Phased Transactional Memory Dan Nussbaum Scalable Synchronization Research Group Joint work with Yossi Lev and Mark Moir Sun Microsystems Labs August 16, 2007 1 1 Transactional Memory (TM) Replace locks with atomic sections.

slide-1
SLIDE 1

1

Dan Nussbaum Scalable Synchronization Research Group Joint work with Yossi Lev and Mark Moir Sun Microsystems Labs August 16, 2007

Phased Transactional Memory

1

slide-2
SLIDE 2

Su n C

  • n

fiden t ial: I n t er n al O n ly

2

Transactional Memory (TM)

  • Replace locks with atomic sections.
  • (Word-based.)
  • Hardware or Software?

> Software (STM) is cheaper and more flexible. > Hardware (HTM) is faster.

  • Hybrid Transactional Memory (HyTM) gets best of

both worlds.

> Common case in hardware -- fast. > Uncommon case in software – correct. > Make effective use of best-effort hardware (Rock).

slide-3
SLIDE 3

Su n C

  • n

fiden t ial: I n t er n al O n ly

3

Hybrid Transactional Memory (HyTM)

  • HyTM approach: compiler plus library.
  • Two code paths:

> Hardware path attempts to use transactional hardware.

–Fast. –Transactions don't always succed:

– Resource limitations. – “Difficult” instructions. – Contention.

> Software path contains calls into an STM library.

–Slower. –Take this path whenever the hardware comes up short.

slide-4
SLIDE 4

Su n C

  • n

fiden t ial: I n t er n al O n ly

4

HyTM: Instrument Hardware Path

  • Problem: TM hardware unaware of software txns.
  • Solution: make hardware transactions aware of

software transactions, by augmenting hardware path:

txn_begin; if(!canHardwareRead(&X)) txn_abort; Y = X + 5; ==> tmp = X; if(!canHardwareWrite(&Y)) txn_abort; Y = tmp + 5; txn_end;

slide-5
SLIDE 5

Su n C

  • n

fiden t ial: I n t er n al O n ly

5

Phased Transactional Memory

  • Arrange to only be executing in a single mode at a

time, system-wide.

> HARDWARE, SOFTWARE, (others).

  • Partition time into phases.
  • When in HARDWARE mode, use the hardware path.

> Don't have to allow for concurrent execution of software

transactions: minimal overhead.

  • When in SOFTWARE mode, use the software path.

> Don't have to allow for concurrent execution of hardware

transactions: fewer constraints on STM.

slide-6
SLIDE 6

Su n C

  • n

fiden t ial: I n t er n al O n ly

6

PhTM Prototype: Mode Transitions

  • Start out in HARDWARE mode, until some transaction (T)

has to run in software.

  • Switch to SOFTWARE mode, making sure that no

hardware transactions are still running.

  • Run in SOFTWARE mode for a while.

> Allow other transactions to start up in SOFTWARE mode.

  • Switch back to HARDWARE mode.
slide-7
SLIDE 7

Su n C

  • n

fiden t ial: I n t er n al O n ly

7

if (FirstTryInHardware()) { HW: chkpt(F); HWPostCheckpoint(); <== if (mode != HARDWARE) fail; <body> commit(); } else { while (!<try body with STM>) { F: if (!RetryInSoftware()) goto HW; } }

PhTM Prototype: Schema

slide-8
SLIDE 8

Su n C

  • n

fiden t ial: I n t er n al O n ly

8

Experimental Set-Up

  • STM-only experiments: E25K.

> Big (144-core) SMP.

  • Transactional hardware: simulator.

> Wisconsin GEMS/ruby/LogTM (Simics-based). > Modified LogTM to better reflect best-effort constraints.

slide-9
SLIDE 9

Su n C

  • n

fiden t ial: I n t er n al O n ly

9

Benchmarks

  • Transactified Berkeley DB Lock subsystem.

> Every thread repeatedly locks and unlocks its own object. > Ought to scale perfectly.

  • Red-Black Tree.

> Tree is half full. > 20% inserts, 20% deletes, 60% lookups. > On larger machines, contention is significant.

slide-10
SLIDE 10

Su n C

  • n

fiden t ial: I n t er n al O n ly

10

Berkeley DB: STM-only

slide-11
SLIDE 11

Su n C

  • n

fiden t ial: I n t er n al O n ly

11

Berkeley DB: Simulations

slide-12
SLIDE 12

Su n C

  • n

fiden t ial: I n t er n al O n ly

12

RedBlackTree: STM-only

slide-13
SLIDE 13

Su n C

  • n

fiden t ial: I n t er n al O n ly

13

RedBlackTree: Simulations

slide-14
SLIDE 14

Su n C

  • n

fiden t ial: I n t er n al O n ly

14

Conclusions

  • First-cut PhTM implementation already performs

pretty well.

> TL2 looks like best choice for PhTM's software phase.

  • With a bit more work, we hope to close the gap

between PhTM and pure hardware even further.

slide-15
SLIDE 15

Su n C

  • n

fiden t ial: I n t er n al O n ly

15

Future Work

  • Performance Improvements.

> Improve phase management strategy. > Improve contention control strategy. > Inline more of the fast path. > Compiler optimizations.

  • More than just two (HARDWARE, SOFTWARE) modes.

> Requires a more generalized approach (see paper).

> HYBRID mode. > SEQUENTIAL mode.

slide-16
SLIDE 16

Su n C

  • n

fiden t ial: I n t er n al O n ly

16

References

  • HyTM Paper (ASPLOS 2006)

> http://research.sun.com/scalable/pubs/ASPLOS2006.pdf

  • TL2 Paper (DISC 2006)

> http://research.sun.com/scalable/pubs/DISC2006.pdf

slide-17
SLIDE 17

Su n C

  • n

fiden t ial: I n t er n al O n ly

17

Acknowledgements

  • Dave Dice and Nir Shavit (TL2).
  • Brian Whitney (E25K).
  • Peter Damron (Compiler).
  • Sasha Fedorova and Victor Luchangco

(Discussions).

  • Kevin Moore (Simulator).
slide-18
SLIDE 18

18

Yossi Lev, Mark Moir and Dan Nussbaum yosef.lev@sun.com mark.moir@sun.com daniel.nussbaum@sun.com

18

slide-19
SLIDE 19

Su n C

  • n

fiden t ial: I n t er n al O n ly

19

PhTM Prototype: Mode Transitions (2)

ModeIndicator = <mode, deferredCount, undeferredCount>

  • Transactions waiting to run in SOFTWARE mode increment
  • deferredCount. Eventually one of them sets mode=SOFTWARE.
  • Transactions that come into being when mode==SOFTWARE and

deferredCount>0 increment undeferredCount and then run in

software.

  • Transactions that come into being when mode==SOFTWARE and

deferredCount==0 wait for mode to change to HARDWARE.

  • All software transactions decrement appropriate count after

they commit. The last of these sees deferredCount==0 &&

undeferredCount==0, and sets mode=HARDWARE.

slide-20
SLIDE 20

Su n C

  • n

fiden t ial: I n t er n al O n ly

20

PhTM: Generalized Approach

  • Many possible modes.

> HARDWARE, SOFTWARE, HYBRID, SEQUENTIAL, ...

  • Managing transitions between modes.

> No interference between one phase and the next. > When to switch; which mode to switch to?

slide-21
SLIDE 21

Su n C

  • n

fiden t ial: I n t er n al O n ly

21

PhTM: Generalized Approach (cont.)

  • ModeIndicator=<mode, mustFinishThis, otherTxns,

nextMode, mustFinishNext, version>

  • Collect candidates for next mode.

NextMode=<next Mode>; mustFinishNext++

  • Mode Transition

> Only OK when mustFinishThis==0 && otherTxns==0

mode=nextMode; nextMode=NONE; mustFinishThis=mustFinishNext; mustFinishNext=0; version++;
