Optimization of Pattern Matching Algorithm for Memory Based Architecture Cheng-Hung Lin, Yu-Tang Tai, and Shih-Chieh Chang National Tsing Hua University, Taiwan, R.O.C Outline Memory architecture for string matching Basic idea Novel
SLIDE 2
SLIDE 3
Introduction
Network Intrusion Detection System is used
to detect network attacks by identifying attack patterns.
Software-only approaches can no longer
meet the high throughput of today’s networking
Hardware approaches for acceleration.
– Logic architecture – Memory architecture
SLIDE 4
Advantage of Memory Architecture
Young H. Cho and William H. Mangione-Smith, “A Pattern Matching Co- processor for Network Security,” in Proc. 42nd IEEE/ACM Design Automation Conference, Anaheim, CA, June 13-17, 2005.
- M. Aldwairi*, T. Conte, and P. Franzon. “Configurable String Matching
Hardware for Speeding up Intrusion Detection,” in Proc. ACM SIGARCH Computer Architecture News, 33(1):99–107, 2005.
- S. Dharmapurikar and J. Lockwood. “Fast and Scalable Pattern Matching
for Content Filtering,” in Proc. Symposium on Architectures for Networking
- and. Communications Systems (ANCS), Oct 2005.
The memory architecture has attracted
a lot of attention because of its easy re- configurability and scalability.
SLIDE 5
Memory Architecture
“bcdf” “pcdg” 1 2 3 5 6 8
p c b c d f d g b b b b ~b & ~p p f f f p p p p b b b b
4 7
Current state Decoder
Input
NS1 NS2 …… NS256 MV <8> <8> …… <8> <16> 256:1 MUX 8
FSM Attack Patterns Memory
match vector
SLIDE 6
Major Issue of Memory Architecture
Due to the increasing number of attacks,
the required memory increases tremendously
– The performance, cost, and power consumption are related to the memory size – Reducing the memory size has become imperative
SLIDE 7
Outline
Memory architecture for string matching Basic idea Novel algorithm for memory architecture Experimental results and Conclusions
SLIDE 8
Review of Aho-Corasick Algorithm
Aho-Corasick (AC) algorithm can reduce large
number of state transitions and memory size.
– Solid line represents valid transitions. – Dotted line represents failure transitions. – Introduce the failure transition to reduce the outgoing transitions. 2 3 4 6 7 8
p c b c d f d g
1 5
AC state machine
- f “bcdf”and “pcdg”
SLIDE 9
Observation
Many string patterns are similar because of
common sub-strings
The similarity does not lead to a small state
machine.
“bcdf” “pcdg”
2 3 4 6 7 8
p c b c d f d g
1 5
AC state machine
SLIDE 10
Merge Similar States
The merg_FSM is a different machine
– smaller number of states and transitions. – smaller memory in memory architecture. 1 2 3 4 5 6 7 8
p c b c d f d g
1 26 37 4 5 8
p c b c d f g
merg_FSM
SLIDE 11
Problem of merg_FSM
Directly merging similar states results in an
erroneous state machine.
1 2 3 4 5 6 7 8
p c b c d g d f
input stream = {p, c, d, f} 1 26 37 4 5 8
p c b c g d f
merg_FSM AC state machine
False Positive
SLIDE 12
Outline
Memory architecture for string matching Basic Idea Novel Algorithm for memory architecture Experimental results and Conclusions
SLIDE 13
State Traversal Mechanism
Store merg_FSM table in memory State traversal mechanism is used to
memorize the precedent state and differentiate merged states.
1 26 37 4 5 8
p c b g c d f
State traversal mechanism merg_FSM
2 3 4 6 7 8
p c b c d d g f
1 5
AC state machine ?2 or ?6
SLIDE 14
New State Information
AC state machine stores match vector. New state machine stores
– PathVec stores path information. – IfFinal indicates whether the state is a final state. match vector
c d
1 2 3 4 5 6 7 8
p c b f d g
00 00 00 00 01 00 00 00 10 AC State Machine pathVec_ifFinal
c d
1 2 3 4 5 6 7 8
p c b f d g 01_0 11_0 01_0 01_0 01_1 10_0 10_0 10_0 10_1
New State Machine
SLIDE 15
Pseudo-Equivalent States
Definition: Two states are pseudo-equivalent if
they have
– identical input transitions – identical failure transitions – identical ifFinal – but different next states.
c d
1 2 3 4 5 6 7 8
p c b f d g 01_0 01_0 01_0 01_1 10_0 10_0 10_0 10_1 11_0
SLIDE 16
Merge Pseudo-Equivalent States
c d 1 2 3 4 5 6 7 8 p c b f d g
01_0 11_0 01_0 01_0 01_1 10_0 10_0 10_0 10_1 11_0
1 26 37 4 5 8
p c b c d f g
10_0 01_0 01_1 10_1 11_0 11_0 11_0 11_0
Pseudo-equivalent states are merged. PathVec and ifFinal are updated by a union
- f merged states
SLIDE 17
State Traversal Mechanism
PreReg traces the precedent pathVec in each
state.
1 26 37 4 5 8
p c b c d f g 11_0 10_0 01_0 11_0 11_0 01_1 10_1
input stream: {p, c, d, f}
Next state pathVec ifFinal
preReg 11 10 10 11 11 10 01 00
SLIDE 18
Outline
Memory architecture for string matching Basic Idea Novel algorithm for memory architecture Experimental results and Conclusions
SLIDE 19
Experiment I
Perform experiments on Snort rule sets. Compare our approach with the Aho-
Corasick algorithm .
A.V. Aho and M.J. Corasick. Efficient String Matching:
An Aid to Bibliographic Search. In Communications of the ACM 1975.
SLIDE 20
Compare with Traditional AC
Tradition AC [24] Our algorithm
# of trans. # of states Memory (bytes) # of trans. # of states Memory (bytes) Memory Reduct.
Oracle 138 4,674 2,180 2,185 880,009 1,389 1,221 452,533 49% Sql 44 1,089 421 422 129,290 321 284 87,011 33% Backdoor 57 599 563 565 191,253 523 497 152,268 20% Web-iis 113 2,047 1,533 1,537 569,651 1,273 1,155 428,072 25% Web-php 115 2,455 1,670 1,675 620,797 1,295 1,142 423,254 32% Web-misc 310 4,711 3,576 3,587 1,444,664 3,031 2,734 1,101,119 24% Web-cgi 347 5,339 3,407 3,419 1,377,002 2,672 2,358 949,685 31% Total rules 1,595 20,921 17,472 17,522 8,745,668 14,704 13,381 6,248,927 29% Ratio 1 1 1 84% 76% 71% 29% Rule Sets
# of patterns # of char.
SLIDE 21
Experiment II
Enhance the bit-split algorithm with our
method
– The results are compared with the original bit-split algorithm.
- L. Tan and T. Sherwood. A high throughput
string matching architecture for intrusion detection and prevention. In ISCA’05.
SLIDE 22
Compare with Traditional Bit-Split
Bit-split [8] Bit-split + Our algorithm
# of trans. # of states Memory (bytes) # of trans. # of states Memory (bytes) Memory Reduct.
Oracle 138 4,674 6,645 6,665 633,175 4,146 3,603 358,499 43% Sql 44 1,089 1,211 1,215 110,565 866 769 72,671 34% Backdoor 57 599 1,697 1,705 155,155 1,441 1,305 126,585 18% Web-iis 113 2,047 4,869 4,885 464,075 3,844 3,374 335,713 28% Web-php 115 2,455 4,991 5,011 476,045 3,871 3,345 332,828 30% Web-misc 310 4,711 10,959 11,003 1,067,291 8,861 7,816 797,232 25% Web-cgi 347 5,339 9,901 9,949 965,053 7,875 6,957 709,614 26% Total ruls 1,595 20,921 53,930 54,130 5,467,130 43,550 38,701 4,237,760 22% Ratio 1 1 1 81% 71% 78% 22% Rule Sets
# of patterns # of char.
SLIDE 23
Conclusion
Provide a concept of merging pseudo-
equivalent states to reduce the number of states and transitions.
Propose a state traversal mechanism working
with the merg_FSM without false positive matching results.
Experimental results demonstrate a
significant reduction in memory requirement.
SLIDE 24
Thank You!
SLIDE 25
Backup
SLIDE 26
Cycle Problem
Merging disorder sections of pseudo-
equivalent states creates cycle problem.
1 2 4 3 12 8 9 10 11 6
a b c d e f d e b c g
7
w
5
SLIDE 27
Cycle Problem
For example, the input string “abcdebcdef” will
be mistaken as a match of the pattern “abcdef.”
1 2 4 3 12 5 6
a b c d e f g
7
w d b
SLIDE 28
Construction of State Traversal Machine
Construction of the state traversal
machine consists of two steps
– Step1: Construct valid transitions, failure transitions, pathVec, and ifFinal function. – Step2: Merge the pseudo-equivalent states.
SLIDE 29
Example
Consider three patterns “abcdef”,
“apcdeg”, “awcdeh”.
1 2 4 3 7 8 9 5 10 11 6 12 13 14 15 16
a b c d e f p w 001_1 001_0 010_0 010_0 010_0 100_0 100_0 100_0 100_0 010_1 100_1 c d e g c d e h 001_0 001_0 001_0 001_0 011_0 111_0 001_0 011_0 111_0 010_0
16 states
SLIDE 30
100_0 d d
13
001_0
Merging Pseudo-equivalent States
1 2 4 3 7 8 9 10 11 6 12 14 15 16
a b c d e p c e w c e 001_1 001_0 001_0 001_0 111_0 111_0 010_0 010_0 010_0 010_0 100_0 100_0 100_0 010_1 100_1
5
f g h 111_0 merging the failure transitions performing the union on the pathVec of the
merged states
SLIDE 31
001_0 100_0 111_0
Merging Pseudo-equivalent States
1 2 4 3 7 9 10 11 6 12 14 15 16
a b c d e p c d e w c d e 001_1 001_0 001_0 111_0 111_0 010_0 010_0 010_0 100_0 100_0 010_1 100_1 f g h
5
SLIDE 32
100_1
15
100_0 111_0
Merging Pseudo-equivalent States
1 2 4 3 7 9 10 11 6 12 14 16
a b c d e f p c d e g w c d e h 001_1 001_0 001_0 001_0 111_0 111_0 010_0 010_0 010_0 100_0 100_0 010_1
5
111_0 111_0
10 states
SLIDE 33
State Traversal Algorithm
Algorithm: State traversal pattern matching algorithm Input: A text string x=a1a2…an where each ai is an input symbol and a state traversal machine M with valid transition function g, failure transition function f, path function pathVec and final function ifFinal. Output: Locations at which keywords occur in x. Method: begin state←0 preReg← 1….1 //all bits are initiated to 1. for i←until n do begin preReg = preReg & pathVec(state)
