
Biltech Building Elements Ltd.
Design and Build structures with GFRG (Rapid wall Panel system) and
- ther
allied sustainable green products
Biltech Prefab Biltech AAC
Aerated Autoclaved Concrete Industrial & Decorative Painting
SLIDE 5
5
BILTECH- Snapshot
Biltech is a part of the USD 4 billion Avantha Group Largest Solid Waste (Fly Ash) Converters of India with a pan India presence. Aggressively working in the building material space for the past 21 years. Capacity- 10 lac cu. m per annum BIS certified products delivering quality. Product being used in large scale townships, hospitals, clubhouses, resorts, hotels, schools, shopping malls and residential towers in public and private sectors. Associated with more than 4000 projects including DDA Mass Housing, T-3 terminal, DMRC Stations, Commonwealth Games Village , Cantonments in J&K to mention a few.
SLIDE 6
6
BILTECH- Presence in India
SLIDE 7
7
BILTECH -AAC Block Sizes
LENGTH (MM) HEIGHT(MM)
- THK. (MM)
625 250 100 625 250 125 625 250 150 625 250 200 625 250 225 625 250 300
SLIDE 8
8
BIS Mark in Biltech AAC Blocks
SLIDE 9
9
BIS -2185(Part-III) : Specification of material BIS- 6041 : Construction of AAC masonry BIS- 6441 (Part I-IX) : Testing Procedure.
B.I.S. Codes Applicable to AAC Block
Density (Oven Dry) Compressive Strength Thermal Conductivity ( K Value) Fire resistance Drying Shrinkage Design Gross Density 551-650 Kg/Cum Minimum 30 Kg/cm2 0.162 W/mK (Average) 2 - 6 hrs depending upon Thk. 0.1 % 850 Kg/Cum.( appx.)
Properties of AAC Block
SLIDE 10
10
Composition by weight :
Fly Ash 60-65% Gypsum 2-3% Cement 8-10% Lime 10-12% Aluminum Powder 0.03% Balance Slurry solids generated during process
Raw Materials in AAC
SLIDE 11
11
Manufacturing Process
SLIDE 12
12
Plant & Machineries used in manufacturing of AAC
Mould filled with raw material De moulding Horizontal cutting Vertical Cutting Autoclaving Blocks at stock yard
Plant & Machinery
SLIDE 13
13
Important Features of AAC
Light Weight Thermal Insulation Fire Resistance Behavior of AAC during Earthquake AAC is Green Building Material
SLIDE 14
14
Density of AAC vis-vis Other Walling Material
500 1000 1500 2000 2500 3000
AAC HOLLOW BLOCK CEMENT CONCRETE BLOCK CLAY BRICK CONCRTE
DENSITY IN KG/CUM
SLIDE 15
15
Thermal Insulation
Energy savings in the operation of buildings are of particular importance as the cost of energy for heating and air conditioning in most cases represent the major cost factor in the operating cost of a building. The entrained air in the cellular structure of BILTEC AAC system gives the product excellent thermal insulation properties, as well as good heat retention characteristics. These characteristics contribute significantly to the energy saving performance of the building .
SLIDE 16
16
Fire Resistance
AAC has one of the highest hourly fire resistance ratings per millimetre of any building material. This makes it an ideal choice for fire protection around steel columns and steel beams, and in the construction of shaft walls, stairwells, corridors and firewalls. A 100mm and a 200 mm non-load bearing wall shall have fir resistance
- f 2 hours and 6 hours respectively .
SLIDE 17
17
Earthquake Resistance
AAC has been used for many years in areas subject to seismic action. Building which consist fully or partly of AAC have in general terms shown good resistance to earthquake forces in practice. The light weight of AAC reduces the seismic forces in common with some other materials. The non combustible and fire resistance nature of the AAC material is an advantage against fires commonly associated with earthquakes. The low weight of AAC in relation to its strength is an intrinsic advantage for earthquake design. AAC permits the designer to reduce the mass of the structure, limiting the impact of accelerations introduced in seismic situation.
SLIDE 18
18
BILTECH AAC IS “GREEN”
Up to 65 % raw materials consist of Industrial Waste i.e. Fly ash Non-polluting Manufacturing process -only steam is released Resource Efficient – less input material Low Energy Consumption throughout Life cycle Healthier Indoor Air Quality
SLIDE 19
19
Use of AAC in Green Buildings
BILTECH AAC Blocks conform to the requirements of IGBC – LEED and TERI –GRIHA rated buildings.
SLIDE 20
20
AAC BLOCK CUTTING NAILABILITY IN AAC BLOCK DOOR FRAME FIXING CONDUITING
Workability in AAC Block
SLIDE 21
21
List of some of our Govt. Projects
Name Application Delhi Development Authority , Delhi Housing Lucknow Development Authority , Lucknow Convention Centre Corporate Office of MOEF , Jorbagh Office UPRNN, Kannuj Medical College GKGH Hospital , Bhuj Medical College HPCL , Kanpur Office Building T3, Delhi Airport CWGV Village, delhi Housing Income Tax , Noida Office Building PWD , Delhi Hospital and School OIDB , Noida Office Building HAREDA , Chandigarh Office Building National Council for Applied Economic Research (NCAER), Delhi Office Building IIITD , Delhi College ONGC , Delhi , Dehradun Office Building Ministry of Defence / MES. Bhadrwah, J&K Residential OTM Accomodation , MES, Gurgaon Residential Haryana Housing Board, Gurgaon Residential DMRC, Delhi Station Building KRIBHCO , Noida Residential
SLIDE 22
22
List of some of our Clients
SLIDE 23
Utilization of C&D Waste in Brick Making
Biltech Building Elements Limited
SLIDE 24
24
Pre-requisites to use C&D Waste
Important considerations before recycling Construction & Demolition (C&D) Waste into building materials Economy Compatibility with other materials Product performance over the building life cycle
SLIDE 25
25
C&D Waste Utilization Pattern
S/S Land Disposal 20% High Value added materials 4% Paint,binder & plaster 5% Aggregates 5% Concrete, roofing sheet 7% Bricks, blocks & tiles 12% Cement 11% Ceramic products, extraction of metals soil conditioner 11% Particle board, panels, composites wood subtitute products 12% Structural fill, soil stabilisation and road embankment work 13%
C&D Waste Usage
SLIDE 26
26
Properties of C&D Waste
SL Properties Sand C&D Waste Aggregates-Fines C&D Waste Aggregates-Coarse 1 Specific Gravity 2.67 2.6 2.4 2 Fineness modulus 2.9 3.2 6.67 3 Water absorption 1% 12% 13.31%
SLIDE 27
27
Important Considerations for C&D waste usage in brick making
SL Properties Red Clay Bricks C&D Bricks 1 Density(Kg/m3) 1850 1900 2 Water Absorption(%) 20% 12% 3 Compressive Strength(N/mm2) 7.5 7-8.5 4 Embodied Energy(MJ /Kg) 9.0 2.0 5 Reference Code BIS 1077 NA
SLIDE 28
28
Various Mix Notations for C&D usage in Bricks
SL Mix Notation Cement Fly Ash Sand C&D Waste Aggregates-Fines C&D Waste Aggregates-Coarse 1 MX#1 1 0.4 2 4 2 MX#2 1 1 3 4 3 MX#3 1 2 4 4 4 MX#4 1 1 1.4 3.6 4 5 MX#5 1.5 1 3 4.5 6 MX#6 1.5 4 4.5
Notes:
- All the above values achieved against controlled curing.
- Polymer used in varied proportions as per mix notations.
SLIDE 29
29
Performance for various Mix Notations
SL Mix Notation Density (Kg/m3)
- Avg. Compressive
Strength (N/mm2) Water Absorption (%) Embodied Energy (MJ per brick) 1 MX#1 2526 31.12 6.39 2.99 2 MX#2 2328 25.27 7.23 2.48 3 MX#3 2211 19.18 9.55 2.05 4 MX#4 2072 9.56 7.56 2.08 5 MX#5 1920 8.10 9.44 2.00 6 MX#6 1866 6.74 12.18 1.93
SLIDE 30
30
Sample Bricks
SLIDE 31
31
Converting C&D Waste into Brick Making
Procurement of C&D waste
Separation of Concrete & masonry waste and Transportation to Brick making plant Crushing bigger concrete blocks and brick waste manually Separation of course and fine aggregates through sieving Proportioning of Raw Material and Mechanical Mixing Feeding to brick making machine and pressing bricks Drying Immersion Curing Testing
SLIDE 32
32
Proposal- Supply of Bricks
To initiate our foray , Biltech proposes to set up a brick making facility at site with following features: Model facility to process 150 tons of C&D waste (equivalent to 30000 bricks /day) Automated Robot Assisted Technology Patented Robot Design Controlled curing Mechanized vertical stacking Superior brick quality
SLIDE 33
33
Proposal- Supply of Bricks
Parameters Particulars Objective To effectively recycle C&D waste so as to use it as a suitable building material for construction activities. Proposal To set up a Brick Making Plant by processing C&D waste. Purpose To supply Bricks to NBCC to be used in construction
- f Residential and Commercial Complexes.
Proposed Capacity 200 ton per day
- No. of Bricks per day 50,000 (weight of a Brick:3.2-3.5 Kg)
Land required Around 2.5 acres Plant Location At Project Site itself
`
SLIDE 34
34
Proposal- Supply of Bricks
Parameters Particulars Technology
- Automatic Patented Robot Assisted brick making
- Solid performance track record
Proposed Recovery (inclusive
- f
all taxes without transportation) To be decided Gestation Period 5-6 months Billing Biltech to directly bill to NBCC Contractor. Quality Need to lab test CDW bricks, for which we request for 1 ton of existing waste from Kidwai Nagar Site. Investment
- Rs. 4-5 crore
SLIDE 35
35
NBCC to provide
2.5 acres of Land for setting up a Brick making plant for a period upto completion of Project Continuous availability of dry C&D waste to ensure full capacity utilization Power connection Water availability 100% Buy Back at a pre-determined price
SLIDE 36
36
Responsibility of Biltech to ensure/provide Invest and set-up the Brick making plant Continuous supply of Bricks as per commercially agreed terms with NBCC Deliver output as per production requirements mutually agreed. Meeting acceptable quality standards desired off C&D Waste
SLIDE 37
37
Integrated Plant Facility-Long Term Plan
Biltech is committed to establish itself as leading supplier of not only AAC Blocks but also other green building materials. We would like to establish long term association with NBCC to optimally process C&D waste enabling generation of aggregates, sand, bricks, pavers, etc, suitably integrating as per opportunity. Assist in formation of BIS code on recycled material, which will create markets for these products.
SLIDE 38
38
