PeeringDB Arnold Nipper arnold@peeringdb.com 2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 1 Agenda PeeringDB 2.0 Membership and Governance Committees Sponsorship Information and Resources 2017-02-28 Apricot 2017,

slide-1
SLIDE 1

PeeringDB

Arnold Nipper arnold@peeringdb.com

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 1

slide-2
SLIDE 2

Agenda

  • PeeringDB 2.0
  • Membership and Governance
  • Committees
  • Sponsorship
  • Information and Resources

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 2

slide-3
SLIDE 3

What is PeeringDB?

  • PeeringDB is the database of peering information on the Internet
  • Contains peering location and contact information for
  • Networks
  • Exchanges
  • Facilities
  • A PeeringDB record makes it easy for people to find you, and helps you to

establish peering

  • If you aren’t registered in PeeringDB, you can register at

https://www.peeringdb.com/register

  • We use basic verification for new accounts and require current whois

information

  • Please update your whois information
  • Please register from a company email address

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 3

slide-4
SLIDE 4

PeeringDB 2.0 is Here!

  • PeeringDB 2.0 launched 15 March, 2016
  • Backend database (1.0) discontinued simultaneously
  • Last legacy SQL dump for public consumption:

https://peeringdb.com/v1/dbexport/peeringdb.sql

  • Investigating 404s for old SQL to contact users
  • Questions to support@peeringdb.com
  • Challenges during the launch
  • Very minor bug fixes required, but overall a success!
  • Lots of support tickets
  • 20C (developer contractor) very responsive to community - thanks!
  • Current release: 2.0.14

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 4

slide-5
SLIDE 5

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 5

slide-6
SLIDE 6

Key New Infrastructure Features

  • Complete rewrite in Python
  • Python: fast and clean, widely used and supported
  • HTML5: adaptive design for desktop and mobile
  • Support for a multideveloper environment
  • Redesigned schema with data validation
  • All data is permissioned and editable
  • Input validation on fields: IP addresses, email addresses, etc.
  • Validation in PeeringDB record: dropdown box to select ASN at exchange
  • Data versioning
  • Revision history for every data change
  • Easy to restore and roll back
  • Historical data import from CAIDA going back to 2010 (not available yet)
  • RESTful API
  • Stateless
  • Incremental database syncs
  • With documentation and tools, oh my!

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 6

slide-7
SLIDE 7

Key New User Features

  • Facilities and exchanges can now update their own info
  • Networks are still required to associate their record at a facility or exchange
  • Multiple records of any type can be associated with an organization
  • Simpler organization management with a single account for network, facility, exchange records
  • One account can manage multiple organizations
  • Manage all of the things with a single account
  • Users can manage their accounts
  • Admin account for an organization can delegate fine-grained permissions
  • Contact info has permissions
  • Private/users/public permissions
  • All users must register, no more guest account
  • Public view can see all info except contact info (no login needed)
  • APIs and local database sync
  • Sync PeeringDB to a local database in any engine format

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 7

slide-8
SLIDE 8

RESTful API Designed for Automation

  • All operations are supported and are designed to be automated
  • Read
  • Create
  • Update
  • Delete
  • Each object type has an associated tag
  • org
  • net
  • ix
  • fac
  • List of objects: https://peeringdb.com/apidocs/
  • API documentation: http://docs.peeringdb.com/api_specs/

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 8

slide-9
SLIDE 9

Quick Examples Return Output in JSON

  • List all networks: curl -X GET

https://<username>:<password>@www.peeringdb.com/api/net

  • Show a specific network: curl -X GET

https://<username>:<password>@www.peeringdb.com/api/net/20

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 9

{"meta": {}, "data": [{"id": 20, "org_id": 10356, "org": {"id": 10356, "name": "20C", "website": "http://20c.com", "notes": "", "net_set": [20], "fac_set": [], "ix_set": [], "address1": "", "address2": "", "city": "Chicago", "country": "US", "state": "IL", "zipcode": "", "created": "2014-11-17T14:59:34Z", "updated": "2016-03-23T20:39:18Z", "status": "ok"}, "name": "20C", "aka": "", "website": "http://20c.com", "asn": 63311, " ... }

slide-10
SLIDE 10

Local Database Sync

  • Database sync gives you a local copy of PeeringDB for customization
  • r internal use
  • Sync as often as you like
  • Incremental sync is supported
  • Improves performance and reduces load on PeeringDB servers
  • Build custom indexes and interfaces
  • Add custom fields
  • Choice of database engines
  • Currently supported: MySQL, Postgres, SQLite
  • Sync using the provided tools or build your own using the API

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 10

slide-11
SLIDE 11

Django Library

  • django-peeringdb is a Django library with a local PeeringDB database

sync

  • Defines the database schema to create a local database copy
  • Easy to integrate in a common framework for locals tools and custom

interfaces

  • Supports multiple database engines (MySQL, Postgres, SQLite)
  • Available at http://peeringdb.github.io/django-peeringdb/

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 11

slide-12
SLIDE 12

Python Client

  • peeringdb-py is a Python client for PeeringDB
  • Gets objects and outputs in JSON or YAML format
  • Provides a whois-like display of records
  • Integrated local database sync
  • Python library for integration with custom tools
  • Available at http://peeringdb.github.io/peeringdb-py/
  • Examples at https://github.com/grizz/pdb-examples

2017-02-28 12 Apricot 2017, Ho Chi Minh City, Viet Nam

slide-13
SLIDE 13

Status Page

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 13

http://status.peeringdb.com/

slide-14
SLIDE 14

Beta Development and Reporting Issues

  • Beta server
  • Available at https://beta.peeringdb.com/
  • Runs the latest beta software version
  • Full access over HTTP and the API
  • Database is local to the beta server only, changes are not reflected on the

production servers

  • Latest changes
  • Available at https://beta.peeringdb.com/changes
  • Redirects to the list of issues on GitHub
  • Documents all of the changes in the current beta version
  • Log bugs and feature requests at

https://github.com/peeringdb/peeringdb/issues on GitHub

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 14

slide-15
SLIDE 15

Agenda

  • PeeringDB 2.0
  • Membership and Governance
  • Committees
  • Sponsorship
  • Information and Resources

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 15

slide-16
SLIDE 16

Membership and Governance

  • PeeringDB organization formally formed 16 Dec, 2015
  • PeeringDB 501(c)(6) filed 7 Jan, 2016 (approved 24 Feb, 2016)
  • 2nd election held April 2016: 94 organizations registered, 80 voted
  • 3rd election scheduled for April 2017
  • 299 addresses subscribed to the Governance mailing list (as of 17 Oct 2016)
  • A corporation, limited liability company, partnership or other legal business

entity may be a Member of the Corporation. Membership is determined by having both an active PeeringDB.com account and an individual representative

  • r role subscription to the PeeringDB Governance mailing list:
  • http://lists.peeringdb.com/cgi-bin/mailman/listinfo/pdb-gov
  • More information available at http://gov.peeringdb.com/

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 16

slide-17
SLIDE 17

Board of Directors and Officers

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 17

Chris Caputo – Secretary & Treasurer (Non-Board Member) Patrick Gilmore – Director (Term Expires 2017) Matt Griswold – Director (Term Expires 2017) Aaron Hughes – President (Term Expires 2018) Arnold Nipper – Director (Term Expires 2017) Job Snijders – Vice President (Term Expires 2018)

slide-18
SLIDE 18

Committees

  • Manage administration of user accounts and

PeeringDB records

  • Answer support tickets
  • Board members Job Snijders (Chair) and

Arnold Nipper (Vice Chair)

  • Seeking 2 community volunteers (1 year term)
  • Contact: support@peeringdb.com
  • Ask for input from the community on desired

features

  • Manage roadmap and development priorities
  • Write SoWs to solicit bids to complete

requested features

  • Board members Aaron Hughes (Chair) and

Matt Griswold (Vice Chair)

  • Seeking 0 community volunteers (1 year term)
  • Contact: productcom@lists.peeringdb.com

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 18

Admin Committee Product Committee

slide-19
SLIDE 19

Samer Abdel-Hafez Hendrik Braasch Kate Gerry Peter Helmenstine Florian Hibler Eric Lindsjö Arnold Nipper – Vice Chair Eduardo Ascenço Reis Job Snijders – Chair Michael Still

Admin Committee

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 19

slide-20
SLIDE 20

PeeringDB 2.0 Support Ticket Statistics

  • Admin Committee volunteers are based around the world in a variety of time

zones

  • Goal is to resolve support tickets within 24 hours

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 20

Month Tickets Tickets/Day Resolve Time (d)

2016-03 954 31.80 0.94 2016-04 704 23.47 0.54 2016-05 657 21.90 0.50 2016-06 611 20.37 0.75 2016-07 536 17.87 0.27 2016-08 468 18.00 0.39 2016-09 633 21.10 0.32 2016-10 691 23.03 0.31 2016-11 691 23.03 0.88 2016-12 776 25.87 1.08 2017-01 707 23.57 1.30

slide-21
SLIDE 21

Karthik Arumugham Matt Griswold – Vice Chair Greg Hankins Aaron Hughes – Chair Martin J. Levy Eric Loos Chris Malayter Stephen McManus Arnold Nipper Kay Rechthien Walt Wollny

Product Committee

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 21

slide-22
SLIDE 22

Become a PeeringDB Sponsor!

  • Diamond Sponsorship - $25,000 / year
  • Limited to 2 sponsors
  • Very large logo on top line of Sponsors page with URL
  • Diamond Sponsor badge display on all records
  • Social media promotion
  • Platinum Sponsorship - $10,000 / year
  • Large logo on second line of Sponsors page with URL
  • Platinum Sponsor badge display on all records
  • Social media promotion
  • Gold Sponsorship - $5,000 / year
  • Medium logo on third line of Sponsors page
  • Gold Sponsor badge display on all records
  • Social media promotion
  • Silver Sponsorship - $2,500 / year
  • Small logo on fourth line of Sponsors page
  • Silver Sponsor badge display on all records
  • Social media promotion
  • Contact sponsorship@peeringdb.com for sponsorship info

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 22

slide-23
SLIDE 23

Diamond Sponsors

Platinum Sponsors

Gold Sponsors

Silver Sponsors

Thank you to our sponsors!

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 23 23

slide-24
SLIDE 24

Information and Resources

  • Announce list:

http://lists.peeringdb.com/cgi- bin/mailman/listinfo/pdb-announce

  • Governance list:

http://lists.peeringdb.com/cgi- bin/mailman/listinfo/pdb-gov

  • Technical list:

http://lists.peeringdb.com/cgi- bin/mailman/listinfo/pdb-tech

  • User Discuss list:

http://lists.peeringdb.com/cgi- bin/mailman/listinfo/user-discuss

  • Docs, presentations, guides, tools:

http://docs.peeringdb.com/

  • Board and Officers:

stewards@lists.peeringdb.com

  • Admins: support@peeringdb.com
  • Bugs and feature requests:

https://github.com/peeringdb/peeringdb/

  • Status: http://status.peeringdb.com/
  • @PeeringDB
  • https://www.facebook.com/peeringdb/
  • https://www.linkedin.com/company/peerin

gdb

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 24

slide-25
SLIDE 25

Questions?

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 25

slide-26
SLIDE 26

Multiple Records Under a Single Organization

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 26

Facilities are Shown Here LINX has 1 Facility Networks are Shown Here LINX has 2 Network Records Exchanges are Shown Here LINX has 6 Exchange Records

slide-27
SLIDE 27

One Account Managing Multiple Organizations

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 27

Account “job” is Affiliated with 4 Organizations

slide-28
SLIDE 28

Request Ownership of an Existing Organization

  • Network records should already have an organization admin copied from

PeeringDB 1.0

  • Facility and exchange records will need to have an organization admin assigned

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 28

Click “Request Ownership” Generates a Support Ticket for Validation and Approval

slide-29
SLIDE 29

Register or Request Affiliation to an Existing Organization

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 29

  • 1. Go to Your Profile
  • 2. Confirm Email Address

(Click Here if not Confirmed)

  • 3. Enter ASN or

Organization Here Autocomplete on Existing ASNs and Organizations in PeeringDB

  • 4. Click “Affiliate”

Existing: Organization Admin Needs to Approve New: Generates a Support Ticket for Validation and Approval

slide-30
SLIDE 30

Adding a New Exchange to Your Organization

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 30

Generates a Support Ticket for Validation and Approval

Enter Exchange Info Here, Then Click “Submit Exchange”

slide-31
SLIDE 31

Editing Your Exchange Record

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 31

Enter Exchange Info Here, Then Click “Save” Networks are Still Required to Associate their Record at a Facility or Exchange

slide-32
SLIDE 32

Editing Your Exchange Record

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 32

Enter LAN Info Here Name – Optional Name DOT1Q – 802.1Q Tag MTU IPv4/IPv6 Addresses Add Facilities Here Autocomplete on Existing Facilities, Must Contact Support to Add a New Facility

slide-33
SLIDE 33

Organization User Management

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 33

Approve or Deny Pending Requests Delegate Permissions for Members Admins Have Access to Everything Change User Access Levels Admin – Administrator Member – Delegate Permissions Remove Users From the Organization Does not Remove the User Account From PeeringDB

slide-34
SLIDE 34

Administrative Permission Delegation

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 34

User “rho” can Manage the “Equinix Connect” Network Record, and Any Exchange or Facility User “equinix-uk” can Manage Several Network Records, but no Exchanges or Facilities Create – New Entries in Record Update – Change Existing Entries in Record Delete – Delete Entries in Record

slide-35
SLIDE 35

Network Record Contact Information Permissions

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 35

Separate Visibility Preferences for Each Role Private – Organization Only (Default) Users – Registered Users Only Public – Anyone (no Login Required) Roles: Abuse Policy Technical NOC Public Relations Sales

slide-36
SLIDE 36

PeeringDB IXP Statistics

  • Not all networks are associated at an IXP even if they are connected
  • As of 2017-02-21

2017-02-28 Apricot 2017, Ho Chi Minh City, Viet Nam 36

Region # of IXP # of members at largest IXP Total # of members (unique) Total # of members (duplicates) # of IXP most peered ASN is connected to Africa 38 172 259 531 18 Australia 27 144 330 1005 17 Asia Pacific 80 208 762 1734 23 Europe 222 749 2963 8008 72 Middle East 8 41 66 76 3 North America 138 273 1480 3642 65 South America 62 735 966 1573 26
