POLARDB for MyRocks

Extending shared storage to MyRocks

Zhang, Yuan Alibaba Cloud Apr, 2018

MORE THAN JUST CLOUD

About me

• Yuan Zhang
• database engineer
• Work at Ailbaba for 5 years
• Focus on MySQL & MyRocks
• email：zhangyuan.zy@alibaba-inc.com

MORE THAN JUST CLOUD

Agenda

• Background
• Basic Architecture
• Implementation details
• Performance Improment
• Future plan

MORE THAN JUST CLOUD

Background

Why POLARDB for MyRocks

Benifits from MyRocks

• Greate space efficiency, better compression
• Greate write efficiency, lower write amplification
• Fast data loading
• Compatiable with MySQL

Benifits from share-storage(polarstore)

• Promising data consistency
• Ability to scale read node immediately without full copy of data

MyRocks + Polarstore

MORE THAN JUST CLOUD

Basic Architecture

Primary

• Accept Read/Write workload

Replica

• Only Accept Read workload
• Share sst/wal with primary

MORE THAN JUST CLOUD

Let’s Begin

prepare for rocksdb wal replication

• Base on AIiSQL5.7
• Port MyRocks from Facebook
• Only support RocksDB and MyISAM engine
• Convert system tables to RocksDB

MORE THAN JUST CLOUD

Convert system tables to RocksDB

Prepare for RocksDB WAL replication

• Convert system tables to RocksDB
• Except mysql.slow_log, mysql.general_log, they store in local disk,

primary and replica have their owen mysql.slow_log, mysql.general_log tables.

MORE THAN JUST CLOUD

Rocksdb WAL/Manifest replication

Architecture

MORE THAN JUST CLOUD

Rocksdb WAL/Manifest replication

Asynchronous replication

WAL Replication

• Replay PUT/DELETE/MERGE

Manifest Replicaion

• Replay flush & compaction

WAL and Manifest Coordination

• Only apply VEdit while Applied lsn > VEdit lsn

MORE THAN JUST CLOUD

Rocksdb WAL/Manifest replication

Control Primary WAL and SST files deletion

WAL deletion - original wal deletion will lead Replica lost wal

• Lm: min_log_number on Primary
• Ln: min_log_number on all Replicas
• new_min_log_number= min(Lm,Ln)
• When WAL’s number < new_min_log_number, then this WAL can be deleted

SST deletion- original SST deleteion will lead Replica cannot find SST and crash

• min_version_number: the minimal version number replica is using
• SST can be deleted only when It will’t be used by Primary and all Replicas

MORE THAN JUST CLOUD

DDL&Cache replication

Architecture

MORE THAN JUST CLOUD

DDL Replication

Remove frm,par files

Frm,par files

• Table metadata information
• If Master and replica share frm,par files, DDL replication must be synchronous

Remove frm,par files

• Store these contents in RocksDB
• Replica can read multi version of table schema
• DDL replication is asynchronous

MORE THAN JUST CLOUD

DDL Replication

Remove frm,par files

DDL replication is asynchronous

• Multiple Table schema version in rocksdb
• Row data also have different verisions

MORE THAN JUST CLOUD

DDL Replication

Primary

• Log MDL lock start and end.

Replica

• Replay MDL lock start
• A. lock MDL
• Replay MDL lock end
• A. update table cache in myrocks
• B. unlock MDL

We have MDL lock to protect DDL operation in Primary. This lock also need in Replica’s DDL.

MORE THAN JUST CLOUD

Cache Replication

ACL, Procedure, Query cache Replicaition

Primary

• Log cache change in RocksDB WAL

ACL, Procedure Replica

• Replay this change from WAL and invaild this cache

MORE THAN JUST CLOUD

Index Statistics Replication

Persistent

• Part index statistics information persist in each SST
• Total index statistics store in INDEX_STATISTICS

Memory

• Rdb_dey_def::m_stats

Update

• Analyze table
• Flush memtable
• Compact


Replica listen PUT operation in INDEX_STATISTICS and reload statistic info to memory.

MORE THAN JUST CLOUD

New Log Format

log change for replication

Log Types

• DDL(START, END)
• Cache change, ACL/Proc

Log format

• PUT/DELETE

Log store location

• __system__ column family

MORE THAN JUST CLOUD

New Log Format

New type in data dictionary

// Data dictionary types enum DATA_DICT_TYPE { DDL_ENTRY_INDEX_START_NUMBER = 1, INDEX_INFO = 2, CF_DEFINITION = 3, BINLOG_INFO_INDEX_NUMBER = 4, DDL_DROP_INDEX_ONGOING = 5, INDEX_STATISTICS = 6, MAX_INDEX_ID = 7, DDL_CREATE_INDEX_ONGOING = 8,

POLAR_LOG = 100, // for polar replication

END_DICT_INDEX_ID = 255 };

enum POLAR_LOG_TYPE { TABLE_DDL = 1, CACHE_CHANGE = 2, …… END_POLAR_ROCK_TYPE = 255 };

MORE THAN JUST CLOUD

New Log Format

New type in data dictionary

DDL_START

• type: PUT
• key: POLAR_LOG+TABLE_DDL+dbname.tablename
• value: NULL

DDL_END

• type: DELETE
• key: POLAR_LOG+TABLE_DDL+dbname.tablename
• value: NULL

CACHE_CHANGE

• type: PUT
• key: POLAR_LOG+CACHE_CHANGE+ACL/Proc
• value: NULL

MORE THAN JUST CLOUD

New Log Format

Problems

DDL_START

• type: PUT
• key: POLAR_LOG+TABLE_DDL+dbname.tablename
• value: NULL

DDL_END

• type: DELETE
• key: POLAR_LOG+TABLE_DDL+dbname.tablename
• value: NULL

DDL_START and DDL_END must be a pair.

Problem 1: Primary Crash

• Primary crash after DDL_START, Primary will

resent DDL_START when restart, and the previous DDL_END will lost.

• Replica replay DDL_START and hold MDL lock, It

will not unlock with DDL_END


MORE THAN JUST CLOUD

New Log Format

Problems DDL_START and DDL_END must be a pair.

Problem 1: Primary Crash

• Primary crash after DDL_START, Primary will

resent DDL_START when restart, and the previous DDL_END will lost.

• Replica replay DDL_START and hold MDL lock, It

will not unlock with DDL_END

Solution

• Primary Scan RocksDB to find record TABLE_DDL

when restart, if found, Primary should resent DDL_END, and Replica will unlock the old lock

MORE THAN JUST CLOUD

New Log Format

Problems DDL_START and DDL_END must be a pair.

Problem 2: Replica Crash

• Replica carsh after DDL_START, Replica will

continue to replay DDL_END when restart

• But the lock with DDL_START will not exist after

restart, Replica replay DDL_END to unlock a MDL lock which is not exist


MORE THAN JUST CLOUD

New Log Format

Problems DDL_START and DDL_END must be a pair.

Problem 2: Replica Crash

• Replica carsh after DDL_START, Replica will

continue to replay DDL_END when restart

• But the lock with DDL_START will not exist after

restart, Replica replay DDL_END to unlock a MDL lock which is not exist


 Solution

• Replica Scan RocksDB to find record TABLE_DDL

when restart, if found, Replica should replay DDL_START to lock

MORE THAN JUST CLOUD

MVCC

MVCC based on RocksDB snapshot

Control compact in Primary

• Compact in Primary should consider about Replica’s snapshot
• Only delete record when sequnce >=Sn, Sn is the laste seqence in Replica
• Primary’s snapshot list merge with replica’ s snapshot list.

Keep a consistent snapshot in Replica

• Replica can’t get the record after Primary compact

MORE THAN JUST CLOUD

MVCC

MVCC based on RocksDB snapshot

Keep a consistent snapshot in Replica

MORE THAN JUST CLOUD

Performance Improment

Optimize write performance

• Async-commit
• Optimize auto_increment

MORE THAN JUST CLOUD

Performance Improment

Async-commit

Original pipeline write

MORE THAN JUST CLOUD

Performance Improment

Async-commit

Async-commit

MORE THAN JUST CLOUD

Performance Improment

Optimize write performance

Optimize auto_increment

• write need check unique
• Do Get first then write
• Get is expensive

Actually, most auto_increment check uniqueness is not necessary. Espacially, when all the auto_incment column is automatically generated.

MORE THAN JUST CLOUD

Performance Improment

Optimize write performance

Optimize auto_increment

• max_specify_pk: user sepcified max auto_increment value
• if pk > max_specify_pk, skip unique check
• if pk <= max_specify_pk nead unique check

max_specify_pk update when user use sepcified auto_increment value

MORE THAN JUST CLOUD

Future

Feature

• Online DDL
• Multiple-Master

Performance

• Compaction optimize

MORE THAN JUST CLOUD

Q&A
