Predicting Regulatory Elements Predicting Regulatory Elements in P. falciparum in P. falciparum Chengyong Yang Erliang Zeng Giri Narasimhan BioInformatics Research Group (BioRG) School of Computer Science Florida International University,

slide-1
SLIDE 1

Chengyong Yang Erliang Zeng Giri Narasimhan

BioInformatics Research Group (BioRG) School of Computer Science Florida International University, Miami, FL.

Kalai Mathee

Department of Biological Sciences Florida International University , Miami, FL.

Predicting Regulatory Elements in P. falciparum Predicting Regulatory Elements in P. falciparum

slide-2
SLIDE 2

2

Outline

  • Biology of Transcription Regulation
  • Mining Regulatory Elements (or Transcription

Factor Binding Motifs or TFBMs)

  • Experimental Results
  • Conclusion
  • Future Work
slide-3
SLIDE 3

3

Transcription Regulation

Exon 1 Exon 2

T r a n s c r i p t i

  • n

S t a r t p

  • i

n t

mRNA

Intron Gene-Specific TF Binding Sites TATA Box CAT Box Basal TF Binding Sites TATAAT CCAAT coding region promoter region enhancer

slide-4
SLIDE 4

4

Transcription Regulation

[ Goffart et al. Exp. Physiology (2003) ]

slide-5
SLIDE 5

5

Outline

  • Biology of Transcription Regulation
  • Mining Regulatory Elements (or Transcription

Factor Binding Motifs or TFBMs)

  • Experimental Results
  • PlasmoTFBM database & Web Query Interface
  • Conclusion
  • Future Work
slide-6
SLIDE 6

6

Transcription Factor Binding Motifs (TFBM)

  • Why look for TFBMs?

– Which TFs regulate a specific gene? – Which genes are co-regulated by same TF? – Understand strength of gene expression. – Understand gene regulatory pathways.

slide-7
SLIDE 7

7

Computational Methods

  • Search for known motifs
  • Predict sites based on pattern discovery in

upstream sequences

How to Find TF Binding Motifs?

Direct Experimental Assays

  • Electrophoretic mobility shift assay
  • Nuclease protection assay

Need to know the TFs. Need to know the TFBMs Only need to know the upstream sequences

slide-8
SLIDE 8

8

CAMDA Data Set

  • Microarray data from DeRisi lab
  • 46 data sets for a 48 hour time period for
  • P. falciparum during the intraerythrocytic

development life cycle.

  • During the 48 hour period, P. falciparum

goes through 4 stages:

– Ring (1-15 hpi) – Trophozoite (16-28 hpi) – Schizont (29-42 hpi) – Merozoite (43-48 hpi)

slide-9
SLIDE 9

9

Broad Questions Raised

  • Are there transcriptional events that

distinguish the 4 stages of the

  • rganism?
  • Are there functional similarities in the

genes that share motifs?

slide-10
SLIDE 10

10

AlignACE

  • Uses Gibbs Sampling to find good alignments of

upstream sequences.

  • Maximizes relative entropy to find significant

motifs.

  • Significant motifs: must over-represent in the

input set and must have small probability of

  • ccurring by chance.

[ Roth et al. Nature Biotechnology (1998) ]

AlignACE

Cluster

  • f Genes

Significant Motifs

slide-11
SLIDE 11

11

Clustering of Samples or/and Genes

  • Transcription

Module

slide-12
SLIDE 12

12

Transcription Module

Transcription Module: a set of genes G and a set of conditions C such that the genes in G are co- regulated under conditions C.

[ Ihmel et al. Nature Genetics (2002) ]

Iterative Signature Algorithm (ISA)

  • Defines the score of a set of genes and

conditions.

  • Iteratively refines the set of genes and conditions

until a “stable” transcription module is obtained.

[ Ihmel et al. Bioinformatics (2004) ]

slide-13
SLIDE 13

13

Predicting TFBMs: Method I

ISA

Clusters

  • f Genes

AlignACE

Significant Motifs Gene Expression Data

Using Method I: 106 transcription modules 840 significant motifs

slide-14
SLIDE 14

14

Strength of TFBMs

  • TFs bind to DNA in sequence-specific

manner.

  • If the motif is “strong”, then the binding is

strong and the regulation is strong.

  • Correlation between gene expression and

the strength of its upstream TFBMs.

  • MotifRegressor [Conlon et al., PNAS 2003]

exploits this correlation.

slide-15
SLIDE 15

15

Motif Regressor

[Conlon et al., PNAS, 2003]

  • 1. Rank all genes by expression and obtain upstream

sequences of highly ranked genes.

  • 2. Use MDscan to find motifs from most induced and most

repressed genes.

  • 3. Score each upstream sequence for matches to each

MDscan reported motif.

  • 4. Perform linear regression between motif matching score

and gene expression and identify significant motifs.

46 separate runs of MotifRegressor resulted in 637 significant motifs.

slide-16
SLIDE 16

16

PlasmoTFBM Database

  • All results were put into a searchable

MySQL database containing:

– Modules – Motifs – Gene Annotation information – Gene Expression data – Upstream sequence data – Miscellaneous data

slide-17
SLIDE 17

17

Outline

  • Biology of Transcription Regulation
  • Mining Regulatory Elements (or Transcription

Factor Binding Motifs or TFBMs)

  • Experimental Results
  • Conclusion
  • Future Work
slide-18
SLIDE 18

18

Results

  • A. Validation of known motifs
  • 1. G-Box motif
  • 2. var gene family
  • B. Motif clusters & motif-stage

correlations

  • C. All Motifs in single gene of interest
  • D. Gene Family Analysis (SERA genes)
slide-19
SLIDE 19

19

A: G-Box Motifs

  • P. falciparum genome is AT-rich (15% GC)
  • G-box: a unique regulatory element
  • Identified in upstreams of heat shock

proteins (hsp).

[Militello et al., MBP, 2004]

(A/G)NGGGG(C/A)

Published Motif

slide-20
SLIDE 20

20

A: G-Box Motifs

[Militello et al., MBP, 2004]

(A/G)NGGGG(C/A) G-Box from PlasmoTFBM

TG-box

New

slide-21
SLIDE 21

21

A: var Gene Family

  • 50 diverse var genes
  • Coding for variants of P. falciparum

erythrocyte membrane protein 1 (PfEMP1)

  • Ability to switch the expression of PfEMP1
  • Allows the parasite to escape specific

immune responses

[Voss et al., Mol Microbiol, 2003]

slide-22
SLIDE 22

22

A: Significant Motifs in var Genes

[Voss et al., Mol Microbiol, 2003]

PFL0935c PF14_048 PFB0010w PF08_0103 PFI1830c PF10_0406 PFL1955w PFA0765c PFD0615c

Induced 11 hpi

PF08_010 PFL0935c PF10_040 PFB0010w PFI1830c PFA0765c

Repressed 38 hpi

ATGTTGTACAT

CPE

TGTGCATAGTG

SPE2

slide-23
SLIDE 23

23

B: Motif Clusters

R T S M

1 2 3 4 5 6 7 8 10 9 11 12

R T S M

[Genesis, http://genome.tugraz.at/Software]

slide-24
SLIDE 24

24

C: EBA140

  • EBA140 is implicated in merozoite

invasion on erythrocytes

  • Putative vaccine target
  • Share sequence homology and

structural features with EBA175

[Thompson et al., Mol Microbiol, 2001]

slide-25
SLIDE 25

25

C: Motifs Found in EBA140

MAL13P1.61, hypothetical protein, sharing all eight motifs Shared by 77 genes including MAL7_1.86 Shared by 77 genes including MAL7P1.86 (TF) Correction: Figure 4, Pg 19 of Abstracts

slide-26
SLIDE 26

26

D: SERA Gene Family

  • Serine repeat antigen (SERA)
  • Adjacent, co-regulated genes from Chr 2
  • Highly expressed in late blood cycle
  • Target of protective immune response
  • Possesses a protease function domain
  • Serves both as a vaccine and a drug

target to control P. falciparum

[Miller et al., JBC, 2002]

slide-27
SLIDE 27

27

D: Motif Discovered in SERA

PFB0325c PFB0330c PFB0335c PFB0340c PFB0345c PFB0350c PFB0355c PFB0360c

SERA Modules

rand5-80_m22_1 PFE0415w_g1.3_c8

Motif

http://biorg.cs.fiu.edu/TFBM/tfbm.php

slide-28
SLIDE 28

28

D: Module Average Expression Profile

PFE0415w_g1.3_c8

slide-29
SLIDE 29

29

D: SERA TFBMs Visualization

M0 M1 M2 M3 M4

slide-30
SLIDE 30

30

Conclusions

  • PlasmoTFBM: first comprehensive database
  • f P. falciparum TFBMs
  • Validated many known P. falciparum motifs
  • Discovered new interesting motifs
  • Web query interface built for biologists
slide-31
SLIDE 31

31

Acknowledgements

  • BioRG members (Tao Li, Gaolin Zheng,

Tom Milledge)

  • Prof. Shirley Liu, Harvard (MotifRegressor)
  • Haifeng Wang, Jing Zhai & Wei Shi

http://biorg.cs.fiu.edu/CAMDA2004 http://biorg.cs.fiu.edu/TFBM/tfbm.php
