Water and Sludge Treatment Plants NO COMPROMISE QUALITY DRIVES TO OUTSTANDING PERFORMANCES! 1 A BIT OF HISTORY Tecnoidea Impianti (in short T.I.) was born at the beginning of 80s as sales structure becoming later a manufacturing


slide-1
SLIDE 1

1

NO COMPROMISE QUALITY

DRIVES TO…

OUTSTANDING PERFORMANCES!

Water and Sludge Treatment Plants

slide-2
SLIDE 2
  • Tecnoidea Impianti (in short T.I.) was born at the beginning of 80s as sales structure becoming later a

manufacturing company where all main devices and components were self-engineered.

  • From 1985 to the beginning of 90s the main sector covered by T.I. was the stone processing industry

(marble and granites) with small-medium size WTP and plate press, mainly installed in Italy and neighboring countries, in India, in North-Africa and South-America countries.

  • During 90s T.I. increase the production to complete a full set of machines for quarries and aggregates

field and started to sell turn-key plants all over the word.

  • In the same years Abra Pompe was based; such sister company (sharing the some T.I. ownership)

design and manufactures centrifugal pumps with abrasion resistant coatings.

  • In the following years (1995 – 2015), the acquired know-how, together with the expansion of the

company personnel and skills, allowed T.I. to penetrate other industrial fields as ceramic, concrete, drilling, tunneling, soil remediation and all the sector involving wet process with mineral particles.

  • Tecnoidea Impianti today can list important references with approx. 3’000 installations worldwide,

and can compete to the maximum level for treatment plants ranging from 1’000 l/min (approx. 270 gall/min) up to 20’000 l/min (5’200 gall/min) of waste waters, and with automatic plate presses for sludge dehydration, having capacity from 0.1 to over 10.0 m3/cycle.

  • All our activities are certified in compliance with ISO 9001 quality standard, and all the plants can be

engineered to fulfill any international requirements (CE , UL, CSA and all the needed certification).

  • Giving priority to the projects success and to customer satisfaction, T.I. now proudly claim the total

absence of any litigation and legal dispute all around the world, an interesting result considering the installation of 4 plants per month (average figure: 2000 - 2016).

A BIT OF… HISTORY

2

slide-3
SLIDE 3

Monza (Milan Area) TECNOIDEA ABRA POMPE Production Unit

TECNOIDEA Impianti Headquarters

3

Segrate (Milan Area) ABRA pumps Steel works / Production Assembly / Testing Design / Engineering

100% IN-House: Quality guarantee

slide-4
SLIDE 4

Specific lab tests on Customer samples Accurate plant parametrization based

  • n tests results

Continuous chemical and processes development Performance guarantees 5 Languages spoken Customer remote support and on site direct service ISO 9001 certified quality management system Proven & reliable customer after-sales support 2D & 3D engineering for parts and plants Full in house know how Stress and dimenisonal analysis No compromises on material selection Turn-key Installation or Supervision options available. Full technical support to customer’s side plant parts construction On-site plant testing, commissioning and start- up, incl. design parameters compliance report. Complete In-house construction and assembly Intensive machinery testing Systemic sub-suppliers periodic audit,

  • riented to quality and performance control

Key spare and wear parts on stock, ready for shipment. Fast shipment service for urgent

  • rders.

Customer-tailored parts management program

slide-5
SLIDE 5

Industrial wet process generating waste water

5

PROCESS OVERVIEW

At a first coarse level, the overall treatment process can be summarized with the following Block Flow diagram. Water clarification (1° Stage) Sludge dehydration (2° Stage)

Tertiary treatment (3° Stage, optional)

Dehydrated sludge cakes Tecnoidea Impianti Battery Limit

A B C D E F

Pos. Description A Waste Water to Primary Stage (Water Clarification) B Clear water from 1° stage (ca. 90% recycle of total water) C Clear water back to the industrial process D Thickened sludge to 2° stage (with 30-40% dry solid) E Filtered water back to 1° stage (ca. 5% recycle of total water) F Dehydrated sludge cakes (with 70-85% dry solid) output X Fresh water adding to compensate for water losses (ca. 5% )

X

Section «A» Section «B»

X

slide-6
SLIDE 6

6

Water Clarification CORE process

FLOCCULATION

Flocculation is the key process in the clarification stage. Suspended solids are chemically destabilized and forced to aggregate into bigger flocks thanks to the addition of a chemical solution (polymer based).

Flocculant Injection Flocks Settling

Suspended Solid particles in balance Particles aggregation into bigger flocks Clarified water Settled Solid

slide-7
SLIDE 7

7

Filtering surface Filter Plates Sludge Inlet Pressure sludge supply filtered water Sludge cake build-up sludge cake fall

Sludge Dehydration CORE process

PLATE PRESSING

Sludge cake discharge

slide-8
SLIDE 8

8

TREATMENT PLANT LAYOUT

01 – Waste water Pit and Pumps 02 – Static Vertical Settling Tank 03 – Flocculant station 04 – Clarified water tank 05 – Thickened Sludge Tank 06 – Sludge conditioning 07 – Thickened Sludge PUMP 08 – Plate Press 09 – Water Neutralization Unit 10 – Chemical Conditioning 11 – Housing 12 – Dehydrated Sludge

01 02 03 04 05 06 07 08 10 09 11 12

slide-9
SLIDE 9

9

TREATMENT PLANT FLOWSHEET

slide-10
SLIDE 10

10

PLANT SECTION «A» WATER CLARIFICATION STAGE

Waste water collection and PUMP

slide-11
SLIDE 11

11

Static vertical SETTLING TANK

PLANT SECTION «A» WATER CLARIFICATION STAGE

slide-12
SLIDE 12

12

FLOCCULANT STATION

PLANT SECTION «A» WATER CLARIFICATION STAGE

slide-13
SLIDE 13

13

CLARIFIED WATER TANK

PLANT SECTION «A» WATER CLARIFICATION STAGE

slide-14
SLIDE 14

14

PLANT SECTION «B» SLUDGE TREATMENT STAGE

Thickened SLUDGE TANK

slide-15
SLIDE 15

SLUDGE CONDITIONING

15

PLANT SECTION «B» SLUDGE TREATMENT STAGE

slide-16
SLIDE 16

16

Sludge feeding PUMP

PLANT SECTION «B» SLUDGE TREATMENT STAGE

slide-17
SLIDE 17

17

PLATE FILTER PRESS

PLANT SECTION «B» SLUDGE TREATMENT STAGE

slide-18
SLIDE 18

18

Plate Press ACCESSORIES

PLANT SECTION «B» SLUDGE TREATMENT STAGE

slide-19
SLIDE 19

19

PLANT SECTION «C» ANCILLARY EQUIPMENTS

Water NEUTRALIZATION UNIT

slide-20
SLIDE 20

CHEMICAL CONDITIONING

20

PLANT SECTION «C» ANCILLARY EQUIPMENTS

slide-21
SLIDE 21

SERVICE UNITS

21

PLANT SECTION «C» ANCILLARY EQUIPMENTS

slide-22
SLIDE 22

HOUSINGS

22

PLANT SECTION «C» ANCILLARY EQUIPMENTS

slide-23
SLIDE 23

Experimental studies of physical-chemical processes for wastewater treatment applications at a pilot scale Physical-chemical characterization of sludge and waste water Material gradations analysis Flocculation tests through for the definition of optimal process and reagents Filtration tests of sludge originated from wastewater treatment at laboratory or pilot scale

23

R&D - LABORATORY A KEY RESOURCE Laboratory tests are paramount to design the most efficient and reliable clarification and filtration process

Even if sludge and wate waters may be coarsely classified on an experience and empirical basis, each one has specific chemical and physical properties that generates clarification and dehydration different behaviours.

slide-24
SLIDE 24

24

R&D - LABORATORY TEST TOOLS AND DEVICES

PILOT PLATE PRESS

Built as a scale reduction of a production plate press, and working at its nominal pressure, this device symulates the entire filtration process, allowing to cast an accurate prediction

  • f the complete plant performances

Sludge solids gradation and physical conditions impact directly on filtration time. This test is capable of defining proper filtration time of customer’s sluge samples, that reflects on the correct press dimensioning. This way customer is safe that the selected press is:

  • Large enougth to manage all the sludge production fulfilling the project specifications, avoiding the risk of

selecting a smaller and insufficient press

  • Not larger than needed, allowing a cost saving in purchasement and maintenance phases
