Psychrometrics

  • from Greek Psychro – To breathe, blow, or

make cold. Metrics – to measure.

  • the field of engineering concerned with the

determination of physical and thermodynamic properties of gas-vapor mixtures.

slide-6
SLIDE 6

The Psychrometric Chart

  • Graphical Representation of Properties of Air /

Water Mixtures.

  • Dry-Bulb (°F db)
  • Wet-Bulb (°F wb)
  • Dew-Point (°F dp)
  • Specific Volume (ft3/lb)
  • Humidity Ratio (Gr/lb)
  • Enthalpy (Btu/lb)
  • Two state points required to fix properties – i.e.

DB/WB, DB/%RH, DB/H, etc.

slide-7
SLIDE 7

Psychrometric Chart

The relationship between DB, WB, and RH is given

by the Mollier diagram (pressure-enthalpy) for water in air, developed by Richard Mollier. Willis Carrier rearranged the Mollier diagram for moist air to allow graphical solutions. Many variations and improvements to the Psychrometric charts have occurred since. ASHRAE now publishes what are considered the modern, standard Psychrometric charts, in both I-P and SI units, for a variety of elevations or air pressures.

slide-8
SLIDE 8

Clever that Carrier guy

slide-9
SLIDE 9

So really, what is Psychrometrics?

  • Study of Air / Water (Vapor) Mixture
slide-10
SLIDE 10

What is Air?

  • Mixture of Gases:
  • Nitrogen – 4 Parts
  • Oxygen – 1 Part
  • Other: Argon, Helium, Krypton, Xenon, Neon,

Carbon Dioxide. and

  • Water Vapor
slide-11
SLIDE 11

So Who Cares?

  • Reconsider the Components of Air:
slide-12
SLIDE 12

So Who Cares?

  • Reconsider the Components of Air:
  • Nitrogen
  • Oxygen
  • Noble Gases
  • Carbon Dioxide
slide-13
SLIDE 13

So Who Cares?

  • Reconsider the Components of Air:
  • Nitrogen
  • Oxygen
  • Noble Gases
  • Carbon Dioxide

Stable in Gas Phase.

slide-14
SLIDE 14

So Who Cares?

  • Reconsider the Components of Air:
  • Water Vapor
slide-15
SLIDE 15

So Who Cares?

  • Reconsider the Components of Air:
  • Nitrogen
  • Oxygen
  • Noble Gases
  • Carbon Dioxide

Stable in Gas Phase

  • Water Vapor

Phase Changes (liq./gas)

slide-16
SLIDE 16

If it’s Not the Heat, It’s the Humidity

slide-17
SLIDE 17

Psychrometric Chart

slide-18
SLIDE 18

Some Definitions

  • Sensible heat, or enthalpy of dry air, is heat

which manifests itself as a change in temperature.

  • Latent heat is the amount of energy in the

form of heat released or absorbed by a substance during a change of phase (i.e. solid, liquid, or gas), also called a phase transition

slide-19
SLIDE 19

Some Definitions

  • The total heat, or enthalpy, of the

atmosphere is the sum of the sensible heat, latent heat, and superheat of the vapor above the saturation or dew-point

  • temperature. Total heat is relatively

constant for a constant wet-bulb temperature, deviating only about 1.5–2% low at relative humidity's below 30%.

slide-20
SLIDE 20

Some Definitions

  • Dry Bulb Temperature
  • Temperature as read by regular (dry) thermometer.
slide-21
SLIDE 21

Dry Bulb

slide-22
SLIDE 22

Some Definitions

  • Wet Bulb Temperature
  • Temperature of air that has gone through an

adiabatic saturation process.

slide-23
SLIDE 23

Wet Bulb

slide-24
SLIDE 24

Some Definitions

  • Relative Humidity
  • The ratio of vapor pressure to saturation pressure.
slide-25
SLIDE 25

Relative Humidity

slide-26
SLIDE 26

Some Definitions

  • Specific Volume
  • cubic feet of air per lb. of air
slide-27
SLIDE 27

Specific Volume

slide-28
SLIDE 28

Some Definitions

  • Dew Point
  • Temperature at which moisture begins to condense

in a particular air / water vapor mixture.

  • This corresponds to the intersection of the wet-bulb

and the saturation curve.

slide-29
SLIDE 29

Dew Point

slide-30
SLIDE 30

Some Definitions

  • Humidity Ratio
  • The ratio of water vapor (mass) to total air (mass).
  • Can be expressed as lb (water) / lb (dry air), or

Gr (water) / lb (dry air).

slide-31
SLIDE 31

Humidity Ratio

slide-32
SLIDE 32

Relative Humidity vs. Humidity Ratio

slide-33
SLIDE 33

Some Definitions

  • Enthalpy
  • Total amount of energy contained in Air /

Water Mixture.

slide-34
SLIDE 34

Enthalpy

slide-35
SLIDE 35

Some Definitions

  • Sensible Heat Ratio
  • The ratio of sensible cooling to total cooling in

a space.

slide-36
SLIDE 36

Sensible Heat Ratio

slide-37
SLIDE 37
  • Adiabatic Saturation Process
  • Process follows lines of constant enthalpy/wet bulb.
  • Change occurs in: dry-bulb temperature, specific

volume, relative humidity, humidity ratio, dewpoint temperature, and vapor pressure of the moist air.

  • No change occurs in: wet-bulb temperature and

enthalpy

  • Representative of any process involving evaporation
  • Cooling Towers, Evaporative Cooling, Fog &

Ultrasonic Humidification, etc.

Some Definitions

slide-38
SLIDE 38

Adiabatic Saturation Process

slide-39
SLIDE 39

Useful Psychrometric Calculations - Air Mixing

  • Based on ratio of mass flows
  • Stream 1: 95 DB / 75 WB
  • Stream 2: 75 DB / 50% RH

V1=2,000 CFM, M1=137 LB/MIN V3=10,000 CFM, M3=704 LB/MIN V1=8,000 CFM, M1=567 LB/MIN

slide-40
SLIDE 40

Air Mixing - Mathematically

  • Plot both points on chart and connect with a line
  • Mixed air dry bulb =

(Stream 1 DB x Stream 1 CFM / Total CFM) + (Stream 2 DB x Stream 2 CFM / Total CFM)

  • Plot mixed air dry bulb on above referenced line

to calculate mixed air wet bulb

slide-41
SLIDE 41

Air Mixing - Measuring

slide-42
SLIDE 42

Sensible Heating / Cooling

  • Process line is horizontal on Psych. Chart.
  • Humidity Ratio does not change
  • Relative Humidity does change.
slide-43
SLIDE 43

Sensible Cooling

slide-44
SLIDE 44

Sensible Heating

slide-45
SLIDE 45

Total Cooling Cycle

  • Process line is horizontal & vertical on

Psychrometric Chart.

  • Humidity Ratio does change
  • Relative Humidity does change.
slide-46
SLIDE 46

Total Cooling Cycle

slide-47
SLIDE 47

Applications – Blow Through

  • Large VAV systems
  • High sensible loads
  • Higher efficiency requirements
  • Sound sensitive applications
slide-48
SLIDE 48

Blow Through

slide-49
SLIDE 49

Applications – Draw Through

  • Compact space requirements
  • High latent loads

– Pools – Underfloor or Displacement

  • Initial cost constraints
slide-50
SLIDE 50

Draw Through

slide-51
SLIDE 51

Applications – Heat Recovery

  • Anything above 30% OA
slide-52
SLIDE 52

Heat Wheel

slide-53
SLIDE 53

Heat Wheel – 33% OA

slide-54
SLIDE 54

Heat Pipe/Plate

slide-55
SLIDE 55

Heat Pipe/Plate – 33% OA

slide-56
SLIDE 56

Applications – Humidification

  • OR rooms
  • Laboratories
  • Wood / Printing
  • Adiabatic especially economical with

economizer systems

slide-57
SLIDE 57

Steam Humidification

slide-58
SLIDE 58

Adiabatic Humidification

slide-59
SLIDE 59

Steam Humidification @ Min OA

slide-60
SLIDE 60

Adiabatic Humidification @ Min OA

slide-61
SLIDE 61

Applications - Dehumidification

  • Desiccant best for < 40 DP
  • Mechanical best for > 40 DP
  • Ice Rinks
  • Swimming Pools
  • Surgery Suites
  • DOAS
  • VRF
  • Geothermal
  • Chilled Beam
  • Corridor Ventilation
slide-62
SLIDE 62

Mechanical Dehumidification

slide-63
SLIDE 63

Return Air Bypass

slide-64
SLIDE 64

Single Pipe/Plate HX

slide-65
SLIDE 65

Dual Wheel – Latent & Sensible

slide-66
SLIDE 66

Desiccant Dehumidification Pre-Cool

slide-67
SLIDE 67

Desiccant Dehumidification - Post-Cool

slide-68
SLIDE 68

Desiccant Dehumidification, Pre & Post-Cool

slide-69
SLIDE 69

Dual Wheel, Low Temp Regeneration Desiccant Dehumidification, Pre Cool

slide-70
SLIDE 70

Is this Dehumidified?

slide-71
SLIDE 71

Tight Temperature and Humidity Control

  • High SHR Equipment
  • Low SHR Equipment
slide-72
SLIDE 72

Reheat for SHR

slide-73
SLIDE 73

Conquer & Divide for SHR

slide-74
SLIDE 74

Conquer & Divide for SHR

slide-75
SLIDE 75

ASHRAE Data Sets

  • Nine Cooling Data Sets:
  • Presented as 0.4%, 1%, 2% Values.
  • DB/MCWB: Useful for Typical Mixed Air Cooling.
  • WB/MCDB: Useful for Adiabatic Saturation

Processes: Cooling Towers, Evaporative cooling

  • DP/MCDB: Highest moisture content of Outside
  • Air. Useful for De-humidification and 100%

Ventilation Systems.

slide-76
SLIDE 76

ASHRAE Data Sets

slide-77
SLIDE 77

Psychrometric Cheat Sheet

slide-78
SLIDE 78

Psychrometric Cheat Sheet

A – Humidify Only B – Heat & Humidify C – Sensible Heat Only D – Desiccant Dehumidify E – Dehumidify Only F – Cool & Dehumidify G – Sensible Cool Only H – Evaporative Cool

slide-79
SLIDE 79

Psychrometric Cheat Sheet

slide-80
SLIDE 80

How Can Jacco Help You?

  • Tight Temperature & Humidity Control
  • Low SHR Applications with Aaon, Munters,

Seasons 4 & Energy Labs

  • High SHR Applications with WaterFurnace,

Samsung, TROX, Beka & Whalen

  • Standard SHR Applications with Aaon
  • Humidification with MeeFog & Vapac
  • Dehumidification with Aaon, Munters,

Seasons 4 & Energy Labs

slide-81
SLIDE 81

Jerry Cohen President Jacco & Assoc.

Thank You
