OSSAMS Open Source Security Assessment Management System System Overview Purpose To provide a framework for security assessors to correlate and


slide-1
SLIDE 1

OSSAMS ¡

Open ¡Source ¡ ¡ Security ¡Assessment ¡ ¡ Management ¡System ¡

slide-2
SLIDE 2

System ¡Overview ¡

  • Purpose ¡

– To ¡provide ¡a ¡framework ¡for ¡security ¡assessors ¡to ¡ correlate ¡and ¡analyze ¡risk ¡to ¡informa=on ¡systems ¡ – To ¡streamline ¡the ¡assessment ¡repor=ng ¡process ¡ – To ¡build ¡a ¡modular ¡process ¡to ¡allow ¡for ¡building ¡on ¡ past ¡assessments ¡

  • System ¡Architecture ¡

– LAMP ¡– ¡Ubuntu/FreeBSD ¡MYSQL, ¡PHP ¡ – Backen ¡Scrip=ng ¡and ¡parsing ¡

  • Perl, ¡Python, ¡Ruby, ¡etc ¡
slide-3
SLIDE 3

Backend ¡Architecture ¡

  • MYSQL ¡

– Open ¡Source ¡DB ¡

  • PHP ¡

– Easy ¡to ¡code, ¡does ¡not ¡require ¡a ¡lot ¡of ¡code ¡ – The ¡No ¡frills ¡web ¡app ¡ – Low ¡code ¡(to ¡much ¡code, ¡not ¡a ¡good ¡thing) ¡ – Fast ¡and ¡not ¡preQy ¡

  • Parsing ¡Data ¡

– Perl ¡and ¡Python ¡Parsing ¡ – Scripts ¡will ¡run ¡as ¡a ¡backend ¡process, ¡called ¡by ¡PHP ¡or ¡ stored ¡a ¡CRON ¡jobs. ¡

slide-4
SLIDE 4

Subsystem ¡

  • Parser ¡Engine ¡

– Command ¡Line ¡style ¡scripts ¡to ¡simply ¡parse ¡the ¡XML, ¡ test, ¡or ¡other ¡scan ¡output ¡into ¡a ¡structured ¡database. ¡ – Does ¡not ¡perform ¡analysis ¡

  • Correla=on ¡Engine ¡

– Perl ¡or ¡SQL ¡process ¡for ¡submiVng ¡queries ¡and ¡storing ¡ results ¡in ¡a ¡table ¡for ¡structured ¡reports. ¡

  • Web ¡Front ¡End ¡

– Ques=onnaire ¡for ¡Customers ¡ – Assessment ¡Management ¡for ¡InfoSec ¡Team ¡

slide-5
SLIDE 5

Subsystem ¡(Cont) ¡

  • Config ¡Parser ¡

– Parse ¡Text ¡file ¡configs ¡and ¡create ¡rela=onal ¡ network ¡diagram ¡

  • Recommenda=on ¡System ¡

– System ¡to ¡offer ¡recommedna=ons ¡based ¡on ¡ findings ¡from ¡other ¡subsystems ¡ – Modular ¡and ¡managed ¡by ¡InfoSec ¡

  • The ¡OSSAMS ¡will ¡give ¡a ¡brief ¡example ¡of ¡

recommenda=on ¡

  • We ¡don’t ¡want ¡to ¡give ¡the ¡secret ¡sauce ¡away ¡
slide-6
SLIDE 6

Parsing ¡SCAN ¡Output ¡

  • Many ¡tools ¡such ¡as ¡Nessus, ¡NMAP, ¡etc ¡provide ¡an ¡XML ¡
  • utput ¡file. ¡
  • The ¡system ¡will ¡not ¡perform ¡scans, ¡but ¡can ¡schedule ¡

scans ¡on ¡another ¡system ¡

  • The ¡output ¡will ¡then ¡be ¡parsed ¡and ¡put ¡into ¡MySQL ¡

database ¡

  • The ¡Customer ¡ID, ¡Project ¡ID, ¡and ¡IP ¡Address ¡ID ¡(cst_id, ¡

prj_id ¡and ¡ipadd_id) ¡will ¡be ¡together ¡be ¡Primary ¡key ¡ for ¡SCAN ¡result ¡table. ¡

  • Learn ¡from ¡other ¡projects ¡(but ¡not ¡take) ¡

– DRADIS ¡Server ¡-­‑ ¡hQp://dradisframework.org ¡ – Seccubus ¡-­‑ ¡hQp://www.seccubus.com ¡

slide-7
SLIDE 7

Correla=on ¡Engine ¡

  • As ¡Scan ¡data ¡is ¡entered ¡into ¡DB, ¡based ¡on ¡the ¡

cst_id, ¡prj_id ¡and ¡ipadd_id ¡will ¡be ¡mapped ¡ together ¡to ¡show ¡true ¡results ¡of ¡scan ¡of ¡a ¡single ¡

  • system. ¡

– Might ¡include ¡hostname ¡also ¡

  • Output ¡from ¡Config ¡parser ¡will ¡also ¡be ¡checked ¡

– i.e. ¡firewall ¡rules ¡etc ¡ – Network ¡Diagram ¡Tool ¡(network ¡notepad, ¡but ¡need ¡to ¡ make ¡a ¡linux ¡version) ¡

slide-8
SLIDE 8

Config ¡Parser ¡

  • Tool ¡to ¡replace ¡NIPPER ¡and ¡RAT ¡

– Use ¡RAT ¡code ¡to ¡learn ¡how ¡they ¡parse ¡ – Then ¡do ¡it ¡beQer ¡ – Simliar ¡to ¡my ¡ACL2CSV ¡tool ¡

  • Create ¡Network ¡Map ¡

– Using ¡IP ¡to ¡Interface, ¡CDP ¡and ¡etc ¡

  • Map ¡ACL’s ¡to ¡IP ¡Address ¡
  • Config ¡Plugin ¡Parsing ¡

– Create ¡RegEx ¡parsing ¡plug-­‑in ¡framework ¡so ¡the ¡ parsing ¡can ¡be ¡easily ¡expanded ¡

slide-9
SLIDE 9

Web ¡Front ¡End ¡Architecture ¡

  • PHP ¡

– We ¡might ¡do ¡something ¡else, ¡but ¡here ¡are ¡the ¡concerns ¡I ¡ have ¡the ¡most ¡ – To ¡Much ¡code, ¡means ¡more ¡errors ¡ – No ¡frills, ¡we ¡want ¡fast ¡and ¡browser ¡independent, ¡when ¡ you ¡use ¡flash, ¡ac=vex ¡and ¡etc ¡you ¡can ¡cause ¡more ¡issues ¡

  • SECURITY ¡is ¡PARAMOUNT ¡

– We ¡can’t ¡have ¡config ¡issues ¡or ¡anything ¡like ¡that ¡ – We ¡have ¡to ¡have ¡a ¡secure ¡system ¡ – ASA ¡Web ¡Portal ¡for ¡Customer ¡Access ¡ – Not ¡Accessible ¡by ¡Internet ¡

slide-10
SLIDE 10

Web ¡Frontend ¡Design ¡

  • Two ¡primary ¡systems ¡

– InfoSec ¡Management ¡ – Customer ¡Ques=onnaire ¡

  • InfoSec ¡Management ¡

– Enter ¡Scan ¡Data ¡ – Manage ¡Customer ¡Data ¡ – Generate ¡Text ¡File ¡Report ¡ – CSV ¡based ¡reports ¡for ¡Graphs ¡and ¡etc ¡

slide-11
SLIDE 11

Web ¡Frontend ¡Design ¡(Cont) ¡

  • Customer ¡Ques=onnaire ¡

– Customer ¡Ques=onnaire ¡forms ¡ – Canbe ¡filled ¡out ¡by ¡InfoSec ¡or ¡Cust ¡

  • Example: ¡

– Policy ¡Ques=onnaire ¡ – PCI ¡Self ¡Assessment ¡ – Security ¡Technology ¡

  • Responses ¡will ¡map ¡to ¡recommenda=ons ¡
slide-12
SLIDE 12

Recommenda=on ¡System ¡

  • A ¡modular ¡framework ¡

– Create ¡thresholds ¡to ¡be ¡found ¡in ¡parsed ¡data ¡ – Easily ¡created ¡and ¡easily ¡to ¡have ¡many ¡ recommenda=ons ¡

  • Threshold ¡to ¡Recommenda=on ¡Output ¡

– Snip-­‑it ¡of ¡the ¡report ¡data ¡ – Recommenda=on ¡Summary ¡ – Recommenda=on ¡Full ¡report ¡

  • Use ¡Tags ¡similar ¡to ¡word ¡press ¡blogs ¡
