S oot P article -AMS or or L aser V aporizer -AMS Aerodyne Research, Inc. et al. Outline SP-AMS technique and hardware Reference material SP-AMS applications Quick highlight a few applications SP-AMS quantification

slide-1
SLIDE 1

SootParticle-AMS

  • r
  • r

LaserVaporizer-AMS

Aerodyne Research, Inc. et al.

slide-2
SLIDE 2

Outline

  • SP-AMS technique and hardware
  • Reference material
  • SP-AMS applications
  • Quick highlight a few applications
  • SP-AMS quantification
  • Challenges and summary
slide-3
SLIDE 3

SP-AMS hardware

SP Module

Second vaporizer in AMS Different ionization chamber configuration Three potential vaporizer configurations

ADQ, ePTOF, BWP (ebox) upgrades

slide-4
SLIDE 4

Laser Vaporizer Module

Onasch et al. (AS&T 2012)

slide-5
SLIDE 5

Ionizer Configurations

HR-AMS (Tungsten vaporizer)

  • Filaments on sides of ion

chamber

  • Filament position is

mechanically set

  • Filament wire is typically well

positioned with respect to well formed slits in ion chamber walls

  • Narrow or Wide chamber widths

SP-AMS (Laser Vaporizer)

  • Filament is on bottom of ion

chamber

  • Filament position is moveable (vert

& horz)

  • Filament slit width and breadth

may vary due to custom procedure

  • Large holes in sides to

accommodate laser beam

  • Narrow or Wide chamber widths

Need to

  • ptimize

vertical position

slide-6
SLIDE 6

Vaporizer Configurations

  • 1. Tungsten Vaporizer (HR-AMS)
  • 2. Laser Vaporizer
  • 3. Laser + Tungsten Vaporizers
slide-7
SLIDE 7

SP-AMS Orthogonal Detection Axes

Sampled Particles Ion Extraction and MS detection

  • Characterization of particle-laser interaction region:
  • Vertical Particle Beam Walk
  • Horizontal/Vertical Beam Width Probe
  • Laser Beam Walk
slide-8
SLIDE 8

Laser Vaporizer Detection Scheme

The laser is not the vaporizer, the absorbing particles are the vaporizer!!

slide-9
SLIDE 9

Ambient Mass Spectrum

slide-10
SLIDE 10

Nomenclature

Corbin et al., 2014 - ETH

4000 oC

PM = Particulate Matter NR = Non-Refractory R = Refractory L = Light Absorbing (1064 nm) LR-PM:

  • 1. Refractory Black Carbon (rBC)
  • 2. Metals
slide-11
SLIDE 11

SP-AMS applications

Ambient rBC measurements (Massoli et al., 2015) Source characterization of laboratory metal nanoparticles (Nilsson et al., 2015) Dual vaporizer measurements including single particle detection (Lee et al., 2015)

slide-12
SLIDE 12

CalNex 2010 – Massoli et al., 2014 JGR

Separate instruments operated side-by-side:

  • SP-AMS laser vaporizer
  • HR-AMS tungsten vaporizer
slide-13
SLIDE 13

rBC particle chemical composition and size

  • Increasing Photochemical aging
  • Observations of secondary

condensation

  • Observations of compaction

and growth of rBC particles

slide-14
SLIDE 14

Direct comparison between rBC subset of particles and total aerosol loading

Chemical information Mass information

slide-15
SLIDE 15

Source characterization of metal nanoparticles – Nilsson et al., 2015 Nano Research

  • Chemical information,

including metal composition, oxide formation, and contaminants

slide-16
SLIDE 16

Source characterization of metal nanoparticles – Nilsson et al., 2015 Nano Research

  • Size and effective

density information

slide-17
SLIDE 17

Dual vaporizer measurements of ambient rBC particles – Lee et al., 2015 ACP

  • Single particle detection

allows for the measurement

  • f rBC particles even with dual

vaporizer configurations

slide-18
SLIDE 18

Average MS comparisons

  • Apparent increased sensitivity to NR-PM vaporized in laser vaporizer!
slide-19
SLIDE 19

SP-AMS Quantification

Sensitivities

Refractory black carbon (rBC) [Laser] Non-Refractory PM [Laser and Tungsten]

Collection Efficiencies

Tungsten Vaporizer Laser Vaporizer

slide-20
SLIDE 20

mIE calibrations

300 nm AN

NR-PM using tungsten vaporizer rBC using laser vaporizer

  • We need to include a third calibration: NR-PM for laser vaporizer!
slide-21
SLIDE 21

mIE NR-PM calibrations using laser vaporizer

  • Difficult, but not impossible
  • Two approaches attempted to date:
  • 1. Coat Regal black with DOS (Willis et al., 2014 AMT)
  • 2. Atomize ammonium nitrate with Regal black (Carbone et al., 2015 AMTD)
slide-22
SLIDE 22
  • Coated Regal black particles with

DOS to make spherical

  • With thicker coatings, RIE_rBC

increased as the particle beam narrowed down closer to laser beam width

  • Dual laser/tungsten vaporizer setup
  • Both rBC and Org ion signals

increased

  • NR-PM mIE for DOS appears to be

~2x larger from laser vaporizer than from tungsten vaporizer!

~2x CE ~2x mIE rBC CE determination NR-PM mIE determination

Willis et al., 2014 AMT

DOS coated BC with vaporizer and laser

slide-23
SLIDE 23

AN coated BC with vaporizer and laser

Carbone et al., 2015 AMTD; Fortner lab experiments

  • Dual vaporizers
  • Atomize solution of Regal

black and ammonium nitrate

  • Large [AN] likely produce

significant number of particles without Regal black

  • Small [AN] likely produce

Regal black particles with thin coatings of AN

  • Apparent mIE for AN on laser

vaporizer is ~2.3x tungsten vaporizer (laser OFF)

slide-24
SLIDE 24

mIE NR-PM calibrations using laser vaporizer

  • Need to further refine mIE calibrations for NR-PM on rBC particles
  • Need to assess the differences between mIE for laser and tungsten

vaporizer PM

  • Need to verify whether the standard suite of RIE’s, determined using

tungsten vaporizer only, hold for the laser vaporizer

slide-25
SLIDE 25

Tungsten Vaporizer Collection Efficiency

EL = Aerodynamic Lens transmission EB = Incomplete vaporization due to particle Bounce ES = Particle beam divergence due to particle Shape (and size) EL ~ 1 for dva = 70-700 nm EB ~ 0.5 due to solid/refractory particle bounce ES = 1 as particle beam width < tungsten vaporizer width

Mass concentration of species “s” EB governs the overall CE for Tungsten Vaporizer

CE = EL · EB · ES

slide-26
SLIDE 26

Laser Vaporizer Collection Efficiency

Mass concentration of species “s” ES governs the overall CE for rBC and NR-PM (laser only)  Beam width probe measurement EB complicates rBC (RBC) measurements

CELaser = EL · EB · ES

EL = Aerodynamic Lens transmission EB = Incomplete vaporization ** ES = Particle beam divergence due to particle Shape (and size) EL ~ 1 for dva = 70-700 nm EB ≤ 1 due inefficient energy absorption/transfer issues ** ES < 1 as particle beam width < laser vaporizer width

slide-27
SLIDE 27

Beam Width Probe (Huffmann et al./Salcedo et al.)

laser wire wire motion Particle beam

slide-28
SLIDE 28

BWP Results

  • Two independent measures of narrowing of particle beam with coating
  • Decreasing particle beam width increases particle-laser beam overlap
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31

Incomplete vaporization and laser power

  • Laser Power Drop experiments show a stronger particle-laser beam overlap dependence for rBC

than NR-PM

slide-32
SLIDE 32

SP-AMS CE’s Vaporizer-dependent

Vaporizer Measured Species Tungsten NR-PM * E B Laser (rBC + R-PMǂ + NR-PMǂ) * E S Laser and Tungsten (rBC + R-PMǂ + NR-PMǂ) * E S + (NR-PM - NR-PMǂ * E S ) * E B NR-PM = Nonrefractory Particulate Material measured by a standard AMS [Jimenez et al., 2003 ] R-PM = Refractory Particulate Material measured by the SP-AMS (see text for details) rBC = Refractory black carbon measured by the SP-AMS (and SP2) [Schwarz et al., 2006 ]

ǂ = Particulate Material on rBC particles as mesaured by the SP-AMS (see text for details)

E B = Particle bounce related Collection Efficiency of the AMS E S = Size and shape related Collection Efficiency of the SP-AMS

slide-33
SLIDE 33

Laser vaporizer only

Flame 3

Fortner et al., 2015

Regal black

slide-34
SLIDE 34

Resistively heated tungsten vaporizer only

slide-35
SLIDE 35

Refractory black carbon (rBC)

Tungsten vaporizer only Dual vaporizers Laser vaporizer only PMF deconvolution

slide-36
SLIDE 36
slide-37
SLIDE 37

Laser ON vs OFF

Government Flats fire (8/21/2013). SP-AMS plume transect with dual vaporizers (left) and tungsten only (right)

slide-38
SLIDE 38

Summary of quantification issues:

# Issue Importance Comments 1 Differences between vaporizer sensitivities

major

mIE sensitivity issue likely due to vaporization temperatures of molecules and subsent velocities in ion formation chamber. Difficult mIE measurements for NR- PM from laser vaporizer. Laser vaporizer RIE's need verification (or determination). Not well characterized to date. 2 Incomplete vaporization

major

Collection efficiency (CE) issue that has not been characterized very well to date and causes over-estimates of [NR-PM]/[rBC] ratios. 3 Particle beam - laser beam overlap

major

Collection efficiency (CE) issue strongly depenent upon alignment and particle

  • morphologies. BWP will help with quantification, though difficult (and slow)

measurements. 4 Laser misalignment

minor

Includes laser beam hitting tungsten vaporizer or ion formation chamber. Can be mitigated through careful alignment procedures. 5 Cn+ ion interference from Org

minor

Problem for dual vaporizer measurements with significant NR-PM Organics. PMF

  • f rBC ion signals appears to effectively distinguish Cn+ ion sources.

6 Large (mid and fullerene) Cn+ ion formation

minor

Apparent laser power issue that has yet to be resolved.

slide-39
SLIDE 39

Summary

  • SP-AMS hardware = laser vaporizer inside HR-AMS
  • Provides refractory PM detection (chemical, mass, and size information)
  • Three vaporizer configurations (laser only, tungsten vaporizer only, dual

vaporizers)

  • Single particle detection
  • SP-AMS technique finding applications in ambient measurements,

source (combustion) characterization, laboratory measurements, metal nanoparticles, and single particle detection

  • SP-AMS quantification is challenging, but we are making progress
