Johannes Obermaier, Marc Schink, Kosma Moczek August 11, 2020 One Exploit to Rule them All? On the Security of Drop-in Replacement and Counterfeit Microcontrollers Outline - Research Scope - Optical Die Inspection - Security Concept -

slide-1
SLIDE 1

Johannes Obermaier, Marc Schink, Kosma Moczek August 11, 2020

One Exploit to Rule them All? On the Security of Drop-in Replacement and Counterfeit Microcontrollers

slide-2
SLIDE 2

Outline

  • Research Scope
  • Optical Die Inspection
  • Security Concept
  • Debugger-based Attack Vectors
  • Hardware-based Attack Vectors
  • Conclusion and Outlook
slide-3
SLIDE 3

Research Scope

Drop-in Replacement and Counterfeit Devices

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 2 / 17

slide-4
SLIDE 4

Research Scope

Drop-in Replacement and Counterfeit Devices

FAKE!

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 2 / 17

slide-5
SLIDE 5

Research Scope

Drop-in Replacement and Counterfeit Devices

FAKE!

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 2 / 17

slide-6
SLIDE 6

Research Scope

Drop-in Replacement and Counterfeit Devices

FAKE!

→ Research: One exploit to rule them all? Unknown source: Surplus devices? Manufacturing data leak? Device security unknown / undisclosed Limitation: DiY attacks only!

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 2 / 17

slide-7
SLIDE 7

Research Scope

Selected Devices

STM32F103(C8T6)

→

The original device

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 3 / 17

slide-8
SLIDE 8

Research Scope

Selected Devices

STM32F103(C8T6)

→

The original device

GD32F103(C8T6) CKS32F103(C8T6) APM32F103(CBT6) GD32F130(C8T6) GD32VF103(CBT6)

→

Cortex-M3 only except for one RISC-V device

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 3 / 17

slide-9
SLIDE 9

Optical Die Inspection

Digging Deeper...

Sulfuric acid chip decapping Exposes the silicon die for comparison

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 4 / 17

slide-10
SLIDE 10

Optical Die Inspection

Digging Deeper...

Sulfuric acid chip decapping Exposes the silicon die for comparison STM32F103C8T6 APM32F103CBT6 CKS32F103C8T6 GD32F103C8T6 GD32F130C8T6 GD32VF103CBT6

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 4 / 17

slide-11
SLIDE 11

Optical Die Inspection

Digging Deeper...

Sulfuric acid chip decapping Exposes the silicon die for comparison STM32F103C8T6 APM32F103CBT6 CKS32F103C8T6 GD32F103C8T6 GD32F130C8T6 GD32VF103CBT6

→ Individually developed devices

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 4 / 17

slide-12
SLIDE 12

Security Concept

Readout Protection Levels

Read Protection Debug Permissions Config Value RDP Level 0 Full Access 0xA55A RDP Level 1 Flash Read Protection Others

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 5 / 17

slide-13
SLIDE 13

Security Concept

Readout Protection Levels

Read Protection Debug Permissions Config Value RDP Level 0 Full Access 0xA55A RDP Level 1 Flash Read Protection Others Yes Full erase

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 5 / 17

slide-14
SLIDE 14

Security Concept

Readout Protection Levels

Read Protection Debug Permissions Config Value RDP Level 0 Full Access 0xA55A RDP Level 1 Flash Read Protection Others Yes Full erase RDP Level 2 Debug Interface Disabled 0x33CC Yes Never (GD32F130 only)

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 5 / 17

slide-15
SLIDE 15

Security Concept

Bus Masters and Flash Access Permissions

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Bus masters: Debug, CPU, DMA

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 6 / 17

slide-16
SLIDE 16

Security Concept

Bus Masters and Flash Access Permissions

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Bus masters: Debug, CPU, DMA CPU or DMA: Flash access allowed

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 6 / 17

slide-17
SLIDE 17

Security Concept

Bus Masters and Flash Access Permissions

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Bus masters: Debug, CPU, DMA CPU or DMA: Flash access allowed

Attacker

Debugger: Flash access blocked

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 6 / 17

slide-18
SLIDE 18

Security Concept

Bus Masters and Flash Access Permissions

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Bus masters: Debug, CPU, DMA CPU or DMA: Flash access allowed

Attacker

Debugger: Flash access blocked → Debugger via CPU or DMA: Indirect flash access permitted?

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 6 / 17

slide-19
SLIDE 19

Debugger-based Attack Vectors

Load Instructions (GD32VF103, CKS32F103)

GD32VF103 CKS32F103

CPU Core RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 7 / 17

slide-20
SLIDE 20

Debugger-based Attack Vectors

Load Instructions (GD32VF103, CKS32F103)

GD32VF103 CKS32F103

CPU Core RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

SRAM writeable+executable via debugger APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 7 / 17

slide-21
SLIDE 21

Debugger-based Attack Vectors

Load Instructions (GD32VF103, CKS32F103)

GD32VF103 CKS32F103

CPU Core RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

SRAM writeable+executable via debugger Flash read access when running from SRAM APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 7 / 17

slide-22
SLIDE 22

Debugger-based Attack Vectors

Load Instructions (GD32VF103, CKS32F103)

GD32VF103 CKS32F103

CPU Core RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

SRAM writeable+executable via debugger Flash read access when running from SRAM → Dump flash via SRAM firmware APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 7 / 17

slide-23
SLIDE 23

Debugger-based Attack Vectors

Load Instructions (GD32VF103, CKS32F103)

GD32VF103 CKS32F103

CPU Core RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

SRAM writeable+executable via debugger Flash read access when running from SRAM → Dump flash via SRAM firmware Single stepping via debugger allowed APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 7 / 17

slide-24
SLIDE 24

Debugger-based Attack Vectors

Load Instructions (GD32VF103, CKS32F103)

GD32VF103 CKS32F103

CPU Core RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

SRAM writeable+executable via debugger Flash read access when running from SRAM → Dump flash via SRAM firmware Single stepping via debugger allowed CPU registers can be modified APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 7 / 17

slide-25
SLIDE 25

Debugger-based Attack Vectors

Load Instructions (GD32VF103, CKS32F103)

GD32VF103 CKS32F103

CPU Core RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

SRAM writeable+executable via debugger Flash read access when running from SRAM → Dump flash via SRAM firmware Single stepping via debugger allowed CPU registers can be modified → Dump flash via LDR-gadget stepping APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 7 / 17

slide-26
SLIDE 26

Debugger-based Attack Vectors

Demo: CKS32F103 Memory Extraction

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 8 / 17

slide-27
SLIDE 27

Debugger-based Attack Vectors

Exceptional Failure (APM32F103, CKS32F103, STM32F103)

Interrupt routine address fetched from flash Debugger can trigger interrupts

+0x10 VTOR +0x20 +0x30 +0x40 0x0801 0000

MSP MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3

+0x70

Ext 12 Ext 13 Ext 14 Ext 15

  • APM32F103

CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 9 / 17

slide-28
SLIDE 28

Debugger-based Attack Vectors

Exceptional Failure (APM32F103, CKS32F103, STM32F103)

Interrupt routine address fetched from flash Debugger can trigger interrupts

+0x10 VTOR +0x20 +0x30 +0x40 0x0801 0000

MSP MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3

+0x70

Ext 12 Ext 13 Ext 14 Ext 15

  • MSP

MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3 Ext 12 Ext 13 Ext 14 Ext 15

  • Fetched address leaks memory contents

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 9 / 17

slide-29
SLIDE 29

Debugger-based Attack Vectors

Exceptional Failure (APM32F103, CKS32F103, STM32F103)

Interrupt routine address fetched from flash Debugger can trigger interrupts

+0x10 VTOR +0x20 +0x30 +0x40 0x0801 0000

MSP MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3

+0x70

Ext 12 Ext 13 Ext 14 Ext 15

  • MSP

MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3 Ext 12 Ext 13 Ext 14 Ext 15

  • Fetched address leaks memory contents

VTOR

MSP MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3

VTOR 0x0801 0080 +0x10 +0x20 +0x30 +0x40

Reset MSP NMI HardFault MemManage BusFault UsageFault SVCall DebugMon PendSV SysTick Ext 0 Ext 1 Ext 2 Ext 3

+0x70

Ext 12 Ext 13 Ext 14 Ext 15

  • Ext 12
  • Ext 13

Ext 14 Ext 15

  • Interrupt vector table relocateable

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 9 / 17

slide-30
SLIDE 30

Debugger-based Attack Vectors

Exceptional Failure (APM32F103, CKS32F103, STM32F103)

Interrupt routine address fetched from flash Debugger can trigger interrupts

+0x10 VTOR +0x20 +0x30 +0x40 0x0801 0000

MSP MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3

+0x70

Ext 12 Ext 13 Ext 14 Ext 15

  • MSP

MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3 Ext 12 Ext 13 Ext 14 Ext 15

  • Fetched address leaks memory contents

VTOR

MSP MemManage DebugMon Ext 0

  • Reset

BusFault Ext 1

  • NMI

UsageFault PendSV Ext 2

  • HardFault

SVCall SysTick Ext 3

VTOR 0x0801 0080 +0x10 +0x20 +0x30 +0x40

Reset MSP NMI HardFault MemManage BusFault UsageFault SVCall DebugMon PendSV SysTick Ext 0 Ext 1 Ext 2 Ext 3

+0x70

Ext 12 Ext 13 Ext 14 Ext 15

  • Ext 12
  • Ext 13

Ext 14 Ext 15

  • Interrupt vector table relocateable

→ Dump ~90% of flash via interrupt generation APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 9 / 17

slide-31
SLIDE 31

Debugger-based Attack Vectors

VTOR Control Flow Redirection (GD32F103)

SRAM writeable by debugger

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 10 / 17

slide-32
SLIDE 32

Debugger-based Attack Vectors

VTOR Control Flow Redirection (GD32F103)

SRAM writeable by debugger

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Interrupt vector table relocation + triggering allowed APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 10 / 17

slide-33
SLIDE 33

Debugger-based Attack Vectors

VTOR Control Flow Redirection (GD32F103)

SRAM writeable by debugger

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Interrupt vector table relocation + triggering allowed Flash accessible from SRAM, if CPU-debugging is off APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 10 / 17

slide-34
SLIDE 34

Debugger-based Attack Vectors

VTOR Control Flow Redirection (GD32F103)

SRAM writeable by debugger

CPU Core CM3 Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Interrupt vector table relocation + triggering allowed Flash accessible from SRAM, if CPU-debugging is off → Dump flash via an injected interrupt routine in SRAM APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 10 / 17

slide-35
SLIDE 35

Debugger-based Attack Vectors

DMA-based Extraction (CKS32F103, GD32F103)

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Flash accessible by the DMA module APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 11 / 17

slide-36
SLIDE 36

Debugger-based Attack Vectors

DMA-based Extraction (CKS32F103, GD32F103)

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Flash accessible by the DMA module DMA reconfigurable via the debugger APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 11 / 17

slide-37
SLIDE 37

Debugger-based Attack Vectors

DMA-based Extraction (CKS32F103, GD32F103)

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Flash accessible by the DMA module DMA reconfigurable via the debugger Configure: Copy from flash to SRAM APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 11 / 17

slide-38
SLIDE 38

Debugger-based Attack Vectors

DMA-based Extraction (CKS32F103, GD32F103)

CPU Core CM3 / RISC-V Debug Bus Matrix

ICode DCode System DMA

DMA Flash memory SRAM Peripherals

DBG

Flash accessible by the DMA module DMA reconfigurable via the debugger Configure: Copy from flash to SRAM → Dump flash via the DMA+SRAM module SRAM readable via the debugger APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 11 / 17

slide-39
SLIDE 39

Hardware-based Attack Vectors

Invasive Data Eavesdropping (GD32F103, GD32F130)

Logic die Flash die

Stacked die concept APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 12 / 17

slide-40
SLIDE 40

Hardware-based Attack Vectors

Invasive Data Eavesdropping (GD32F103, GD32F130)

Logic die Flash die

Stacked die concept

Logic die Flash die

Access to Logic-to-Flash interconnect grinded APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 12 / 17

slide-41
SLIDE 41

Hardware-based Attack Vectors

Invasive Data Eavesdropping (GD32F103, GD32F130)

Logic die Flash die

Stacked die concept

Logic die Flash die

Access to Logic-to-Flash interconnect grinded

Bonding wires

IO3 IO0 IO1 IO2

Silver paint contact pads APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 12 / 17

slide-42
SLIDE 42

Hardware-based Attack Vectors

Invasive Data Eavesdropping (GD32F103, GD32F130)

Logic die Flash die

Stacked die concept

Logic die Flash die

Access to Logic-to-Flash interconnect grinded

Bonding wires

IO3 IO0 IO1 IO2

Silver paint contact pads Obfuscated QSPI transmissions Address+data permutation APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 12 / 17

slide-43
SLIDE 43

Hardware-based Attack Vectors

Invasive Data Eavesdropping (GD32F103, GD32F130)

Logic die Flash die

Stacked die concept

Logic die Flash die

Access to Logic-to-Flash interconnect grinded

Bonding wires

IO3 IO0 IO1 IO2

Silver paint contact pads Obfuscated QSPI transmissions Address+data permutation Deobfuscation successful → Firmware extraction via eavesdropping (untested) APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 12 / 17

slide-44
SLIDE 44

Hardware-based Attack Vectors

Invasive RDP Manipulation (GD32F130)

RDP setting at 0x4000: 33CC [....] APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 13 / 17

slide-45
SLIDE 45

Hardware-based Attack Vectors

Invasive RDP Manipulation (GD32F130)

RDP setting at 0x4000: 33CC [....] Factory config at 0x0400: A55A [...] APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 13 / 17

slide-46
SLIDE 46

Hardware-based Attack Vectors

Invasive RDP Manipulation (GD32F130)

RDP setting at 0x4000: 33CC [....] Factory config at 0x0400: A55A [...] RDP level 0 setting?!? APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 13 / 17

slide-47
SLIDE 47

Hardware-based Attack Vectors

Invasive RDP Manipulation (GD32F130)

RDP setting at 0x4000: 33CC [....] Factory config at 0x0400: A55A [...] RDP level 0 setting?!? Overwrite address phase of RDP loading with 0x0400

(other data / pattern) RDP Firmware Debug/SWD QSPI IO2 DuT Attack Board

IO2

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 13 / 17

slide-48
SLIDE 48

Hardware-based Attack Vectors

Invasive RDP Manipulation (GD32F130)

RDP setting at 0x4000: 33CC [....] Factory config at 0x0400: A55A [...] RDP level 0 setting?!? Overwrite address phase of RDP loading with 0x0400

(other data / pattern) RDP Firmware Debug/SWD QSPI IO2 DuT Attack Board

IO2

→ Firmware extraction via security downgrade to RDP 0 APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 13 / 17

slide-49
SLIDE 49

Hardware-based Attack Vectors

Shellcode Exec. via Glitch and Patchpoint (APM32F103, STM32F103)

Attack Board DuT

BOOT0 VCC Debug/ UART Reset SWD

Attached debugger prevents flash access and execution APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 14 / 17

slide-50
SLIDE 50

Hardware-based Attack Vectors

Shellcode Exec. via Glitch and Patchpoint (APM32F103, STM32F103)

Attack Board DuT

BOOT0 VCC Debug/ UART Reset SWD

Attached debugger prevents flash access and execution Load 2-stage shellcode to SRAM APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 14 / 17

slide-51
SLIDE 51

Hardware-based Attack Vectors

Shellcode Exec. via Glitch and Patchpoint (APM32F103, STM32F103)

Attack Board DuT

BOOT0 VCC Debug/ UART Reset SWD

Attached debugger prevents flash access and execution Load 2-stage shellcode to SRAM Disconnect Debugger, apply power glitch (debug module resets, SRAM shellcode remains)

DuT VDD DuT RESET

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 14 / 17

slide-52
SLIDE 52

Hardware-based Attack Vectors

Shellcode Exec. via Glitch and Patchpoint (APM32F103, STM32F103)

Attack Board DuT

BOOT0 VCC Debug/ UART Reset SWD

Attached debugger prevents flash access and execution Load 2-stage shellcode to SRAM Disconnect Debugger, apply power glitch (debug module resets, SRAM shellcode remains)

DuT VDD DuT RESET

Boot SRAM/stage 1: Add Patchpoint to flash entry point Boot from flash, control flow gets "patched" into stage 2 APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 14 / 17

slide-53
SLIDE 53

Hardware-based Attack Vectors

Shellcode Exec. via Glitch and Patchpoint (APM32F103, STM32F103)

Attack Board DuT

BOOT0 VCC Debug/ UART Reset SWD

Attached debugger prevents flash access and execution Load 2-stage shellcode to SRAM Disconnect Debugger, apply power glitch (debug module resets, SRAM shellcode remains)

DuT VDD DuT RESET

Boot SRAM/stage 1: Add Patchpoint to flash entry point Boot from flash, control flow gets "patched" into stage 2 → Flash reader shellcode execution APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 14 / 17

slide-54
SLIDE 54

Hardware-based Attack Vectors

Demo:APM32 Flash Extraction via Shellcode

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 15 / 17

slide-55
SLIDE 55

Conclusion and Outlook Instead: Vulnerabilities expose EACH one to DiY methods

NO exploit to rule them ALL

Insufficient security engineering (design, testing, ...) APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 16 / 17

slide-56
SLIDE 56

Conclusion and Outlook Instead: Vulnerabilities expose EACH one to DiY methods

NO exploit to rule them ALL

Insufficient security engineering (design, testing, ...) Coordinated disclosure process performed But: Very little responsiveness from manufacturers APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 16 / 17

slide-57
SLIDE 57

Conclusion and Outlook Instead: Vulnerabilities expose EACH one to DiY methods

NO exploit to rule them ALL

Insufficient security engineering (design, testing, ...) Coordinated disclosure process performed But: Very little responsiveness from manufacturers Weaknesses all in hardware, no known (software) workarounds → New fixed hardware revisions required

? ? ? ? ? ?

APM32F103 CKS32F103 GD32F103 GD32F130 GD32VF103 STM32F103

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 16 / 17

slide-58
SLIDE 58

Contact Information

Johannes Obermaier mail@obermaier-johannes.de Marc Schink mail@marcschink.de Kosma Moczek kosma@kosma.pl Supplementary materials at: https://science.obermaier-johannes.de/f103-analysis

One Exploit to Rule them All? | Johannes Obermaier, Marc Schink, Kosma Moczek | August 11, 2020 | 17 / 17
