Optimized Control- and Communication- Architecture for highest Performance TwinCAT The eXtreme Fast Real-time Control Software

• real-time with MS Windows -> cycle times up to 50µs
• standard IEC61131 programming in XFC real-time tasks
• standard features of Windows and TwinCAT are

XFC compliant

EtherCAT The eXtreme Fast Control Communication Technology

• 1000 distributed digital I/O‘s in 30µs
• EtherCAT direct down to the bus terminal, no sub-bus
• optimized usage of standard Ethernet NIC‘s,

i.e. Intel PC chips set architecture

• enhanced real-time features based on

Distributed Clocks:

• synchronization, time stamping, oversampling

Optimized Control- and Communication- Architecture for highest Performance

Bus Terminals The eXtreme Fast I/O Technology

• complete I/O product portfolio for all signals
• high speed digital and analog I/O’s
• time stamping and oversampling terminals for

highest time resolution up to 10ns

Optimized Control- and Communication- Architecture for highest Performance

IPC The eXtreme Fast Control CPU

• Industrial-PCs based on powerful and real-time

capable motherboards

• compact design optimized for control applications

Optimized Control- and Communication- Architecture for highest Performance

Fast reaction time required ? Fast I/O Terminals 1µs Ton / Toff

Signal

minimum reaction time

Time

Input: EL1202 Output: EL2202

Exact time resolution or time equidistant reaction required? – Time Stamp Terminals

Signal

exact reaction time

Time

Input: EL1252 Output: EL2252

Fast signal sampling / output of very short pulses required ? Oversampling Terminals

Signal

exact output pulses

Time Signal

Output: EL2262

Oversampling-Factor = 10

100µs

50µs

Bus- Cycle samples DI

10 µs

DO

EL1262 / EL2262 / EL37xx / EL47xx

Fast signal scanning / output of very short pulses required ? Oversampling Terminals

System Performance

• cycle time:

100 µs (min. 50 µs)

• I/O reaction time:

85 µs (185 µs)

• Distributed Clocks
• resolution:

10 ns

• accuracy:

< 100 ns

• Signal Oversampling
• sampling rate:

200 kHz (500 kHz)

• time resolution:

5 µs (2 µs)

• accuracy:

< 100 ns

• Time Stamping
• resolution:

10 ns

• accuracy:

< 100 ns

XFC Performance Data

I/O Response Time < 100µs

Input Conversion Input Communi- cation Calculation Output Communi- cation Output Conversion

I/O Response Time = 100 µs

XFC - eXtreme Fast Control Technology
