Nested sampling with demons

Michael Habeck

Max Planck Institute for Biophysical Chemistry and Institute for Mathematical Stochastics Göttingen, Germany

Amboise, September 23, 2014

Bayesian inference

• Probability rules

posterior × evidence = likelihood × prior Pr(θ|D, M) × Pr(D|M) = Pr(D|θ, M) × Pr(θ|M) p(θ) × Z = L(θ) × π(θ)

• Inference
• Evidence

Z = ∫ L(θ) π(θ) dθ

• Posterior

p(θ) = 1 Z L(θ) π(θ)

Nested sampling

• The evidence reduces to a one-dimensional integral:

Z = ∫ L(θ) π(θ) dθ = ∫ 1 L(X) dX summing over prior mass X(λ) = ∫

L(θ)≥λ

π(θ) dθ, X(0) = 1, X(∞) = 0.

Nested sampling

• The evidence reduces to a one-dimensional integral:

Z = ∫ L(θ) π(θ) dθ = ∫ 1 L(X) dX summing over prior mass X(λ) = ∫

L(θ)≥λ

π(θ) dθ, X(0) = 1, X(∞) = 0.

• Prior masses can be ordered:

X(λ) < X(λ′) if λ > λ′

• Idea: We can evaluate L exactly and estimate X

Estimation of prior masses

• Nested sequence of truncated priors:

p(θ|λ) = Θ[L(θ) − λ] X(λ) π(θ) where Θ(x) = { 0 ; x < 0 1 ; x ≥ 0

• Distribution of prior masses at likelihood contour λ:

X ∼ Uniform(0, X(λ))

• Order statistics:

Xmax ∼ N X N−1 X(λ)N where Xmax is the maximum of N uniformely distributed Xn ∼ Uniform(0, X(λ))

Nested sampling algorithm

Require: N (ensemble size), m (number of iterations) λ0 = 0, X0 = 1, S = {θ1, . . . , θN} (states) where θn ∼ π(θ) ▷ Initialize for k = 1, . . . , m do θk = argmin{L(θn)|n = 1, . . . , N} ▷ Store state with smallest likelihood λk = L(θk) ▷ Define new likelihood contour Xk = t Xk−1 where t ∼ N t N−1 ▷ Estimate prior mass θ ∼ p(θ|λk) ▷ Draw new state from truncated prior S ← S \ {θk} ∪ {θ} ▷ Replace current with new state end for Z = ∑m

k=1 λk (Xk−1 − Xk)

▷ Estimate evidence

Compression

• Compression achieved by a single nested sampling iteration

H(λ → λ′) = ∫ p(θ|λ′) ln[p(θ|λ′)/p(θ|λ)] dθ = ln[X(λ)/X(λ′)]

• Average compression is constant

⟨H(λ → λ′)⟩ = −⟨ln t ⟩t∼Beta(N,1) = 1/N

Physical analogy

Bayesian inference Statistical physics model parameters θ configuration/microstate θ negative log likelihood − ln L(θ) potential energy E(θ) log prior mass ln X(λ) volume entropy S(ϵ) = ln X(ϵ) likelihood contour L(θ) > λ energy bound E(θ) < ϵ prior mass X(λ) cumulative DOS X(ϵ) = ∫ ϵ

−∞ g(E) dE

evidence Z = ∫ L(X )dX partition function Z(β) = ∫ e−βEg(E) dE truncated prior microcanonical ensemble

Microcanonical ensemble

• Density of states (DOS)

g(E ) = ∫ δ[E − E(θ)] π(θ) dθ = ∂EX(E )

• Microcanonical entropy and temperature:

S(E ) = ln X(E ), T(E ) = 1/∂ES(E )

• Compression:

H(ϵ′ → ϵ) = S(ϵ′) − S(ϵ) = ∫ ϵ′

ϵ

β(E ) dE where the inverse temperature β = 1/T measures the entropy production

Enter the demon

• Implement truncated prior as microcanonical ensemble with additional

demon absorbing energy D : p(θ, D |ϵ) = 1 X(ϵ) δ[ϵ − D − E(θ)] Θ(D) π(θ) and explore constant energy shells

• Creutz algorithm:

Require: ϵ (upper bound on total energy) θ ∼ π(θ) with energy E = E(θ) ≤ ϵ, D = ϵ − E ▷ Initialize while not converged do θ ′ ∼ π(θ) with energy E ′ = E(θ ′) ▷ Generate a candidate D ′ = D − ∆E where ∆E = E ′ − E ▷ Update demon’s state if D ′ ≥ 0 then (θ, D) ← (θ ′, D ′) ▷ Accept end if end while

Sampling the Ising model with a single demon

8000 6000 4000 2000

energy E

2500 2000 1500 1000 500

Gibbs entropy SG (E)

A

estimated lnXk

• Nearest-neighbor interaction on a 64 × 64 lattice: E(θ) = ∑

⟨i,j ⟩ θiθj where

θi = ±1

• Nested sampling provides a very accurate estimate of the volume entropy

S = ln X

Sampling the Ising model with a single demon

8000 6000 4000 2000

energy E

0.0 0.2 0.4 0.6 0.8 1.0

inverse temperature βG (E)

B

heat capacity ln(1 +

p

2)/2

• H(ϵ′ → ϵ) = S(ϵ′) − S(ϵ) =

∫ ϵ′

ϵ β(E ) dE

• ⟨H(ϵ′ → ϵ)⟩ = 1/N, therefore β(ϵk) (ϵk − ϵk+1) ≈ 1/N
• histogram of energy bounds ϵk matches the inverse temperature /

entropy production β(E )

Sampling the Ising model with a single demon

8000 6000 4000 2000

energy E

0.0 0.2 0.4 0.6 0.8 1.0

inverse temperature βG (E)

C

estimated βB

• The demon’s energy distribution is

p(D|ϵ) = ∫ p(θ, D|ϵ) dθ = g(ϵ − D) X(ϵ) ≈ 1 T(ϵ) exp{−D/T(ϵ)}

• The demon may serve as a thermometer: D ≈ T

Properties of nested sampling

Pros: . 1 Nested sampling is a microcanonical approach: energy E is the control parameter rather than the temperature used in thermal approaches . . 2 constructs an adaptive “cooling” protocol {ϵk} . . 3 progresses at constant thermodynamic speed: ∆S ≈ 1/N . . 4 provides an estimate of the entropy S Cons: . . 1 Nested sampling requires efficient sampling from p(θ|ϵ) = 1 X(ϵ) Θ[ϵ − E(θ)] π(θ) = 1 X(ϵ) ∫ δ[ϵ − D − E(θ)] Θ(D) π(θ) dD

Releasing more demons

• We would like to preserve nested sampling’s adaptive behavior but be

more flexible in terms of the ensemble

• Idea: introduce more demons in order to smooth the ensemble

p(θ, D, K |ϵ) = 1 Y(ϵ) δ[ϵ − D − K − E(θ)] Θ(D ) f(K ) π(θ) where the prior mass of the compound system is Y(ϵ) = ∫ Θ(ϵ − H ) (f ⋆ g)(H ) dH involving the convolution (f ⋆ g)(H )

• Nested sampling tracks Y(ϵ) where ϵ is an upper bound on the total

energy H = K + E

Releasing more demons

• Nested sampling estimates the evidence of the extended system

ZH = ∫ e−H(f ⋆ g)(H ) dH = ZK ZE from which we can obtain the evidence of the original system ZE

• Marginal distribution of configurations

p(θ|ϵ) = ∫ p(θ, D, K |ϵ) dD dK = 1 Y(ϵ) π(θ) F [ϵ − E(θ)] where F(K ) = ∫ K

−∞ f(t) dt is the cdf of the demon’s energy distribution

• Sampling (θ, K ):

θ ∼ p(θ|ϵ) ∝ π(θ) F [ϵ − E(θ)] K ∼ p(K |θ, ϵ) ∝ f(K ) Θ[ϵ − E(θ) − K ]

Demonic nested sampling of the ten state Potts model

Demon: f(K ) ∝ Θ(Kmax − K) Kd/2−1 (d-dimensional harmonic oscillator where d =dimension of configuration space) p(θ|ϵ) ∝ Θ[ϵ − E(θ)] π(θ) × { [ϵ − E(θ)]d/2; ϵ − E(θ) ≤ Kmax Kd/2

max;

ϵ − E(θ) > Kmax

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5

iteration k

1e5 2.0 1.5 1.0 0.5 0.0

energy bounds ǫk

1e3

A

standard NS demonic NS 1080 1060 1040 1020 1000 980 960 940

energy E

1 2 3 4 5 61e3

B

100 200 300 400 500

demon capacity Kmax

10 5 5 10

relative accuracy logZ [%] C

Nested sampling in phase space

• In continuous configuration spaces, it is convenient to unfold the demon

and introduce momenta f(K) = ∫ δ[K − K(ξ)] dξ where K(ξ) = 1 2

d

∑

i=1

ξ2

i

(kinetic energy)

• The marginal distribution in configuration space is

p(θ|ϵ) ∝ Θ[ϵ − E(θ)] π(θ) × { [ϵ − E(θ)]d/2; ϵ − E(θ) ≤ Kmax Kd/2

max;

ϵ − E(θ) > Kmax

• Hamiltonian dynamics for exploration:

(θ, ξ) L → (θ′, ξ′) where L is an integrator (e.g. the leapfrog)

Microcanonical Hamiltonian Monte Carlo

• 2(d + 1) dimensional phase space: implement demon D as harmonic
• scillator with energy D = (ξ2

d+1 + θ2 d+1)/2

• Require: ϵ (total energy), configuration θ with E(θ) < ϵ

θd+1 = 0 ▷ Initialize demon D while not converged do ξ ∼ N(0, 1) ▷ Draw momenta from (d + 1)-dim Gaussian ξ ← ξ × √ ϵ − E − D/∥ξ∥ ▷ Scale momenta so as to match excess energy (θ, ξ) L → (θ′, ξ′) ▷ Run the leapfrog algorithm H ′ = E(θ ′) + K(ξ ′) ▷ Compute total energy of candidate if H ′ < ϵ then θ ← θ′, E ← E(θ) ▷ Accept end if end while

Application to GS peptide

0.0 0.2 0.4 0.6 0.8 1.0 1.2

iteration k

1e4 100 100 200 300 400 500 600 700 800

energy E(θk )

B

1 2 3 4 5

RMSD [ ]

50 100 150 200

C

• A: Native structure of the GS peptide
• B: Evolution of the energy (goodness-of-fit) during nested sampling
• C: Structure’s accuracy measured by the root-mean square deviation

(RMSD) to the crystal structure

Other demons

Distribution of system’s energy p(E |ϵ) = Θ(ϵ − E ) Y(ϵ) g(E ) F(ϵ − E ) demon pdf f(K) cdf F(K) Gauss √

β 2π e− β

2 K2

1 2 [1 + erf(

√ β/2 K)] Logarithmic K(ξ1, ξ2) = 1

2ξ2 1 + β−1 ln |ξ2|

• scillator

⇒ √8πβ eβK √ 8π/β eβK Fermi β

e−βK (1+e−βK)2 1 1+e−βK

Application to SH3 domain

• Structure determination from sparse distance data measured by NMR

spectroscopy

• Structure ensemble as accurate and precise as with parallel tempering

Summary

• Nested sampling is a powerful method to study the microcanonical

ensemble

• By means of demons we can smooth the microcanonical ensemble, which

eases the exploration of configuration space

• All of the desired features of nested sampling are preserved
