NAPCA Workshop Brent Lichty Damage Prevention Engineer UPRR August 15, 2013 1 There are only.. 16 DAYS until College Football GO VOLS! 2 Overview UPRR System AAR Open Top Loading Rules Committee AAR Open Top Rules

slide-1
SLIDE 1

1

NAPCA Workshop

Brent Lichty Damage Prevention Engineer UPRR August 15, 2013

slide-2
SLIDE 2

2

There are only…..

  • 16 DAYS until – College Football – GO VOLS!
slide-3
SLIDE 3

3

Overview

  • UPRR System
  • AAR Open Top Loading Rules Committee
  • AAR Open Top Rules
  • Rules and Application Review
  • Common Errors
  • Innovations
slide-4
SLIDE 4

4

Fast Facts

  • Commodity

Revenue $15.5 B

  • Route Miles

32,200 in 23 States

  • Employees

49,000

  • Annual Payroll

$3.9 B

  • Customers

25,000

  • Locomotives

8,700

Union Pacific System

Portland Oakland LA Calexico Nogales El Paso Seattle Eagle Pass SLC Eastport Brownsville Houston KC

  • St. Louis

Omaha Twin Cities Duluth Denver Laredo Dallas Memphis Chicago New Orleans

slide-5
SLIDE 5

5 DAMAGE PREVENTION SERVICES - FIELD OPERATIONS (Page 2 of 3)

WAYNE RONCI

Director Damage P revention Field Operations

PAUL SEDILLO

Manager Customer P roducts Damage P revention Services (Denver, CO)

KIRK JACOBSON

Manager Customer P roducts Damage P revention Services (Chicago, IL)

KEITH KEARNS

Manager Customer P roducts Damage P revention Services (Salt Lake City, UT)

BETH LAMBERT

Manager Customer P roducts Damage P revention Services (Kansas City, MO)

HARRY CHAMBERS

Manager Customer P roducts Damage P revention Services (Mira Loma, CA)

MARCO VILLARREAL

Manager Customer P roducts Damage P revention Services (San Antonio, TX)

NICHOLAS KELLY

Manager Customer P roducts Damage P revention Services (N. Little Rock, AR)

ANDREW JOHNSON

Manager Customer P roducts Damage P revention Services (P

  • rtland, OR)

JEFF VANCE

Manager Customer P roducts Damage P revention Services (Houston, TX)

SETH COX

Manager Customer P roducts Damage P revention Services (Roseville, CA)

Union Pacific DPS Field Managers

slide-6
SLIDE 6

6

AAR Open Top Loading Rules Committee

slide-7
SLIDE 7

7

Does this look SAFE ? Did I adhere to the AAR Loading Requirements ?

What are AAR Loading Requirements?????

slide-8
SLIDE 8

8

General Rule Tie Down : 5.3.1 3 G Longitudinal x 2 G Lateral x 2 G Vertical

3 G 3 G 2 G 2 G 2 G

slide-9
SLIDE 9

9

AAR Figure 285 – Revised 06/2013

slide-10
SLIDE 10

10 10

General Rule 10.3 “All Wood of Good Quality”

slide-11
SLIDE 11

11 11

General Rule 10.3 “Wood Quality”

Inexcusable Quality

slide-12
SLIDE 12

12 12

General Rule 10.1 Note #3 “Douglas Fir” Full 3”x4”

slide-13
SLIDE 13

13 13

General Rule 11.2.3 “Bearing Piece Securement”

slide-14
SLIDE 14

14 14

General Rule 11.2 “Separators”

Separator Inadequate Length for Width of Load. NO CHOCK

slide-15
SLIDE 15

15 15

General Rule 17.2.8 “Free Ends no more than 12” From Seal”

Potential Coating Damage/Scrapes

slide-16
SLIDE 16

16 16

General Rule 17.5.8 “Notch Type Joint Seal”

Band Seal Applied Next to Pipe

slide-17
SLIDE 17

17 17

General Rule 20.6.3

A synthetic webbing and/or tie-down assembly must be removed from service if any of the following conditions are present. (Refer to Fig. 20.7 for illustrations of some sample defect conditions.)

slide-18
SLIDE 18

18 18

General Rule 20.7.3 “Marking along with ABS & WLL

slide-19
SLIDE 19

19 19

“LOOK FOR’S”

This Car had 6 Missing Chocks on Bearing Pieces , 1 side of load

slide-20
SLIDE 20

20 20

“LOOK FOR’S”

slide-21
SLIDE 21

21 21

“LOOK FOR’S”

Chock not making contact to pipe, Quality Rejectable

slide-22
SLIDE 22

22 22

“LOOK FOR’S”

Improper Chock Application and Band Placement

slide-23
SLIDE 23

23 23

“LOOK FOR’S”

Pipe Length Variation / Placement and Separators Doing Nothing. Any pipe movement and these separators become obstructions

slide-24
SLIDE 24

24 24

New Innovations – Non-Metallic Banding

slide-25
SLIDE 25

25 25

New Innovations – Dhatec - System 88

slide-26
SLIDE 26

26 26

New Innovations – Replaceable Bulkhead Walls

slide-27
SLIDE 27

27 27

When Open Tops Go Wrong !!!!

slide-28
SLIDE 28

28 28

Contacts

  • Michael Sandoval

Manager

  • AAR Loading Rules

Damage Prevention Office(719) 584-0511 Cell(719)248-1871 Fax: (719) 585-1895 Email: mike_sandoval@aar.com

  • Brent A. Lichty

Damage Prevention Services Industrial Products and Open Top Loads Union Pacific Center 1400 Douglas Street MC STOP 1330 Omaha, NE 68179-1330 Office: 402-544-6531 Fax: 402-233-3333 Email: balichty@up.com

slide-29
SLIDE 29

29 29

Review & Questions

  • UPRR System
  • AAR Open Top Loading Rules Committee
  • AAR Open Top Rules
  • Rules and Application Review
  • Common Errors
  • Innovations
  • QUESTIONS
