Presentation

ORTIC Group ORTIC 3D AB ORTIC AB Machinery Bendiro Profile Tech AB Contracting Northcone AB Lighting Columns Strandbygget AB

Real estate

CTO, CFO

• Focus on Rollforming
• Machinery, contracting, products
• Employees: 60 (2013)
• Estimated turnover 2013: 135 MSEK
• Founded:
• 1943 - Bendiro
• 1984 - ORTIC
• 2009 – Northcone
• 2011 – Strandbygget AB

Leading Company Group within roll forming in Scandinavia. Company Group Vision to become leading within roll formning in Europe. ORTIC Group have defined a CSR Strategy with focus mainly on environment, working conditions, safety and anti corruption.

ORTIC GROUP

2

ORTIC 3D AB also has a minority share of the company CrossBorder Technologies AB.

• Located in Falkenberg
• Estimated turnover 2013 : 80 MSEK
• Bendiro produces roll formed shapes, specializing in customized profiles
• Focus on the following sectors:

– Construction – Industry – Furniture – Automotive – Telecom

Bendiro Profile Tech AB

3

• Located in Borlänge
• Estimated Turnover 2013 : 50 MSEK
• Experts in roll forming, well known world wide for its patented 3D roll forming used in many

sports arenas etc:

• Specialized in construction, automotive and storage systems
• Important know how for future development of 3D roll forming

ORTIC AB

4

• First product company based on 3D roll forming

– Lighting columns are well suited for 3D roll forming because of their long shape and the possibility to design them with a conical shape

• Located in Stockholm and Borlänge
• Development and sales of lighting columns
• Planned sales start 2013

Northcone AB

5

Roll forming

6

Every year approximately 1,000 million tons of steel is produced The majority of all steel is stamped Approximately 8% of all cold rolled steel is being roll-formed

Global steel production

7

Trends Escalating raw material prices – An increasing share of the end product cost comes from raw material Increased environmental focus – Weight savings is a top priority in new cars – OEM’s are paying up to €10 per saved kilo

Trends in the Steel Industry

8

3D Roll forming

9

Year 2001

• BEMO sold a roof that could not be produced
• Required roll-forming with a variable cross section
• Turned to ORTIC

Background

10

4,700 unique panels 1 machine Container portable

Budapest Arena

11

Olympic Games – Athens 2004

Later productions

12

Intellectual Property

• More than 10 patent families
• Global reach
• Method as well as product protection

– Automotive – Construction – Lighting columns

Extensive IPR

13

ROLL-FORMING STAMPING Complex structures

The design limitation has isolated roll-forming from the major market

Industry standard Minimal material waste Easier with high strength steel High capacity Low capital cost

Stamping versus conventional Roll‐forming (2D)

14

Industry standard Minimal material waste Easier with high strength steel High capacity Low capital cost 3D ROLL-FORMING STAMPING

Without the design limitations the competitive edge is obvious

Stamping versus 3D rollforming

15

So far Future applications

– Furniture – Automotive – Lighting columns – Boats – …

Applications

16

17

One of the main potential application areas for 3D roll forming is the Automotive industry as a lot of improvements can be made compared to stamping:

• Minimal material waste
• Easy to form with high strength steel
• High capacity
• Lower investment costs
• Less tooling costs

Automotive
