ORLAND PARK Development Services Department 14700 Ravinia Avenue . - - PowerPoint PPT Presentation

• 1. Welcome from Mayor Daniel McLaughlin
• 2. Permit process Updates
• 3. Inspections process Updates
• 4. Residential Building code Updates
• 5. Common issues and code enforcement Q&A

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

AGENDA

Development Services – Building Division Team

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

MICHAEL COLEMAN

BUILDING DIVISION MANAGER BUILDING OFFICIAL

KEVIN WAGNER

BUILDING INSPECTOR / PLAN REVIEWER – FIRE CODE

JAMIE KUCALA

PLUMBING INSPECTOR

ED LARKE

ELECTRICAL INSPECTOR

KRYZ KOCIOLEK

BUILDING INSPECTOR / PLAN REVIEWER

GEOFF GALGAN

PART-TIME CONCRETE & BUILDING INSPECTOR

DAN MCKENNA

PART-TIME ELECTRICAL & BUILDING INSPECTOR

JOE KUCALA

PART-TIME ELECTRICAL & BUILDING INSPECTOR

RICK PIEPRZAK

BUILDING INSPECTOR / PLAN REVIEWER

CHERYL JORDAN

CODE ENFORCEMENT

JIM CONNEL

PART-TIME CODE ENFORCEMENT

KARINA HUAMAN

PART-TIME CODE ENFORCEMENT

GEOFF HILES

HEALTH INSPECTOR

KARIE FRILING

DIRECTOR OF DEVELOPMENT SERVICES

MIKE TATRO

PART-TIME PLUMBING & BUILDING INSPECTOR

$0 $5,000,000 $10,000,000 $15,000,000 $20,000,000 $25,000,000 2009 2010 2011 2012 2013 2014 2015 2016

Residential Permits Valuation 2009 - 2016

Single Family Detached Single Family Attached Single Family Remodels and Additions Existing Residential Misc. Permits

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

13 18 27 25 42 33 33 44

PERMIT PROCESS UPDATES

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

PERMITS

PERMIT PROCESS UPDATES - HIGHLIGHTS

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

PERMITS

 Build Orland Program will be extended in 2017. This defers payment of permit and impact fees until time of final inspection for new single-family homes.  Electronic plan reviews – Village has issued an RFP for new IT equipment so that plans can be submitted and reviewed digitally.  Permit fee changes – the Village Board of Trustees has requested that all permit fees be reviewed by the staff and revised if necessary (mid 2017).

PERMITS

Permit Process for New Single Family Construction – Detached Houses and Townhomes

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. PERMIT SUBMITTAL
• PERMIT APPLICATIONS
• 2 SETS OF PLANS
• PROPOSED ENGINEERING PLAN
• 2. REVIEW COMMENTS
• PLAN REVIEW COMMENTS
• CONTRACTOR LICENES
• LETTER OF INTENT
• 4. FOUNDATION PERMIT ISSUED
• PERMIT FEES DEFERRED UNTIL

FINAL INSPECTION

• BASE OF EXCAVATION REPORT

REQUIRED FOR NEW SITES

• 3. RE-SUBMITTAL (IF REQUIRED)
• MISSING PERMIT APPLICATIONS
• MISSING CONTRACTOR LICENSES
• REVISED PLANS
• 5. TOP OF FOUNDATION SURVEY
• MUST BE REVIEWED AND

APPROVED BY VOP

• 6. BUILDING PERMIT ISSUED
• MUST BE DISPLAYED ON SITE

BEFORE WORK PROGRESSES BEYOND FOUNDATION

• 7. FINAL GRADE SURVEY + FEES
• SUBMIT FINAL GRADE
• PAY PERMIT FEES
• SCHEDULE FINAL INSPECTIONS
• 8. CERTIFICATE OF OCCUPANCY
• ISSUED WITHIN 7 DAYS OF FINAL

APPROVALS (TYPICALLY WITHIN 2-3 DAYS)

Permit Process for Residential Additions and Remodels

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. PERMIT SUBMITTAL
• PERMIT APPLICATIONS
• 2 SETS OF PLANS
• PROPOSED ENGINEERING PLAN
• 2. REVIEW COMMENTS
• PLAN REVIEW COMMENTS
• CONTRACTOR LICENES
• LETTER OF INTENT
• 3. RE-SUBMITTAL (IF REQUIRED)
• MISSING PERMIT APPLICATIONS
• MISSING CONTRACTOR LICENSES
• REVISED PLANS
• 6. BUILDING PERMIT ISSUED
• MUST BE DISPLAYED ON SITE

BEFORE WORK PROGRESSES BEYOND FOUNDATION

• 8. CERTIFICATE OF COMPLIANCE

(LARGER PROJECTS ONLY)

• ISSUED WITHIN 7 DAYS OF FINAL

APPROVALS (TYPICALLY WITHIN 2-3 DAYS)

PERMITS

Permit Submittal Requirements – Residential New Construction / Additions / Remodels

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

PERMITS

Permit Submittal Requirements – Residential New Construction / Additions / Remodels

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

PERMITS

Permit Submittal Requirements – Residential New Construction / Additions / Remodels

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

New Construction:  2 Sets of plans – both copies stamped and signed by an architect  Completed Building Permit applications, including sub-permits for MEP  Letter of Intent from Plumbing Contractor  HOA approval letter (if applicable)  Proposed site development / engineering plan (2 copies) Additions / Remodels:  Plans – for 1 story additions under 400 sq. ft. plans don’t have to be stamped by an architect – but must be drawn with straight edge, labeled and dimensioned. Second story additions, additions over 400 sq. ft., or structure not designed prescriptively per code will require an architect’s stamped plans.  Completed Building Permit applications, including sub-permits for MEP  Letter of Intent from Plumbing Contractor (if applicable)  HOA approval letter (if applicable)  Proposed site development / engineering plan / site plan (if applicable)

PERMITS

Permit Submittal Requirements – Plans

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Architectural Plans must include the following information on the plans:

• Applicable Codes (see website)
• Building Height (as defined by Code) – especially important for high slope roofs, lookouts,

and walkouts

• Gross area for the building (measured to exterior face of walls on each story)
• Plumbing schematic diagram, Electrical plans, and other info required by code
• Site plan with lot coverage calculations and zoning district designation (if not shown on

proposed engineering plan)

Engineering Plans must include the following information on the plans:

• Zoning District Designation
• Required setbacks
• Actual building setbacks
• Lot coverage calculations
• Grading contours
• Heights of retaining walls (if applicable)
• Structural design of retaining walls (or product info) (if applicable)

PERMITS

Permit Review Comments

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

PROJECT INFO CONTRACTOR LICENSES OTHER SUBMITTALS PLAN REVIEW COMMENTS

EMAIL ADDRESS REQUIRED – PERMIT REVIEW COMMENTS WILL BE EMAILED TO APPLICANT 2 WEEK REVIEW TIME TYPICAL (LONGER DURING PEAK TIMES)

PERMITS

Certificates of Occupancy / Compliance

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• Issued within 7 days of approved final inspection

(typically in 2-3 days)

• Issued in the name of the permit holder or name of new

homeowner (if requested in writing by permit holder)

• Original paper copy will be available for pick up next to

Window #5 at service counter TEMPORARY OCCUPANCY

• Will only be considered due to weather related delays

for exterior items such as grading, site work, and tree mitigation, between November 15 and April 15

• Requires a min. $5,000 cash / check bond, refundable

upon issuance of final certificate of occupancy (less $250 admin fee) PERMIT EXPIRATION

• Permits expire 12 months after issuance, or 6 months after last inspection if inactive
• Expired permits must be renewed and renewal fee paid, and permit holder must schedule a progress

inspection to verify status of project. Permit renewal fee is $150 for new const. or remodeling and $50 for accessory structures.

PERMITS

INSPECTIONS PROCESS UPDATES

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

INSPECTIONS

Inspections Process Updates - New Permit Cards

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org FRONT BACK

PERMIT CARD MUST BE DISPLAYED ON SITE: NO PERMIT CARD ON SITE – NO INSPECTION PERMIT CARD MUST BE ACCESSIBLE TO BUILDING INSPECTORS (PLACE IN PLASTIC SHEET PROTECTOR ON OUTSIDE/INSIDE OF BUILDING IN LOCATION PROTECTED FROM WEATHER) APPROVED / DISAPPROVED STICKERS ARE NO LONGER USED ON YELLOW PERMIT CARDS

INSPECTIONS

Inspections Process Updates - Scheduling

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

INSPECTIONS

Inspections Process Updates - Scheduling

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 4 PM CUT-OFF TIME FOR NEXT BUSINESS DAY SCHEDULING – NO EXCEPTIONS
• TIMED INSPECTIONS ARE ONLY FOR:
• CONCRETE PREPOUR INSPECTIONS
• EMERGENCY SEWER REPAIR WORK (NOT REGULAR SEWER/WATER OR UNDERGROUND)
• HOOD DUCT (COMMERCIAL KITCHEN ONLY)

INSPECTIONS

Inspections Process Updates – Inspections Required

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• EROSION CONTROL & TREE PROTECTION (CONTACT LOY LEE)
• FOOTING

(BASE OF EXCAVATION REPORT REQUIRED FOR NEW LOTS, UNLESS SPECIFICALLY WAIVED BY BUILDING OFFICIAL)

• PLUMBING / ELECTRICAL UNDERGROUND
• SEWER / WATER / SUMP
• BASEMENT/GARAGE SLAB (6 MIL VAPOR BARRIER)
• DRAIN TILE

(BASEMENT WALLS MUST BE BRACED AT TOP AND BOTTOM BEFORE BACKFILLING, OR MUST HAVE LETTER FROM ARCHITECT AUTHORIZING BACKFILL PRIOR TO FIRST FLOOR DECK INSTALLATION)

• FOUNDATION INSULATION (IF APPLICABLE)
• ELECTRICAL SERVICE (SEPARATE PAPER FORM REQ’D)
• ROUGH INSPECTIONS (INCLUDES FIRE STOPPING)
• INSULATION INSPECTION
• CONCRETE EXTERIOR FLATWORK INSPECTIONS
• FINAL INSPECTIONS (DEFERRED PERMIT FEES MUST BE PAID)

INSPECTIONS

RESIDENTIAL CODE UPDATES AND AMENDMENTS

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Previous Codes

2012 IBC Building Code 2012 International Mechanical Amendments 2011 National Electrical Code 2014 State of Illinois Plumbing Code 2012 International Fire Code 2012 International Property Maintenance 2012 Illinois Energy Conservation Code (IECC) 1997 Illinois Accessibility Code 2013 ASME A17.1 Safety Code for Elevators and Escalators 2013 NFPA 13 2013 NFPA 72 2013 NFPA 17A 2011 NFPA 96 2013 Permit Fees – Village Code (Most of the above model codes have been amended by the Village of Orland Park in Chapter 5 of the Village Code)

Current Codes

2015 IBC Building Code 2015 IRC International Residential Code 2012 International Mechanical Code 2014 National Electrical Code 2014 State of Illinois Plumbing Code 2012 International Fire Code 2012 International Property Maintenance 2015 Illinois Energy Conservation Code (IECC) 1997 Illinois Accessibility Code 2013 ASME A17.1 Safety Code for Elevators and Escalators 2013 NFPA 13 2013 NFPA 72 2013 NFPA 17A 2011 NFPA 96 2013 Permit Fees – Village Code (Most of the above model codes have been amended by the Village of Orland Park in Chapter 5 of the Village Code)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Current Codes

2015 IBC Building Code 2015 IRC International Residential Code 2012 International Mechanical Code 2014 National Electrical Code 2014 State of Illinois Plumbing Code 2012 International Fire Code 2012 International Property Maintenance 2015 Illinois Energy Conservation Code (IECC) 1997 Illinois Accessibility Code 2013 ASME A17.1 Safety Code for Elevators and Escalators 2013 NFPA 13 2013 NFPA 72 2013 NFPA 17A 2011 NFPA 96 2013 Permit Fees – Village Code (Most of the above model codes have been amended by the Village of Orland Park in Chapter 5 of the Village Code)

• 2015 IRC was adopted by ordinance on 6/20/2016 by the Board of Trustees
• Applicable to detached dwellings and multiple, vertically attached single family

dwellings not more than 3-stories in height

• Single Family Detached Houses
• Single Family Townhomes
• Single Family Duplexes
• Chapters 11-43 of the IRC Code are amended almost in entirety as they relate to

Energy, Electrical, Plumbing and other special trades

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

2015 IRC – International Residential Code with Village of Orland Park Amendments per VC-5-1-14.

Deleted from the model code and/or from previous Village amendments:

• 1. Fire Sprinklers for Single Family Residences are not required
• 2. Mechanical exhaust fans for attached garages are not required any longer

Less stringent than previous Village amendments:

• 3. Guardrails requirement for heights exceeding 18”, has been changed to 30”
• 4. Handrail for stairs with 3 risers or more, has been changed to 4 risers or more
• 5. Basement insulation of R15 continuous / R19 cavity, has been changed to R10/R13
• 6. Hot water pipe insulation of R3 now required only on ¾” or larger pipes
• 7. Fire rating of door between dwelling and garage was 60 min., has been changed to 20 min. or solid core 1 ¾”
• 8. Number of basement emergency egress windows – egress from common space allowed through bedroom now
• 9. Requirement for 3-car garages to be side-loaded, has been changed to allow for 3-car garages to face the front

More stringent than previous Village amendments:

• 10. Decks over 500 sq. ft. in size or 9 ft. in height must be designed by an Architect or Structural Engineer
• 11. Maximum sizes for detached and attached garages
• 12. Maximum size for detached gazebos / pool houses is 200 square feet
• 13. Garage slabs shall be 5” min. thick with WWF or fiber mesh
• 14. Cumulative construction clause added – sum of all additions or remodels during 36 month period
• 15. Reductions in joist span table for Southern Yellow Pine, Doug-Fir Larch and Hem-Fir

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Summary of 2015 IRC w/ Village amendments

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

GROUND SNOW LOAD 30 PSF Minimuma WIND DESIGN SPEED 115 mph – 3 second gust (Vult) 90 mph – 3 second gust (Vasd) SEISMIC CATEGORY A - per Figure R301.2(2)

CALCULATED SDS SEISMIC DESIGN CATEGORY

WEATHERING Severe FROST LINE DEPTH 42” TERMITE Moderate to Heavy WINTER DESIGN TEMPERATE

• 1 o F

ICE BARRIER UNDERLAYMENT REQ’D Yes FLOOD HAZARDS Check flood zone map AIR FREEZING INDEX 1508 MEAN ANNUAL TEMPERATURE 49o F

TABLE R301.2(1) CLIMATIC AND GEOGRAPHIC DESIGN CRITERIA

• Reductions to snow load for sloped roofs are not permitted

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

FIRE SEPARATION DISTANCE: TABLE R302.1(1) EXTERIOR WALLS FOR DETACHED AND ATTACHED DWELLINGS Exterior walls of detached dwellings closer than 7 feet to property lines: Will have to be fire-rated for 1 HR. (Closer than 3 feet must be rated for 2 HR) Fire rating must be per UL listed assembly, must be shown on plans, rated for exposure from both sides Maximum amount of windows /

• penings is limited to 15% of

elevation (no openings if distance less than 3 feet) Extra “screw pattern” inspection will be required and must be scheduled by contractor before taping and mudding

EXTERIOR WALL ELEMENT MINIMUM FIRE- RESISTANCE RATING MINIMUM FIRE SEPARATION DISTANCE “X” WALLS (DETACHED DWELLINGS & DUPLEXES) a FIRE –RESISTANCE RATED 2 HOUR – PER ASTM E119 OR UL 263, RATED FOR EXPOSURE BOTH SIDES < 3 FEET FIRE –RESISTANCE RATED 1 HOUR – PER ASTM E119 OR UL 263, RATED FOR EXPOSURE BOTH SIDES 3 FEET ≤ X < 7 FEET NOT -RATED 0 HOURS ≥ 7 FEET WALLS (ATTACHED DWELLINGS / TOWNHOMES)a, b FIRE-RESISTANCE RATED 2 HOURS – PER ASTM E119 OR UL 263, RATED FOR EXPOSURE BOTH SIDES <5 FEET FIRE-RESISTANCE RATED 1 HOUR – PER ASTM E119 OR UL 263, RATED FOR EXPOSURE BOTH SIDES 5 FEET ≤ x < 15 FEET NOT -RATED 0 HOURS ≥ 15 FEET PROJECTIONS (DETACHED DWELLINGS) NOT ALLOWED N/A < 3 FEET FIRE-RESISTANCE RATED 1 HOUR ON UNDERSIDE 3 FEET ≤ x < 7 FEET NOT -RATED 0 HOURS ≥ 7 FEET PROJECTIONS (ATTACHED DWELLINGS) NOT ALLOWED N/A < 5 FEET FIRE-RESISTANCE RATED 1 HOUR ON UNDERSIDE 5 FEET ≤ x < 15 FEET NOT -RATED 0 HOURS ≥ 15 FEET OPENINGS (DETACHED DWELLINGS) NOT ALLOWED N/A < 3 FEET 15% MAX. WALL AREA 0 HOURS 3 FEET ≤ X < 7 FEET UNLIMITED 0 HOURS ≥ 7 FEET OPENINGS (ATTACHED DWELLINGS) NOT ALLOWED N/A <5 FEET 15% MAX. WALL AREA 0 HOURS 5 FEET ≤ x < 15 FEET UNLIMITED 0 HOURS ≥ 15 FEET PENETRATIONS ALL PER SECTION R302.4 < 3 FEET NONE REQUIRED ≥ 3 FEET

Required Fire Separation between units:

R302.2 TOWNHOMES: Townhomes (vertically attached) shall be separated by a masonry wall or three (3) wall system with the center wall having a two (2) hours fire resistance rating and shall be continuous from the foundation to the underside to the fire retardant roof sheathing installed per Sections 705, 706 and 708 of IBC and as required further by this code. The two (2) hour fire resistance rated wall shall not be penetrated. R302.2.1 TOWNHOMES IN PLANNED UNIT DEVELOPMENTS: Planned Unit Developments (P. U. D's) of single family vertically attached townhouse units (R-3), may use a two (2) hour fire rated non-combustible wall assembly when located on a lot line between units. Exterior walls when located on or near lot lines and open to a separate non-buildable lot of at least 30' in width used as a common yard or open to a public way (street), may have zero (0) hours fire rating when located within the same P. U. D. R302.3 TWO-FAMILY DWELLINGS (DUPLEXES): Vertically attached dwelling units in two-family dwellings shall be separated by a masonry wall or three (3) wall system, same as required for Townhomes in section R302.2 above. Stacked (horizontally attached) two-family dwelling units must comply with the requirements of IBC as amended in VC-5-1-13.

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Townhomes

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Townhomes

Required Fire Separation between units:

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

TABLE R302.6 DWELLING GARAGE SEPARATION Must provide minimum of 5/8” Type “X” Gypsum Board or Equal to Garage Side

SEPARATION MATERIAL FROM RESIDENCE AND ATTICS NOT LESS THAN 5/8” TYPE X GYPSUM BOARD OR EQUIVELANT APPLIED TO THE GARAGE SIDE FROM HABITABLE ROOMS ABOVE GARAGE NOT LESS THAN 5/8” TYPE X GYPSUM BOARD OR EQUIVELANT APPLIED TO THE GARAGE SIDE STRUCTURE SUPPORTING FLOOR/CEILING USED FOR SEPARATION REQUIRED BY THIS SECTION NOT LESS THAN 5/8” TYPE X GYPSUM BOARD OR EQUIVELANT APPLIED TO THE GARAGE SIDE DETACHED/PARTIALY DETACHED GARAGES LOCATED LESS THAN 10 FEET FROM DWELLING UNIT ON SAME LOT NOT LESS THAN 5/8” GYPSUM BOARD APPLIED TO THE INTERIOR SIDE OF GARAGE

Interior Light and Vent Requirements :

R303.1.1 BASEMENT NATURAL LIGHT: A minimum natural lighting of 2% of the floor areas is required for basements. Habitable spaces in finished basements must follow section R303.1 for habitable rooms for minimum light and ventilation requirements. Exception: Portions of basements only housing mechanical equipment not exceeding 200 square are not required to meet the 2% natural light requirement. R303.3 BATHROOMS: Bathrooms, water closet compartments and other similar rooms shall be provided with aggregate glazing area in windows of not less than 3 square feet (0.3 m2), and with mechanical ventilation with minimum local exhaust rates determined in accordance with Section M1507. Exhaust air from the space shall be exhausted directly to the outdoors. Exception: The glazed areas shall not be required where artificial light is provided per section R303.1.” M1503.1 KITCHEN EXHAUST: Kitchen shall be provided with mechanical exhaust ventilation. Mechanical ventilation shall be provided in accordance with the mechanical code as referenced in Title 5, Chapter 6 of the Village Code. Residential kitchen range hood and exhaust duct must be of a smooth hard non-combustible material such as galvanized sheet metal, stainless steel, aluminum or copper. All range hood exhaust shall be vented to the exterior with the joints sealed using a material that is suitable for a long term exposure. Backdraft dampers are required to prevent infiltration of outdoor air when the exhaust system is not operating. Kitchen exhaust duct shall not terminate within the building. M1507.2 MECHANICAL VENTILATION AND THE RECIRCULATION OF AIR: Recirculation of air from kitchens, toilet rooms, bathrooms, restrooms, locker rooms, storage areas, laboratories, garages , laundry rooms, closets, and similar rooms shall not be permitted.

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Guardrails and Handrails Requirements :

R311.7.8 HANDRAILS: Handrails shall be provided on not less than one side

• f each continuous run of treads or flight with four or more risers.

R311.7.8.2 CONTINUITY: Handrails for stairways shall be continuous for the full length of the flight, from a point directly above the top riser of the flight to a point directly above the lowest riser of the flight. Handrail ends shall be returned or shall terminate in newel posts or safety terminals. Handrails adjacent to a wall shall have a space of not less than 11/2 inches (38 mm) between the wall and the handrails. Exceptions:

• 1. Handrails shall be permitted to be interrupted

by a newel post at the turn.

• 2. The use of a volute, turnout, starting easing or

starting newel shall be allowed over the lowest tread.

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

R312.1.1 GUARDS – WHERE REQUIRED: Guards shall be located along open-sided walking surfaces, including stairs, ramps and landings, that are located more than 30 inches measured vertically to the floor or grade below at any point within 36 inches horizontally to the edge of the open side. Insect screening shall not be considered a guard.

Basement Emergency Escape and Rescue Openings:

R310.1 Emergency escape and rescue opening required: Basements, habitable attics, and every sleeping

room shall have not less than one operable emergency escape and rescue opening. Where basements contain one or more sleeping rooms, an emergency escape and rescue opening shall be required in each sleeping room. Emergency escape and rescue openings shall open directly into a public way, or to a yard or court that opens to a public way.

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Per 2015 IRC Code Commentary – “Where a basement contains sleeping rooms and a habitable space, an emergency escape and rescue opening is required in each sleeping room, but is not required in adjoining areas of the basement”. Required Emergency Window Required Emergency Window No additional emergency window required out of the adjoining area

Minimum size of Single Family Residences:

R304.4 MINIMUM FLOOR AREA FOR DWELLINGS: The minimum floor area above grade for single and multi-family dwellings, excluding the garages, based on the appropriate Zoning district shall be as required in Sections R304.4.1 through R304.4.5. R304.4.1 DISTRICT E-1 (SINGLE FAMILY):

One story and split level type to contain 2000 square feet. One story raised ranch main floor area to contain 2000 square feet. Two story to contain 2600 square feet with a minimum of 1400 square feet of said floor area to be on the first floor.

R304.4.2 DISTRICT R-1 (SINGLE FAMILY):

One story and split level type to contain 1800 square feet. One story raised ranch main floor area to contain 1800 square feet. Two story to contain 2400 square feet with a minimum of 1200 square feet of said floor area to be on the first floor.

R304.4.3 DISTRICT R-2 (SINGLE FAMILY):

One story and split level type to contain 1600 square feet. One story raised ranch main floor to contain 1600 square feet. Two story to contain 2200 square feet with a minimum of 1100 square feet of said floor area to be on the first floor.

R304.4.4 DISTRICT R-3 (SINGLE FAMILY DETACHED AND ATTACHED):

Detached One story and split level type to contain 1400 square feet. Detached One story raised ranch main floor to contain 1400 square feet. Detached Two story to contain 2000 square feet with a minimum of 1000 square feet of said floor area to be on the first floor. Attached One story and split level type to contain 1000 square feet. Attached One story raised ranch main floor to contain 1000 square feet. Attached Two story to contain 1400 square feet with a minimum of 800 square feet of said floor area to be on the first floor.

R304.4.5 DISTRICT R-4 (SINGLE FAMILY ATTACHED AND DETACHED AND MULTI-FAMILY):

Detached: See Section R304.4.4 Attached (Townhomes) One story and split level type to contain 1000 square feet. Attached (Townhomes) One story raised ranch main floor to contain 1000 square feet. Attached (Townhomes) Two story to contain 1400 square feet with a minimum of 800 square feet of said floor area to be on the first floor.

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Single-Family Garages:

R309.1 MAXIMUM GARAGE SIZE:

• 1. Attached garages shall not exceed 50% of first floor gross area of the entire building including the

garage, with the maximum size of the garage not to exceed 1,500 square feet.

• 2. Detached garages shall be limited in size based on zoning district as follows:
• a. In Zoning Districts R4, R3, R2, detached garage shall not exceed 720 square feet.
• b. In Zoning District R1, detached garage shall not exceed 800 square feet.
• c. In Zoning District E1, detached garage shall not exceed 1,000 square feet.

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

13 feet Maximum height to mean height of roof Detached garages over 720 square feet may be required to have 42” trench foundation instead of slab-on-grade allowed for smaller garages R309.1.1 FLOOR SURFACE: Garage floor shall be constructed of concrete 5” thick with welded wire mesh or fiber reinforcement, and sloped to facilitate movement of liquids towards garage entry door.

Foundation Requirements:

R403.1.1 PRESCRIPTIVE FOOTINGS FOR LIGHT FRAME CONSTRUCTION: Footings supporting light frame construction shall be 20” wide and 10” thick minimum, with soil bearing capacity 3000 psf or greater. Footings placed on soil with bearing capacity

• f less than 3000 psf shall be engineered and

designed by a registered design professional and plans submitted for review to the building official. All basement walls shall be designed by a licensed design professional . R403.1.4 FOOTINGS – MINIMUM DEPTH BELOW GRADE: Exterior footings, foundation walls, piers, and other permanent supports of buildings and structures shall be protected from frost by placement at not less than 42 inches below the undisturbed ground surface. Exceptions: Detached garages less than 720 square feet in area, and detached storage sheds not exceeding 200 square feet. Foundation erected on solid rock.

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

12” deep min.

• Detached garages
• Sheds

42” deep min. 12” thick min.

• 1-story additions without brick,

under 400 sq. ft. or smaller

• 3-season rooms
• Enclosed porches with windows

and/or knee walls over 18” high

• Detached garages over 720 sq. ft

42” deep min. 10” thick foundation wall and 10x20” spread footing

• Additions with brick
• New Residential Construction

42” deep min. 10” diameter min.

• Open decks
• Patio covers, gazebos, pergolas
• Open (or screened-in) porches with

knee walls less than 18” high. Monolithic Slab

• n Grade with

downturned footing Trench footing, with or without monolithic slab Foundation wall with spread footing Pier foundation

Foundation Requirements:

DELETE SECTION R403.2 in its entirety (“FOOTINGS FOR WOOD FOUNDATIONS”) DELETE SECTION R403.3 in its entirety (“FROST PROTECTED SHALLOW FOUNDATIONS”) DELETE SECTION R404.1.2 in its entirety (“DESIGN OF MASONRY FOUNDATION WALLS”) DELETE SECTION R404.1.5.3 in its entirety (“PIER AND CURTAIN WALL FOUNDATIONS”) DELETE SECTION R404.2 in its entirety (“WOOD FOUNDATION WALLS”)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

NOT ALLOWED WOOD FOUNDATIONS CMU FOUNDATIONS SHALLOW FOUNDATIONS

Wood Framing – Span Tables updated:

Example of span reductions for decks

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Southern Yellow Pine and Douglas Fir-Larch joist spans have been reduced by up to 15% Canadian Lumber, if specified and used to achieve spans greater than revised span tables, will require contractor to provide PO or documentation

Wood Framing – Fire Protection of Floors (TJI’s, trim joists, open web trusses):

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

R302.13 FIRE PROTECTION OF FLOORS: Floor assemblies that are not required elsewhere in this code to be fire-resistance rated, shall be provided with a ½” gypsum board membrane, 5/8” wood structural panel membrane, or equivalent

• n the underside of the floor framing member. Penetrations or openings for

ducts, vents, electrical outlets, devices luminaires, wires, speakers, drainage, piping and similar openings shall be permitted. Exceptions:

• 1. Floor assemblies located directly over a space protected by an automatic

sprinkler system in accordance with section NFPA 13D, or other approved equivalent sprinkler system.

• 2. Floor assemblies located directly over a crawl space not intended for storage
• r fuel-fired appliances.
• 3. Portions of floor assemblies shall be permitted to be unprotected where

complying with the following: 3.1 The aggregate area of the unprotected portions does not exceed 80 SF 3.2 Fireblocking in accordance with Section R302.11.1 is installed along the perimeter of the unprotected portion to separate the unprotected portion from the remainder of the floor assembly

• 4. Wood floor assemblies using dimensional lumber or structural composite

lumber equal to or greater than 2x10 nominal dimension, or other approved floor assemblies demonstrating equivalent fire performance.

Wood Framing – Exterior Decks

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Section R507 Exterior Decks:

New section in 2015 IRC to allow for prescriptive design of decks. Amended by Village of Orland Park as follows:

R508.1 SIZE OF DECKS - PERSCRIPTIVE: Decks which are more 500 square feet, or measure more than 9 feet in height from finished grade to the deck level shall be designed by a licensed architect or structural engineer/design professional.

Brick Requirement – New Construction and Additions

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

R703.8 ANCHORED STONE AND MASONRY VENEER: All single family

attached and detached residences shall contain anchored brick, stone

• r masonry veneer, with a minimum 2.625" thickness on a minimum
• f 90% of their first floor and walk out area/ground level elevations,

and a minimum of 50% of all elevations. Any other material exceeding the 10% for the remaining ground level wall surfaces shall be approved by the code official. EXCEPTIONS: Existing residential developments constructed where original buildings were of non-masonry exterior finishes may permit the use of other code approved materials under the following conditions:

• a. Where the building’s total floor area is not being increased by

more than 50% of the existing building’s floor area.

• b. Where the building’s 50% floor area allowance is regarded as the

total combined floor areas of all additions made to the residence within a 36 month consecutive time period. c. As may be permitted per the Land Development code for the Historic Preservation Standards. The Land Development Code (Zoning Ordinance) section

Other amendments and requirements

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

R408.4 CRAWLSPACE ACCESS: Access shall be provided to crawl spaces by a minimum opening size of 24 inches by 24 inches, but not less than what would be required to remove and install any equipment taken out. R303.10.1 AIR-BORNE NOISE: Walls, partitions and floor/ceiling assemblies, separating dwelling units from each other or from public or service areas shall have a sound transmission class (STC) of not less than 50 for air-borne noise when tested in accordance with ASTM E90. This requirement shall not apply to dwelling unit entrance doors; however, such doors shall be tight fitting to the frame and sill. Masonry walls shall be calculated in accordance with TMS 0302 or as determined by through testing in accordance with ASTM E 492. A reduction is allowed to be reduced to an STC of 45 when the assembly is field tested by approved methods. R303.10.2 STRUCTURE BORNE SOUND: Floor/ceiling assemblies between dwelling units or between a dwelling unit and a public or service area within the structure shall have an impact insulation class (IIC) rating of not less than 50 when tested in accordance with ASTM E492. A reduction is allowed to be reduced to an IIC of 45 when the assembly is field tested by approved methods. R602.1.8.1 WOOD STRUCTURAL PANELS: Exterior wall sheathing shall be 7/16” thick min. R703.2 WATER-RESISTIVE BARRIER: One layer of No. 15 asphalt felt, free from holes and breaks, complying with ASTM D 226 for Type 1 felt or

• ther approved water-resistive barrier shall be applied over sheathing of all exterior walls. Such felt or material shall be applied horizontally,

with the upper layer lapped over the lower layer not less than 2 inches (51 mm). Where joints occur, felt shall be lapped not less than 6 inches (152 mm). The felt or other approved material shall be continuous to the top of walls and terminated at penetrations and building appendages in a manner to meet the requirements of the exterior wall envelope as described in Section R703.1. R703.9.2.1 EIFS WITH DRAINAGE: Special inspection shall be required for any EIFS installations having a total area greater than 1,000 sq. ft. R803.2.4 MINIMUM THICKNESS FOR ROOF SHEATHING: Roof sheathing shall be at least 7/16” thick and shall have permanent grade mark specifying grade and performance category. Roof sheathing spans shall not exceed values set forth in Table R503.2.1.1(1). BEDROOM (Definition) : A room within a dwelling unit capable of being used for sleeping purposes and having a closet.

Energy Code Requirements (Amendments to 2015 IECC / 2015 IRC)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

IRC CHAPTER 11 – ENERGY EFFICIENCY That Chapter 11 shall be revised in its entirety to read as follows: R1101.1 SCOPE: Buildings shall be designed and constructed in accordance with the 2015 International Energy Conservation Code (Climate Zone 5A), as regulated by the State of Illinois with the following Village of Orland Park amendments. R1101.2 MENDATORY MINIMUM R-VALUES: The building thermal envelope shall meet the prescriptive requirements of Table R1101.2 (R402.1.2 IECC) as amended below. Simulated Performance Alternative method of compliance is not permitted in lieu of minimum R-values for specific components listed in the amended Table R1101.2

Energy Code updates (Amendments to 2015 IECC / 2015 IRC)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

TABLE R1101.2 (IECC R402.1.2) INSULATION AND FENESTRATION REQUIREMENTS BY COMPONENT

FENESTRATIO

N U-FACTOR SKYLIGHT U-FACTOR CEILING R- VALUE WOOD FRAME WALL R- VALUE MASS WALL R- VALUE FLOOR R-VALUE BASEMENT WALL R-VALUE SLAB R-VALUE & DEPTH CRAWL SPACE WALL R-VALUE

0.32 b 0.55 b 49 20 13+5CI h 13/17 i 30 g 10/13 c 10/15 d 2ft 10/19 c

• a. R-values are minimums. U-factors and SHGC are maximums. When insulation is installed in a cavity which is less than the label or design

thickness of the insulation, the installed R-value of the insulation shall not be less than the R-value specified in the table.

• b. The fenestration U-factor column excludes skylights. The SHGC column applies to all glazed fenestration. Exception: Skylights may be

excluded from glazed fenestration SHGC requirements in climate zones 1 through 3 where the SHGC for such skylights does not exceed 0.30.

• c. “15/19” means R-15 continuous insulation on the interior or exterior of the home or R-19 cavity insulation at the interior of the

basement wall. “15/19” shall be permitted to be met with R-13 cavity insulation on the interior of the basement wall plus R-5 continuous insulation on the interior or exterior of the home. “10/13” means R-10 continuous insulation on the interior or exterior of the home or R- 13 cavity insulation at the interior of the basement wall.

• d. R-5 shall be added to the required slab edge R-values for heated slabs. Insulation depth shall be the depth of the footing or 2 feet,

whichever is less in Climate Zones 1 through 3 for heated slabs.

• e. There are no SHGC requirements in the Marine Zone. (Not Applicable)
• f. Basement wall insulation is not required in warm-humid locations as defined by Figure R301.1 and Table R301.1. (Not Applicable)
• g. Or insulation sufficient to fill the framing cavity, R-19 minimum.
• h. The first value is cavity insulation, the second value is continuous insulation, so “13+5” means R-13 cavity insulation plus R-5 continuous

insulation.

• i. The second R-value applies when more than half the insulation is on the interior of the mass wall.

Energy Code updates (2015 code changes)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

N1101.14 (R401.3) Certificate (Mandatory). A permanent certificate shall be completed by the builder or registered design professional and posted on a wall in the space where the furnace is located, a utility room or an approved location inside the building. Where located on an electrical panel, the certificate shall not cover or obstruct the visibility of the circuit directory label, service disconnect label or other required labels. The certificate shall list the predominant R-values of insulation installed in or on ceiling/roof, walls, foundation (slab, basement wall, crawl space wall and/or floor) and ducts outside conditioned spaces; U-factors for fenestration and the solar heat gain coefficient (SHGC) of fenestration, and the results from any required duct system and building envelope air leakage testing done on the building. Where there is more than one value for each component, the certificate shall list the value covering the largest area. The certificate shall list the types and efficiencies of heating, cooling and service water heating equipment. Where a gas-fired unvented room heater, electric furnace, or baseboard electric heater is installed in the residence, the certificate shall list "gas-fired unvented room heater," "electric furnace" or "baseboard electric heater," as appropriate. An efficiency shall not be listed for gas- fired unvented room heaters, electric furnaces or electric baseboard heaters. N1103.5.3 (R403.5.3) Hot water pipe insulation (Prescriptive): Insulation for hot water pipe with a minimum thermal resistance (R-value) of R-3 shall be applied to the following:

• 1. Piping 3/4 inch (19 mm) and larger in nominal diameter.
• 2. Piping serving more than one dwelling unit.
• 3. Piping located outside the conditioned space.
• 4. Piping from the water heater to a distribution manifold.
• 5. Piping located under a floor slab.
• 6. Buried in piping.
• 7. Supply and return piping in recirculation systems
• ther than demand recirculation systems.

Plumbing Code Requirements (Amendments to 2014 Illinois Plumbing Code)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

VC 5-4-1-1: DELETIONS: The following Sections or Subsections are not adopted and are specifically excluded in their entirety, unless otherwise specified:

• 1. Section 890.320(1) (2) Joints and Fittings in Plastic Pipe for potable water.
• 2. Section 890. Appendix A, Table A, Approved Building Drainage/Vent Pipe, Item

12 reference to Polyvinyl Chloride (PVC) Pipe with Cellular Core only and footnote 4.

• 3. Section 890, Appendix A, Table A, Approved Materials for Water Service Pipe,

Items 1, 4, 7, 8, 9, 10, 11 and 12.

• 4. Section 890, Appendix A, Table A, Approved Materials for Water Distribution

Pipe, Items 2, 5, 7, 8 and 9. (Ord. 5002, 7-6-15) VC 5-4-1-2: MODIFICATIONS: The following Sections shall be amended in the following respects:

• 1. Section 890.310 shall be amended to add at the end of the section the following

words: "All copper water tubing, when installed underground shall be a minimum of Type K, and when above grade shall be a minimum of Type L."

• 2. Section 890.330(c) shall be amended to delete the reference to CPVC for

potable water applications.

• 3. Section 890.340 f) Copper water tube is to be amended to add the following

language at the end of the subsection:

• a. Flared joint adapter shall be required at all water service supply lines two (2)

inch or less with full port ball valve upstream of water meter.

• b. Soldered and/or braised fittings shall not be installed below grade. (Ord. 5002,

7-6-15)

Plumbing Code Requirements (Amendments to 2015 IRC)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

VC 5-4-1-3: SECTION ADDITIONS: The following new Sections or Subsections shall be added at the appropriate location in their entirety:

• 1. Section 890.420 (a) (6) Pipe Cleanouts

On multiple units with slab on grade construction a cleanout shall be extended to the exterior of foundation at end of building drain run(s) where feasible.

• 2. Section 890.1360 - Sanitary wastes below sewer: b) Design: add at

end subsection no sump or ejector basin shall be less than 30" deep with minimum 14" sump below inlet pipe invert or of approved design specified by the manufacturer. (Ord. 5002, 7-6-15) P3302.1 SUBSOIL DRAINS: Subsoil drains shall discharge no closer than 10 feet from any property line, and shall not create a nuisance to adjacent properties or the public right of way. (Note that Village is considering additional amendment to the above, requiring all subsoil drains to be routed to the front or rear of the property) P3303.1.2 SUMP PIT: Sump pit shall be 30” deep and top of sump pit shall extend 2” above adjacent floor finish.

Plumbing Code Requirements – WaterSense

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

VC 5-4-3: SECTION ADDITIONS: WATER CONSERVATION: …..All new plumbing fixtures and irrigation controllers installed after the effective date of this ordinance shall bear the WaterSense label (as designated by the U.S Environmental Protection Agency WaterSense Program), when such labeled features are available. ARCHITECT’S PLANS MUST SPECIFY REQUIREMENT FOR WATERSENSE FIXTURES FOR FOLLOWING LOCATIONS:

• WATER CLOSETS (WATERSENSE)
• LAVATORIES (WATERSENSE)
• SHOWERS (WATERSENSE)
• LAWN SPRINKLERS (WATERSENSE)
• DISHWASHERS (ENERGY STAR)
• CLOTHES WASHERS (ENERGY STAR)

CONTRACTOR TO DEMONSTRATE COMPLIANCE IN ONE OF TWO WAYS:

• ORIGINAL FIXTURE PACKAGING WITH

LABEL TO BE ON SITE DURING FINAL INSPECTON OR

• SUBMIT PURCHASE ORDER ALONG

WITH MANUFACTURER SPECS

Mechanical Requirements (Amendments to 2015 IRC)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

DELETE SECTION G2425.8 ITEMS # (5), (6), (7) ONLY ("Appliances not required to be vented") DELETE SECTION G2445 IN ITS ENTIRTEY ("UNVENTED ROOM HEATERS").

• UNVENTED GAS HEATERS ARE NOT

ALLOWED

• GARAGE EXHAUST FANS ARE NO

LONGER REQUIRED

Electrical Requirements (Amendments to 2014 NEC)

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

210.12 ARC FAULT CIRCUIT INTERRUPTER PROTECTION: (A) Dwelling Units: All 120-volt, single phase, 15- and 20 ampere branch circuits supplying outlets in dwelling unit family rooms, dining rooms, living rooms, parlors, libraries, dens, bedrooms, closets, hallways, recreation room, and sunrooms, or similar room or areas shall be protected by listed arc-fault circuit interrupter, combination combination-type, installed to provide protection of the branch circuit. 210-52(c) COUNTER TOPS / ISLANDS: (c) In kitchens and dining areas of dwelling units, a receptacle outlet shall be installed at each counter space wider than 12 inches. Receptacles shall be installed so that no point along the wall line is more than 24 inches, measured horizontally from a receptacle outlet in that space. Island counter tops 12 inches or wider shall have at least one receptacle for each four feet counter top. Counter top spaces separated by range tops, refrigerators, or sinks shall be considered as separate counter top spaces. Receptacles rendered inaccessible by appliances fastened in place or appliances

• ccupying dedicated space shall not be considered as these required outlets

230-70(D). SERVICE LOCATION: The location of the underground service and meter for new subdivisions shall be approved by the Electrical Inspector prior to installation. (Typically the electrical service feeds must enter on side of house, as this allows the service line to be located in the utility easement )

2015 RESIDENTIAL CODE UPDATES – ANY QUESTIONS?

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

COMMON ISSUES

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• DEVELOPMENT
• ZONING
• BUILDING
• ELECTRICAL
• MECHANICAL
• PLUMBING
• ACCESSORY STRUCTURES
• PROPERTY MAINTENANCE

Common Issues - Development

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

New Subdivisions

• Must have all approvals from Planning Department and MWRD before applying for building permits
• Discuss issues of lot coverage, setbacks, building heights with Planning staff before finalizing the

development agreement. Impact and Water Connection Fees

• Impact fees are assessed according to the rates agreed on in the development agreement
• If agreement has expired, fees will be assessed based on prevailing rates as required by current code

at time of permit issuance for each individual lot.

• Fees for schools and parks are based on number of bedrooms in the house. Note that any room

with a closet that could be used for sleeping purposes is considered a bedroom, regardless of how its labeled on the plans. Model Plans and Building Codes

• We are open to accommodating builders with model / prototype plans for larger subdivisions to

eliminate the requirement for separate full size plan submittal with each building permit.

• Typically homes must follow whatever building/zoning code is in effect at time of permit submittal.

If we are nearing a next code update, discuss the possible ramifications with the Zoning/Building Official

DEVELOPMENT

Common Issues - Zoning

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

LOT COVERAGE

• Most new single family houses are located in R-3 zoning district – limiting lot coverage to

40% of the lot area

• This is a problem with large homes on relatively small lots with large in-ground pools and

patios – educate your customers regarding this prior to them wanting a pool permit

• Permeable pavers must allow storm water to percolate into the ground below – applicant

must submit cut sheet and product info for approval prior to installation if utilizing permeable paver lot coverage bonus of additional 5%. Zoning District

• Max. Lot

Coverage w/ side load garage w/ Side load garage and permeable pavers E1 25% 25% 30% R1 35% 35% 40% R2 35% 38% 43% R3 40% 43% 48% R4 45% 45% 50%

ZONING

Common Issues - Zoning

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

BUILDING HEIGHT

• Most new single family houses are located in R-3 zoning district –

limiting building height to 30 feet.

• Following scenarios require closer scrutiny:

3-story houses Lookout and walk-out basements Houses with high slope roofs Houses with high ceilings in the basement

• Height is measured from average grade plane to the mean height of

highest roof structure

Zoning District Max. Building Height E1 35 FT R1 35 FT R2 35 FT R3 30 FT R4 30 FT

3-CAR GARAGES in R3 zoning districts

• Allowed to face the front, with a 3 feet offset for 3rd bay
• Allowed to face corner side, with a 1 foot offset for 3rd

bay.

• No offset required for 3rd bay if side-loaded and facing

interior lot line.

ZONING

Common Issues - Zoning

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

BUILDING SETBACKS – R3 ZONING DISTRICT FRONT SETBACKS

• Code changed - Setback has been reduced from 30 feet to 25 feet for R-3 zoning district
• The 5 ft garage encroachment allowance has been removed from code

SIDE SETBACKS

• Required minimum side setback is 10% of lot width, but not less than 8 feet
• Any lot which is less than 80 feet wide, must still maintain a minimum 8 feet side setback

IRREGULAR LOTS

• Ask for code interpretation on required setbacks prior to customer settling on a house design (or lot

purchase)

• Typically, narrowest side of corner lot facing the ROW is considered the “front” yard, regardless of

which way the house faces or street address. ZONING VARIANCES

• Exceeding the setbacks, lot coverage, height, and similar zoning code issues requires a Minor Zoning

Variance

• Public hearing process, with required notification of neighbors within 300 feet of subject property
• Applicant must demonstrate a unique hardship. If reason applies to other residents, it’s not unique.

ZONING

Common Issues – Building Code

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

3-STORY STRUCTURES (ATTACHED & DETACHED)

• Must use type 5A construction as defined by International Building Code or must be fully fire

sprinklered with a NFPA 13D system

• Habitable attics are considered a story, unless they qualify as mezzanine
• Basements with high ceilings could be considered story above grade if first floor above is elevated

above adjacent grade plane

3 STORY 3 STORY 2 STORY WITH MEZZANINE

ATTIC HABITABLE HABITABLE HABITABLE ATTIC HABITABLE HABITABLE HABITABLE MEZZANINE HABITABLE HABITABLE HABITABLE BASEMENT (BASEMENT IS CONSIDERED STORY ABOVE GRADE)

BUILDING

Common Issues – Building Code

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

FIRE SEPARATION DISTANCE (SETBACK TO PROPERTY LINES)

• Regardless of zoning requirements, single family detached houses must be at least 7 feet away from

property line

• If setback is less than 7 feet, then exterior walls must be 1-hour fire rated for exposure from both

sides

• If setback less than 3 feet, then exterior wall must be 2-hour rated for exposure from both sides,

and no windows

• Architect must show appropriate UL-listed fire rated wall assembly on plans
• Contractor must schedule an extra inspection for “screw pattern” prior to taping and mudding for

each layer of gypsum board.

BUILDING

Common Issues – Framing

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

REDUCED SPAN TABLES – 2015 IRC and American Wood Council NDS Design Values Supplement

• Architects and contractors should double check that floor joists, ceiling joists and roof rafters comply

with new reduced span tables, especially for wood sizes spanning close to their maximum HEIGHT OF UNBRACED WALL FRAMING

• Studs must be continuous on gable ends and at

double height spaces unless braced with a floor, ceiling or roof diaphragm at 10 feet height (for load bearing walls) or 20 feet height (non-load bearing) when using 2x6 lumber.

• Tall walls exceeding these heights, without

bracing will need a structural design from architect to resist lateral wind loads and buckling. SILL PLATE ANCHORS - LOCATION

• Must be located in the middle third of sill plate

width.

BUILDING

Common Issues – Framing

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

OVER NOTCHING – LOAD BEARING

• Bored hole max. diameter 40%
• f stud depth
• Min. distance to edge from

bored hole – 5/8”

• Notching not to exceed 25% of

stud depth

• Use stud shoes as required to

reinforce studs HURRICANE CLIPS

• Install hurricane clips at every

truss

BUILDING

Common Issues – Framing

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

RIDGE BEAM VS. RIDGE BOARD

• Vaulted ceilings must provide a means to

resist the outer thrust of roof rafters

• Rafter ties (spaced 48” O.C. and

located in lower 1/3 of rafters)

• r
• Ridge designed as beam, transferring loads

to built-up post at both ends

BUILDING

Common Issues – Window Fall Protection

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

R312.2.1 Window Sills

In dwelling units, where the top of the sill of an operable window opening is located less than 24 inches above the finished floor and greater than 72 inches above the finished grade or other surface below on the exterior of the building, the operable window shall comply with one of the following:

• 1. Operable windows with opening

that will not allow a 4-inch diameter sphere to pass through.

• 2. Operable windows that are

provided with window fall prevention devices per ASTM F 2090

• 3. Operable window that are

provided with window opening control devices per R312.2.2.

BUILDING

Common Issues – Safety Glazing

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

BUILDING

Common Issues – Safety Glazing

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

BUILDING

Common Issues – Retaining Walls, Guardrails, Handrail

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

RETAINING WALLS:

• 3 FEET MAXIMUM HEIGHT
• MUST BE TIERED IF HEIGHT EXCEEDS 3

FEET

• 3 FEET MINIMUM SETBACK TO

PROPERTY LINES, BUT CANNOT OBSTRUCT STORMWATER DRAINAGE

• NEED VOP ENGINEERING APPROVAL

AND SUBMITTAL OF GRADING PLAN IF LOCATED IN EASEMENTS GUARDRAILS REQUIRED:

• WHEN WALKING SURFACE IS LOCATED

NEXT TO A FALL HAZARD EXCEEDING 30” IN HEIGHT

• GUARDAIL TO BE 36” HIGH MIN.
• HANDRAIL REQUIRED FOR STAIRS WITH

4 RISERS OR MORE

BUILDING

Common Issues – Energy

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. Simulated Performance Alternative method not allowed! – Must follow

prescriptive insulation values for exterior envelope

FENESTRATIO N U-FACTOR SKYLIGHT U-FACTOR CEILING R- VALUE WOOD FRAME WALL R- VALUE MASS WALL R- VALUE FLOOR R-VALUE BASEMENT WALL R-VALUE SLAB R-VALUE & DEPTH CRAWL SPACE WALL R-VALUE

0.32 b 0.55 b 49 20 13+5CI h 13/17 i 30 g 10/13 c 10/15 d 2ft 10/19 c

PRESCRIPTIVE REQUIREMENTS (REQUIRED):

• WALLS – R20 MIN.
• BASEMENT WALLS – R10 FULL HEIGHT
• ATTIC – R49
• SLAB ON GRADE – R10 (2 FEET)
• WINDOWS – U –VALUE 0.32 OR BETTER

BUILDING

Common Issues – Energy

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. Heated slabs – require additional insulation

R5 insulation required under entire slab when heated R15 insulation required at edge of heated slab (2 feet) (instead R10 for unheated slab)

BUILDING

Common Issues - Electrical

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. Temper resistant outlets are required throughout

the house

• 2. At least one receptacle outlet is required for each

car space in garage

• 3. Electrical service should be located on the side of

house (not rear)

• 4. 200 amp service specified on most plans is often

insufficient for size of homes being built Any house with gross occupiable area over 4,500 square feet (including unfinished basements and attached garages) will require 400 Amp Service per new code

ELECTRICAL

Common Issues - Mechanical

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. Condensate discharge should drain by gravity

(Condensate pumps will only be allowed where gravity drain is technically infeasible)

• 2. Clearances for venting of high-efficiency direct vent

appliances to be per manufacturer listing

• 3. Mechanical outside air intake required unless every

habitable space is provided with natural ventilation

(damper is required for outdoor air intake, and finished basements almost always require mechanical source of outdoor air)

MECHANICAL

Common Issues - Plumbing

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. Type “L” copper (above ground) and Type “K” copper (below

grade) - required

• 2. Foam core PVC waste piping is not allowed
• 3. Sump pit to be 30” deep minimum for storm and sanitary,

and storm sump pit must terminate 2” above adjacent floor

• 4. WaterSense – provide appropriate documentation
• 5. Water temperature for showers must be set at the faucet

controls, not at the Water Heater – 115 degrees max.

• 6. Sewer and water inspections – make sure pipe is labeled, and

label faces up so inspector can verify material used

• 7. B-box should not be located in the driveway if possible
• 8. 10 feet separation required between service and sanitary

sewer where they exit the house

PLUMBING

Common Issues – Passive Radon System Requirements

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

• 1. Passive Radon Reduction System must be

installed in compliance with Illinois state laws, consisting of, but not limited to the following components:

• 1. 6 mil gas barrier under slab with 12” sealed
• verlaps sealing of all openings in basement

including the sump pit

• 2. Tape around all plumbing and column

penetrations with approved tape

• 3. 3” PVC vent piping terminating 12” above

highest roof eave and 10ft from openings, labeled at every level

• 4. Power source for future installation of fan

as part of active radon mitigation system

PLUMBING

Common Issues – Property Maintenance

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Construction Debris and Materials

• All materials must be kept on private property only, not ROW
• Daily cleanup of street required, keep materials orderly and protected from wind
• Citations will be issued and fines between $250-$1,000 per day can be assessed if building

materials or debris end up blown around the subdivision

• No burning of garbage, leafs, or construction debris

PROPERTY MAINTENANCE

Construction Fencing and Toilet Facilities

• Fencing is not required for single family

residences under construction

• Provide portable toilet on job site,

preferable not visible from the ROW Construction Hours – Noise Complaints

• 7 AM – 9:30 PM
• Keep construction traffic away from

residential areas, site should be accessed from arterial roads to extent possible.

Common Issues – Accessory Structures

ORLAND PARK

Development Services Department

14700 Ravinia Avenue . Orland Park, Illinois 60462 . Phone (708) 403-5300 . Fax (708) 403-6215 Website www.orlandpark.org . Email developmentservices@orlandpark.org

Applicable Codes

• Land Development Code – Section 6-302
• Permits required (unless approved as part of new single family home permit)
• Accessory structures are not allowed without primary structure on the lot
• Full list of accessory structures listing maximum size, height, and location. See few examples below

Driveways

• Width limited based on size of garage / doors – 20 ft for 1-car, 26 ft for 2-car, and 36 ft for 3-car
• Side loaded garage driveway must be at least 3 feet away from side property line
• Only one driveway per lot. Circular driveway allowed if lot is more than 90 feet wide

Patios, Terraces, Decks

• Must be at least 5 feet away from property lines

Sheds

• Maximum size – 100 sq. ft. (for lots over 10,000 sq. ft. size can be 1% of lot size w/ max. 200 sq. ft.)
• Allowed only in the rear yard

Swimming Pools

• Must be at least 10 feet from property lines and only in rear yards

ACCESSORY STRUCTURES
