Own your Android! Yet Another Universal Root Wen Xu Yubin Fu xuwen.sjtu@gmail.com QooBee1993@gmail.com Keen Team Usenix Woot 15' 1 About Me Security research intern at Keen Team Mobile vulnerability research Android Rooting

slide-1
SLIDE 1

Own your Android! Yet Another Universal Root

Wen Xu Yubin Fu xuwen.sjtu@gmail.com QooBee1993@gmail.com Keen Team

Usenix Woot 15' 1

slide-2
SLIDE 2

About Me

  • Security research intern at Keen Team

– Mobile vulnerability research

  • Android Rooting

– Software Exploitation

  • Undergraduate student at Shanghai Jiao Tong

University

– Research member of LoCCS

Usenix Woot 15' 2

slide-3
SLIDE 3

Introduction

  • Universal Android root solution by Keen Team

– CVE-2015-3636 kernel use-after-free vulnerability – Undocumented overwriting techniques targeting kernel use-after-free vulnerabilities

  • Reliable
  • Universal applied

– First 64bit root case in the world

  • PingPongRoot
  • PXN bypassed by kernel ROP

Usenix Woot 15' 3

slide-4
SLIDE 4

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 4

slide-5
SLIDE 5

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 5

slide-6
SLIDE 6

Vulnerability (CVE-2015-3636)

  • Critical paging fault at 0x200200

Usenix Woot 15' 6

slide-7
SLIDE 7

Vulnerability (CVE-2015-3636)

Usenix Woot 15' 7

  • sk: PING socket object in kernel
slide-8
SLIDE 8

Vulnerability (CVE-2015-3636)

  • Ping_unhash(hlist_nulls_del) two times

– LIST_POISON2 == 0x200200 – 0x200200 not mapped -> kernel crash

Usenix Woot 15' 8

slide-9
SLIDE 9

Vulnerability (CVE-2015-3636)

  • Invoke connect() in user program two times

– sa_family == AP_UNSPEC

Usenix Woot 15' 9

slide-10
SLIDE 10

Vulnerability (CVE-2015-3636)

  • Review ping_unhash

– Map 0x200200 to avoid crash – sock_put(sk)?

Usenix Woot 15' 10

slide-11
SLIDE 11

Vulnerability (CVE-2015-3636)

  • sock_put(sk) twice -> ref-count is 0 -> sk_free
  • A dangling file descriptor in the user program

Usenix Woot 15' 11

slide-12
SLIDE 12

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 12

slide-13
SLIDE 13

Proof-of-Concept

  • Work only on Android devices

– int sockfd = socket(AF_INET, SOCK_DGRAM, IPPROTO_ICMP); – struct sockaddr addr = { .sa_family = AF_INET }; – int ret = connect(sockfd, &addr, sizeof(addr)); – struct sockaddr _addr = { .sa_family = AF_UN- SPEC }; – ret = connect(sockfd, &_addr, sizeof(_addr)); – ret = connect(sockfd, &_addr, sizeof(_addr));

Usenix Woot 15' 13

slide-14
SLIDE 14

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 14

slide-15
SLIDE 15

Exploitation: Goal

  • Control the content of freed PING objects
  • close(fd) to hijack control flow of the kernel

Usenix Woot 15' 15

slide-16
SLIDE 16

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 16

slide-17
SLIDE 17

Exploitation: Re-filling

  • Difficulties of exploiting UAF in the kernel:

– Slab allocator: Separation between objects – Few candidates: Lack of controllability of kernel

  • bjects

– Multi-thread/core: Unpredictable kernel heap layout – Content control: Lack of controllability of content

  • f kernel objects

Usenix Woot 15' 17

slide-18
SLIDE 18

Exploitation: Re-filling

  • PING socket object in Linux kernel

– In custom use cache: “PING” cache – kmem_cache_alloc(“PING”, priority & ~__GFP_ZERO);

  • Size varies on different Android devices

Usenix Woot 15' 18

slide-19
SLIDE 19

Exploitation: Re-filling

  • Physmap, the direct-mapped memory, is memory in the

kernel which would directly map the memory in the user space into the kernel space. – ret2dir: Rethinking Kernel Isolation (USENIX 14’)

Usenix Woot 15' 19

slide-20
SLIDE 20

Exploitation: Re-filling

  • How to create: iteratively mmap() in user

space

  • Data control: fully user-controlled (fill

mmap()’ed area with our payload)

  • Physmap with payload grows by occupying the

free memory in the kernel

Usenix Woot 15' 20

slide-21
SLIDE 21

Exploitation: Re-filling

  • Size control: Large enough to fill any freed memory in

the kernel theoretically

  • Exploit UAF bugs regardless of types of vulnerable
  • bjects

Usenix Woot 15' 21

slide-22
SLIDE 22

Exploitation: Re-filling

  • Info leak by ioctl(): get to know whether the
  • verwriting is done or not

– A dword value inside the object

Usenix Woot 15' 22

slide-23
SLIDE 23

Exploitation: Re-filling

  • 1. Allocate hundreds of PING socket objects in group.

– Every M padding objects with N targeting object considered as a vulnerable one.

  • 2. Free padding PING socket objects normally by calling

close()

  • 3. Free targeting PING socket objects by triggering the bug

– Such de-allocation generates large pieces of free memory for physmap

  • 4. Iteratively call mmap() in user space and fill the areas

– Payload + magic number for re-filling checking

  • 5. Iteratively call ioctl() on targeting PING socket objects

– ioctl() returns magic number? Done.

  • 6. Otherwise further physmap spraying is needed.

Usenix Woot 15' 23

slide-24
SLIDE 24

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 24

slide-25
SLIDE 25

Exploitation: 64bit devices

  • The exploitation strategy is applied for 64bit

Android devices.

  • LIST_POISON2

– Remains to be 0x200200

  • Physmap is proved to be able to cover SLAB

caches on 64bit devices.

Usenix Woot 15' 25

slide-26
SLIDE 26

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 26

slide-27
SLIDE 27

Exploitation: Privilege escalation

  • For most 32bit Android devices:

– When pc controlled, return to shellcode in user space – What does shellcode do?

  • Leak kernel stack address to get thread_info address
  • Overwrite addr_limit to 0 to achieve kernel arbitrary

read/write ability

Usenix Woot 15' 27

slide-28
SLIDE 28

Exploitatoin: Privilege escalation

  • For many 64bit devices, PXN is applied.

– Ret2usr no longer works. – Kernel ROP is required. – 2 ROP chains:

  • 1 for leakage
  • 1 for overwriting

– Hardcoded address of gadgets

Usenix Woot 15' 28

slide-29
SLIDE 29

Exploitatoin: Privilege escalation

  • JOP (Jump-Oriented-Programming) is preferred:

– To avoid stack pivoting in kernel which brings uncertainty – Make full use of current values of the registers

  • High 32bits of kernel addresses are the same

– Only need to read/write low 32bits

  • Work hard to find cool gadgets

– One GOD gadget does both leaking and overwriting in some ROMs

Usenix Woot 15' 29

slide-30
SLIDE 30

Roadmap

  • Vulnerability (CVE-2015-3636)
  • Proof-of-Concept
  • Exploitation

– Goal – Re-filling – 64bit devices – Privilege escalation

  • Conclusion

Usenix Woot 15' 30

slide-31
SLIDE 31

Conclusion

  • We propose a universal applied attack strategy

for use-after-free vulnerabilities in Linux kernel.

  • We achieve root on popular Android devices
  • n market.

– First 64bit root case in the world

Usenix Woot 15' 31

slide-32
SLIDE 32

Acknowledgement

  • Keen Team

– wushi – James Fang – Liang Chen – Slipper – Peter

Usenix Woot 15' 32

slide-33
SLIDE 33

References

  • 1. V. P. Kemerlis, M. Polychronakis, and A. D. Keromytis. ret2dir: Rethinking

kernel isolation. USENIX Security Symposium, 2014.

  • 2. Jon Oberheide, Dan Rosenberg. Stackjacking Your Way to grsecurity/PaX
  • Bypass. INFILTRATE 2011.
  • 3. https://www.kernel.org/doc/Documentation/vm/slub.txt.
  • 4. Vasileios P. Kemerlis, Georgios Portokalidis, and Angelos D. Keromytis.

kGuard: Lightweight Kernel Protection against Return-to-user Attacks. USENIX Security Symposium, 2012.

  • 5. Marco Prandini and Marco Ramilli. Return-oriented programming.

Security and Privacy, IEEE, 2012.

  • 6. Tyler Bletsch, Xuxian Jiang, Vince W. Freeh, Zhenkai Liang. Jump-

Oriented Programming: A New Class of Code-Reuse Attack. Proceedings of the 6th ACM Symposium on Information, Computer and Communications

  • Security. ACM, 2011.

Usenix Woot 15' 33

slide-34
SLIDE 34
  • Thank you!
  • Q&A

Usenix Woot 15' 34
