SLIDE 1
XYZ Cell
Presentation Kwang Lim Single Axis Bench Test XYZ Cell Finished - - PDF document
Presentation Kwang Lim Single Axis Bench Test XYZ Cell Finished - - PDF document
Presentation Kwang Lim Single Axis Bench Test XYZ Cell Finished Mold XYZ Cell Require Development and Workflow Casting of machine structure Design of mold using 2D acrylic sheets Assemble mold Assemble lead screw, precision
SLIDE 2
SLIDE 3
XYZ Cell
Finished Mold
SLIDE 4
Require Development and Workflow
Casting of machine structure
Design of mold using 2D acrylic sheets Assemble mold Assemble lead screw, precision shaft into mold Mix plaster Pour plaster into mold Wait for 45 minutes Detach from acrylic sheet mold Allow to cure for one day
SLIDE 5
Cost and Benefits
Machine Structure (~ $60 for 3 axis)
Structure is ¼ cost of entire XYZ cell (~ $1000 for 3 axis)
Low cost machine structure
< $20 per axis
Requires only 1 acrylic mold to produce many machine structures
No oven drying
SLIDE 6
Plaster Disaster Development
SLIDE 7
Plaster Disaster Mold
SLIDE 8
Plaster Disaster XY axis Top Mold
SLIDE 9
Plaster Disaster XY axis Details
SLIDE 10
Z Carriage Mold
SLIDE 11
Z Axis
SLIDE 12
Shuttle and Yankers
SLIDE 13
Completed PD
SLIDE 14
PD Repeatability Test
SLIDE 15
Driving Mechanisms
Capstan and Belt Drive Belt Drive Lead Screw Drive
SLIDE 16
Lead Screw Concept
SLIDE 17
Lead Screw Drive Demo
SLIDE 18
Software
Linux CNC
Does not work on notebook
Fab@Home
Work notebook
SLIDE 19
Power Electronics
Allegro A3984
Improving batwing power dissipation
SLIDE 20
Selection of sense resistors and reference voltage
Rtop 10K and Rbottom 7K
Rs = 0.5 Ω
Vref = 2 V
SLIDE 21
A3984 Microstepping
SLIDE 22
Speed Control
Non-Linear
ATMega88 Timer Interrupt
Taylor Series Approximation
SLIDE 23
Air Assist Compressor Water Cooled To Radiator Exhaust
Laser Machine Concept
SLIDE 24
Laser Tube – CO2
40W CO2 Laser Power Supply
40W CO2 10600nm Laser Tube
Water Pump
$1200 (Ebay)
SLIDE 25
Cooling system for CO2 Laser
$320
SLIDE 26
Fiber Laser
Compact Fiber Laser
1.6W
US$20,000
SLIDE 27
Used Fiber Laser
20 W 1565nm US$399 1 W 830nm US$149 20 Watt 808nm US$399.95
SLIDE 28
What Next?
Acceleration and deceleration code for ATMega88
Laser cutting using ~800 nm laser
SLIDE 29
