Orchestrating an OpenStack DevOps Cloud for R&D to Achieve Continuous Delivery

Ting Zou & Tanay Nagjee – November 7, 2013

Introductions

2

Tanay Nagjee Solutions Engineer @ Electric Cloud Former ElectricCommander Engineer Ting Zou Director, Cloud Computing R&D Data Center Huawei USA

A privately-owned Global Company An ICT Industry Leader An Innovative Industry Contributor

This is Huawei

 A global company providing information

and communications technology (ICT) solutions.

 Products and solutions have been

deployed in 140+ countries, serving 1/3 of the world’s population.

 A privately-owned company founded in

1987, Shenzhen

A Privately-owned Global Company

5

Sustainable Growth

By BG (2012) By Region (2012)



2012 Revenue amounted to $35.4 billion, a YoY increase of 8%; net profit reached $2.47 billion



2012 USD 4.8 billion R&D investment



1H 2013, Revenue amounted to USD $18.5B, a YoY increase of 10.8%; Expected net profit margin of 7-8% in 2013. 73% 22% 5%

Carrier Network

25.7 bn

Consumer

7.8 bn

Enterprise

1.9 bn

Americas

5.1 bn

China

11.8 bn

Asia Pacific

6.0 bn

EMEA

12.5bn

15% 33% 17% 35%

Currency: USD Currency: USD

1.5Bn 2Bn 2.7Bn 3.8Bn 4.8Bn 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012

 2012 R&D investment: USD 4.8

billion, 13% of 2012 revenues

 70,000 R&D employees  16 R&D centers worldwide  28 joint innovation centers



41,948 patents in China, 12,453 international PCTs, 14,494 patents in outside of China.



US$300 million in patent royalties each year.



150+ standards organizations



30,000+ standards proposals

Accumulated R&D investments: USD 19

billion

Continuous Innovation Investment

Problem overview

What are we solving?

Large scale R&D environment with complicated tools requires multi- thousands of CPU cores available on demand.

8 120 10

Current Build Time Expected Build Time

300 9

Actual Time Engineering Expectation

5 Million LOC Build （unit: minute） 10 Million LOC code coverage testing report （unit：minute）

What are we solving?

Environment/tools provisioning is very time-consuming; lab asset utilization is low.

9

100 200 300 400 500 Current expected 480

20

environment provision

Current Provision time Expected Provision Time

10 2

Compile/Build environment Provision （unit：minute） Software Testing environment provision （unit：hour）

What are we solving?

R&D data grows rapidly; requires the flexibility of dynamically expanding PB storage capability.

10

500 1000 1500 2000 2500 2011年 2012年 1300

2500

500G 1000G daily execution data generated by daily build

Millions LoC build static analysis/ build coverage to generate PB data annually Data Generated by the Tools in Auto Testing/CI

What are we solving?

Integration between development and operation; DevOps enabled continuous delivery required.

11

Virtualization and cloud computing converged infrastructure Automatic provision and configuration management technology DevOps Cloud R & D requires multi-layer and multi- platform infrastructure Allow developers more control over the production environment Concise definition of R&D processes, automate as much as possible Bridging the gap between development and operations Globally distributed R&D teams

Solution overview

Virtualization/Cloud sounds like a good solution, but...

Servers CPUs Standard Enterprise Enterprise Plus 3000 6000 8 million US$ 20 million US$ 25 million US$

 To virtualize 3k 2-CPUs servers, commercial SW license + 1 year support is a big investment:  Shall we leverage low-cost(free) open source cloud OS to reduce R&D TCO?

Source: http://www.qyjohn.net

Choose OpenStack as the Provider of IAAS

Controller Node #3 Controller Quantum(A) Swift Swift-Proxy Private Switch (Network) External Switch (Network) Controller Node #2 Controller Quantum(A) Storage Node Swift Swift-Proxy iLCM (Lab Configuration Manager) Cobbler Chef Puppet etc In-House Dev Module Controller Node #1 Controller Quantum(A) vSwitch

• 8 Huawei RH2285(dual 6-cores CPUs, 96GB MEM, 8TB storage) servers used in PoC
• Openstack is provisioned and managed by Huawei iLCM(intelligent Lab Configuration Manager) with backend

integration with cobbler/chef/puppet open source tools

• Leverage the OpenStack open source community as much as we can (Devstack, Mirantis, RPC, Dell crossbar etc)

plus in house developed script modules, will contribute back to the community once it is ready.

Single Portal for Cloud Admin and Users

Cloud Admin Portal for users with different level of privileges, integrated with LDAP at the backend Cloud resource usage monitoring (Roadmap) Cloud VM provision and software configuration management Cloud Network, Storage and Security configuration management (Roadmap)

Cloud is free now, what else can be free?

Design sign modeling deling Code de analysis lysis CI CI Redmine dmine Func nc Testing ting Requi quirem rement nt Analysys alysys Proje

• ject

ct Mgmt SCM SCM Collabora llaboratio tio n Design sign Developme velopment nt Testing sting gUnit nit,cpp ,cppUnit Unit Automatio tomation n Framework mework Unit it Testing ting Selenium lenium Pef Pef Testing ting IOMeter Meter Others hers Hadoop doop Provision

• vision

Chef ef Travis avis-CI CI memcached mcached Github thub Reviewboa viewboard rd Trac ac Puppe ppet RabbitMQ bbitMQ ActiveMQ tiveMQ Hive ve、 HBase ase CFEngine Engine Subversio bversion Nagios gios Monitor nitor CloudStac

• udStack

OpenStack enStack Cloud

• ud Platform

tform Sourc urceFo eForge ge Jenkins nkins PcLint Lint valgrind lgrind Jmeter eter Mobit bitest est gMock

• ck,JMo

,JMock ck CppCheck pCheck Cpplint plint Page ge Speed ed JIRA RA GIT GIT Gerrit rrit Mercurial rcurial OpenGrok enGrok Bugzilla gzilla

HUDOS (Huawei Unified DevOps System) Technologies

Single Portal for R&D engineering

SaaS (instant creation of an environment with complete portfolio of common R&D tools) Lab topology creation with compute, network, storage etc (Roadmap) Project R&D data statistics monitoring Single dashboard portal for engineering to access all the needed resource/tools in R&D process

IaaS and PaaS enable DevOps-Engineering link

 R&D tools PaaS integrated with engineering desktop dashboard  IaaS integrated with engineering desktop dashboard

OpenStack integration

Electric Cloud’s Software Delivery System

Apps Continuous Delivery Manager

Release Trains | Feature Boards | Pipelines | Gates | Dashboards Workflow | Resource management I Tools integration | API | Security | Reporting

Automation & Acceleration Services

Software Delivery Platform

Platform

Build Automation CI Test Automation CT Build Acceleration Test Acceleration

Build Test Deploy

Deploy AutomationC D Infrastructure Provisioning

Before and After Electric Cloud

Issue

Before Electric Cloud After Electric Cloud Business Impact Develop to Deploy 90 Days 10 Minutes 99.93% Build to Release/Deploy 10+ errors/cycle ~0 errors/cycle 99+% Audit application changes (who, what, how, why, when) Days Minutes 90+% Time to troubleshoot problems 20 Days Minutes 99+%

OpenStack integration

23

OpenStack integration

24

OpenStack integration

25

OpenStack integration

26

OpenStack integration

27

Solution walk-through

Development Scenario

29

Reviewer Mike HUDOS Developer Joe

Eclipse

Modify code launch preflight

Subversion

Check out sources

• verlay deltas

Redmine

Mark issue as “build & unit test”

Jenkins

Launch build + test w/ preflight source

Redmine

Mark issue as “code review”

Review Board

Create review request

Redmine

Mark issue as “resolved”

Review Board

Review modified code

Build + test success? Review success?

Eclipse

Build + test failed; notify developer

Eclipse

Code rejected; notify developer

Eclipse

Success auto-commit code

Time Savings

Redmine: select a bug to fix

30

Eclipse: modify code & launch a preflight

31

Commander: SVN preflight & Jenkins launch

32

Redmine: auto-updated issue status

33

Jenkins: auto-launched build

34

Commander: build succeeds; wait for review

35

Review Board: auto-submitted review request

36

Review Board: accept the changes

37

Commander: the workflow succeeds

38

Eclipse: auto-commit the changes

39

Test Scenario

40

HUDOS Test Engineer Jill

Redmine

Mark issue as “verifying”

OpenStack

Provision specified virtual machines

Testing success?

OpenStack

Teardown virtual machines

Redmine

Mark issue as “closed”

Commander

Launch automated tests

Notification

Tests failed; VMs ready to inspect

Notification

Tests passed; issue closed

Commander

Pick issue to verify and tests cases

Time Savings

OpenStack: no dynamically deployed VMs

41

Commander: launch test workflow

42

Commander: provision VMs

43

OpenStack: VMs are dynamically deployed

44

Commander: successful tests; auto-teardown

45

Summary

武汉

深圳 ECTC 北京 ECTC 印度 ECTC 成都 ECTC 西安 ECTC 武汉 ECTC 上海 ECTC 苏州 ECTC 杭州 ECTC

What a DevOps Cloud brings to us

R&D Cloud Data Center facility to provide the capability of acceleration More than 2000 releases per year More than 50000 compile & builds per day More than 1million test cases run per day More than 30million LoC, product is complicated More than 480K code review/analysis per year More than 170k system integration testing per year

Design Develop Product Validation Solution Validation Architect Evaluation Code Analysis Compile & Build Hardware Emulation Full Functional Testing Solution Testing Hours-> Minutes Days-> Hours Weeks-> Days Hours-> Minutes Days-> Hours Months->Weeks Full Regression Testing(System) Days-> Hours Regression Testing(software) Days-> Minutes

Did we address the stated concerns?

• Large scale R&D environment with complicated tools requires

multi-thousands of CPU cores available on demand.

• Environment/tools provisioning is very time-consuming; lab asset

utilization is low.

• R&D data grows rapidly; requires the flexibility of dynamically

expanding PB storage capability.

• Integration between development and operation; DevOps enabled

continuous delivery required. Achievements:

• Reduced cost of delivering software
• Increased resource utilization and productivity
• Shorter time to market with higher quality

48

What’s next?

49

武汉

上海

南京 北京 西安

成都

深圳

Hangzhou: 400 + Server Size: 1600 + core, memory 10TB, Storage 500TB Shenzhen HQ: 2000+ Server Size: 10k+ core, memory 50TB, 1-2PB storage 杭州 Beijing: 200 + server Size: 800 core, memory 5TB, Storage 200TB R&D DATA CENTER 3000 + server, 15k + core, 10K + virtual machine memory 100TB, storage 2PB, reduce costs 2M US$

Thank you!
