Pier 4 Phase 1 Removal Action Prebid Meeting Relocate Navigation BLAIR WATERWAY Lights Existing Pier 4 Pier 3 Future Pier 4 Reconfiguration Existing wharf deck to remain PARTIAL WHARF DEMOLITION Dredge 49,000 CY BLAIR WATERWAY

SLIDE 1

Pier 4 Phase 1 Removal Action Prebid Meeting

SLIDE 2

PARTIAL WHARF DEMOLITION

Future Pier 4 Reconfiguration Existing wharf deck to remain Relocate Navigation Lights Existing Pier 4

BLAIR WATERWAY

Pier 3

SLIDE 3

DREDGING & DISPOSAL OF TBT MATERIAL

Future Pier 4 Reconfiguration Dredge 49,000 CY contaminated material

BLAIR WATERWAY

Pier 3

Dredge 9,000 CY clean material Central Hot Spot Southern Hot Spot

SLIDE 4

Pier 3 Pier 4 APM TERMINALS Transload Site

SLIDE 5

SLIDE 6
