Outline

→ Introduction → MDE Ecosystem → Metamodel Evolution → Coupled Evolution Management Process → Change Impact Visualization → Dependencies Visualization in TraceVis → Proposed Tool Chain → Recurrent Patterns → Conclusions and Future Works

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

3

Introduction

Model Driven Engineering (MDE) aims capturing problems in terms of concepts. Problems are mapped to solutions by means of model

• perations defined by transformations

Problem and solution are described with the help of models Model is expressed in terms of concepts and relationships among them given in metamodels

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Metamodel is the central core of an ecosystem containing a wide range of artifacts

4

MDE Ecosystem

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

5

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Metamodel Evolution

Classification of changes:

• Do not affect the artefacts

→

No adaptation required

• Affect the artefact:

→

Automatically adapted

→

Not automatically adapted

6

MDE Ecosystem

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

7

MDE Ecosystem

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

8

MDE Ecosystem

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Trace and visualize the dependencies within the ecosystem in

• rder to enable the modeler to detect those modification

compromising the existing artifacts

9

Coupled Evolution Management Process

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

[1] Di Ruscio, D., Iovino, L., Pierantonio, A.: A methodological approach for the coupled evolution of metamodels and ATL transformation. In: Proc. 6th International Conference on Model Transformation (ICMT'13). (2013)

10

Change Impact Visualization

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

• TraceVis [1] is a tool able to graphically represent

traceability information between structured data

• TraceVis has been used also to visualize traceability

links between source and target models of a transformation [2]

• Our idea: Using TraceVis to graphically represent

the impact that the changes being addressed on a metamodel can have on the artefact

[1] Van Ravensteijn, W.: Visual traceability across dynamic ordered hierarchies. Master's thesis, Eindhoven Univ. of Technology, The Netherlands (2011) [2] Amstel, M., Brand, M., Serebrenik, A.: Traceability visualization in model transformations with tracevis. In Hu, Z., Lara, J., eds.

11

Dependencies Visualization in TraceVis

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

12

Dependencies Visualization in TraceVis

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Initial Metamodel

13

Dependencies Visualization in TraceVis

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Difference Model

14

Dependencies Visualization in TraceVis

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Existing Transformation

15

Dependencies Visualization in TraceVis

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

16

Dependencies Visualization in TraceVis

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

17

Dependencies Visualization in TraceVis

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

18

Proposed Tool Chain

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

19

Proposed Tool Chain

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

20

Proposed Tool Chain

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Differences Derivation

21

Proposed Tool Chain

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Model2Model Transformation

22

Proposed Tool Chain

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Model2Code Transformation

23

Recurrent Patterns

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Changes in the affected artefacts are not always directly proportional to the changes in the metamodel

Uniform impact on metamodel and artifact

24

Recurrent Patterns

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Changes in the affected artefacts are not always directly proportional to the changes in the metamodel

Uniform impact example

25

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Heavy metamodel evolution – Light impact on the artifact Heavy metamodel evolution – Light impact on the artifact example

EVO

Extract abstract superclass with mandatory field

26

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Light metamodel evolution – Heavy impact on the artifact Light metamodel evolution – Heavy impact on the artifact example Metaclass renaming

27

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Heavy metamodel evolution – Heavy impact on the atifact Heavy metamodel evolution – Heavy impact on the atifact example

• Usually is characterized

by a strong change step passing from MM ver 1.0 to vers 3.0

28

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

Non breaking changes with no impact

EVO

Extract abstract superclass Non breaking changes with no impact example

29

Conclusion and future works

• The problem of adapting artifacts composing a

metamodeling ecosystem when metamodel changes is intrinsically difficult

• Visualize dependencies between metamodel and

artifact in term of traceability information can help the modeler to manage the complexity

• A live monitoring of the change impact reflecting on

the artifact the proposed change could be an interesting application

• The visualization can be enriched with the

categorization of the refactoring

GMLD ‘13 - 2 JULY 2013, MONTPELLIER, FRANCE

30
