SLIDE 1

Natural Language Processing (CSE 490U): Featurized Language Models

Noah Smith

c 2017 University of Washington nasmith@cs.washington.edu

January 9, 2017

1 / 62

SLIDE 2

What’s wrong with n-grams?

Data sparseness: most histories and most words will be seen only rarely (if at all).

2 / 62

SLIDE 3

What’s wrong with n-grams?

Data sparseness: most histories and most words will be seen only rarely (if at all). Next central idea: teach histories and words how to share.

3 / 62

SLIDE 4

Log-Linear Models: Definitions

We define a conditional log-linear model p(Y | X) as:

◮ Y is the set of events/outputs ( for language modeling, V) ◮ X is the set of contexts/inputs ( for n-gram language

modeling, Vn−1)

◮ φ : X × Y → Rd is a feature vector function ◮ w ∈ Rd are the model parameters

pw(Y = y | X = x) = exp w · φ(x, y)

y′∈Y

exp w · φ(x, y′)

4 / 62

SLIDE 5

Breaking It Down

pw(Y = y | X = x) = exp w · φ(x, y)

y′∈Y

exp w · φ(x, y)

5 / 62

SLIDE 6

Breaking It Down

pw(Y = y | X = x) = exp w · φ(x, y)

y′∈Y

exp w · φ(x, y) linear score w · φ(x, y)

6 / 62

SLIDE 7

Breaking It Down

pw(Y = y | X = x) = exp w · φ(x, y)

y′∈Y

exp w · φ(x, y) linear score w · φ(x, y) nonnegative exp w · φ(x, y)

7 / 62

SLIDE 8

Breaking It Down

pw(Y = y | X = x) = exp w · φ(x, y)

y′∈Y

exp w · φ(x, y) linear score w · φ(x, y) nonnegative exp w · φ(x, y) normalizer

y′∈Y

exp w · φ(x, y′) = Zw(x)

8 / 62

SLIDE 9

Breaking It Down

pw(Y = y | X = x) = exp w · φ(x, y)

y′∈Y

exp w · φ(x, y) linear score w · φ(x, y) nonnegative exp w · φ(x, y) normalizer

y′∈Y

exp w · φ(x, y′) = Zw(x) “Log-linear” comes from the fact that: log pw(Y = y | X = x) = w · φ(x, y) − log Zw(x)

constant in y

This is an instance of the family of generalized linear models.

9 / 62

SLIDE 10

The Geometric View

Suppose we have instance x, Y = {y1, y2, y3, y4}, and there are

nly two features, φ1 and φ2.

(x, y3) ϕ1 ϕ2 (x, y1) (x, y4) (x, y2)

10 / 62

SLIDE 11

The Geometric View

Suppose we have instance x, Y = {y1, y2, y3, y4}, and there are

nly two features, φ1 and φ2.

(x, y3) ϕ1 ϕ2 (x, y1) (x, y4) (x, y2)

w · φ = w1φ1 + w2φ2 = 0

11 / 62

SLIDE 12

The Geometric View

Suppose we have instance x, Y = {y1, y2, y3, y4}, and there are

nly two features, φ1 and φ2.

(x, y3) ϕ1 ϕ2 (x, y1) (x, y4) (x, y2)

p(y3 | x) > p(y1 | x) > p(y4 | x) > p(y2 | x)

12 / 62

SLIDE 13

The Geometric View

Suppose we have instance x, Y = {y1, y2, y3, y4}, and there are

nly two features, φ1 and φ2.

(x, y3) ϕ1 ϕ2 (x, y1) (x, y4) (x, y2)

13 / 62

SLIDE 14

The Geometric View

Suppose we have instance x, Y = {y1, y2, y3, y4}, and there are

nly two features, φ1 and φ2.

(x, y3) ϕ1 ϕ2 (x, y1) (x, y4) (x, y2)

p(y3 | x) > p(y1 | x) > p(y2 | x) > p(y4 | x)

14 / 62

SLIDE 15

Why Build Language Models This Way?

◮ Exploit features of histories for sharing of statistical strength

and better smoothing (Lau et al., 1993)

◮ Condition the whole text on more interesting variables like the

gender, age, or political affiliation of the author (Eisenstein et al., 2011)

◮ Interpretability!

◮ Each feature φk controls a factor to the probability (ewk). ◮ If wk < 0 then φk makes the event less likely by a factor of

1 ewk .

◮ If wk > 0 then φk makes the event more likely by a factor of

ewk.

◮ If wk = 0 then φk has no effect. 15 / 62

SLIDE 16

Log-Linear n-Gram Models

pw(X = x) =

ℓ

j=1

pw(Xj = xj | X1:j−1 = x1:j−1) =

ℓ

j=1

exp w · φ(x1:j−1, xj) Zw(x1:j−1)

assumption

=

ℓ

j−1

exp w · φ(xj−n+1:j−1, xj) Zw(xj−n+1:j−1) =

ℓ

j=1

exp w · φ(hj, xj) Zw(hj)

16 / 62

SLIDE 17

Example

The man who knew too much many little few . . . hippopotamus

17 / 62

SLIDE 18

What Features in φ(Xj−n+1:j−1, Xj)?

18 / 62

SLIDE 19

What Features in φ(Xj−n+1:j−1, Xj)?

◮ Traditional n-gram features: “Xj−1 = the ∧ Xj = man”

19 / 62

SLIDE 20

What Features in φ(Xj−n+1:j−1, Xj)?

◮ Traditional n-gram features: “Xj−1 = the ∧ Xj = man” ◮ “Gappy” n-grams: “Xj−2 = the ∧ Xj = man”

20 / 62

SLIDE 21

What Features in φ(Xj−n+1:j−1, Xj)?

◮ Traditional n-gram features: “Xj−1 = the ∧ Xj = man” ◮ “Gappy” n-grams: “Xj−2 = the ∧ Xj = man” ◮ Spelling features: “Xj’s first character is capitalized”

21 / 62

SLIDE 22

What Features in φ(Xj−n+1:j−1, Xj)?

◮ Traditional n-gram features: “Xj−1 = the ∧ Xj = man” ◮ “Gappy” n-grams: “Xj−2 = the ∧ Xj = man” ◮ Spelling features: “Xj’s first character is capitalized” ◮ Class features: “Xj is a member of class 132”

22 / 62

SLIDE 23

What Features in φ(Xj−n+1:j−1, Xj)?

◮ Traditional n-gram features: “Xj−1 = the ∧ Xj = man” ◮ “Gappy” n-grams: “Xj−2 = the ∧ Xj = man” ◮ Spelling features: “Xj’s first character is capitalized” ◮ Class features: “Xj is a member of class 132” ◮ Gazetteer features: “Xj is listed as a geographic place name”

23 / 62

SLIDE 24

What Features in φ(Xj−n+1:j−1, Xj)?

◮ Traditional n-gram features: “Xj−1 = the ∧ Xj = man” ◮ “Gappy” n-grams: “Xj−2 = the ∧ Xj = man” ◮ Spelling features: “Xj’s first character is capitalized” ◮ Class features: “Xj is a member of class 132” ◮ Gazetteer features: “Xj is listed as a geographic place name”

You can define any features you want!

◮ Too many features, and your model will overfit ◮ Too few (good) features, and your model will not learn

24 / 62

SLIDE 25

What Features in φ(Xj−n+1:j−1, Xj)?

◮ Traditional n-gram features: “Xj−1 = the ∧ Xj = man” ◮ “Gappy” n-grams: “Xj−2 = the ∧ Xj = man” ◮ Spelling features: “Xj’s first character is capitalized” ◮ Class features: “Xj is a member of class 132” ◮ Gazetteer features: “Xj is listed as a geographic place name”

You can define any features you want!

◮ Too many features, and your model will overfit

◮ “Feature selection” methods, e.g., ignoring features with very

low counts, can help.

◮ Too few (good) features, and your model will not learn

25 / 62

SLIDE 26

“Feature Engineering”

◮ Many advances in NLP (not just language modeling) have

come from careful design of features.

26 / 62

SLIDE 27

“Feature Engineering”

◮ Many advances in NLP (not just language modeling) have

come from careful design of features.

◮ Sometimes “feature engineering” is used pejoratively.

27 / 62

SLIDE 28

“Feature Engineering”

◮ Many advances in NLP (not just language modeling) have

come from careful design of features.

◮ Sometimes “feature engineering” is used pejoratively.

◮ Some people would rather not spend their time on it! 28 / 62

SLIDE 29

“Feature Engineering”

◮ Many advances in NLP (not just language modeling) have

come from careful design of features.

◮ Sometimes “feature engineering” is used pejoratively.

◮ Some people would rather not spend their time on it!

◮ There is some work on automatically inducing features (Della

Pietra et al., 1997).

29 / 62

SLIDE 30

“Feature Engineering”

◮ Many advances in NLP (not just language modeling) have

come from careful design of features.

◮ Sometimes “feature engineering” is used pejoratively.

◮ Some people would rather not spend their time on it!

◮ There is some work on automatically inducing features (Della

Pietra et al., 1997).

◮ More recent work in neural networks can be seen as

discovering features (instead of engineering them).

30 / 62

SLIDE 31

“Feature Engineering”

◮ Many advances in NLP (not just language modeling) have

come from careful design of features.

◮ Sometimes “feature engineering” is used pejoratively.

◮ Some people would rather not spend their time on it!

◮ There is some work on automatically inducing features (Della

Pietra et al., 1997).

◮ More recent work in neural networks can be seen as

discovering features (instead of engineering them).

◮ But in much of NLP, there’s a strong preference for

interpretable features.

31 / 62

SLIDE 32

How to Estimate w?

n-gram log-linear n-gram pθ(x) =

ℓ

j=1

θxj|hj

ℓ

j−1

exp w · φ(hj, xj) Zw(hj) Parameters: θv|h wk

∀v ∈ V, h ∈ (V ∪ {})n−1 ∀k ∈ {1, . . . , d}

MLE: ˆ θv|h = c(hv) c(h) no closed form

32 / 62

SLIDE 33

MLE for w

◮ Let training data consist of {(hi, xi)}N i=1.

33 / 62

SLIDE 34

MLE for w

◮ Let training data consist of {(hi, xi)}N i=1. ◮ Maximum likelihood estimation is:

max

w∈Rd N

i=1

log pw(xi | hi) max

w∈Rd N

i=1

log exp w · φ(hi, v) Zw(hi) = max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v)

Zw(hi)

34 / 62

SLIDE 35

MLE for w

◮ Let training data consist of {(hi, xi)}N i=1. ◮ Maximum likelihood estimation is:

max

w∈Rd N

i=1

log pw(xi | hi) max

w∈Rd N

i=1

log exp w · φ(hi, v) Zw(hi) = max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v)

Zw(hi)

◮ This is concave in w.

35 / 62

SLIDE 36

MLE for w

◮ Let training data consist of {(hi, xi)}N i=1. ◮ Maximum likelihood estimation is:

max

w∈Rd N

i=1

log pw(xi | hi) max

w∈Rd N

i=1

log exp w · φ(hi, v) Zw(hi) = max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v)

Zw(hi)

◮ This is concave in w. ◮ Zw(hi) involves a sum over V terms.

36 / 62

SLIDE 37

MLE for w

max

w∈Rd N

i=1

w · φ(hi, xi) − log Zw(hi)

fi(w)

37 / 62

SLIDE 38

MLE for w

max

w∈Rd N

i=1

w · φ(hi, xi) − log Zw(hi)

fi(w)

Hope/fear view: for each instance i,

◮ increase the score of the correct output xi,

score(xi) = w · φ(hi, xi)

◮ decrease the “softened max” score overall,

log

v∈V exp score(v)

38 / 62

SLIDE 39

MLE for w

max

w∈Rd N

i=1

w · φ(hi, xi) − log Zw(hi)

fi(w)

Gradient view: ∇wfi = φ(hi, xi)

bserved features

−

v∈V

pw(v | hi) · φ(h, v)

expected features

Setting this to zero means getting model’s expectations to match empirical observations.

39 / 62

SLIDE 40

MLE for w: Algorithms

◮ Batch methods (L-BFGS is popular) ◮ Stochastic gradient ascent/descent more common today,

especially with special tricks for adapting the step size over time

◮ Many specialized methods (e.g., “iterative scaling”)

40 / 62

SLIDE 41

Stochastic Gradient Descent

Goal: minimize N

i=1 fi(w) with respect to w.

Input: initial value w, number of epochs T, learning rate α For t ∈ {1, . . . , T}:

◮ Choose a random permutation π of {1, . . . , N}. ◮ For i ∈ {1, . . . , N}:

w ← w − α · ∇wfπ(i) Output: w

41 / 62

SLIDE 42

Avoiding Overfitting

Maximum likelihood estimation: max

w∈Rd N

i=1

w · φ(hi, xi) − log Zw(hi)

◮ If φj(h, x) is (almost) always positive, we can always increase

the objective (a little bit) by increasing wj toward +∞.

42 / 62

SLIDE 43

Avoiding Overfitting

Maximum likelihood estimation: max

w∈Rd N

i=1

w · φ(hi, xi) − log Zw(hi)

◮ If φj(h, x) is (almost) always positive, we can always increase

the objective (a little bit) by increasing wj toward +∞. Standard solution is to add a regularization term: max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v) − λwp

p

where λ > 0 is a hyperparameter and p = 2 or 1.

43 / 62

SLIDE 44

MLE for w

If we had more time, we’d study this problem more carefully! Here’s what you must remember:

◮ There is no closed form; you must use a numerical

ptimization algorithm like stochastic gradient descent.

◮ Log-linear models are powerful but expensive (Zw(hi)). ◮ Regularization is very important; we don’t actually do MLE.

◮ Just like for n-gram models! Only even more so, since

log-linear models are even more expressive.

44 / 62

SLIDE 45

To-Do List

◮ Online quiz: due 11:59 pm Tuesday ◮ Read: Collins (2011) §2 ◮ A1, out today, due January 18

45 / 62

SLIDE 46

References I

Galen Andrew and Jianfeng Gao. Scalable training of ℓ1-regularized log-linear models. In Proc. of ICML, 2007. Adam Berger, Stephen Della Pietra, and Vincent Della Pietra. A maximum entropy approach to natural language processing. Computational Linguistics, 22(1):39–71, 1996. Michael Collins. Log-linear models, MEMMs, and CRFs, 2011. URL http://www.cs.columbia.edu/~mcollins/crf.pdf. Stephen Della Pietra, Vincent Della Pietra, and John Lafferty. Inducing features of random fields. IEEE Transactions on Pattern Analysis and Machine Intelligence, 19 (4):380–393, 1997. Jacob Eisenstein, Amr Ahmed, and Eric P Xing. Sparse additive generative models of

text. In Proc. of ICML, 2011.

Joshua Goodman. Classes for fast maximum entropy training. In Proc. of ICASSP, 2001. John Langford, Lihong Li, and Tong Zhang. Sparse online learning via truncated

gradient. In NIPS, 2009.

Raymond Lau, Ronald Rosenfeld, and Salim Roukos. Trigger-based language models: A maximum entropy approach. In Proc. of ICASSP, 1993. Roni Rosenfeld. Adaptive Statistical Language Modeling: A Maximum Entropy

Approach. PhD thesis, Carnegie Mellon University, 1994.

Robert Tibshirani. Regression shrinkage and selection via the lasso. Journal of the Royal Statistical Society. Series B (Methodological), pages 267–288, 1996.

46 / 62

SLIDE 47

Extras

47 / 62

SLIDE 48

Special Case: Logistic Regression

Consider the case where Y = {+1, −1}. pw(Y = +1 | x) = exp w · φ(x, +1) exp w · φ(x, +1) + exp w · φ(x, −1)

48 / 62

SLIDE 49

Special Case: Logistic Regression

Consider the case where Y = {+1, −1}. pw(Y = +1 | x) = exp w · φ(x, +1) exp w · φ(x, +1) + exp w · φ(x, −1) = logit−1 (w · (φ(x, +1) − φ(x, −1)))

49 / 62

SLIDE 50

Special Case: Logistic Regression

Consider the case where Y = {+1, −1}. pw(Y = +1 | x) = exp w · φ(x, +1) exp w · φ(x, +1) + exp w · φ(x, −1) = logit−1 (w · (φ(x, +1) − φ(x, −1)))

notation change

= logit−1 (w · f(x))

50 / 62

SLIDE 51

Special Case: Logistic Regression

Consider the case where Y = {+1, −1}. pw(Y = +1 | x) = exp w · φ(x, +1) exp w · φ(x, +1) + exp w · φ(x, −1) = logit−1 (w · (φ(x, +1) − φ(x, −1)))

notation change

= logit−1 (w · f(x))

◮ Should be familiar, if you know about logistic regression.

51 / 62

SLIDE 52

Special Case: Logistic Regression

Consider the case where Y = {+1, −1}. pw(Y = +1 | x) = exp w · φ(x, +1) exp w · φ(x, +1) + exp w · φ(x, −1) = logit−1 (w · (φ(x, +1) − φ(x, −1)))

notation change

= logit−1 (w · f(x))

◮ Should be familiar, if you know about logistic regression. ◮ When Y = {1, 2, . . . , k}, log-linear models are often called

multinomial logistic regression.

52 / 62

SLIDE 53

Special Case: Classic n-Gram Language Model

Consider an n-gram language model, where X = Vn−1 and Y = V. Let:

◮ d = 1 ◮ φ1(h, v) = log c(hv) ◮ w1 = 1 ◮ Z(h) =

v′∈V

exp log c(hv′) =

v′∈V

c(hv′) = c(h)

53 / 62

SLIDE 54

Special Case: Classic n-Gram Language Model

Consider an n-gram language model, where X = Vn−1 and Y = V. Let:

◮ d = 1 ◮ φ1(h, v) = log c(hv) ◮ w1 = 1 ◮ Z(h) =

v′∈V

exp log c(hv′) =

v′∈V

c(hv′) = c(h) Alternately:

◮ d = |V|n ◮ φ˜ h,˜ v(h, v) =

1

if h = ˜ h ∧ v = ˜ v

therwise

◮ w˜ h,˜ v = log c(˜ h˜ v) c(˜ h) ◮ Z(h) = 1

54 / 62

SLIDE 55

ℓ1 Regularization

This case warrants a little more discussion: max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v) − λw1 Note that: w1 =

d

j=1

|wj|

◮ This results in sparsity (i.e., many wj = 0).

55 / 62

SLIDE 56

ℓ1 Regularization

This case warrants a little more discussion: max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v) − λw1 Note that: w1 =

d

j=1

|wj|

◮ This results in sparsity (i.e., many wj = 0).

◮ Many have argued that this is a good thing (Tibshirani, 1996);

it’s a kind of feature selection.

56 / 62

SLIDE 57

ℓ1 Regularization

This case warrants a little more discussion: max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v) − λw1 Note that: w1 =

d

j=1

|wj|

◮ This results in sparsity (i.e., many wj = 0).

◮ Many have argued that this is a good thing (Tibshirani, 1996);

it’s a kind of feature selection.

◮ Do not confuse it with data sparseness (a problem to be

vercome)!

57 / 62

SLIDE 58

ℓ1 Regularization

This case warrants a little more discussion: max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v) − λw1 Note that: w1 =

d

j=1

|wj|

◮ This results in sparsity (i.e., many wj = 0).

◮ Many have argued that this is a good thing (Tibshirani, 1996);

it’s a kind of feature selection.

◮ Do not confuse it with data sparseness (a problem to be

vercome)!

◮ This is not differentiable at wj = 0.

58 / 62

SLIDE 59

ℓ1 Regularization

This case warrants a little more discussion: max

w∈Rd N

i=1

w · φ(hi, xi) − log

v∈V

exp w · φ(hi, v) − λw1 Note that: w1 =

d

j=1

|wj|

◮ This results in sparsity (i.e., many wj = 0).

◮ Many have argued that this is a good thing (Tibshirani, 1996);

it’s a kind of feature selection.

◮ Do not confuse it with data sparseness (a problem to be

vercome)!

◮ This is not differentiable at wj = 0. ◮ Optimization: special solutions for batch (e.g., Andrew and

Gao, 2007) and stochastic (e.g., Langford et al., 2009) settings.

59 / 62

SLIDE 60

Maximum Entropy

Consider a distribution p over events in X. The Shannon entropy (in bits) of p is defined as: H(p) = −

x∈X

p(X = x) if p(X = x) = 0 log2 p(X = x)

therwise

This is a measure of “randomness”; entropy is zero when p is deterministic and log |X| when p is uniform. Maximum entropy principle: among distributions that fit the data, pick the one with the greatest entropy.

60 / 62

SLIDE 61

Maximum Entropy

If “fit the data” is taken to mean ∀k ∈ {1, . . . , d}, Ep[φk] = ˜ E[φk] then the MLE of the log-linear family with features φ is the maximum entropy solution. This is why log-linear models are sometimes called “maxent” models (e.g., Berger et al., 1996)

61 / 62

SLIDE 62

“Whole Sentence” Log-Linear Models

(Rosenfeld, 1994)

Instead of a log-linear model for each word-given-history, define a single log-linear model over event space V†: pw(x) = exp w · φ(x) Zw

◮ Any feature of the sentence could be included in this model! ◮ Zw is deceptively simple-looking!

Zw =

x∈V†

exp w · φ(x)

62 / 62
