Overview of LHC conventional and advanced collimation systems Stefano Redaelli, CERN, BE-ABP on behalf the collimation team X-BEAM Workshop: Beam Dynamics meets Vacuum, Collimations and Surfaces logo 8-10 March 2017 area Karlsruhe

slide-1
SLIDE 1

logo area

Overview of LHC conventional and advanced collimation systems

Stefano Redaelli, CERN, BE-ABP


  • n behalf the collimation team

X-BEAM Workshop: Beam Dynamics meets Vacuum, Collimations and Surfaces 8-10 March 2017 Karlsruhe Institute of Technology, Karlsruhe, Germany

slide-2
SLIDE 2

logo area

  • S. Redaelli, X-Beam workshop

Table of contents

▪ Introduction ▪ LHC Collimation


— Overall layout and collimator design
 — Operational cleaning performance

▪ Upgrade plans for HL-LHC


— New challenges for the upgrade
 — Crystal collimation developments
 — Status of hollow e-lens

▪ Conclusions

2

slide-3
SLIDE 3

logo area

  • S. Redaelli, X-Beam workshop

Introduction

3

So far, no quenches from circulating beam losses at the LHC!

The LHC collimation system is designed to prevent superconducting magnet quenches from losses of the 360MJ LHC proton beams

LHC stored beam energy vs time in 2016 at 6.5 TeV

Record: 270MJ

slide-4
SLIDE 4

logo area

  • S. Redaelli, X-Beam workshop

LHC collimation layout

4

Total of 118 [was 108 in
 Run I] collimators
 (108 [was 100] movable).

Dedicated insertions for betatron (IR7) and momentum (IR3) cleaning systems. Cleaning of incoming beam
 in all experiments. Physics debris collimation
 in the high-lumi IR1/5.

slide-5
SLIDE 5

logo area

  • S. Redaelli, X-Beam workshop

Collimator design and main features

5

Beam

V a c u u m t a n k

Jaw (Carbon)

What the beam sees!

~ 2 mm

Two-jaw design:
 Beam cannot “drift away”!

slide-6
SLIDE 6

logo area

  • S. Redaelli, X-Beam workshop

Collimator design and main features

6

Beam

V a c u u m t a n k

Jaw (Carbon)

What the beam sees!

~ 2 mm

Two-jaw design:
 Beam cannot “drift away”!

Tunnel installation (TCT in IP2)

slide-7
SLIDE 7

logo area

  • S. Redaelli, X-Beam workshop

New: BPM-integrated design

7

  • A. Dallocchio,

  • L. Gentini

18 new BPM collimators installed around experiments in 2014 for faster alignment and orbit monitoring.

5 10 15 20

BPM pick-up signals

5 10 15 20

Beam position [mm]

0.5 1

UP DW

5 10 15 20

Left jaw [mm]

15.5 16 16.5

LU LD

Time [s]

5 10 15 20 25

Right jaw [mm]

  • 15
  • 14.5
  • 14
  • 13.5

RU RD

  • G. Valentino

Beam centring, angular adjustment

slide-8
SLIDE 8

logo area

  • S. Redaelli, X-Beam workshop

Collimator materials — inventory

8

Bake-able to 250 deg during 24h (> 60 over 20 years) Clean, with no traces of hydrocarbons, organic and inorganic residues
 (partial pressure < 10-11 mbar) Leak tight: global helium leak rate < 10-10 mbar.l/s Outgassing rate 10-12 mbar.l/s.cm2 i.e. furnace treatment at 1000 deg
 under vacuum (carbon surface, stainless steel, ferrites …) Total outgassing rate ~ 10-7 mbar.l/s

  • V. Baglin for the vacuum team

Vacuum guidelines and requirements were taken into account from initial phases of production. Careful selection of well- qualified materials.

slide-9
SLIDE 9

logo area

  • S. Redaelli, X-Beam workshop

Multi-stage cleaning — a beam dynamics topic

9

Complex beam dynamics Material science, impedance, interaction with matter,

  • perational optimisation, …
slide-10
SLIDE 10

logo area

  • S. Redaelli, X-Beam workshop

Betatron cleaning: simulation and measurement

10

  • A. Vallone

Beam

Multi-turn cleaning process “limited” by dispersive losses in the dispersion suppressors downstream of the collimation insertion. TCLA
 (absorbers) TCSG
 (secondary)

Beam 1

TCP
 (primary) Cleaning measurement: controlled excitation of beams (white noise in transverse damper), then plot ratio of losses:

BLMi / BLMTCP

(BLM = beam loss monitor)

  • D. Mirarchi
slide-11
SLIDE 11

logo area

  • S. Redaelli, X-Beam workshop

Overall cleaning performance

11

Beam 1

Off-momentum Dump TCTs TCTs TCTs Betatron

Vertical losses

Excellent cleaning: highest cold losses ~ 0.0001!

1e-5

  • D. Mirarchi

6.5 TeV, β* = 40 cm

slide-12
SLIDE 12

logo area

  • S. Redaelli, X-Beam workshop

Table of contents

12

▪ Introduction ▪ LHC Collimation


— Overall layout and collimator design
 — Beam cleaning performance

▪ Upgrade plans for HL-LHC


— New challenges for the upgrade
 — Crystal collimation developments
 — Status of hollow e-lens

▪ Conclusions

slide-13
SLIDE 13

logo area

  • S. Redaelli, X-Beam workshop

HL-LHC: Scope of collimation upgrade

13

Increased beam stored energy: 362MJ → 700MJ at 7 TeV


Collimation cleaning versus quench limits of superconducting magnets.
 Machine protection constraints from beam tail population
 (7 MJ above 3 sigmas even for perfect Gaussian tails!).

Larger bunch intensity (Ib=2.2x1011p) in smaller emittance (2.2 μm)


Collimation impedance versus beam stability.
 Collimator robustness against regular and abnormal beam losses
 at injection as well as top energy.

Larger p-p luminosity (1.0 x 1034cm-2s-1 → 5.0-7.5 x 1034cm-2s-1)


Need to improve the collimation of physics debris.
 Overall upgrade of the collimation layouts in the insertion regions.

Much smaller β* in the collision points (55 cm → 15 cm)


Cleaning and protection of high-luminosity insertions and physics background.

Operational efficiency is a critical for HL-LHC!


Reliability of high precision devices in high radiation environment; alignment.

Upgraded ion performance (6 x 1027cm-2s-1, i.e. 6 x nominal)

slide-14
SLIDE 14

logo area

  • S. Redaelli, X-Beam workshop

Collimation upgrade baseline

14

Ion physics debris:
 DS collimation

Cleaning: DS coll. + 11T dipoles, 1 unit per beam

Low-impedance, high robustness secondary collimators: coated MoGr

Completely new layouts
 Novel materials: TCTs in CuCD
 IR1+IR5, per beam: 4 tertiary collimators
 3 physics debris collimators
 fixed masks

slide-15
SLIDE 15

logo area

  • S. Redaelli, X-Beam workshop

Dispersion suppressor collimation

15

Main beam dp/p<0 Collimators

slide-16
SLIDE 16

logo area

  • S. Redaelli, X-Beam workshop

Dispersion suppressor collimation

16

▪ One standard 15 m long dipole replaced with 2 shorter 11 T dipole, making space for a warm collimator in the cold region. Installation: 2020! ▪ Similar solution around ALICE detector, with collimator in connection cryostat ▪ Cold collimator option was dismissed because of vacuum arguments
 Topics for discussion: cryo collimators for future multi-100MJ beams?

Courtesy D. Duarte.

Q7 Q8 Q9 Q10

60cm active length, Tungsten alloy. Design of “TCLD” collimator finalised:
 prototype under construction.
 Production: 4 collimator units for 2020.

slide-17
SLIDE 17

logo area

  • S. Redaelli, X-Beam workshop

New collimator designs

17

TCLD for DS TCTX/TCLX for TAXN/D2 regions TCTPW for beam-beam compensation studies

Compression

Tertiary collimator with embedded wire for long-range beam- beam MDs

New secondary collimator jaw

Vacuum of second beam?

slide-18
SLIDE 18

logo area

  • S. Redaelli, X-Beam workshop

New collimator designs

18

TCLD for DS TCTX/TCLX for TAXN/D2 regions TCTPW for beam-beam compensation studies New secondary collimator jaw

Vacuum of second beam?

slide-19
SLIDE 19

logo area

  • S. Redaelli, X-Beam workshop

Advanced materials for future collimators

19

Scope: more robust tertiary collimators; low-impedance secondaries.
 Most promising: Mo-Gr composited, with or without Mo coating.
 Copper Carbon-diamond (CuCD). Our ambitious plan:
 Build and install 12 low-impedance collimators by 2020! Many challenges ahead (for a short time):


  • Prototype will be installed next week in the LHC.

  • Production techniques for new materials, including coating

  • Material properties under high irradiation

  • UHV behaviour of novel materials, with coating.

Mo-­‑Gr ¡composite Cu-­‑CD ¡composite Cu-­‑CD ¡Fracture ¡Analysis

Synergy : FCC collimation studies

slide-20
SLIDE 20

logo area

  • S. Redaelli, X-Beam workshop

Status of prototyping and vacuum

20

V a c u u m i s a c r i t i c a l c

  • n

c e r n ! C

  • l

l i m a t

  • r

t

  • b

e i n s t a l l e d n e x t w e e k f

  • r

b e a m t e s t s i n 2 1 7 .

MoGr block coated with TiN (yellow top) and Mo (bottom)

Novel ¡composite ¡ absorber

  • C. Accettura, F. Carra
slide-21
SLIDE 21

logo area

  • S. Redaelli, X-Beam workshop

Table of contents

21

▪ Introduction ▪ LHC Collimation


— Overall layout and collimator design
 — Beam cleaning performance

▪ Upgrade plans for HL-LHC


— New challenges for the upgrade
 — Crystal collimation developments
 — Status of hollow e-lens

▪ Conclusions

slide-22
SLIDE 22

logo area

  • S. Redaelli, X-Beam workshop

Advanced collimation studies

22

Active halo control through hollow electron-lenses


Recent project review on HEL: acknowledged the need for active halo
 controls at the HL-LHC and fully recommended to deploy HELs.
 Details: https://indico.cern.ch/event/567839
 We are in the process of assessing the addition of HELs to the baseline.

Crystal collimation with bent crystals


Goals: improve ion cleaning performance
 LHC tests: first observation of channeling at 6.5 Z TeV (proton + Pb ions).

slide-23
SLIDE 23

logo area

  • S. Redaelli, X-Beam workshop

Hollow e-lens concept

23

“Non-material” scraper — adds scraping functionality but particles are disposed of by the present collimation system. Can be installed in other points than IR7, because kicks per turn are small. Require overlap of e- and proton beam over ~3 meters.

slide-24
SLIDE 24

logo area

  • S. Redaelli, X-Beam workshop

24

Hollow e-lens design

  • D. Perini

Technical design of hollow e- lens for the HL-LHC is well advanced! All key components have been addressed. Timeline: studying a possible implementation of two lenses in 2023 (LS3)!

Magnetic shield Electrical insulation

slide-25
SLIDE 25

logo area

  • S. Redaelli, X-Beam workshop

CERN electron gun

25

2 4 6 8 10 1 2 3 4 5 Cathode−anode voltage [kV] Peak collector current [A]

  • CERN hollow electron gun prototype (CHG1)

Fermilab electron−lens test stand, 4 Jan 2017 Heater: 8.9 A, 8.6 V Solenoids: 0.1 T / 0.4 T / 0.1 T Pulse width 8 µs, rep. rate 2 Hz Perveance: 6.14 µperv

At CERN At Fermilab The first CERN hollow electron gun was tested
 in the Fermilab electron beam test-stand. Achieved output current 5.4A (new record).

Measurements by G. Stancari (FNAL).

Design goal: 5A

slide-26
SLIDE 26

logo area

  • S. Redaelli, X-Beam workshop

Controls R&D and development for crystals

26

  • A. Masi for the STI controls team

Limiting component: Optic fibre feedthrough limited to 180˚C. R&D underway with external company to develop a 220˚C compatible version.

Interfererometer optical heads with high temperature Ceramabond glue High temperature, vacuum compatible

  • ptic fibres

Rotational stage with thermal expansion compensation spring assembly and custom piezo actuator with high Curie temperature, no glue and high temperature solder for electrode wires

Piezo goniometer modifications
 for 220˚C bakeout compatibility

First demonstration of LHC halo channeling at 6.5 TeV! 4 bent crystals in the LHC as of 2017. Studying a 1 MJ collimator absorber for proton beams

slide-27
SLIDE 27

logo area

  • S. Redaelli, X-Beam workshop

▪ Reviewed the LHC collimation system and the main activities planned for its HL-LHC upgrade


Excellent performance of present system, and further improvements
 needed for the upgrade.

▪ The collimation upgrade focused on improved collimator impedance, dispersion suppressor cleaning and new layouts

  • f high-luminosity interaction regions


Highlighted some concerns related to vacuum aspects.
 Presently focused on making novel materials compatible with UHV operation.

▪ We are pushing forward new advanced collimation concepts, not yet baseline but proceeding at full steam as R&D topics


Hollow e-lenses for active halo control of 700MJ beams
 Crystal collimation, with focus on heavy ion cleaning concerns

▪ Several issues / points of contact with the communities at this workshop!


I am looking forward to discussing further!

27

Conclusions
