PETS components and waveguide PETS components and waveguide connections CLIC W CLIC Workshop 2007 k h 2007 David Carrillo Index A design to connect PETS with accelerating structures will be discussed choke flange And also we will deal


  1. PETS components and waveguide PETS components and waveguide connections CLIC W CLIC Workshop 2007 k h 2007 David Carrillo

  2. Index A design to connect PETS with accelerating structures will be discussed � choke flange And also we will deal with two components for testing the PETS � Input coupler p p � Single test bar device David Carrillo CIEMAT

  3. Choke flange X-band This device allows power transmission without electrical contact � between waveguides Motivation : During the CLIC operation the two linacs (drive and main) M ti ti D i th CLIC ti th t li (d i d i ) � will have independent alignment. That is why the development of the special device which transfer power without mechanical contact from PETS to accelerating structures is important PETS to accelerating structures is important Schematic layout of independent alignment of the two David Carrillo CIEMAT linacs with the fixed RF phase

  4. Choke flange It consists of a transition from rectangular to circular waveguide � In between there is a choke that stop electromagnetic energy to flow � outwards and provide full transmission of energy to the other port t d d id f ll t i i f t th th t This device is flexible and provides a place to produce vacuum inside � the waveguide Being equipped with outside bellow it will provide the range of the � possible transverse orientations of the two waveguides 3D solid view of quarter of choke flange David Carrillo CIEMAT

  5. Choke flange es (dB) ation mode Electric field complex p e) and radia magnitude S11(blue Frequency (GHz) It It is i necessary t to minimize i i i reflection fl ti and d E magnitude radiation through the choke. Also there is a It will be tested at SLAC at compromise between length and E field on the nominal power of 135/2 MW (E p ( surface. Device has been designed as short as surface. Device has been designed as short as field on surface < 30 MV/m possible David Carrillo CIEMAT

  6. Choke flange. Shifts & twist � Shifts in different directions and twists are simulated in order to study the device performance X-shift 0 x z 20 0.3 mm 0.5 mm y S11 (dB) 40 S 0.2 60 0.0 80 11.6 11.8 12 12.2 12.4 Frequency (GHz) Coordinate axis x-shift appears to be the x shift appears to be the most critical displacement issue David Carrillo CIEMAT

  7. Choke flange. Shifts & twist Z-shift 0 12 Dynamic range for the accepted 0 5 mm 0.5 mm 20 performance (S11< -45 dB) f (S11< 45 dB) S11 (dB) Twist X – shift: ± 0.25 mm 0 12 40 40 − -0.5 mm Y – shift: ± 0.5 mm 20 60 Z – shift: ± 0.5 mm Twist: < 5 0 40 40 − 80 11.6 11.8 12 12.2 12.4 3 0 Y-shift 0 0 60 12 5 0 20 80 (dB) 11.6 11.8 12 12.2 12.4 Frequency (GHz) q y ( ) S11 40 40 − x, y shifts do not change the 0.5 mm 60 transmitted RF phase 80 11.6 11.8 12 12.2 12.4 Frequency (GHz) David Carrillo CIEMAT

  8. Mode launcher � Inside the PETS, electrons are decelerated and they produce mode TM 01 . In order to measure PETS RF quality this mode must be put into the PETS by the mode launcher (coupler) � The input signal is the fundamental one (TE 10 mode) in the rectangular waveguide which is transformed into the TM 01 (not f fundamental) in the circular waveguide d t l) i th i l id David Carrillo CIEMAT

  9. Mode launcher S 11 S12 (TE 11 ) S12 (TE 11 ) Frequency (GHz) Not only reflection must It is designed for low Electric field complex be minimized but also be minimized but also power tests t t magnitude transmission to TE 11 David Carrillo CIEMAT

  10. Mode launcher � Two couplers will be built to provide low power RF measurements � The number of measures will be done: Test the couplers themselves – Measure S parameters with extractor/or both couplers Measure S parameters with extractor/or both couplers – – Measure phase-advance between PETS cells – Mode Power PETS PETS launcher Extractor David Carrillo CIEMAT

  11. Testing single PETS bar A device has been designed to do RF tests of the single PETS bar � It consists of two side blocks that will be put together with a single PETS � bar in order to create inside a mode (TE 10 ) with same phase advance, v g , b i d t t i id d (TE ) ith h d etc as the decelerating mode (TM 01 ) PETS Single bar PETS Single bar Phase/period=90 Frequency =11.994 GHz V / Vg/c=0.466 0 466 Mode TE 10 David Carrillo CIEMAT

  12. Testing single PETS bar Full assembly y simulation PETS bar + 2 side PETS bar + 2 side wr90 blocks taper David Carrillo CIEMAT

  13. Testing single PETS bar Without this device, all single bars must be put together (8 bars), and it � can only be measured performance of the whole PETS as can be seen y p in the following picture With the single test bar device, a defective bar could be found (if we � ever get one ☺ ) It would be possible as well to know specifically which ever get one ☺ ) It would be possible as well to know specifically which is wrong with the bar (matching cells, shape profile, etc) David Carrillo CIEMAT

  14. Conclusions � A Choke flange design has been done, which will allow a flexible connection between PETS and accelerating structures and also will provide a vacuum port � Single bar test device will allow us to measure RF quality of single bars before putting all together � Mode launcher designed will be used to introduce and extract power in order to test phase-shift and S parameters for PETS power in order to test phase shift and S parameters for PETS David Carrillo CIEMAT
