Overview of Selected NETL Research Office of Research and Development Geological and Environmental Systems Dustin L. McIntyre, PhD National Energy Technology Laboratory www.netl.doe.gov Office of Fossil Energy September 18, 2009 Outline

slide-1
SLIDE 1

September 18, 2009

Overview of Selected NETL Research

National Energy Technology Laboratory www.netl.doe.gov

Office of Fossil Energy

Office of Research and Development Geological and Environmental Systems Dustin L. McIntyre, PhD

slide-2
SLIDE 2

2

Outline

  • Brief Overview of NETL and ongoing research efforts
  • X-ray CT scanning – CO2 sequestration research
  • Recent Work – GeoX2010 model optimization
  • Recent Work – ARMA Powder River Basin Coal
  • Current Work – Carbonated brine flow in fractures
  • Future Work – CO2 soluble surfactants, EOR
  • New Industrial CT scanner facility
  • Opportunities at NETL

Paper # FEDSM2009 – 78118

slide-3
SLIDE 3

3 Paper # FEDSM2009 – 78118

slide-4
SLIDE 4

4 Paper # FEDSM2009 – 78118

slide-5
SLIDE 5

5

Secretary of Energy Visit 2005

Paper # FEDSM2009 – 78118

Secretary of Energy Sam Bodman

slide-6
SLIDE 6

6

Secretary of Energy Visit 2010

Paper # FEDSM2009 – 78118

West Virginia Senator Jay Rockefeller Secretary of Energy Steven Chu

slide-7
SLIDE 7

7

NETL’s Office of Research & Development

  • Tackling important national energy problems –

– CO2 management, energy security, advanced fuels development, hydrogen technology, hybrid cycles, mercury capture, hydrates

  • Capitalizing on unique facilities and capabilities

– History dates to early 1900’s

  • Achieving breakthrough science-

– Computational science and application, hydrogen technologies, combustion science and engineering, sequestration mechanisms

  • Achieving technology successes –

– R&D 100 awards, technology transfer awards, publications, licenses, etc.

slide-8
SLIDE 8

8

Research and Development Focus Areas

slide-9
SLIDE 9

9

X-ray CT Scanning

  • Nondestructive
  • Experiments at Temperature and Pressure
  • Identification of Areas of Interest

– Post Mortem

  • Confocal Laser Microscope
  • Scanning Electron Microscope
  • Thin Sectioning
  • Proximate Analysis
  • Visualization

– Segmentation – Time Studies – Surfaces and Videos

  • Digitization for Numerical Analysis

Paper # FEDSM2009 – 78118

slide-10
SLIDE 10

10 10

X-ray CT Scanning

  • Carbon Sequestration

– Unmineable Coal Seams – Combined Coalbed Methane – Combined EOR – Brine Reservoirs – Natural Seal Integrity – Wellbore Seal Integrity

Paper # FEDSM2009 – 78118

slide-11
SLIDE 11

11 11

Production from coal can be a complex process.

  • Flow through coal is defined in

large part by the cleat network.

  • Methane sorbed on the coal is

released by decreasing pressure.

  • Water needs to be moved out of

cleats before gas can flow.

  • CO2 injection causes reverse

process (adsorption instead of desorption.

SORPTION DIFFUSION ADVECTION

slide-12
SLIDE 12

12 12

How much CO2 can be stored (and methane removed)?

  • Sorption is typically

considered to follow a Langmuir isotherm.

  • The gas pressure in the

coal seam determines how much is sorbed to the coal.

  • CO2 is preferentially

sorbed to coal, compared to methane.

slide-13
SLIDE 13

13 13

Computed Tomography Scanning of Coal

  • Computed Tomography

– 2D X-ray images reconstructed to generate 3D volumes. – Porosity, Permeability, Swelling – Preferential Sorption

CT slices show density variations of coal core

slide-14
SLIDE 14

14 14

Changes due to confining pressure

  • Visualization

– Fractures – Density Variations – Saturation – Deformation

  • Most important effect is
  • n permeability
  • Most important coal

properties for shrinkage and swelling: – Porosity (f) – Young’s modulus (E) – Poisson’s ratio (n)

slide-15
SLIDE 15

15 15

Visualize Flow within Sandstone

  • Visualization

– Preferential Flow – Saturation – Porosity – Permeability

slide-16
SLIDE 16

17 17

Image Processing of Marcellus Shale

Grey scale CT slices CT slices with false coloring Three-dimensional reconstruction

slide-17
SLIDE 17

19 19

Multi-scale & Multi-phase

CT Scanning Image Processing and Micro-Scale CFD Develop Flow Relationships Reservoir-Scale Implementation

slide-18
SLIDE 18

20 20

  • GeoX 2010, 3rd International Workshop on X-ray CT

for Geomaterials, March 1-3, 2010, New Orleans

  • Vary Roughness by Resampling
  • Vary Aperture by Resizing
  • Model Refinement

– Model Minimization and Optimization – Computational Complexity – Time – Cost

Paper # FEDSM2009 – 78118

CT Scanning and Flow Simulations

slide-19
SLIDE 19

21 21

CT Scanning and Flow Simulations

Paper # FEDSM2009 – 78118

slide-20
SLIDE 20

22 22

CT Scanning and Flow Simulations

Paper # FEDSM2009 – 78118

  • JRC provides a more linear relationship than the

Fractal Dimension

slide-21
SLIDE 21

23 23

CT Scanning and Flow Simulations

Paper # FEDSM2009 – 78118

  • T follows cubic relationship fairly well above 0.7mm

aperture

slide-22
SLIDE 22

24 24

44th U.S. Rock Mechanics Symposium

  • “Mechanical Properties, Flow Properties, and

Heterogeneous CO2 Sorption in Confined Powder River Coal Cores” Salt Lake City Utah, June 27-30, 2010

  • Sorption as a function of confining stress
  • Long term sorption
  • Permeability as a function of confining stress
  • Mechanical Strength as a function of sorption
  • Model manipulation and optimization

Paper # FEDSM2009 – 78118

slide-23
SLIDE 23

September 18, 2009

Computed Tomography Analysis of Alterations in Fractured Caprock Resulting from CO2- acidified Brine

Brian R. Ellis NETL Seal Integrity Group Meeting August 10, 2010

slide-24
SLIDE 24

26 26

Motivation

  • Predict impact on seal integrity due to vertical

leakage of CO2-acidified brine

  • Better understand conditions that will lead to self-

sealing or continued dissolution

slide-25
SLIDE 25

27 27 Secondary Seal: Fine-grained LS/DS Primary Seal: Cherty Dolostone

CO2 inj. well

Injection Formation

Site Selection – Michigan MRCSP Injection Well

Amherstburg Bois Blanc Bass Island Injection Formation: Dolostone

slide-26
SLIDE 26

28 28

Sample Preparation

  • 1” diameter, vertical core subsample

taken from injection well core

  • Core fracture was artificially induced
slide-27
SLIDE 27

29 29

EXPERIMENTAL DESIGN

slide-28
SLIDE 28

30 30

ISCO Pump ISC O Pum p H2O

  • r

Oil CO

2

Gas/Liqui d Separator

CO2 vent pH probe Check valve Thermocouple Brine Pressure transducer Pressure gauge 2-way shut-off valve BP R

1450 psi 15 psi

Experimental Design

slide-29
SLIDE 29

31 31

BPR, L/G separator and union cross for pH probes Mixing Vessel  at 30° angle to increase surface area contact Core holder inlet side Confining pressure and injection pumps

slide-30
SLIDE 30

32 32 CT Scanner

CT scanning during active flow-through at temperature and pressure

slide-31
SLIDE 31

33 33

Starting Brine Composition

Species [mol/L] Na 1.00 x 100 Ca 4.63 x 10-2 Mg 1.86 x 10-2 Cl 1.00 x 100 SO4 2.36 x 10-2 Sr 1.00 x 10-4 CO2(aq) 1.07 x 100 pH 4.86

Representative of 1 M NaCl brine having previously reacted with injection formation minerals under CO2-saturated conditions – near equilibrium with Calcite, Dolomite, and Anhydrite

  • Temperature = 40°C
  • CO2 pressure = 1450 psi
  • Confining pressure = 2000

psi

  • Flow rate = 10 ml min-1
slide-32
SLIDE 32

34 34

CT Scanning Results

slide-33
SLIDE 33

35 35 Day 2 Day 7 Medical Scanner CT Resolution = 250 μm Outlet end of core Inlet end of core Top 1/3 Middle 1/3 Bottom 1/3

slide-34
SLIDE 34

36 36

Micro-CT Imaging

2-D slice of top 1/3 of core – Prior to CO2-brine flow

Micro CT Resolution = 27 μm

2-D slice of top 1/3 of core – After 1 week of CO2-brine flow

slide-35
SLIDE 35

37 37

2-D slice of middle 1/3 of core – Prior to CO2-brine flow 2-D slice of middle 1/3 of core – After 1 week of CO2- brine flow

slide-36
SLIDE 36

38 38

1 mm 2 mm

2-D slice of bottom 1/3 of core – After 1 week of CO2- brine flow 2-D slice of bottom 1/3 of core – Prior to CO2-brine flow

slide-37
SLIDE 37

39 39

Continued Analysis

  • SEM/EDS analysis of sectioned core

– Sr-substitued calcite precipication? – Investigate extent and location of mineral dissolution along fracture pathway

  • ICP-AES analysis of brine effluent
  • Estimation of aperture change over time and the

corresponding change in fracture volume

slide-38
SLIDE 38

40 40

Acknowledgements

  • Dr. Catherine A. Peters
  • Dr. Grant Brohmal
  • Dr. Dustin McIntyre
  • Dr. Hema Siriwardane
  • Dr. Jinesh Jain
  • Dr. Bob Warzinski
  • Dr. Dustin Crandell
  • Eilis Rosenbaum
  • Bryan Tennant
  • Karl Jarvis

Funding Support

  • ORISE
  • Department of

Energy Under Award Number DE- FE0000749

slide-39
SLIDE 39

41 41

Future Facilities and Work

  • Microfocus X-ray CT facility

– 30” x 48” Scanning Envelope – 5 micron Resolution (small samples) – 225 kV and 320 kV Sources

  • Carbon Sequestration

– Seal Interaction with Carbonated Brine

  • Natural and Wellbore (Cement) Seals
  • Strength
  • Mineralization
  • Open/Close Pathways

Paper # FEDSM2009 – 78118

slide-40
SLIDE 40

42 42

Custom Industrial CT Scanner

Paper # FEDSM2009 – 78118

slide-41
SLIDE 41

43 43

Visualization of Coal

Paper # FEDSM2009 – 78118

slide-42
SLIDE 42

44 44

Future High Resolution Industrial CT Facility

Paper # FEDSM2009 – 78118

slide-43
SLIDE 43

45 45

NETL Opportunities

  • Proposal Solicitations through Project Management

Center

  • Federal Employee
  • URS Contractor Employee
  • ORISE Student
  • Regional University Alliance (RUA)

– CMU, PSU, WVU, Pitt, VT

  • Minority Mentoring Internship Program (MMIP)
  • Student Career Experience Program (SCEP)
  • Mickey Leyland Internship Program

Paper # FEDSM2009 – 78118
