Online Path Planning for Autonomous Underwater Vehicles in Unknown Environments Juan David Hernandez, Eduard Vidal, Guillem Vallicrosa, Enric Galceran, and Marc Carreras ICRA 2015 Presented by Youngki Kwon Contents Introduction Main
SLIDE 2
SLIDE 3
3
Contents
- Introduction
- Main contribution
- Background
- Anytime path planning
- Lazy collision evaluation
- Octree-based map
- Main approach
- Framework
- Motion planning
- Experiment and result
- Summary
SLIDE 4
4
INTRODUCTION
SLIDE 5
5
Introduction
- AUVs must operate in unknown, cluttered and
dynamic environments
- AUVs are more exposed to collisions
- Drift effects on the position estimated by navigation
system
- Online capabilities of path planner make AUVs
- vercome global position inaccuracy
SLIDE 6
6
MAIN CONTRIBUTION
SLIDE 7
7
Main Contribution
- Combination of ideas from lazy collision
evaluation and anytime path planning algorithm
- For online path planning
- incrementally built octree-based representation of the
environment
- The experimental evaluation of the resulting
planning framework using the SPARUS-II AUV in a real-world setting
SLIDE 8
8
BACKGROUND
SLIDE 9
9
- Overall approach
- Quickly find a solution that is feasible, but not
necessarily optimal
- Exploit execution time to incrementally improve
towards optimal solution
- Desired properties
- Form of completeness guarantees
- Asymptotic optimality given more computation time
Anytime Path Planning
Anytime RRT* - Matthew Walter’s slide
SLIDE 10
11
Lazy Collision Evaluation
- Only check for collisions when we have to
Check the collision after building the roadmap
SLIDE 11
12
Octree-based Map
Techniques for 3d mapping - Wolfram burgard’s slide
SLIDE 12
13
Octree-based Map
- Octomap
Techniques for 3d mapping - Wolfram burgard’s slide
SLIDE 13
14
MAIN APPROACH
SLIDE 14
15
Framework
- To solve start-to-goal queries for an AUV in an
unknown environment
- Framework for path planning online for AUVs
SLIDE 15
16
Anytime Approach
- Under the time constraint, current T is left image
- Assume T is valid
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
Time limit
SLIDE 16
17
Anytime Approach
- Traverse T, check the collision, cut the subtree in collision
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
Lazy Collision Evaluation
SLIDE 17
18
Anytime Approach
- Sample configuration
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
SLIDE 18
19
Anytime Approach
- Extension in RRT*
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
SLIDE 19
20
Anytime Approach
- Extension in RRT*
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
SLIDE 20
21
Anytime Approach
- Extension in RRT*
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
SLIDE 21
22
Anytime Approach
- Extension in RRT*
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
SLIDE 22
23
Anytime Approach
- Extension in RRT*
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
SLIDE 23
24
Anytime Approach
- Find solution
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖
SLIDE 24
25
Anytime Approach
- After Satisfying stop condition
𝒓𝒉𝒑𝒃𝒎 𝑺𝒑𝒑𝒖 𝑺𝒑𝒑𝒖
SLIDE 25
26
EXPERIMENT & RESULT
SLIDE 26
27
Experiment & Result
- AUV use
- Pressure sensor, Doppler velocity log, IMU
measurement, GPS
- Five Echosounders
- Experiments in both simulation and real world
SLIDE 27
28
Experiment & Result
- Experiment in simulation
SLIDE 28
29
Experiment & Result
- Experiment in real-world
SLIDE 29
30
SUMMARY
SLIDE 30
31
Summary
- Online capabilities of path planner make AUVs
- vercome global position inaccuracy
- Combination of ideas from lazy collision
evaluation and anytime path planning algorithm
