Parquet Modular Encryption

Gidon Gershinsky

IBM Research – Haifa Lab

Speaker

Senior Architect at IBM Research – Haifa Lab gidon@il.ibm.com Leading role in Apache Parquet work on definition of encryption format and its implementation

• community work, folks from many companies are involved

Number of projects on secure analytics on encrypted data

• connected car and healthcare usecases
• Apache Spark with Parquet encryption
• Spark&AI Summit talk, 2018

Overview

• Goals of this technology
• Parquet encryption – Features
• Sample usecases
• How to use Parquet encryption API
• Basic integration with Apache Spark
• Performance implications
• Roadmap

Apache Parquet

Popular columnar storage format Encoding, compression Advanced data filtering

• columnar projection: skip columns
• predicate push down: skip files, or row groups,
• r data pages

Performance benefits

• less data to fetch from storage: I/O, latency
• less data to process: CPU, latency

How to protect sensitive Parquet data?

• in any storage - keeping projection/predicates, supporting column access control, data tamper-

proofing etc.

Parquet Encryption: Goals

Protect sensitive data-at-rest (in storage)

• data privacy/confidentiality: encryption - hiding sensitive information
• data integrity: tamper-proofing sensitive information
• in any storage - untrusted, cloud or private, file system, object store, archives

Preserve performance of analytic engines

• full Parquet capabilities (columnar projection, predicate pushdown, etc)

with encrypted data

Leverage encryption for fine-grained access control

• per-column encryption keys
• key-based access in any storage: private -> cloud -> archive

Parquet Encryption: Features

Privacy: Hiding sensitive information

• Full encryption: all data and metadata modules
• min/max values, schema, encryption key ids, list of sensitive

columns, etc

• Separate keys for sensitive columns
• column data and metadata
• column access control
• Separate key for file-wide metadata
• Parquet file footer – encrypted with footer key
• Storage server / admin never sees encryption keys or

unencrypted data

• “client-side” encryption

Parquet Encryption: Features

Privacy: Hiding sensitive information (continued)

• Multiple encryption algorithms
• different security and performance trade-offs
• currently two algorithms are defined and implemented
• AES_GCM: encrypts and tamper-proofs everything (data and metadata)
• AES_GCM_CTR: encrypts everything, tamper-proofs metadata only

could be useful in platforms without AES hardware acceleration, like Java 8

• if you need a new one, talk to us
• Optional plaintext footer mode for legacy readers
• any (old) Parquet reader can access unencrypted columns
• footer is unencrypted – but tamper-proofed
• signed with footer key

Parquet Encryption: Features

Data integrity verification

• File data and metadata are not tampered with
• modifying data page contents
• replacing one data page with another
• File not replaced with wrong file
• unmodified - but e.g. outdated
• sign file contents and file id
• Example: altering customer / billing data
• Example: altering healthcare data (!) - patient

record or medical sensor readings

• AES GCM: “authenticated encryption”
• implemented in hardware

customers-jan-2014.part0.parquet customers-sept-2019.part0.parquet

Current Status

• Apache Parquet community work
• Encryption specification approved in January 2019
• signed-off by PMC
• Specification and Thrift format merged
• in apache/parquet-format master
• part of parquet-format-2.7.0 release pull request (merged too)
• Implementation
• C++ and Java code
• pull requests being reviewed, some already merged
• implementation and API that closely follows the encryption specification

Parquet Encryption Usecases

Same as “Parquet Usecases” – with sensitive column data

• Data queries, analytic applications - in any industry
• Spark/Hive/Presto with Parquet: horizontal platform, not a vertical solution
• Protect data privacy / confidentiality
• personal data privacy
• sensitive business data
• regulations
• Protect data integrity
• business processes
• wrong billing due to tampering with e.g. customer data
• personal health
• wrong treatment due to tampering with patient records or sensor readings

Connected Car Usecase

“RestAssured” –

EU Horizon 2020 research project (N 731678)

Project partners

IBM, Adaptant, OCC, Thales, UDE, IT Innovation

Project usecases

• usage-based car insurance, social services
• encryption: protect personal data
• integrity: prevent billing tampering

Spark&AI Summit EU 2018: demo shots with Spark/Parquet Encryption

Healthcare Usecase

“ProTego” –

EU Horizon 2020 research project (N 826284)

Project partners

St Raffaele hospital, Marina Salud hospital, IBM, GFI, ITI, UAH, IMEC, KUL, ICE

Project usecases

• Queries / analytics on sensitive healthcare data
• HL7 FHIR standard: maps nicely to Parquet
• encryption: protect personal data
• integrity: prevent tampering with diagnosis and

treatment

Encryption API

• Parquet API - without encryption

ParquetFileWriter fileWriter = new ParquetFileWriter(file_path, schema, …);

• then write data

ParquetFileReader fileReader = ParquetFileReader.open(file_path, options);

• then read data
• Parquet API - with encryption

ParquetFileWriter fileWriter = new ParquetFileWriter(file_path, schema, …, fileEncryptionProperties);

• then write data (just like before)

ParquetFileReader fileReader = ParquetFileReader.open(file_path, options, fileDecryptionProperties);

• then read data (just like before)

File Encryption Properties

Trivial

• encrypt all columns (and footer) with key0
• tamper-proof encrypted content
• enable columnar projection, predicate pushdown, etc

byte[] key0 = … // e.g. 128 bit key – 16 bytes FileEncryptionProperties fileEncryptionProps = FileEncryptionProperties.builder(key0).build();

File Encryption Properties

Basic

• encrypt columnA with key1, columnB with key2 (and footer with key0)
• differential column access control
• assign key IDs (key metadata) for simplified key retrieval
• tamper-proof encrypted content
• enable columnar projection, predicate pushdown, etc

File Encryption Properties

Basic

• encrypt columnA with key1, column with key2 (and footer with key0)

byte[] key1 = … // e.g. 128 bit key – 16 bytes ColumnEncryptionProperties encrColumnA = ColumnEncryptionProperties .builder(“columnA") .withKey(key1) .withKeyID(”key1”) .build(); same for column B. Then file properties: FileEncryptionProperties fileEncryptionProps = FileEncryptionProperties.builder(key0) .withFooterKeyID(“key0”) .withEncryptedColumns(encryptedColumns) // list (map) of column encryption properties .build();

File Encryption Properties

Advanced

• Protect against file replacement attacks
• Replacement with untampered but e.g. outdated file (table partition)

String fileID = “customers-sept-2019.part0”; byte[] aadPrefix = fileID.getBytes(); FileEncryptionProperties fileEncryptionProps = FileEncryptionProperties.builder(key0) .withFooterKeyID(“key0”) .withAADPrefix(aadPrefix) .withEncryptedColumns(encryptedColumns) .build();

File Encryption Properties

Advanced

• Allow legacy clients to read unencrypted columns in encrypted files
• plaintext (unencrypted) footer mode
• visible file metadata (schema, names of secret columns and of their keys, etc)
• tamper-proof (sign) file metadata with footer key

FileEncryptionProperties fileEncryptionProps = FileEncryptionProperties.builder(key0) .withFooterKeyID(“key0”) .withPlaintextFooter() .withEncryptedColumns(encryptedColumns) .build();

File Encryption Properties

Advanced

• Use alternative encryption algorithm
• better performance in old Java versions
• tamper-proofing metadata only (not data)

FileEncryptionProperties fileEncryptionProps = FileEncryptionProperties.builder(key0) .withFooterKeyID(“key0”) .withAlgorithm(ParquetCipher.AES_GCM_CTR_V1) .withEncryptedColumns(encryptedColumns) .build();

File Decryption Properties

Simpler than encryption properties

• most of details are specified in file metadata

StringKeyIdRetriever keyRetriever = new StringKeyIdRetriever(); keyRetriever.putKey(“key0”, key0); keyRetriever.putKey(“key1”, key1); keyRetriever.putKey(“key2”, key2); FileDecryptionProperties fileDecryptionProps = FileDecryptionProperties.builder() .withKeyRetriever(keyRetriever) .build();

File Decryption Properties

Advanced

• Protect against file replacement attacks

String fileID = “customers-sept-2019.part0”; byte[] aadPrefix = fileID.getBytes(); FileDecryptionProperties fileDecryptionProps = FileDecryptionProperties.builder() .withKeyRetriever(keyRetriever) .withAADPrefix(aadPrefix) .build();

Beyond Low Level API

Low level API – full power of Parquet encryption

• directly implements the approved specification features
• enables any key management scheme
• work with KMS instead of explicit keys
• you need to build one – choosing from many options for KMS, Auth, envelope

encryption (data key wrapping)

• if you know how – Parquet low level encryption API is all you need
• no one-size-fits-all solution for KMS/Auth/Wrapping

Beyond Low Level API

Low level API – full power of Parquet encryption In addition, helper tools (*) on top, for tasks like

• Work with KMS
• Key management system service, on-prem or in any cloud
• Envelope encryption
• Data encrypted with random DEKs, DEKs encrypted (wrapped) with Master keys (kept in KMS)
• Even better: double envelope encryption (minimize KMS interaction)
• Rotation of Master keys
• Encryption setup via Hadoop properties, instead of API
• (*) open PR code – functional but not merged yet, subject to change
• Feel free to use as examples for your key management code

Hadoop Encryption Parameters

Hide low level API (* prototype – subject to change)

Mandatory parameters

• "encryption.column.keys"
• list of columns to encrypt, with master key IDs.
• "encryption.footer.key"
• master key ID for footer encryption/signing
• "encryption.kms.client.class"
• name of class implementing KmsClient interface
• "encryption.key.access.token"
• auth token that will be passed to KMS

Optional parameters

• "encryption.algorithm"
• "encryption.file.id"
• file replacement protection
• "encryption.plaintext.footer"
• "<masterKeyID>:<colName>,<colName>;<masterKeyID>:<colName>, ..“
• jointly defined for Parquet and ORC column encryption

HIVE-21848

Hadoop Decryption Parameters

Less parameters than for encryption

Mandatory parameters

• "encryption.kms.client.class"
• name of class implementing KmsClient interface
• "encryption.key.access.token"
• auth token that will be passed to KMS

Optional parameters

• "encryption.file.id“
• file replacement protection

KMS Client Interface

public interface KmsClient { // get encryption key byte[] getKeyFromServer(String keyIdentifier) // OR: // encrypt data key with master key (envelope encryption) String wrapDataKeyInServer(byte[] dataKey, String masterKeyIdentifier) // decrypt data key byte[] unwrapDataKeyInServer(String wrappedDataKey, String masterKeyIdentifier) }

Spark with Parquet Encryption

No changes in Spark code

• For example: Spark 2.3.0 - replace Parquet-1.8.2

with Parquet-1.8.2-E (a couple of jar files)

Writing Parquet files in standard encryption format!

• signed-off by community

Invoke encryption via Hadoop parameters

• Hadoop configuration already passed from Spark to

Parquet

KMS and envelope encryption supported Spark Parquet

Spark Client

AUTH

Token

KMS

Parquet and Spark in IBM Cloud

IBM Analytics Engine

• n-demand Spark (and Hadoop) clusters in IBM cloud

Watson Studio Spark Environments

• cloud tools for data scientists and application developers
• dedicated Spark cluster per Notebook

DB2 Event Store

• rapidly ingest and analyze streaming data for time-

series, event-driven and IoT use cases

• store and retrieve with C++ Parquet

SQL Query Service

• SQL aaS on TBs on object storage. Uses Spark & data

skipping index & extenders for timeseries & location data

• SQL-based ETL & analytics on TBs of object storage

data & automated data pipelines

Performance Effect of Encryption

AES ciphers implemented in CPU hardware (AES-NI)

• Gigabyte(s) per second
• Order(s) of magnitude faster than “application stack”

(App/Framework/Parquet/compression/IO)

C++

• OpenSSL EVP libraries tap into AES-NI directly

Java

• AES-NI support in HotSpot since Java 9
• Java 11.0.4 – enhanced AES GCM decryption
• Thank you Java folks!

Sensitive columns: ~ one in ten in a typical table

• further reduction in encryption time

Benchmark example

• Java 11.0.4
• Intel Core i7
• Parquet with SNAPPY compression
• AES_GCM algorithm
• Decryption overhead
• all (19) columns encrypted: 3.6%
• 2 columns encrypted: 0.7%
• Reader app that does nothing (blackhole)
• real apps: lower overhead!

Bottom line: Encryption won’t be your bottleneck

• app workload, data I/O, encoding, compression

Roadmap

• Complete Java and C++ open source implementations
• Key management tools (PARQUET-1373)
• High level interface to Parquet encryption (PARQUET-1568)
• Assist in Spark, Hive, Presto integration
• Data obfuscation / anonymization (PARQUET-1376)

Questions?

Backup

Existing Solutions
