Perceptrons

2-29-16

• A NN is a directed acyclic graph.
• Nodes are organized into layers.
• Consecutive layers are fully connected.
• Edges have a weight.
• Nodes have activation functions.

Other topologies are possible:

• sparser inter-layer connectivity
• edges within layers
• edges jumping layers

What is a neural network?

input layer hidden layer(s)

• utput layer
• 0.5

0.2 0.8

• 1.2

3.0 0.1 1.5 2.7

• 0.3
• 1.6

0.4

• 1.0

connection weights activation functions

• 0.5

0.8 3.0

What does a neural network compute?

Each node computes the weighted sum of its inputs.

• .5 * 1.2 + .8 * -.8 + 3 * .4 = -.04

This sum is then passed through the node’s activation function. f(x) = 1 / (1 + e-x) = 1 / (1 + e.04) ≈ .49 This output is passed on to the next layer.

1.2

• 0.8

0.4

Exercise: finish feeding values through the network.

Sigmoid activation function: Threshold activation function:

1.2

• 0.8

0.4

• 0.5

0.2 0.8

• 1.2

3.0 0.1 1.5 2.7

• 0.3
• 1.6

0.4

• 1.0

What type of learning problem is this?

Supervised or unsupervised?

• We’ll be studying neural nets for supervised learning.
• They can also be used for unsupervised learning.

Classification or regression?

• Depends on the output units:

○ Discrete-valued output units for classification. ○ Continuous-valued output units for regression.

What is the hypothesis space?

Unspecified parameters:

• Network topology

○ Number of hidden layers ○ Size of each hidden layer ○ Connectivity of hidden layers

• Activation functions
• Edge weights

typically hand-picked typically learned

What is a perceptron?

A perceptron is a 2-layer neural network.

• Only input & output; no hidden units.

All activation functions are thresholds.

• Threshold at 0.

One input is a constant 1.

• 0.5

0.2 0.8

• 1.2

3.0 0.1

1

Perceptrons represent a decision surface

• 0.5

0.8 3.0

1 x1 x2

Linear separability

Perceptrons can only classify linearly separable data.

Our task: learn perceptron weights from data.

Key idea: loop through the training data and update weights when wrong. while any training example is misclassified: for each training example:

• utput = run example through the network

for each node i in the output: if output[i] != target[i]: for each input weight w_j to node i: w_j = w_j + Delta(w_j) Delta(w_j) = learning_rate * (target[j] - output[j]) * example[j]

Example: learn AND

AND( 0 , 0 ) = 0 AND( 0 , 1 ) = 0 AND( 1 , 0 ) = 0 AND( 1 , 1 ) = 1

Exercise: learn OR

OR( 0 , 0 ) = 0 OR( 0 , 1 ) = 1 OR( 1 , 0 ) = 1 OR( 1 , 1 ) = 1

We can compose perceptrons like logic gates.

• We can represent AND, OR, and NOT with perceptrons.
• By composing these, we can make multi-layer networks.
• AND, OR, and NOT constitute a universal gate set, so we

can make any boolean function by combining perceptrons. In fact, we can represent any boolean function with a 2-layer perceptron.
