Monitoring HTCondor Andrew Lahiff STFC Rutherford Appleton Laboratory European HTCondor Site Admins Meeting 2014 Introduction Two aspects of monitoring General overview of the system How many running/idle jobs? By user/VO? By

slide-1
SLIDE 1

Monitoring HTCondor

Andrew Lahiff STFC Rutherford Appleton Laboratory

European HTCondor Site Admins Meeting 2014

slide-2
SLIDE 2

Introduction

  • Two aspects of monitoring

– General overview of the system

  • How many running/idle jobs?

By user/VO? By schedd?

  • How full is the farm?
  • How many draining worker nodes?

– More detailed views

  • What are individual jobs doing?
  • What’s happening on individual worker nodes?
  • Health of the different components of the HTCondor pool
  • ...in addition to Nagios
slide-3
SLIDE 3

Introduction

  • Methods

– Command line utilities – Ganglia – Third-party applications

(which run command-line tools or use python API)

slide-4
SLIDE 4

Command line

  • Three useful commands

– condor_status

  • Overview of the pool (including jobs, machines)
  • Information about specific worker nodes

– condor_q

  • Information about jobs in the queue

– condor_history

  • Information about completed jobs
slide-5
SLIDE 5

Overview of jobs

  • bash-4.1$ condor_status -collector

Name Machine RunningJobs IdleJobs HostsTotal RAL-LCG2@condor01.gridpp.rl. condor01.gridpp.rl 10608 8355 11347 RAL-LCG2@condor02.gridpp.rl. condor02.gridpp.rl 10616 8364 11360

slide-6
SLIDE 6

Overview of machines

  • bash-4.1$ condor_status -total

Total Owner Claimed Unclaimed Matched Preempting Backfill X86_64/LINUX 11183 95 10441 592 0 0 0 Total 11183 95 10441 592 0 0 0

slide-7
SLIDE 7

Jobs by schedd

  • bash-4.1$ condor_status -schedd

Name Machine TotalRunningJobs TotalIdleJobs TotalHeldJobs arc-ce01.gridpp.rl.a arc-ce01.g 2388 1990 13 arc-ce02.gridpp.rl.a arc-ce02.g 2011 1995 31 arc-ce03.gridpp.rl.a arc-ce03.g 4272 1994 9 arc-ce04.gridpp.rl.a arc-ce04.g 1424 2385 12 arc-ce05.gridpp.rl.a arc-ce05.g 1 0 6 cream-ce01.gridpp.rl cream-ce01 266 0 0 cream-ce02.gridpp.rl cream-ce02 247 0 0 lcg0955.gridpp.rl.ac lcg0955.gr 0 0 0 lcgui03.gridpp.rl.ac lcgui03.gr 3 0 0 lcgui04.gridpp.rl.ac lcgui04.gr 0 0 0 lcgvm21.gridpp.rl.ac lcgvm21.gr 0 0 0 TotalRunningJobs TotalIdleJobs TotalHeldJobs Total 10612 8364 71

slide-8
SLIDE 8

Jobs by user, schedd

  • bash-4.1$ condor_status -submitters

Name Machine RunningJobs IdleJobs HeldJobs group_ALICE.alice.alice043@g arc-ce01.gridpp.rl 0 0 0 group_ALICE.alice.alicesgm@g arc-ce01.gridpp.rl 540 0 1 group_ATLAS.atlas_pilot.tatl arc-ce01.gridpp.rl 142 0 0 group_ATLAS.prodatls.patls00 arc-ce01.gridpp.rl 82 5 0 group_CMS.cms.cmssgm@gridpp. arc-ce01.gridpp.rl 1 0 0 group_CMS.cms_pilot.ttcms022 arc-ce01.gridpp.rl 214 390 0 group_CMS.cms_pilot.ttcms043 arc-ce01.gridpp.rl 68 100 0 group_CMS.prodcms.pcms004@gr arc-ce01.gridpp.rl 78 476 4 group_CMS.prodcms.pcms054@gr arc-ce01.gridpp.rl 12 910 0 group_CMS.prodcms_multicore. arc-ce01.gridpp.rl 47 102 0 group_DTEAM_OPS.ops.ops047@g arc-ce01.gridpp.rl 0 0 0 group_LHCB.lhcb_pilot.tlhcb0 arc-ce01.gridpp.rl 992 0 2 group_NONLHC.snoplus.snoplus arc-ce01.gridpp.rl 0 0 0 …

slide-9
SLIDE 9

…Jobs by user

RunningJobs IdleJobs HeldJobs group_ALICE.alice.al 0 0 0 group_ALICE.alice.al 3500 368 5 group_ALICE.alice_pi 0 0 0 group_ATLAS.atlas.at 0 0 0 group_ATLAS.atlas.at 0 0 0 group_ATLAS.atlas_pi 414 12 10 group_ATLAS.atlas_pi 0 0 2 group_ATLAS.prodatls 354 36 11 group_CMS.cms.cmssgm 1 0 0 group_CMS.cms_pilot. 371 2223 0 group_CMS.cms_pilot. 0 0 1 group_CMS.cms_pilot. 68 200 0 group_CMS.prodcms.pc 188 1905 10 group_CMS.prodcms.pc 312 3410 0 group_CMS.prodcms_mu 47 102 0 …

slide-10
SLIDE 10

condor_q

[root@arc-ce01 ~]# condor_q

  • - Submitter: arc-ce01.gridpp.rl.ac.uk : <130.246.180.236:64454> : arc-

ce01.gridpp.rl.ac.uk ID OWNER SUBMITTED RUN_TIME ST PRI SIZE CMD 794717.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794718.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794719.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794720.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794721.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794722.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794723.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794725.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) 794726.0 pcms054 12/3 12:07 0+00:00:00 I 0 0.0 (gridjob ) … 3502 jobs; 0 completed, 0 removed, 1528 idle, 1965 running, 9 held, 0 suspended

slide-11
SLIDE 11

Multi-core jobs

  • bash-4.1$ condor_q -global -constraint 'RequestCpus > 1’
  • - Schedd: arc-ce01.gridpp.rl.ac.uk : <130.246.180.236:39356>

ID OWNER SUBMITTED RUN_TIME ST PRI SIZE CMD 832677.0 pcms004 12/5 14:33 0+00:15:07 R 0 2.0 (gridjob ) 832717.0 pcms004 12/5 14:37 0+00:12:02 R 0 0.0 (gridjob ) 832718.0 pcms004 12/5 14:37 0+00:00:00 I 0 0.0 (gridjob ) 832719.0 pcms004 12/5 14:37 0+00:00:00 I 0 0.0 (gridjob ) 832893.0 pcms004 12/5 14:47 0+00:00:00 I 0 0.0 (gridjob ) 832894.0 pcms004 12/5 14:47 0+00:00:00 I 0 0.0 (gridjob ) …

slide-12
SLIDE 12

Multi-core jobs

  • Custom print format
  • bash-4.1$ condor_q -global -pr queue_mc.cpf
  • - Schedd: arc-ce01.gridpp.rl.ac.uk : <130.246.180.236:39356>

ID OWNER SUBMITTED RUN_TIME ST SIZE CMD CORES 832677.0 pcms004 12/5 14:33 0+00:00:00 R 2.0 (gridjob) 8 832717.0 pcms004 12/5 14:37 0+00:00:00 R 0.0 (gridjob) 8 832718.0 pcms004 12/5 14:37 0+00:00:00 I 0.0 (gridjob) 8 832719.0 pcms004 12/5 14:37 0+00:00:00 I 0.0 (gridjob) 8 832893.0 pcms004 12/5 14:47 0+00:00:00 I 0.0 (gridjob) 8 832894.0 pcms004 12/5 14:47 0+00:00:00 I 0.0 (gridjob) 8 …

https://htcondor-wiki.cs.wisc.edu/index.cgi/wiki?p=ExperimentalCustomPrintFormats

slide-13
SLIDE 13

Jobs with specific DN

  • bash-4.1$ condor_q -global -constraint

'x509userproxysubject=="/DC=ch/DC=cern/OU=Organic Units/OU=Users/CN=atlpilo1/CN=614260/CN=Robot: ATLAS Pilot1”’

  • - Schedd: arc-ce03.gridpp.rl.ac.uk : <130.246.181.25:62763>

ID OWNER SUBMITTED RUN_TIME ST PRI SIZE CMD 678275.0 tatls015 12/2 17:57 2+06:07:15 R 0 2441.4 (arc_pilot ) 681762.0 tatls015 12/3 03:13 1+21:12:31 R 0 2197.3 (arc_pilot ) 705153.0 tatls015 12/4 07:36 0+16:49:12 R 0 2197.3 (arc_pilot ) 705807.0 tatls015 12/4 08:16 0+16:09:27 R 0 2197.3 (arc_pilot ) 705808.0 tatls015 12/4 08:16 0+16:09:27 R 0 2197.3 (arc_pilot ) 706612.0 tatls015 12/4 09:16 0+15:09:37 R 0 2197.3 (arc_pilot ) 706614.0 tatls015 12/4 09:16 0+15:09:26 R 0 2197.3 (arc_pilot ) …

slide-14
SLIDE 14

Jobs killed

  • Jobs which were removed

[root@arc-ce01 ~]# condor_history -constraint 'JobStatus == 3’ ID OWNER SUBMITTED RUN_TIME ST COMPLETED CMD 823881.0 alicesgm 12/5 01:01 1+06:13:22 X ??? /var/spool/arc/grid03/CVuMDmBSwGlnCIXDjqi 831849.0 tlhcb005 12/5 13:19 0+18:52:26 X ??? /var/spool/arc/grid09/gWmLDm5x7GlnCIXDjqi 832753.0 tlhcb005 12/5 14:38 0+17:07:07 X ??? /var/spool/arc/grid00/5wqKDm7C9GlnCIXDjqi 819636.0 alicesgm 12/4 19:27 1+12:13:56 X ??? /var/spool/arc/grid00/mlrNDmoErGlnCIXDjqi 825511.0 alicesgm 12/5 03:03 0+18:52:10 X ??? /var/spool/arc/grid04/XpuKDmxLyGlnCIXDjqi 823799.0 alicesgm 12/5 00:56 1+05:58:15 X ??? /var/spool/arc/grid03/DYuMDmzMwGlnCIXDjqi 820001.0 alicesgm 12/4 19:48 1+06:43:22 X ??? /var/spool/arc/grid08/cmzNDmpYrGlnCIXDjqi 833589.0 alicesgm 12/5 16:01 0+14:06:34 X ??? /var/spool/arc/grid09/HKSLDmqUAHlnCIXDjqi 778644.0 tlhcb005 12/2 05:56 4+00:00:10 X ??? /var/spool/arc/grid00/pIJNDm6cvFlnCIXDjqi …

slide-15
SLIDE 15

Jobs killed

  • Jobs removed for exceeding memory limit

[root@arc-ce01 ~]# condor_history -constraint 'JobStatus==3 && ResidentSetSize>1024*RequestMemory' -af ClusterId Owner ResidentSetSize RequestMemory 823953 alicesgm 3500000 3000 824438 alicesgm 3250000 3000 820045 alicesgm 3500000 3000 823881 alicesgm 3250000 3000 … [root@arc-ce04 ~]# condor_history -constraint 'JobStatus==3 && ResidentSetSize>1024*RequestMemory' -af x509UserProxyVOName | sort | uniq -c 515 alice 5 cms 70 lhcb

slide-16
SLIDE 16

condor_who

  • What jobs are currently running on a worker node?

[root@lcg1211 ~]# condor_who OWNER CLIENT SLOT JOB RUNTIME PID PROGRAM tatls015@gridpp.rl.ac.uk arc-ce02.gridpp.rl.ac.uk 1_2 654753.0 0+00:01:54 15743 /usr/libexec/condor/co tatls015@gridpp.rl.ac.uk arc-ce02.gridpp.rl.ac.uk 1_5 654076.0 0+00:56:50 21916 /usr/libexec/condor/co pcms004@gridpp.rl.ac.uk arc-ce04.gridpp.rl.ac.uk 1_10 1337818.0 0+02:51:34 31893 /usr/libexec/condor/co pcms004@gridpp.rl.ac.uk arc-ce04.gridpp.rl.ac.uk 1_7 1337776.0 0+03:06:51 32295 /usr/libexec/condor/co tlhcb005@gridpp.rl.ac.uk arc-ce02.gridpp.rl.ac.uk 1_1 651508.0 0+05:02:45 17556 /usr/libexec/condor/co alicesgm@gridpp.rl.ac.uk arc-ce03.gridpp.rl.ac.uk 1_4 737874.0 0+05:44:24 5032 /usr/libexec/condor/co tlhcb005@gridpp.rl.ac.uk arc-ce04.gridpp.rl.ac.uk 1_6 1336938.0 0+08:42:18 26911 /usr/libexec/condor/co tlhcb005@gridpp.rl.ac.uk arc-ce01.gridpp.rl.ac.uk 1_8 826808.0 1+02:50:16 3485 /usr/libexec/condor/co tlhcb005@gridpp.rl.ac.uk arc-ce03.gridpp.rl.ac.uk 1_3 722597.0 1+08:44:28 22966 /usr/libexec/condor/co

slide-17
SLIDE 17

Startd history

  • If STARTD_HISTORY defined on your WNs

[root@lcg1658 ~]# condor_history ID OWNER SUBMITTED RUN_TIME ST COMPLETED CMD 841989.0 tatls015 12/6 07:58 0+00:02:39 C 12/6 08:01 /var/spool/arc/grid03/PZ6NDmPQPHlnCIXDjqi 841950.0 tatls015 12/6 07:56 0+00:02:40 C 12/6 07:59 /var/spool/arc/grid03/mckKDm4OPHlnCIXDjqi 841889.0 tatls015 12/6 07:53 0+00:02:33 C 12/6 07:56 /var/spool/arc/grid01/X3bNDmTMPHlnCIXDjqi 841847.0 tatls015 12/6 07:50 0+00:02:35 C 12/6 07:54 /var/spool/arc/grid00/yHHODmfJPHlnCIXDjqi 841816.0 tatls015 12/6 07:48 0+00:02:36 C 12/6 07:51 /var/spool/arc/grid04/iizMDmVHPHlnCIXDjqi 841791.0 tatls015 12/6 07:45 0+00:02:33 C 12/6 07:48 /var/spool/arc/grid00/N3vKDmKEPHlnCIXDjqi 716804.0 alicesgm 12/4 18:28 1+13:15:07 C 12/6 07:44 /var/spool/arc/grid07/TUQNDmUJqGlnzEJDjqI

…

slide-18
SLIDE 18

Ganglia

  • condor_gangliad

– Runs on a single host (can be any host) – Gathers daemon ClassAds from the collector – Publishes metrics to ganglia with host spoofing

  • At RAL we have on one host

GANGLIAD_VERBOSITY = 2 GANGLIAD_PER_EXECUTE_NODE_METRICS = False GANGLIAD = $(LIBEXEC)/condor_gangliad GANGLIA_CONFIG = /etc/gmond.conf GANGLIAD_METRICS_CONFIG_DIR = /etc/condor/ganglia.d GANGLIA_SEND_DATA_FOR_ALL_HOSTS = true DAEMON_LIST = MASTER, GANGLIAD

slide-19
SLIDE 19

Ganglia

  • Small subset from schedd
slide-20
SLIDE 20

Ganglia

  • Small subset from central manager
slide-21
SLIDE 21

Easy to make custom plots

slide-22
SLIDE 22

Total running, idle, held jobs

  • f
slide-23
SLIDE 23

Running jobs by schedd

slide-24
SLIDE 24

Negotiator health

  • s

Negotiation cycle duration Number of AutoClusters

slide-25
SLIDE 25

Draining & multi-core slots

slide-26
SLIDE 26

(Some) Third party tools

slide-27
SLIDE 27

Job overview

  • Condor Job Overview Monitor

http://sarkar.web.cern.ch/sarkar/doc/condor_jobview.html

slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31

Mimic

  • Internal RAL application
slide-32
SLIDE 32

htcondor-sysview

slide-33
SLIDE 33

htcondor-sysview

  • Hover mouse over a core to get job information
slide-34
SLIDE 34

Nagios

  • Most (all?) sites probably use Nagios or an alternative
  • At RAL

– Process checks for condor_master on all nodes – Central mangers

  • Check for at least 1 collector
  • Check for the negotiator
  • Check for worker nodes

Number of startd ClassAds needs to be above a threshold Number of non-broken worker nodes above a threshold

– CEs

  • Check for schedd
  • Job submission test
