PICNet CONFERENCE 2013 S COPING THE HORIZON Penny Brawn

THE ORIGINAL STEAM STERILIZERS

ORIGINAL STEAM STERILIZER

A LITTLE HISTORY  Back in 1450 BC in Moses time, writings were found in books of Leviticus involving purification of materials by fire and boiling water.  In 460 – 377BC Hippocrates poured boiling water on surgical instruments to clean them.  In 1729 – 1799 Italian Biologist Lazzaro S pallanzani discovered it took 30 minutes to kill bacteria by heating them in glass flasks

HISTORY Cont… ..  1880’ s Louis Pasteur also showed that once a medium is sterilized it will remain sterilized until introduced to micro organisms. S imple boiling to 100C was not totally effective because it did not kill all spores, but he learned that by increasing the pressure by 15pounds, then the water will boil at 121Deg C. This did kill all life forms in 15 minutes or less.

HISTORY Cont…  Current design of the autoclave was largely finalized in 1880 by Charles Chamberland, a colleague of Pasteur’ s  1681 Denis Papin a physicist invented the steam engine but he also invented a steam pressure cooker… an early version of the autoclave.

AUTOCLAVE  Why is it called an Autoclave? Descibes a device that automatically locks shut when the pressure rises. The word is French, but comes from the Greek “ auto “ for automatic and the Latin “ clvis “ for key. (as in lock and key)

REPROCESSING FOR SMALL FACILITIES  Rural Health Care ( clinics/ diagnost ic & treatment centres )  Personal Care S ervices ( foot care )  Dental Offices  Dr’ s Offices  Tattoo Establishment s

REPROCESSING  Problems around reprocessing:  Lack of standards  Lack of training/ knowledge for staff  Lack of a proper reprocessing area  Lack of Manufacturer’ s Instructions for reprocessing - instruments and sterilizer  Little or no monitoring

STANDARDS FOR TABLE TOP STERILIZERS What S tandards?  2011 Ministry of Health, Best Practice Guidelines for Cleaning, Disinfection and S terilization in Health Authorities  CS A S tandards Z314.3-09 Effective S terilization in Healthcare Facilities by the S team Process  CS A S tandards Z314.8-08 Decontamination or Reusable Medical Devices  ANS I/ AAMI S T55:2010 Table Top S team S terilizers

HOSPITAL ACQUIRED INFECTIONS  In Canada, 220,000 people acquire HAI’ s every year  Over 8,000 DIE!  HAI’ s cause needles human suffering, resulting in huge financial burden (Dr Dick Zoutman MD FRCPC Professor Microbiology & Infectious Diseases Queens University)

HOSPITAL ACQUIRED INFECTIONS  The cost to treat 1 individual with MRS A is estimated to be in excess of $8,000 to $10,000 Canadian

WORDS OF WISDOM  Proper cleaning is the FIRS T step in the sterilization process  S terilization does NOT occur by magic!  It takes people, process knowledge, commitment, and technical information.

REPROCESSING MEDICAL DEVICES  Decontaminat ion is the 1 st most important step  Always wear PPE!  Disassemble any instruments  Use fresh enzymatic detergent in warm water.  Allow this detergent the appropriate time to do it’ s j ob!  Brush under the level of the water.

REPROCESSING MEDICAL DEVICES  Rinse thoroughly  Lubricate if necessary with a water soluble lubricant  Assemble and wrap the sets or single instruments  Prepare for sterilization

TABLE TOP STERILIZER/AUTOCLAVE Pressure Vessel : sealed cavity capable of withstanding internal pressure above atmospheric pressure

TABLE TOP STERILIZER  S terilizer  Apparatus used to sterilize medical devices by direct exposure to a sterilizing agent  Usually saturated steam under pressure

TABLE TOP STERILIZER  A table top steam sterilizer is defined as:  A compact steam sterilizer that has a chamber volume of not more than 2 cubic feet.  Generates it’ s own steam when distilled or de-ionized water is added to a reservoir by the user!

TABLE TOP STERILIZER  Always follow manufactures instructions on how to use the sterilizer.  Make sure policies and procedures are in place  S taff must be trained prior to using the sterilizer

TABLE TOP STERILIZER  Packaging: – Lubricate device with a water soluble lubricant so steam will penetrate – Do not assemble devices – S elect appropriate packaging – Medical grade and seal appropriately – Use an appropriate Chemical Indicator such as a class 4 inside each package – Label package with a non toxic permanent marking pen on the plastic side of a peel pouch. Not paper side. – Date, name of device or set, signature etc.

DISPOSABLE POUCHES

DISPOSABLE WRAP

CLASS 4 CHEMICAL INDICATOR  S ample of the Class 4 Chemical Indicator multi variable (reacting to two critical parameters e.g. time & temp)

TABLE TOP STERILIZER  Check the level of the water in the reservoir. Use distilled or de-ionized water  List the items going into the chamber for your records  Load devices according to manufacturer’ s recommendations… … stand peel pouches on their side, bowls on their side or upside down, trays should be on their side unless they have holes in

TABLE TOP STERILIZER NO, NO, NO,… … NEVER DO THIS !

TABLE TOP STERILIZER  Position a Biological Indicator according to manufacturer’ s instructions (usually in the center of the load) with a Chemical Indicator Class 5  Packages should not touch the chamber walls  S elect the correct cycle

BIOLOGICAL INDICATOR

TABLE TOP STERILIZERS Program/Load Temperature Time BI 270 ° F-274 ° F Unwrapped inst rument s on a 3 BI in unwrapped (132 ° C-135 ° C) t ray or glassware Minut es t ray 270 ° F-274 ° F Wrapped t ray of inst rument s or 4-5 BI in wrapped (132 ° C-135 ° C) individually wrapped Minut es t ray or pouch & include porous it ems 250 ° F (121 ° C ) Packs, wrapped 30 BI in wrapped Minut es pack t hat is representat ive of t he load 250 ° F (121 ° C ) Liquids 15 BI suspended Minut es above a t est cont ainer of t he load

TABLE TOP STERILIZERS  When cycle is complete – Verify the cycle parameters  Exposure Time  Temperature  Pressure This is found on the printout and sign it.

TABLE TOP STERILIZERS  Vent the steam  Ensure the pressure has returned to zero  Crack the door and wait for the steam to escape  Leave the load in the sterilizer to cool and dry before removing the load.  Verify the Chemical Indicator has turned correctly  Incubate the Biological Indicator as per manufacturer’ s instructions

TABLE TOP STERILIZER  No evidence of moisture is acceptable  Chemical indicator must have changed colour  Incubate Biological Indicator, a negative result is required.  Observe packaging for burn marks and moisture spots  Complete documentat ion as required.

STEAM STERILIZATION ACHIEVED  To prove you have achieved sterilization you need – The print out – permanent record – keep for the life of the machine! – The Biological Indicator – Negative result – The Chemical Indicator Class 3 or Class 4 – to show steam has penetrated inside your bundles.

STORAGE OF STERILE PACKAGES  S torage of sterile devices – When packages are completely dry store in a clean environment  In a closed cupboard,  On a clean wire shelf in washable containers.

TABLE TOP STERILIZER QUES TIONS ? Thank you!
