Opensource Column Store Databases: MariaDB ColumnStore vs. ClickHouse Alexander Rubin VirtualHealth About me Working with MySQL for 10-15 years Started at MySQL AB 2006 - Sun Microsystems, Oracle (MySQL Consulting) - Percona since

slide-1
SLIDE 1

Opensource Column Store Databases: MariaDB ColumnStore vs. ClickHouse

Alexander Rubin VirtualHealth

slide-2
SLIDE 2

2

About me

  • Working with MySQL for 10-15 years

○ Started at MySQL AB 2006

  • Sun Microsystems, Oracle (MySQL Consulting)
  • Percona since 2014

○ Recently joined Virtual Health (medical records startup)

slide-3
SLIDE 3

3

MariaDB ColumnStore, ClickHouse and Storage Formats

Caution: 1. This talk is not about specifics of implementation

○ A number of presentations about Clickhouse and MariaDB @ Percona Live 2019

2. This is all about:

○ What? -- what is the problem ○ Why? -- why queries are slow ○ How? -- how to solve

3. Examples are real-world example, medical insurance records

○ (but no actual PII data shown)

slide-4
SLIDE 4

4

MySQL = { } }

Into: MySQL and Slow Queries

Simple query - top 10 - clients who visited doctors most often (data from 2017-2019)

mysql> SELECT

  • > client_id,
  • > min(date) as first_visit,
  • > max(date) as last_visit,
  • > count(distinct date) as days_visited,
  • > count(cv.id) as visits,
  • > count(distinct cv.service_location_name) as locations
  • > FROM client_visit cv
  • > GROUP BY client_id
  • > ORDER by visits desc
  • > LIMIT 10;

+-----------+-------------+------------+--------------+--------+-----------+ | client_id | first_visit | last_visit | days_visited | visits | locations | +-----------+-------------+------------+--------------+--------+-----------+ | ......... | 2017-08-07 | 2019-05-24 | .. | ... | .. |

10 rows in set (46.24 sec)

slide-5
SLIDE 5

5

What exactly is slow?

Is 47 seconds slow? … depends on expectations

  • Data Science world it is blazing fast
  • Realtime report/dashboard - extremely slow

… Web based queries - users tends to reload page if it is slow … Leaving MySQL with tons of queries doing the same thing

slide-6
SLIDE 6

6

What to do?

Some ideas:

  • 1. Use index Luke!
  • 2. Table per report
  • 3. Pre-aggregate - table per group of reports
  • 4. Something else
slide-7
SLIDE 7

7

Use index

But, it is already using index: id: 1

select_type: SIMPLE table: cv partitions: NULL type: index possible_keys: FK_client_visit key: FK_client_visit key_len: 5 ref: NULL rows: 10483873 filtered: 100.00 Extra: Using temporary; Using filesort 1 row in set, 1 warning (0.00 sec) PRIMARY KEY (`id`), KEY `FK_client_visit_author_id` (`client_id`)

slide-8
SLIDE 8

8

Ok, better index: covered index

mysql> alter table client_visit add key comb(client_id, date, service_location_name); Query OK, 0 rows affected (38.48 sec) Records: 0 Duplicates: 0 Warnings: 0 table: cv partitions: NULL type: index possible_keys: FK_client_id,comb key: comb key_len: 776 ref: NULL rows: 10483873 filtered: 100.00 Extra: Using index; Using temporary; Using filesort

10 rows in set (12.18 sec)

Still slow!

slide-9
SLIDE 9

9

Ok, how large is the table?

mysql> show table status like 'client_visit'\G *************************** 1. row *************************** Name: client_visit Engine: InnoDB Version: 10 Row_format: Dynamic Rows: 10483873 Avg_row_length: 233 Data_length: 2 452 602 880 Index_length: 1 644 773 376

~= 4G on disk, that is it!

24 columns, including `notes` text `description` text etc...

slide-10
SLIDE 10

10

Ok, other options in MySQL?

Create table per each report Problems 1. Too many tables 2. Hard to maintain

slide-11
SLIDE 11

11

Ok, other options in MySQL?

Pre-aggregate in a table:

  • group by client_id + avg, sum, …
  • group by date + avg,sum

Final report will do another aggregation if needed Problems: 1. Some aggregates can’t be re-aggregated 2. Still too many tables 3. Hard to maintain

slide-12
SLIDE 12

12

And it was only the beginning… now this:

SELECT cv.client_id as client_id, min(date) as first_visit, max(date) as last_visit, count(distinct date) as days_visited, count(distinct cv.id) as visits, count(distinct cp.cpt_code) as procedures, count(distinct cv.service_location_name) as locations, sum(billed_amount) as total_billed, max(billed_amount) as max_price, avg(billed_amount) as avg_price FROM client_visit cv join client_procedure cp on cp.encounter_id = cv.encounter_id join client_procedure_claim cpc on cp.id = cpc.client_procedure_id join client_claim cc on cc.id = cpc.client_claim_id GROUP BY client_id ORDER BY total_billed desc LIMIT 10 Highly normalized schema

slide-13
SLIDE 13

13

4 table JOIN, all large tables

+-----------+-------------+------------+--------------+--------+------------+-----------+--------------+-----------+-------------+ | client_id | first_visit | last_visit | days_visited | visits | procedures | locations | total_billed | max_price | avg_price | +-----------+-------------+------------+--------------+--------+------------+-----------+--------------+-----------+-------------+ | ....... | 2018-02-14 | 2019-04-22 | 64 | 64 | .. | .. | 200K | 11K | 449.34 | ...

10 rows in set (5 min 18.16 sec)

slide-14
SLIDE 14

14

Why MySQL is slow for such queries?

1. Row oriented - even if we retrieve 2 fields it will need to read a row 2. InnoDB organize table by pages (16k page) - will need to read more 3. MySQL will use 1 cpu core per query, not utilizing all cores

slide-15
SLIDE 15

15

Why MySQL is slow for such queries?

Row-oriented DBMS (MySQL) Column-oriented DBMS

https://clickhouse.yandex/docs/en/

slide-16
SLIDE 16

16

Column Store Databases

MariaDB Columnstore https://mariadb.com/kb/en/library/mariadb-columnstore/

Tips and Tricks with MariaDB ColumnStore

Wednesday 5:10 PM - 5:35 PM@ Texas

slide-17
SLIDE 17

17

Column Store Databases

Yandex Clickhouse https://clickhouse.yandex/

Low Cost Transactional and Analytics With MySQL and Clickhouse, Have Your Cake and Eat It Too!

Wednesday 5:40 PM - 6:05 PM

Clickhouse Features to Blow your Mind

Thursday 11:55 AM - 12:45 PM

slide-18
SLIDE 18

18

Column-store tests

Testing box 1:

  • AWS ec2 instance, c5d.4xlarge
  • RAM: 32.0 GiB
  • vCPU: 16
  • Disk: NVMe SSD + EBS

Testing box 2:

  • AWS ec2 instance, c5d.18xlarge
  • RAM: 144.0 GiB
  • vCPU: 72
  • Disk: NVMe SSD + EBS
slide-19
SLIDE 19

19

Is it worth using column store: Q1

MySQL Clickhouse MariaDB Response time (sec) 46.24 0.754 11.43 Speed increase compared to MySQL (times, %) 62x 6248% 4x 404%

AWS ec2 instance, c5d.4xlarge

slide-20
SLIDE 20

20

Is it worth using column store: Q2

MySQL Clickhouse MariaDB Response time (sec) 5 min 18.16 sec 33.83 sec 1 min 2.16 sec Speed increase compared to MySQL (times, %) 9x 940% 5x 511%

AWS ec2 instance, c5d.4xlarge

slide-21
SLIDE 21

21

Table sizes on disk

MySQL Clickhouse ColumnStore client_visit 5,876,219,904 793,976,832 3,606,462,464 client_procedure 13,841,203,200 2,253,180,928 9,562,865,664 client_procedure_claim 2,466,250,752 292,007,936 335,683,584 client_claim 11,710,496,768 2,400,182,272 6,720,749,568 Total 33,894,170,624 5,739,347,968 20,225,761,280 Smaller compared to MySQL size (x) 5.91 1.68

Compression

slide-22
SLIDE 22

22

Exporting from MySQL

Usually 3 options

  • 1. ETL to Star Schema
  • 2. ETL to flat de-normalized tables
  • 3. Copy / replicate realtime (as is)

I will talk about option 3.

slide-23
SLIDE 23

23

Yandex Clickhouse

sudo apt-get install clickhouse-client clickhouse-server

slide-24
SLIDE 24

24

Clickhouse: export from mysql (schema)

https://github.com/Altinity/clickhouse-mysql-data-reader

1. Schema import

$ clickhouse-mysql --create-table-sql \

  • -src-host=mysql-replica-host \
  • -src-user=export \
  • -src-password=xxxxxx \
  • -src-schemas=main \
  • -src-tables=client_condition,client_procedure,client_visit

It will choose partition key and sort key, i.e.

ENGINE = MergeTree() PARTITION BY toYYYYMM(created_date) ORDER BY client_id

Beware: enum is not supported (bug)

slide-25
SLIDE 25

25

Clickhouse: export from MySQL (data)

1. Use clickhouse-mysql-data-reader (slower) 2. Use native Clickhouse MySQL connection:

INSERT INTO client_procedure_claim SELECT * FROM mysql('host', 'db', 'client_procedure_claim', 'export', 'xxxxx') Ok. 0 rows in set. Elapsed: 17.821 sec. Processed 37.40 million rows, 299.18 MB (2.10 million rows/s., 16.79 MB/s.)

slide-26
SLIDE 26

26

Clickhouse: connect using MySQL client

https://github.com/sysown/proxysql/wiki/ClickHouse-Support

$ wget https://github.com/sysown/proxysql/releases/download/v2.0.4/p roxysql_2.0.4-ubuntu18_amd64.deb $ dpkg -i proxysql_2.0.4-clickhouse-ubuntu18_amd64.deb $ proxysql --clickhouse-server

slide-27
SLIDE 27

27

Clickhouse: connect using MySQL client

$ mysql -h 127.0.0.1 -P 6032 ... Admin> SELECT * FROM clickhouse_users; Empty set (0.00 sec) Admin> INSERT INTO clickhouse_users VALUES ('clicku','clickp',1,100); Query OK, 1 row affected (0.00 sec) Admin> LOAD CLICKHOUSE USERS TO RUNTIME; Query OK, 0 rows affected (0.00 sec) Admin> SAVE CLICKHOUSE USERS TO DISK; Query OK, 0 rows affected (0.01 sec)

https://github.com/sysown/proxysql/wiki/ClickHouse-Support

slide-28
SLIDE 28

28

Clickhouse: connect using MySQL client

mysql -h 127.0.0.1 -P 6090 -uclicku -pclickp ... Server version: 5.5.30 (ProxySQL ClickHouse Module) mysql> select client_id, count(cv.id) as visits, count(distinct cv.service_location_name) as locations from client_visit cv group by client_id order by visits desc limit 10; +-----------+--------+-----------+ | client_id | visits | locations | +-----------+--------+-----------+ ... 10 rows in set (0.53 sec)

slide-29
SLIDE 29

29

ProxySQL to Clickhouse - experimental

Some bugs exists: select min(date) as first_visit, max(date) as last_visit from client_visit; ERROR 2013 (HY000): Lost connection to MySQL server during query

slide-30
SLIDE 30

30

Clickhouse - joining MySQL source

CREATE VIEW clients_mysql as select * from mysql('mysql_host', 'db', 'client', 'export', 'xxxx'); select count(*) from clients_mysql; SELECT count(*) FROM clients_mysql ┌─count()─┐ │ 1035284 │ └─────────┘

slide-31
SLIDE 31

31

Clickhouse - joining MySQL source

SELECT cv.client_id as client_id ... FROM

...

INNER JOIN ( SELECT user_id, is_active FROM clients_mysql ) AS c ON cv.client_id = c.user_id WHERE c.is_active = 1

...

10 rows in set. Elapsed: 36.653 sec. Processed 122.58 million rows, 2.30 GB (3.34 million rows/s., 62.72 MB/s.) CREATE VIEW clients_mysql as select * from mysql('mysql_host', 'db', 'client', 'export', 'xxxx');

slide-32
SLIDE 32

32

MariaDB Column Store Architecture

slide-33
SLIDE 33

33

MariaDB ColumnStore: export from mysql

Schema import - need to create custom schema mysqldump --no-data … change engine=InnoDB to engine=Columnstore

slide-34
SLIDE 34

34

MariaDB ColumnStore: export from mysql

Schema import - need to create custom schema mysqldump --no-data does not work out of the box $ mcsmysql test < client_visit.sql ERROR 1069 (42000) at line 25: Too many keys specified; max 0 keys allowed $ mcsmysql test < client_visit.sql ERROR 1075 (42000) at line 25: Incorrect table definition; there can be only one auto column and it must be defined as a key

slide-35
SLIDE 35

35

MariaDB ColumnStore: export from mysql (data)

Fastest way - 1. mysql > select into outfile … 2. $ cpimport ... Easiest way: 1. Import into InnoDB locally (columnstore includes MySQL server) 2. Run “insert into columstore_table select * from innodb_table”

slide-36
SLIDE 36

36

MariaDB ColumnStore: Joining MySQL source

1. Export using InnoDB storage engine 2. JOIN across engines

SELECT ... FROM client_visit cv join client_procedure cp on cp.encounter_id = cv.encounter_id join client_procedure_claim cpc on cp.id = cpc.client_procedure_id join client_claim cc on cc.id = cpc.client_claim_id join client_innodb c on cv.client_id = c.user_id WHERE c.is_active = 1 GROUP BY client_id ORDER BY total_billed desc limit 10;

slide-37
SLIDE 37

37

Clickhouse: replication from MySQL

clickhouse-mysql --src-server-id=1 --src-resume --src-wait

  • -nice-pause=1 --src-host=10.0.0.142 --src-user=chreader
  • -src-password=pass --src-tables=wiki.pageviews
  • -dst-host=127.0.0.1 --pump-data --csvpool
slide-38
SLIDE 38

38

ColumnStore: replication from MySQL

Coming soon https://jira.mariadb.org/browse/MCOL-498 https://jira.mariadb.org/browse/MCOL-593

slide-39
SLIDE 39

39

Update / delete - MariaDB ColumnStore

DMLs are usually the slowest in Columnar Stores Single row: MariaDB [vh]> update client set is_active = 0 where user_id = 3216031; Query OK, 1 row affected (0.156 sec) Rows matched: 0 Changed: 0 Warnings: 0

slide-40
SLIDE 40

40

Update / delete - Clickhouse

Implemented as “Alter table update” (mutations) Asynchronous

https://clickhouse.yandex/docs/en/query_language/alter/#alter-mutations

Single row:

:) ALTER TABLE client UPDATE is_active = 0 WHERE user_id = 3216031 Ok. 0 rows in set. Elapsed: 0.006 sec.

slide-41
SLIDE 41

41

When NOT to use Column Store db (1)

Single row (full row) by id: select * from client_claim where id = <num>; MySQL: 1 row in set (0.00 sec) Columnstore: 1 row in set (0.039 sec) Clickhouse: 1 rows in set. Elapsed: 0.023 sec.

slide-42
SLIDE 42

42

When NOT to use Column Store db (2)

When we will be using index in MySQL + limit SELECT * FROM client_claim WHERE place_of_service = 'OFFICE' ORDER BY received_date DESC LIMIT 10 MySQL: 10 rows in set (0.00 sec) Columnstore: 10 rows in set (20.838 sec) Clickhouse: 10 rows in set. Elapsed: 1.148 sec

ERROR 1815 (HY000): Internal error: IDB-2015: Sorting length

  • exceeded. Session

variable max_length_for_sor t_data needs to be set higher. Index scan

slide-43
SLIDE 43

43

When NOT to use Column Store db (2)

mysql> explain SELECT * FROM client_claim WHERE place_of_service = 'OFFICE' ORDER BY received_date DESC LIMIT 10\G *************************** 1. row *************************** id: 1 select_type: SIMPLE table: client_claim partitions: NULL type: ref possible_keys: place_of_service_received_date key: place_of_service_received_date key_len: 768 ref: const rows: 13072594 filtered: 100.00 Extra: Using where

slide-44
SLIDE 44

44

Other idea: daily online snapshots

  • Size is columnar store DB is significantly smaller
  • We can load daily snapshots

○ I.e. store 30 days of data that can be queried (without restore from backup)

slide-45
SLIDE 45

45

Summary: Clickhouse

Advantages

  • Fastest queries
  • Very efficient storage

Disadvantages

  • For JOINs needs RAM to store all JOINed tables
  • No native MySQL protocol (only via ProxySQL)
  • No standard sql support (data types, etc)
slide-46
SLIDE 46

46

Summary: MariaDB ColumnStore

Advantages

  • Native MySQL protocol - easier to integrate
  • Native shared nothing cluster

Disadvantages

  • Slower queries
slide-47
SLIDE 47

47

Conclusion (1)

Clickhouse and MariaDB ColumnStore can help optimizing slow reporting queries

a. Those queries can be slow by design in MySQL b. MySQL is good for lots of small queries rather than some smaller ones c. MySQL will not be able to utilize all hardware resources

slide-48
SLIDE 48

48

Conclusion (2)

We can see 5x-10x to 60x performance increase for some queries

○ From 5 minutes for 30 seconds in Clickhouse

slide-49
SLIDE 49

49

Conclusion (3)

Both systems can be used together with MySQL

a. Sync data quickly b. Replicate realtime

slide-50
SLIDE 50

50

Thank you!
