No or low cost Extrusion Coating Improvements Lou Piffer Senior Sales Engineer Davis-Standard, LLC Paper #6.1 Effectiveness Performance Availability Quality No or low cost e/c improvements Lou Piffer What they really want!

slide-1
SLIDE 1

No or low cost Extrusion Coating Improvements

Lou Piffer Senior Sales Engineer – Davis-Standard, LLC Paper #6.1

slide-2
SLIDE 2

No or low cost e/c improvements Lou Piffer

Effectiveness

  • Performance
  • Availability
  • Quality
slide-3
SLIDE 3

No or low cost e/c improvements Lou Piffer

What they really want!

slide-4
SLIDE 4

No or low cost e/c improvements Lou Piffer

Performance – Labor related

  • Staffing – Liaison
slide-5
SLIDE 5

No or low cost e/c improvements Lou Piffer

The value of employees!

slide-6
SLIDE 6

No or low cost e/c improvements Lou Piffer

Performance – Labor related

  • Staffing – Liaison
  • Complacency – Old line/new line
  • Organized labor
slide-7
SLIDE 7

No or low cost e/c improvements Lou Piffer

Performance The need for Speed!

slide-8
SLIDE 8

No or low cost e/c improvements Lou Piffer

Organized Labor – A success story

  • 600 FPM avg. to 950 – 1000 FPM avg.
  • Revenue increase plant wide of 60%

–“Folklore of the floor” –“Re-evaluate your assumptions” –“Increase training” – Inter-connectiveness –“Keep good supervisors” –Alignment –Operators do gapping of dies

slide-9
SLIDE 9

No or low cost e/c improvements Lou Piffer

Performance – other issues

  • Output

– Screw – Motor

slide-10
SLIDE 10

No or low cost e/c improvements Lou Piffer

4.5”, 30L/D Extruder Screw: Single Stage, Mixing Material: 7MI LDPE

50 100 150 200 250 300 350 400 450 50 100 150 200 250 SCREW SPEED (RPM) OUTPUT RATE (KG/HR)

slide-11
SLIDE 11

No or low cost e/c improvements Lou Piffer

4.5”, 30L/D Extruder Screw: Single Stage, Mixing Material: 7MI LDPE

310 312 314 316 318 320 322 324 50 100 150 200 250 SCREW SPEED (RPM) MELT TEMPERATURE (C)

slide-12
SLIDE 12

No or low cost e/c improvements Lou Piffer

4.5”, 30L/D Extruder Screw: Single Stage, Mixing Material: 7MI LDPE

20 40 60 80 100 120 50 100 150 200 250 SCREW SPEED (RPM) POWER CONSUMPTION (KW)

slide-13
SLIDE 13

No or low cost e/c improvements Lou Piffer

Performance – other issues

  • Output

– Screw – Motor

  • Ancillary systems (trim, blowers, etc)
slide-14
SLIDE 14

No or low cost e/c improvements Lou Piffer

Corona treater blower

slide-15
SLIDE 15

No or low cost e/c improvements Lou Piffer

Trim Pick-up

slide-16
SLIDE 16

No or low cost e/c improvements Lou Piffer

Trim Pick-up

slide-17
SLIDE 17

No or low cost e/c improvements Lou Piffer

Performance – other issues

  • Output

– Screw – Motor

  • Ancillary systems (trim, blowers, etc)
  • Edge Weave
slide-18
SLIDE 18

No or low cost e/c improvements Lou Piffer

Edge Instability is the Limitation

slide-19
SLIDE 19

No or low cost e/c improvements Lou Piffer

Edge Instability is the Limitation

slide-20
SLIDE 20

No or low cost e/c improvements Lou Piffer

Edge Instability is the Limitation

slide-21
SLIDE 21

No or low cost e/c improvements Lou Piffer

Edge weave issues

  • ID die set correctly?
slide-22
SLIDE 22

No or low cost e/c improvements Lou Piffer

Series 50 Internal Deckles

slide-23
SLIDE 23

No or low cost e/c improvements Lou Piffer

Relative Positions of Internal Blades Influence Edge Bead Size and Shape

slide-24
SLIDE 24

No or low cost e/c improvements Lou Piffer

Edge Instability is the Limitation

slide-25
SLIDE 25

No or low cost e/c improvements Lou Piffer

Restabilizing the Edge

slide-26
SLIDE 26

No or low cost e/c improvements Lou Piffer

Further Edge Reduction

slide-27
SLIDE 27

No or low cost e/c improvements Lou Piffer

Edge weave issues

ID die set correctly?

  • Running too thin?
  • Can you change the melt index?
slide-28
SLIDE 28

No or low cost e/c improvements Lou Piffer

Performance – other issues

  • Output

– Screw – Motor

  • Ancillary systems (trim, blowers, etc)
  • Edge weave
  • Stripping problems
slide-29
SLIDE 29

No or low cost e/c improvements Lou Piffer

Temperature Distribution Around Chill Roll

360 100 200 300 400 500 600 30 60 90 120 150 180 210 240 270 300 33 Round Chill Roll [°] °C °F 38 94 150 204 260 316 s u b s t r a t e (pre-heated) p l a s t i c 90°F web melt 600°F 100°F 80°F 120°F 200°F speed 260m/min 800 ft/min 22 mil

Water

316°C

Contact time 0.24 sec.

shell = 12 mm (0.5”)

75°F plastic stripping temperature

slide-30
SLIDE 30

No or low cost e/c improvements Lou Piffer

Stripping problems

  • Increase chill roll diameter
  • Increase surface roughness
  • Air condition building
  • Air condition laminator area
  • See if finish is smoothing out over time
slide-31
SLIDE 31

No or low cost e/c improvements Lou Piffer

Performance – other issues

  • Output

– Screw – Motor

  • Ancillary systems (trim, blowers, etc)
  • Edge weave
  • Stripping problems
  • Roll Handling
slide-32
SLIDE 32

No or low cost e/c improvements Lou Piffer

Roll Handling

slide-33
SLIDE 33

No or low cost e/c improvements Lou Piffer

Roll Handling

  • Simple change – composite shafts
  • Greater change – automatic system
slide-34
SLIDE 34

No or low cost e/c improvements Lou Piffer

Availability Waste is a waste!

slide-35
SLIDE 35

No or low cost e/c improvements Lou Piffer

Availability

  • Internal deckle dies inefficiencies

– Cleaning of lands

slide-36
SLIDE 36

No or low cost e/c improvements Lou Piffer

External Deckle Die - Cleaning

slide-37
SLIDE 37

No or low cost e/c improvements Lou Piffer

External Deckle Die - Cleaning

slide-38
SLIDE 38

No or low cost e/c improvements Lou Piffer

Internal Deckle Die - Cleaning

9.5MM (3/8”)

slide-39
SLIDE 39

No or low cost e/c improvements Lou Piffer

Availability

  • Internal deckle dies inefficiencies

– Cleaning of lands – Leakage

slide-40
SLIDE 40

No or low cost e/c improvements Lou Piffer

External-Only Deckles

  • Disadvantage: External-only deckles increase edge bead size

and create stagnation areas within the die flow channel.

slide-41
SLIDE 41

No or low cost e/c improvements Lou Piffer

Leakage

slide-42
SLIDE 42

No or low cost e/c improvements Lou Piffer

Leakage

slide-43
SLIDE 43

No or low cost e/c improvements Lou Piffer

Internal Deckle Die - Cleaning

9.5MM (3/8”)

slide-44
SLIDE 44

No or low cost e/c improvements Lou Piffer

Availability

  • Internal deckle dies inefficiencies

– Cleaning of lands – Leakage – Resin Type

slide-45
SLIDE 45

No or low cost e/c improvements Lou Piffer

Availability

  • Internal deckle dies inefficiencies

– Cleaning of lands – Leakage – Resin type – Material Left on the Core

slide-46
SLIDE 46

No or low cost e/c improvements Lou Piffer

Material Left on the Core

slide-47
SLIDE 47

No or low cost e/c improvements Lou Piffer

Material left on the core

  • Present day – encoder/drive = 2 wraps
  • Yesterday – sonar = 1/8” – ¼” left
  • Years ago – contact device – ¼” left
  • Always there – operator – 2 wraps to ¼”+
slide-48
SLIDE 48

No or low cost e/c improvements Lou Piffer

Availability

  • Internal deckle dies inefficiencies

– Cleaning of lands – Leakage – Resin type

  • Material left on core
  • Obsolescence
slide-49
SLIDE 49

No or low cost e/c improvements Lou Piffer

Availability

  • Internal deckle dies inefficiencies

– Cleaning of lands – Leakage – Resin type

  • Material left on core
  • Obsolescence
  • More recipe variables = less down time
slide-50
SLIDE 50

No or low cost e/c improvements Lou Piffer

Controls – Recipe driven

  • New width adjustment for unwind/winder
  • Slitter positioning
  • Deckle width
  • Edge guide positioning
  • Treater width
  • Valve stem
slide-51
SLIDE 51

No or low cost e/c improvements Lou Piffer

Motorized spindle adjustment

  • Unwinds and winders automatically adjust to new recipe

web width.

  • Lead screw RPM read by encoder
slide-52
SLIDE 52

No or low cost e/c improvements Lou Piffer

Motorized slitter positioning

  • Servo drives move slitter assemblies to recipe

determined positions

  • Trim extraction system mounted to the motorized base

to follow slitter assembly

  • Position feedback to control system
slide-53
SLIDE 53

No or low cost e/c improvements Lou Piffer

65.0 [1651] WEB MAX. 38.0 [965] WEB MIN.
slide-54
SLIDE 54

No or low cost e/c improvements Lou Piffer

Motorized Deckles

  • Deckle position provided in recipe with motorized

movement coordinated with control cycle.

  • Programmed closure of deckles for startup and moving
  • nline and offline
  • Position feedback to the line control
slide-55
SLIDE 55

No or low cost e/c improvements Lou Piffer

slide-56
SLIDE 56

No or low cost e/c improvements Lou Piffer

Motorized Guide Sensor

  • Motorized sensors positioned to recipe dependent

position

  • Position feedback to the line control
slide-57
SLIDE 57

No or low cost e/c improvements Lou Piffer

slide-58
SLIDE 58

No or low cost e/c improvements Lou Piffer

Motorized Treater Adjustment

  • Flame treater motorized deckle and gap adjustment.

Info is placed in recipe

  • Power or treatment level is recipe driven with feedback
  • Exhaust system uses AC variable drive to adjust to line

speed

slide-59
SLIDE 59

No or low cost e/c improvements Lou Piffer

slide-60
SLIDE 60

No or low cost e/c improvements Lou Piffer

Motorized Valve Stem

  • Position of valve stem adjusted through motor
  • Valve stem position can be placed in pressure PID

control loop.

slide-61
SLIDE 61

No or low cost e/c improvements Lou Piffer

Motorized Adapters

slide-62
SLIDE 62

No or low cost e/c improvements Lou Piffer

Availability

  • Internal deckle dies inefficiencies

– Cleaning of lands – Leakage – Resin type

  • Material left on core
  • Obsolescence
  • More recipe variables = less downtime
  • Transfers and splices
slide-63
SLIDE 63

No or low cost e/c improvements Lou Piffer

Quality Quality is King!

slide-64
SLIDE 64

No or low cost e/c improvements Lou Piffer

Quality

  • Melt

– Screw

slide-65
SLIDE 65

No or low cost e/c improvements Lou Piffer

Old Screw

slide-66
SLIDE 66

No or low cost e/c improvements Lou Piffer

Quality

  • Melt

– Screw – Water Circulation System

slide-67
SLIDE 67

No or low cost e/c improvements Lou Piffer

Feed Section

  • Cast iron jacketed
  • Initial point where resin is

introduced

  • Space between gear box and

resin feeding point

slide-68
SLIDE 68

No or low cost e/c improvements Lou Piffer

Quality

  • Melt

– Screw – Water Circulation System – Adapter

slide-69
SLIDE 69

No or low cost e/c improvements Lou Piffer

screw movable valve melt channel pressure sensor screen pack

Valved Adapter

slide-70
SLIDE 70

No or low cost e/c improvements Lou Piffer

Quality

  • Melt

– Screw – Water Circulation System – Adapter

  • Stretching and Wrinkling
slide-71
SLIDE 71

No or low cost e/c improvements Lou Piffer

Stretching and Wrinkling

  • Few tension isolation points can create stretching issues
slide-72
SLIDE 72

No or low cost e/c improvements Lou Piffer

Tandem Line – Tension Isolation

slide-73
SLIDE 73

No or low cost e/c improvements Lou Piffer

Stretching and Wrinkling

  • After unwind
  • General alignment – wrinkling source
  • New drives?
slide-74
SLIDE 74

No or low cost e/c improvements Lou Piffer

Thank You

PRESENTED BY

Lou Piffer Senior Sales Engineer

Davis-Standard LLC pifferl@bc-egan.com

Please remember to turn in your evaluation sheet...
