Reinforcement Learning Generalization Using State Aggregation with a Maze-Solving Problem Mohamed K. Gunady Walid Gomaa

Department of Computer Science Engineering Egypt-Japan University of Science and Technology (E-JUST) Alexandria, Egypt Presented by: Mohamed K. Geunady

Overview

• Introduction.
• Q-Learning.
• State Aggregation.
• SAQL Algorithm.
• Experimental Results.
• Future Work.
• Conclusion.

JEC-ECC March 2012, Alexandria, Egypt 2 SAQL - M. Gunady - EJUST

Introduction

• Reinforcement Learning.

– Learn by Trial & Error. – Interaction with the environment. – Best strategy to maximize the total rewards. – Based on MDP model.

• current state s, action a, next state s', reward R(s, a)

– Many algorithms:

• Q-learning, TD(λ), Sarsa-Learning..

JEC-ECC March 2012 Alexandria, Egypt 3 SAQL - M. Gunady - EJUST

Q-Learning

• Observing <s, a, r, s'>
• Learn an optimal policy π* : S → A.
• Max the cumulative discounted Reward:
• Let

V*(s) = maxa Q(s,a)

then

JEC-ECC March 2012 Alexandria, Egypt 4 SAQL - M. Gunady - EJUST

Vπ(st) = rt + γ rt+1 + γ2 rt+2 +… (1) Q(s,a) = r(s,a) + γ maxa' Q(s',a') (2)

Q-Learning (Contd.)

• Guaranteed to converge. However, slow

convergence rate.

• Lookup table for Q(s,a) , high computation,

space complexity.

• curse of dimensionality in state-action space.
• Thus, more compact representations.

– hence, Generalization Techniques.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 5

State Aggregation

• Generalization Techniques:

– Function Approximators: e.g. NN. – Hierarchical Learning. – State Aggregation.

• Reduce time and storage requirements.
• Mostly, smooth state space, i.e. the values of

the adjacent states are nearly equal.

– Combine similar states.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 6

State Aggregation (Contd.)

• Then, Two questions:

– How to determine the similarity between states? – How to learn over the new state-action space?

• Terminologies:

– Ground space, the actual MDP. – Abstract space, the hypothetical reduced MDP.

• Denote X for the abstract state space.
• Ax for the abstract action space.
• Rx for the new reward function.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 7

SAQL Algorithm

• Main Steps:

– Discover similar states. – Group them into one abstract state. – Learn over this single abstract state instead of the many similar ground states.

• how to decide a group of states are similar, i.e.

consistent, enough to be grouped?

– if some neighbouring states have consistent reward payoffs.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 8

SAQL Algorithm

Consistency Test

• Let abstract state x,
• s, s’ ground states to be grouped into x.
• Consistency Rule for x:

IF THEN group x is consistent, construct abstract state x.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 9

(3)

SAQL Algorithm

Abstract-Ground Mapping

• Abstract action space Ax
• ax abstract action, from abstract state x to x',
• ne of the neighboring abstract states to x.
• Map ax to the equivalent ground actions within

x, i.e. Internal Actions Ain

• Internal actions have to be planned

algorithmically not by learning.

– Use simple group topology, e.g. square-shaped

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 10

SAQL Algorithm

System Architecture

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 11

• Check the paper for the full

algorithm.

Experimental Results

• Maze-solving problem as a test bed.
• Problem Settings:

– * mark starting state, location (row, col). – X mark absorbing state (goal). – {N, S, E, W} actions. – Reward function:

• +10 for goal state.
• - 10 for obstacle state.
• - 0.02 otherwise.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 12

Experimental Results

Convergence Rate

• Learning Episodes.

– Each contains many iterations.

• 60x60 maze.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 13

Experimental Results

State Space Size

• Different maze sizes.
• 100, 900, 3600 states.
• QL suffers high increase in number of

iterations by increasing state space size.

• SAQL suffers much less.
• Speedup 3.9x, for state space of size 3600,

within the first 100 episodes.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 14

Experimental Results

State Space Size

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 15

Experimental Results

Maze Complexity

• Aggregation depends on the reward function

w.r.t. the neighboring states.

• The more consistent regions, the more

aggregation efficiency => more reduction.

• i.e. number & distribution of obstacles

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 16

Experimental Results

Maze Complexity

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 17

• 30x30 maze, different obstacles

Experimental Results

Iteration Complexity

• Tradeoffs: the learning iteration became more

complex.

• Extra computational work:

– Consistency test. – States merging. – Mapping between ground/abstract states and actions.

• But usually, the number of learning actions is

highly costly compared to computations.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 18

Future Work

• Simple grouping technique and shapes.
• Arbitrary shapes rather than squared ones.

– How to plan internal actions, and quickly.

• More complex groping technique

– E.g. allow group breaking and regrouping.

• Extend to probabilistic and dynamic

environments.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 19

Conclusion

• RL Generalization with state aggregation is

promising.

• Modified QL, SAQL, algorism and system

architecture is introduced.

• Speedup of 4x.
• 60% state space reduction.

JEC-ECC March 2012, Alexandria, Egypt SAQL - M. Gunady - EJUST 20

ًاركش Thank You
