Status of Storm+Lustre and Multi-VO Support

YAN Tian for Distributed Computing Group Meeting

• Oct. 23, 2014

StoRM + Lustre: Test Bed

SE server configuration:

Model Dell PowerEdger R620 CPU Xeon E5-2609 v2 @ 2.50 GHz CPU Cores 8 cores Memory 64 GB HDD scsi 300 GB Network 1 eth0: 1 Gbps Network 2 eth4: 10 Gbps A symblic link to Lustre directory , User can access files in this directory through StoRM webDAV portal This test machine is originally prepared for dCache+Lustre frontend, thus with good network performance

StoRM + Lustre Test 1: single thread download

• Test time: Oct 15, 17:50--18:40
• Lustre is not busy (load 7%, out 80 MB/s)
• 20 files of size 1 GB
• Average download speed: 10.6 MB/s
• with eth0: 1 Gbps
• load of SE: 0.8~1.1 load, 11~13% wa

v.s. When Lustre is busy:

• ut 500~1400 MB/s

StoRM + Lustre Test 2: multi threads/processes download

• Multi-tread download tool: mytget, can’t start multi-thread mode for Lustre
• Multi-process wget download, do not improve much, 22~33 M/s

4 processes 8 processes

StoRM + Lustre Test 3: Symbolic Link Problem

Modify namespace.xml is under trying.

Storm+Lustre Test: To Do

• Solve symblik link problem
• Dataset transfer test between IHEPD-USER
• Open ports 50000:55000
• Dataset transfer test between WHU/USTC-USER

ILC-DIRAC Study: User Interface

• Python code, which can be directly execute
• A job script example:

from DIRAC.Core.Base import Script Script.parseCommandLine() from ILCDIRAC.Interfaces.API.DiracILC import DiracILC dirac = DiracILC(True,“my_job_repository.rep") from ILCDIRAC.Interfaces.API.NewInterface.UserJob import UserJob job = UserJob() job.setName("MyJobName") job.setJobGroup("Agroup") job.setCPUTime(86400) from ILCDIRAC.Interface.API.NewInterface.Application import Mokka, Marlin mo = Mokka() mo.setLogFile(“sim-job.log”) mo.setInputFile(“init.macro”) mo.setOutputFile(“E250-CDR_wo_Pnnh.eL.eR.001.slcio”) mo.setNumberOfEvents(1000) job.append(mo) mar = Marlin() mar.setParameters(“value”) mar.getInputFromApp(mo) job.append(mar) job.submit(dirac)

applications stack dirac instance is job reciever define and set para. for app.

ILC-DIRAC Study: Job Repository

• Repo. Contains all necessary information of jobs
• for Job Monitoring

$ dirac-repo-monitor repo.cfg

• for Retrive all the output sandbox and output data
• $ dirac-repo-retrieve-jobs-output –r –O repo.cfg
• Repository is a functionality provided by DIRAC

call 3 methods

ILC-DIRAC Study: Applications

• Many applications

Generation: Whizard, Pythia, StdHepCut Simulation: Mokka, SLIC Reconstruction: Marlin, LCSIM, SLICPandora Analysis: Marlin, ROOT, Druid, etc…

• A command for user to querry avaliable app. and it’s version

$ dirac-ilc-show-software

• Applications are all defined in module

– ILCDIRAC.Interfaces.API.NewInterface.Application (base class) – ILCDIRAC.Interfaces.API.NewInterface.Applications

• In job script:

from ILCDIRAC.Interface.API.NewInterface.Application import Mokka mo = Mokka() mo.setParameters1(“value1”) mo.setParameters2(“value2”) job.append(mo)

A Generic application for executable outside ILCsoft, e.g.

ga = GenericApplication() ga.setScript(“boss.exe”) ga.setArguments(“jobOptions.txt”)

ILC-DIRAC Study: User Input Data

• For ILC analysis jobs, users always need his own lib. file *.so
• ILC solution: upload to SE, download to WN

$ tar czf lib.tar.gz lib/ $ dirac-dms-add-files /ilc/user/i/initial/some/path/lib.tar.gz lib.tar.gz CERN-SRM $ dirac-dms-remove-files /ilc/user/i/initial/some/path/lib.tar.gz

• In Job Script:

job.setInputSandbox("LFN:/ilc/user/i/initial/some/path/lib.tar.gz")

• ILC allow user to use $ dirac-dms-filecatalog

ILC-DIRAC Study: Class Inheritance

Dirac Job DiracILC UserJob ProductionJob Application Applications ModuleBase MokkaAnalysis MarlinAnalysis PhthiaAnalysis etc… Spliter? DIRAC classes ILC-DIRAC classes

ILC-DIRAC: Module Example (MokkaAnalysis)

called by Job Agent

from ILCDIRAC.Workflow.Modules import MokkaAnalysis ma = MokkaAnalysis() ma.execute()

In this module:

1. retrieve job parameters 2. write a shell script to

a) set environment b) run application c) return status code
