Office Supplier of TPMS for Dongfeng-Nissan and Tesla Introduction - - PowerPoint PPT Presentation

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Introduction of Valor TPMS-203 (With transceiver)

Why TPMS Introduction of Valor TPMS Target Market Functions Characteristics Operation Comparison with Other TPMS Awards & Certificates Benefit from Valor TPMS

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Why TPMS?

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

■Truck fleets recognize that tires are "capital goods" for them. ■The deficiency of pressure is 0.6 bar, the rolling resistance increases by 20%, which can increase fuel consumption by 6% and overall expenditure by close to 2 %. ■ Professional tire resource management, therefore, can significantly lower operating cost-per-mile.

*Source: Michelin

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Approximate 75% of all running tires are underinflated.

• U.S.A National Highway Traffic Safety Administration

An estimated 23,464 crashes and 535 fatal crashes annually involve blowouts or flat tires.

• The Fatality Analysis Reporting System of USA

Accident Caused By Under-inflated Tire

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

A tire 20% underinflated has a running life 30% less 30% underinflated has a running life 45% less 20% overinflated has a running life 10% less

Decreased Tire Life with Lower Pressure (Source: Continental Tires)

Tire Loss

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

According to Continental Tires’ research, we assume that: * Average yearly tire loss is between 15%; *There is around 15% from blow-out, 80% of blow-out is from under-inflated; *TPMS can help fleet to extend tire life at least 20%; *Average price of a truck tire is EUR300.00. Thus, a 100 12-wheel fleet would save: 21.6 pcs blow-out tires which are worth 6,480 EURO; Tire life about 30.6 pcs which are worth 9,180 EURO. * Therefore With TPMS Whole fleet can save:

(6,480 + 9,180) = 15,660EURO/ year on tires.

156.6 EURO of tire saving for one truck in one year.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

This Figure has shown us that the corresponding effect of inflation pressure on the fuel consumption of a typical tractor-trailer at 55 MPH on a level highway. 20% percent under-inflation of tires results in about a 3 percent decrease.

Fuel Loss

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

According to Goodyear’s research, we assume that: * 50% of a year is running under-inflated * Fuel Consumption (Without TPMS): 39.2 L/ 100km * Avg. Annual Fuel Consumption : 6,6640 L * Fuel Cost Per Year: 85,299.2 € (1.28 €/L—Avg. retail price per litre in Europe October 2008) A 100 vehicles fleet covering an average of 170,000 km each per year would save:

100 x 85,299.2€ x 50% x3 % = 127,949 €

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

It is difficult to visually determine the under-inflated level, as the 30% pressure lower looks like proper inflated tire.

• Office of Crash Avoidance Standards, NHTSA

TPMS provides an early warning

• n abnormal pressure & temperature!

100% Inflation 70% Inflation

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Introduction

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Tire Pressure Monitoring System (TPMS) for trucks and buses is a valuable vehicle safety device that drivers should always consider. Valor TPMS provide peace of mind and safety, maximize fuel savings and tire life, and environment-friendly. Safety Savings Environment

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Valor TPMS-203 has been developed specifically for the challenges of tire pressure monitoring on large-scale and multi-wheeled fleets operating in fast-moving logistics. Each battery-powered wheel transmitter installed inside the tire measuring the pressure and temperature every 4 seconds, the data of tractor wheels are sent to display directly, the data of trailer wheels are sent to transceiver which transfer to display wirelessly. The integrated display evaluates the data, identifies the transmitter and decides whether or not the driver needs to be informed. Each display has an exclusive ID register, they have same ID code. The ID register is used to send the ID code to transceiver so that the transceiver can confirm which display it should transfer data to.

Office Supplier of Tire Service Products for Ford, GM and Chrysler

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

ID Register

Mounting Diagram

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Target Market

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Valor TPMS-203 is applied for:

• Medium and heavy duty trucks
• Trucks with trailers
• Specialty vehicles
• Buses

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Principle of TPMS-203

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

TPMS is abbreviation of Tire Pressure Monitoring System, it’s a reliable proactive safety device which always monitors pressure and temperature of each tire in both driving and parking. If the sensor gets the abnormal conditions such as high pressure, low pressure, high temperature and leakage, it will immediately send signal to receiver wirelessly, then the display gives driver an alarm of danger. The system consists of receiver-display, transmitter, transceiver, ID register and antenna.

Principle of TPMS-203

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Display Transceiver Transmitter ID Register Antenna Components

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Fixed in rim channel pressure and

• Temp. Sensor

MCU RF Transmitter

Battery

Principle of Transmitter (or Sensor)

Transmitter consists of temperature & pressure sensor, MCU, RF transmitter and battery, They are integrated in one plastic housing. The sensor in transmitter detects changes of tire pressure and temperature, transforms the changes to electrical data through electrical components, then MCU transforms the electrical data and the ID code to digital signal, which the RF transmitter sent out. The transmitter could be triggered when it detects the pressure lower than settings.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

RF Receiver

Power

12V / 24V ID Module Receiving

Principle of Transceiver

MCU RF Transmitter Transmitting

Transceiver consists of MCU, RF receiver, RF transmitter and ID module, They are integrated in one plastic housing. The RF receiver receiving digital signal sent by transmitter and transfer it to MCU which will demodulate the signal, then the RF transmitter will send it out to display together with the ID number of trailer transmitters.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

The receiver and display is integrated, the receiver receives signal from transmitter via antenna and demodulate it, then the display shows the data, the process is controlled by MCU. When the received pressure and temperature is lower or greater than the setting value, MCU will order the display to warn the driver by lighting or sound. Driver then could take positive actions. There are at least 6 sensors in the truck to transmit data, that is, the receiver will get data from multiple sources at the same time. Each sensor has a corresponding ID module in the MCU, so the receiver can get the right data

• f each corresponding tires.

Receiver MCU Display

Power

12V or 24V ID MODULE Antenna

Principle of Receiver and Display

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Functions

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

In order to make drivers in heavy-vehicles can see the displayed pressure and temperature more clearly and conveniently, we designed a large display with large digits.

Pressure unit Leakage symbol pressure and temperature warning symbol pressure & temp. switch tire position switch Temperature unit

Display

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

The display will monitor tires 24 hours and show each axle tires’ pressure for 5 seconds and automatically switch to next axle when all tires are normal. If you want to check all tires’ temperature, please shortly press the “Pressure & Temperature Switch”, the display begins to show the temperature of each axle circularly. Press the “Pressure & Temperature Switch” to shift pressure interface and temperature interface from each other.

Display in Normal Condition

Pressure Interface Temperature Interface

Office Supplier of TPMS for Dongfeng-Nissan and Tesla When current pressure in the tire is 20% lower than baseline pressure: ① Display show the pressure of axle with abnormal tire; ②Warning sound “Di-Di”; ③Abnormality icon “ ” appears; ④The digits of abnormal wheel position twinkle. The figure shows”2C” tire is underinflated. The display will always show the axle 2 until the problems are corrected.

Low Pressure Warning

Office Supplier of TPMS for Dongfeng-Nissan and Tesla When current pressure in the tire is 30% higher than baseline pressure: ①Display show the pressure of axle with abnormal tire; ②Warning sound “Di-Di”; ③ Abnormality icon “ ” appears; ④The digits of abnormal wheel position twinkle. The figure shows “2D” tire is over-inflated. The display will always show the axle 2 until the problems are corrected.

High Pressure Warning

Office Supplier of TPMS for Dongfeng-Nissan and Tesla When temperature inside tire is higher than 80℃ (176℉): ①Display show the temperature of axle with abnormal tire; ②Warning sound “Di-Di”; ③Abnormality icon “ ” appears; ④The digits of abnormal wheel position twinkle. The figure shows “2B” tire is over-hot. The display will always show the axle 1 until the problems are corrected.

High Temperature Warning

Office Supplier of TPMS for Dongfeng-Nissan and Tesla When 0.33 Bar is lost from the tire in 16 seconds: ①Display show the pressure of axle with abnormal tire; ②Warning sound “Di-Di”; ③Leakage icon “ ” appears; ④ The digits of abnormal wheel position twinkle. The figure shows “2B” tire is leaking. The display will always show the axle 2 and until the problems are corrected.

Leakage Warning

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

System Characteristics

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Tire Identification--ID Module Technology

Why do we need tire identification?

When tire pressure sensor was replaced or a spare tire is mounted, the new sensor will be in an “asleep” mode. To wake up sensor, it must be registered. Each time a wheel sensor rotation occurs, the tire pressure sensors must be relearned. If a tire and wheel rotation is not followed by the relearned procedure, the system will not properly inform the driver with the correct location on the vehicle for a low or high pressure tire.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Valor TPMS ID Module Technology

Each transmitter has a corresponding ID module, they have same exclusive ID code, such as 01EB327F. The ID module is installed in the back of display or in the transceiver to register the ID code and identify the tire position.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Digitire TPMS ID Module Technology

• ---position relation between display and ID module seat

Axle 1 Axle 2 Axle 3 Axle 4 Axle 5 Axle 6 1A 1B 1C 1D 2A 2B 2C 2D 3A 3B 3C 3D

A B C D

6 axles

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

• --- Position of ID modules and transmitters

No transceiver for straight vehicles/buses/OTR vehicles

Office Supplier of TPMS for Dongfeng-Nissan and Tesla For trucks with trailers, install tractor ID modules in the display and trailer ID modules in the transceiver.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla Identification The ID code together with the tire pressure and temperature will be sent to display, which will match the transmitter with its corresponding ID module. Rotation The ID module position resembles tire’s position as the pictures above, if you interchange wheel position, you should also interchange the position

• f ID module. For example, if you interchange wheel 1C and 4C, you

should also interchange the position of ID module 1C and 4C. Change Transmitter When you replace a sensor, first install the new sensor in the wheel, then plug the ID module came with the sensor in the corresponding position. For example, if you replace the sensor in wheel 2D, you should plug the new ID module in the position 2D.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

The Merit of ID Module Technology

Recalibration or complicated setup is unnecessary when doing tire rotation or changing transmitter.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

All tires transmitting data at the same time will interference each

• ther. Our program can effectively reduce these data interference to

about 3%.

High Anti-interference Ability

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

High-performance chip and high- frequency circuit ensure the high quality transmitting and receiving of signal even in high driving speed. The transmitting and receiving

• f the signal are stable at highest

speed of 250km/h.

High Reliability of Signal

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

High-quality cell and extremely optimized circuit design guarantees the battery life up to 5 years. 5 years

Low Energy Consumption

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Using pressure sensor provided by famous sensor supplier GE which have a measuring range of 0-13bar(0-188psi) to satisfy different kinds of model.

Pressure Measuring Range

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Operation

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Setup the Baseline Pressure

It’s necessary to set baseline pressure on the following conditions: ① First use of product. ② Replace transmitter and ID module. Both tractor and trailer need to be set up The baseline pressure has been set in the factory at 4Bar (58PSI) for all wheel positions. We recommend that you set the baseline pressure at the same pressure as standard cold inflation pressure recommended by tire manufacturer.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Setup the Baseline Pressure of Tractor

• 1. Inflate all tires’ pressure to the standard cold inflation pressure.
• 2. Press the SET KEY for five seconds, you will hear sound “beep”, all

backlights are on, the screens show “000”, which means you succeed in deleting the old baseline pressure.

• 3. Go next step---setup the baseline pressure of trailer.

Set Key

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Setup the Baseline Pressure of Trailer

• 1. Inflate all tires’ pressure to the standard cold inflation pressure.
• 2. Turn on the transceiver.
• 3. Press the SET key for five seconds, you will hear sound “beep…..”, the

green light is on, which means you succeed in deleting the old baseline pressure. The display & transceiver will exit setup mode automatically after receiving signal from transmitter. The first pressure value received will be saved as new baseline pressure automatically.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla The system has to be restarted to re-identify the ID module in the following situations: 1) Tire rotation; 2) Trailer interchange; 3) Replace transmitter & ID module; To restart the system, please first turn off the display and transceiver and then turn on again.

Restart the System

Restart Key

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Trailer Change

Because the connection between tractor and trailer is wireless, so trailer change is very easy: disconnect trailer ① and turn off transceiver, then connect trailer ② and turn on transceiver. Restart the system.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Installation

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Installation of Display

Fix the cupule pedestal on the back of display, wipe off any dirt on the windshield and fix the cupule pedestal on the windshield by pressing the cupule tightly, make sure it’s in driver’s field of vision.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Installation of Transmitter

• 1. Loose the steel strap. Wrap the strap around the rim in the lowest spot and

mark it 5 cm (2”) past worm gear (see Figure 1).

• 2. Cut the extra strap tapered and rasp away the edge (see Figure 2).

Figure 1 Figure 2

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

• 3. Install the tapered end of the strap through the opening of the cradle.

Remove the adhesive tape liner from cradle. Keep the strap parallel with the wheel flange and ensure the strap is positioned in the lowest spot possible for correct transmitter and cradle retention.

• 4. Position worm gear 8” (10 cm) away from the edge of the sensor and

tighten worm gear until the sensor can not be moved (see figure 4). Figure 3 Figure 4

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Installation of Cables

Connect the power wire and antenna extension cable with display. Place the cable underneath the rubber layer around the edge of windshield towards circuit box and chassis respectively.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla Install power wire: Correctly connect the red wire and blue wire with positive pole and cathode respectively. Tie up all the cables with a strap and put in the compartment, then replace the cover of circuit box

Office Supplier of TPMS for Dongfeng-Nissan and Tesla Install antenna of tractor: Make the antenna extension cable along the vehicle existing umbilical harness extending to the chassis of tractor, screw the antenna

• nto the antenna extension cable and fix the terminal of antenna on the chassis in

the front of second axle with magnet.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla Install antenna of trailer: Screw the antenna extension cable on the transceiver; place the cable along the chassis harness extending to the front of axle, use magnet to fix the antenna on the chassis.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Installation of Transceiver

Connect to power Connect with antenna installed under the chassis of trailer switch Set key Sender: send information to display wirelessly Magnets used to fix on the trailer

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Use magnets to fix the transceiver on the trailer

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Side elevation of Installation

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Awards & Certificates

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

I SO/ TS 16949:2002

Office Supplier of TPMS for Dongfeng-Nissan and Tesla e-mark: e13*72/245*95/54*3539*00

E-mark

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

FCC

FCC ID:TZSTPMS201

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

CE

Certificate No.: R07041010

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Product I nsurance

Product liability insurance: US$2,000,000.00

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

AAPEX Award

■TPMS-201 was granted the “New Product Showcase Winner of AAPEX 2006” ■ Only 8 products won such award among more than 2,000 products.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Benifit from Valor TPMS

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Advertisement all over the world

Internet: www.baolong.biz www.digitire.com www.google.com www.globalsources.com www.gasgoo.com/ www.alibaba.com www.made-in-china.com www.ebay.com www.ec21.com www.busytrade.com Magazine Globalsources Tyres & Accessories Exhibitions Every year we participate about 10 world exhibitions. Such as AAPEX, SEMA, CES, SAE, AUTOPROMOTEC, ESSEN, IAA FRANKFURT, and so on.

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Attractive Price

E-mail us at: sbic@baolong.biz for more information

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Delivery by air Total lead-time: 3~4 weeks

Production: 2~3 weeks Transportation: 1 week

Short Lead Time

Totally 3~4 weeks

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Promotional Materials

Pamphlet Give a brief introduction of the Valor TPMS s u c h a s t h e r o l e o f T P M S , t h e specifications and features of Valor TPMS, etc.

*One kit of TPMS with one free pamphlet

Office Supplier of TPMS for Dongfeng-Nissan and Tesla

Make Your Wheels Go The Distance!

Shanghai Baolong Automotive Corporation

71 MaoSheng Rd, Dongjing, Songjiang, Shanghai 201619, China Tel: + 8621 5769 0000 (200 Lines) Fax: + 8621 5769 0035 E-mail: sbic@baolong.biz Web: www.baolong.biz www.digitire.com
