Presentation on Marimaca to Fexmin Sergio Rivera, VP Exploration, - PowerPoint PPT Presentation

Presentation on Marimaca to Fexmin Sergio Rivera, VP Exploration, October 2018, Santiago DISCLAIMER & FORWARD LOOKING STATEMENTS This presentation includes certain forward-looking statements about future events and/or financial results which


  1. Presentation on Marimaca to Fexmin Sergio Rivera, VP Exploration, October 2018, Santiago

  2. DISCLAIMER & FORWARD LOOKING STATEMENTS This presentation includes certain forward-looking statements about future events and/or financial results which are forward-looking in nature and subject to risks and uncertainties. Such forward-looking statements or information, including but not limited to those with respect to the development of the Marimaca project, metal prices, metallurgical results and resource estimates, involve known and unknown risks, uncertainties, and other factors which may cause the actual results, performance or achievements of the Company to be materially different from any future results, performance or achievements expressed or implied by such forward-looking statements or information. Forward-looking statements include without limitation, statements regarding the company’s plans, goal or objectives and future completion of mine feasibility studies, mine development programs, capital and operating costs, production, potential mineralization, resources and reserves, exploration results and future plans and objectives of Coro Mining Corp. Forward-looking statements can generally be identified by the use of forward-looking terminology such as “may”, “will”, “expect”, “intend”, “estimate”, “anticipate”, “believe”, or “ continue” or the negative thereof or variations thereon or similar terminology. There can be no assurance that such statements will prove to be accurate and actual results and future events could differ materially from those anticipated in such statements. Important factors that could cause results to differ materially from expectations include risks associated with mining generally and pre-development stage projects in particular. The company is an exploration, development & mining company. Many references to resources and other geological and technical information contained herein have not been verified by an independent expert and are either not in accordance with the requirements under National Instrument 43-101 or have not been prepared in accordance with a preliminary or final feasibility study. Potential investors should conduct their own investigations as to the suitability of investing in securities of Coro Mining Corp. The potential target tonnage and grade noted for the Marimaca project are conceptual in nature as there has been insufficient exploration to define mineral resources, and it is uncertain if further exploration will result in these targets being delineated as mineral resources. Unless otherwise indicated, Coro has prepared the technical information in this presentation (“Technical Information”) based on information contained in the technical reports and news releases (collectively the “Disclosure Documents”) available under Coro Mining Corp.’s company profile on SEDAR at www.sedar.com. Each Disclosure Document was prepared by or under the supervision of a qualified person (a “Qualified Person”) as defined in National Instrument 43-101 – Standards of Disclosure for Mineral Projects of the Canadian Securities Administrators (“NI 43-101”). For readers to fully understand the information in this presentation, they should read the Technical Reports (available on www.sedar.com) in their entirety, including all qualifications, assumptions and exclusions that relate to the information set out in this presentation which qualifies the Technical Information. Readers are advised that mineral resources that are not mineral reserves do not have demonstrated economic viability. The Disclosure Documents are each intended to be read as a whole, and sections should not be read or relied upon out of context. The Technical Information is subject to the assumptions and qualifications contained in the Disclosure Documents. All figures are quoted in US dollars unless otherwise stated. Sergio Rivera, Vicepresident Exploration CEO of Coro Mining Corp, a geologist with more than 35 years of experience is the Qualified Person for the purposes of NI 43-101 and has approved this written disclosure. All Dollar amounts in this presentations are US Dollars unless otherwise stated. 2

  3. Contents 1. Discovery 2. Deposit Geology 3. Resources and exploration Conclusions 3

  4. 1. DISCOVERY 4

  5. LOCATION UBICACION Y PROPIEDAD MINERA Mejillones Marimaca Planta Ivan Mantos Blancos Antofagasta 0 25 KM 5 (Imagen Base: Service Layer Credits: Source: Esri, DigitalGlobe, GeoEye, Earthstar Geographics, CNES/Airbus DS, USDA, USGS, AeroGRID, IGN, and the GIS User Community)

  6. MINING PROPERTY 6

  7. 500 m Marimaca Claim map RECONOCIMIENTO GEOLOGICO – First visit (february 2014) observations points FEBRERO 2014 1 Marimaca 1 al 23 Claimed January,1979 by Mrs 3 Manuel Rivera & Maximiano Carrizo 2 7

  8. Observation point 1 Looking south 8

  9. Observation point 2 Looking north 9

  10. Observation point 3 Looking north 10

  11. RECONOCIMIENTO GEOLOGICO – Location of the FEBRERO 2014 “discovery section” View point “Discovery Section” location 11

  12. D ISCOVERY “ SECTION ” – LOOKING SOUTH Note that wall rock is monzodiorite intruded by mafic and dacitic sills and dykes Goethite>hematite + Copper oxides E W Albite / Chlorite – Strong parallel fract. ~ 280 m true thickness Hanging – Wall alteration: Chlorite/sericite/albite (pyrite) Moderate parallel fract. Foot-Wall alteration: Especularitae/albite/chlorite Minor parallel fract. 150 m: 0.36%CuT/ 0.24%CuS (including 85 m: 0.48%CuT/0.32%CuS) 30 m: 0.53%CuT/ 0.43%CuS 200 m (https://www.coromining.com/news/2014/coro-announces-results-from-marimaca-project-due-diligence/index.html) 12

  13. THE EXPLORATION TARGET DEFINED “Discovery” section location (https://www.coromining.com/news/2014/coro-announces-results-from-marimaca-project-due-diligence/index.html) 13

  14. ROCK GEOCHEMISTRY (CU PPM) 14

  15. 2. Deposit Geology 15

  16. GEOLOGICAL SETTING & Cu MANTO DEPOSITS (Jurassic volcanics and intrusives: 180-170 ma, late dyke swarms ~ 140 Ma) (Modify from: Mapa Geologico de Chile, Serv. Nac. Geol y Min, 2002) 16

  17. Naguayan Stock host rock and parallel fracture system View looking south

  18. 18

  19. DRILLING 2016 – 2017: 27.606 M 2016: AR 11.620 m DDH 2.008 m 2017 AR 11.928 m DDH 2.050 m TOTAL AR: 23.548 m 113 pozos DDH: 4.058 m 16 holes 129 holes 27.606 m 19

  20. SURFACE GEOLOGY Hanging Wall alteration 200 m (map by IMG, 2017) 20

  21. MAIN ROCK TYPES Monzodiorita Microdiorita Pórfido andesítico (“Ocoítico”) Pórfido Monzodiorítico Pórfido dacítico 21

  22. 3D ROCK TYPE DISTRIBUTION MDI PMD 500 m 3D DYKES AND SILLS 3D ROCK TYPES (modelling using Leapfrog MR asisted by Atticus Geo) 22

  23. ROCK ALTERATION & METASOMATISM (-) (+) (Na-K Met) Monzodiorite Monzodiorite Porphyry 23

  24. MAIN STRUCTURES “Feeders” Parallel rock fracturing Faults 200 m 24

  25. COPPER OXIDE MINERALOGY Brochantite Chrysocholla 25

  26. MINERALIZATION ZONES Brochantite Wad Chrysocholla 200 m 3D COPPER OXIDE MINERAL ZONES 3D TOP OF SULPHIDE 26

  27. COPPER OXIDE MINERALOGICAL ZONES 200 m BROCHANTITE CHRYSOCHOLLA WAD 27

  28. “Feeder” Parallel fractured & mineralized monzodiorite View of a “feeder zone” intersecting parallel fractured monzodiorite ~10 m controlling copper oxide mineralization (looking north) 28

  29. “Feeder” Parallel fractured & mineralized monzodiorite 29

  30. NW – SE LONG SECTION: STRUCTURE “Parallel fracturing” NW SE Faults “Feeders” 200 m 30

  31. NW – SE LONG SECTION: COPPER OXIDE MINERAL ZONES Chrysocholla Wad NW SE Brochantite 200 m 31

  32. NW – SE LONG SECTION: CUT (%) BLOCK MODEL NW SE 200 m 32 (block model by NCL, 2018)

  33. SULPHIDE AND MIXED MINERALIZATION (HQ CORE) Massive chalcopyrite Chalcopyrite-magnetite, intense albitized bands Mixed copper oxides:brochantite, chalcocite, cuprite Chalcocite - covellite supergene sulphides 33

  34. 3. Resources and exploration 34

  35. MARIMACA 1 – 23 MINERAL RESOURCES Cris Broc 200 M Wad MINERAL ZONES CuT (%) BLOCK MODEL Medido + Indicado Inferido Medido + Indicado + Inferido LC CuT% Cu Fino (Mt) MMT CuT % CuS % MMT CuT % CuS % MMT CuT % CuS % 0,1 58,6 0,55 0,37 17,3 0,36 0,21 75,9 0,51 0,33 384,6 0,2 46,8 0,65 0,44 11,0 0,48 0,28 57,8 0,62 0,41 357,0 0,3 37,4 0,75 0,52 7,7 0,58 0,34 45,1 0,72 0,49 325,2 TOTAL RESOURCE SUMMARY (NCL 2018) (NCL, 2018, Updated resource estimate for the Marimaca Copper Project, NI 43-101 report available at www.sedar.com) 35

  36. LA ATOMICA Y ATAHUALPA EXPLORATION PROGRAM Atahualpa et al claim group Hanging – Wall Alteration U / G workings La Atómica 1-10 Drill hole collars (2017-2018 resource estimation area) Marimaca 1-23 1 km (UAV image obtained and processed by GeoIT) 36

  37. Conclusions 37

  38. ARE THERE MORE DEPOSITS TO BE DISCOVERED IN NORTHERN CHILE? BE AWARE OF THE “ CONCEPTUAL TRAPS” 38
