SLIDE 1

Modular static analysis of string manipulations in C programsa

Matthieu Journault, Antoine Min´ e, Abdelraouf Ouadjaout August 30, 2018

aThis work is supported by the European Research Council under Consolidator

Grant Agreement 681393 – MOPSA.

SLIDE 2

Introductory example

1 while (*q != ’\0’) { 2

p = q;

3

p++;

4

q++;

5 } 6 *p = *q;

Program 1: strcpy

p

desta desta − op srcl

qsrcl − oq

dest src = ’\0’ = ’\0’ ?

No out of bounds access if srcl − oq < desta − op and srcl ≥ oq and srcl < srca

1

SLIDE 3

Modular analysis?

Goal Infer a summary of strcpy function to prevent reanalysis in top-down analysis.

1 char* strcpy(char* p, char* q) { 2

while (*q != ’\0’) {

3

p = q;

4

p ++;

5

q ++;

6

}

7

p = q;

8 }

Program 2: strcpy

Problems:

What do pointers point to?
What are the aliasing patterns?

2

SLIDE 4

Language

intType

∆

= s8 | s16 | s32 | s64 | u8 | u16 | u32 | u64 scalarType

∆

= intType | ptr type

∆

= scalarType | type[n] n ∈ N | struct{u0 : type, . . . , un−1 : type} | union{u0 : type, . . . , un−1 : type} lval

∆

= *scalarTypeexpr | v ∈ V expr

∆

= cst cst ∈ N | &lval | expr ⋄ expr ⋄ ∈ {+, ≤, . . . } stmt

∆

= v = malloc(e) v ∈ V, e ∈ expr | type v v ∈ V | · · ·

Figure 1: Syntax of the language

array, union type, struct type
string
dynamic allocation
pointer arithmetic
pointer dereference with arbitrary types

Low level (pointer casts) and high level (string length) considerations. 4

SLIDE 6

Cell abstract domain

SLIDE 7

Cell definition

u 1 2 ’a’ v ’b’ ’c’ ’\0’ ’n’ Byte-level memory representation: 258 Cell memory representation: u, 0, u32 v, 0, u8 ’a’ v, 1, u8 ’b’ v, 2, u8 ’c’ v, 3, u8 ’\0’ v, 4, u8 ’n’

Cell definition Cell

∆

= {V , o, t | V ∈ V, t ∈ scalarType, 0 ≤ o ≤ sizeof (typeof (V )) − sizeof (t)}.

5

SLIDE 8

Pointers and numerical values

Pointer representation

a set of all possible base variables pointed to (⊆ V):

PC

∆

= C|ptr → ℘(V ∪ {NULL, invalid})

a numerical variable coding for the offset of the pointer

Example

1

u32 a=1;

2

u32* p=&a; ∅, ⊤, ∅ {a ∆ = a, 0, u32}, a → 1, ∅

a,

p ∆ = p, 0, ptr

,

a → 1 p → 0

, {p → {a}}

6

SLIDE 9

Abstraction

Pointers offsets and numerical cells values? Use a numerical domain to express constraints on both (potentially relational constraints between pointers offsets and numerical variable values). N♯

C: a numerical domain over the cell set C.

D♯

m

∆

= {C, R♯, P | C ⊆ Cell, R♯ ∈ N♯

C, P ∈ PC}

Remarks

Dynamic set of cells
Recency abstraction used for dynamic memory allocations

7

SLIDE 10

String abstraction

SLIDE 11

Introduction

Domain presentation

A set V ⊆ V of string variables.
For s ∈ V: sl, sa denote length and allocated size of buffer s.
Enrich numerical domain to account for length and allocated

size of buffers.

Partition memory in zones dealt with by the cell domain or

the string domain. Example

1 char [3] s; 2 int a = 0; 3 s[a] = ’u’; 4 s[a+1] = ’\0’;

{a ∆ = a, 0, s32},    a = 0, sl = 1, sa = 3    , ∅ 8

SLIDE 12

Computable Galois connection with the Cell abstract domain

Translation functions to cell(s, S♯) (resp. from cell(s, S♯)) computable functions to transform string handling from string domain to cell domain (resp. from cell domain to string domain). Example

∅,

sl = 9

sa = 15

, ∅


              s0

∆

= s, 0, u8 . . . s9

∆

= s, 9, u8 . . . s15

∆

= s, 15, u8                ,                s0 ≥ 1 s0 ≤ 255 s1 ≥ 1 s1 ≤ 255 . . . s9 = 0                , ∅) to cell(s, ·) from cell(s, ·) 9

SLIDE 13

Operators and transformers

Operators Unify strings and cells and rely on numerical domain operators. Transformers Only need definitions for: S♯s[e1] = e2(S♯) where s ∈ V E♯s[e](S♯) where s ∈ V Remarks on analyzer:

Analyzer provides dynamic expression transformations
Evaluations yield a disjunctive form on expressions and

abstract states (℘(expr × D♯))

10

SLIDE 14

Evaluation

E♯s[e](S♯) =

(tests,eval)∈table

(eval, tests(S♯))

case tests on offset evaluation before 0 ≤ e ∧ e < l ∧ e < a [1; 255] at 0 ≤ e ∧ e = l ∧ e < a after 0 ≤ e ∧ e > l ∧ e < a [0; 255] error e > a ∨ e < 0 ∅ = 0 = 0 = 0 = 0 = 0 = 0 l ? ? ? a before at after 11

SLIDE 15

Transformation

S♯s[e1] = e2(S♯) =

(tests,transf)∈table

(transftests(S♯))

case tests on offsets tests on rhs transformation set0 e1 ≥ 0 ∧ e1 ≤ l ∧ e1 < a e2 = 0 l ← e1 = 0 = 0 = 0 = 0 = 0 = 0 l ? ? ? a = 0 set0 12

SLIDE 16

Transformation

S♯s[e1] = e2(S♯) =

(tests,transf)∈table

(transftests(S♯))

case tests on offsets tests on rhs transformation set0 e1 ≥ 0 ∧ e1 ≤ l ∧ e1 < a e2 = 0 l ← e1 setnon0 e1 ≥ 0 ∧ e1 = l ∧ e1 < a e2 = 0 l ← [e1 + 1; a] = 0 = 0 = 0 = 0 = 0 = 0 l ? ? ? a = 0 setnon0 12

SLIDE 17

Transformation

S♯s[e1] = e2(S♯) =

(tests,transf)∈table

(transftests(S♯))

case tests on offsets tests on rhs transformation set0 e1 ≥ 0 ∧ e1 ≤ l ∧ e1 < a e2 = 0 l ← e1 setnon0 e1 ≥ 0 ∧ e1 = l ∧ e1 < a e2 = 0 l ← [e1 + 1; a] unchanged e1 ≥ 0 ∧ e1 < l ∧ e1 < a e2 = 0 . . . . . . . . . . . . = 0 = 0 = 0 = 0 = 0 = 0 l ? ? ? a = 0 unchanged 12

SLIDE 18

Example

1

while (*q != ’\0’) {

2

p = q;

3

p ++;

4

q ++;

5 }; 6 *p = *q;

Program 3: strcpy

{p, q},    p = 0, q = 0, 0 ≤ sl < sa, 0 ≤ tl < ta    , p → s, q → t

{p, q},

       −p + q = 0, sl ≥ p, tl ≥ p + 1, . . .        , p → s, q → t

{p, q},

   tl = sl, q = sl, sl ≥ 0, sa ≥ sl + 1, . . .    , p → s, q → t

13

SLIDE 19

Going modular

SLIDE 20

Avoid losing precision, gain scalability

Goals:

Function analysis should be done with call site information

(pointer aliasing, variable ranges): Top down analysis

Classic top down analysis: function calls are inlined
Use function body analysis to infer a summary
Replace further function body analysis by use of a summary

Incrementation function

1 int

incr(int x) {

2

return (x+1);

3 }

Program 4: incr

Semantic of incr can not be

exactly represented by a list of tabulated input/output pairs.

⇒ use a relational domain:

{x = x′ + 1} = λx.x + 1

14

SLIDE 21

Modular analysis

In practice: Summaries are : {(F0, R0), (F1, R1), . . . } such that:

Fi is a precondition (an abstract element)
Ri is a postcondition (an abstract relation).

When encountering a function call made from an abstract state S♯:

If there exists some Fi such that S♯ ⊑ Fi, return Ri(S♯)
Otherwise if number of summaries is low perform relational

analysis of the body of the function starting from S♯: (yielding R) and store newly found (S♯, R) relation.

Otherwise choose some summary (Fi, Ri), perform relational

analysis of the body of the function starting from Fi▽S♯: (yielding R) and store newly found (Fi▽S♯, R) relation.

15

SLIDE 22

Not just numerical

Incrementation function

1 ... 2

incr(p)

3 ... 4

incr(q)

5 ... 6 void

incr(int* x) {

7

x = x + 1;

8

return;

9 }

{p, a, b},

a ≥ 0,

p = 0

, {p → a}

{q, c},

c = 0,

q = 0

, {q → c}

16

SLIDE 23

Not just numerical

Incrementation function

1 ... 2

incr(p)

3 ... 4

incr(q)

5 ... 6 void

incr(int* x) {

7

x = x + 1;

8

return;

9 }

{p, a, b},

a ≥ 0,

p = 0

, {p → a}

{p, α},

α ≥ 0,

p = 0

, {p → α}

{q, c},

c = 0,

q = 0

, {q → c}

Input generalization

Remove useless information (unreachable blocks) from input
Universal quantification of some memory blocks (α here is a

symbolic cell) ⇒ framing

16

SLIDE 24

Relations on structured states

1 void

incr(int* x) {

2

x = x + 1;

3

return;

4 }

with filter: {x, α},

α ≥ 0,

x = 0

, {x → α}

Discover relations of the form: (Si, N, So): Si = {x, α}, {x → α} N = {α′ ≥ 0, x = 0, α = α′ + 1, x = x′} So = {x, α}, {x → α} ⇒ Can be reused for other calls to incr

17

SLIDE 25

Example

1 void

strcat(char* dest , char* src)

2 { 3

int i; int j;

4

for (i=0; dest[i]!= ’\0’;i++) ;

5

for (j=0; src[j]!= ’\0’;j++)

6

dest[i+j] = src[j];

7

dest[i+j] = ’\0’;

8 }

Program 5: strcat

Summary: When:

dest −

→

0 β

src −

→

0 γ

Then: {β′

l = γl + βl, β′ a = βa, γ′ a = γa, γ′ l =

γl, γ′

l ≥ 0, γ′ l ≤ γ′ a − 1, γ′ l ≤ β′ l, β′ l ≤

β′

a − 1} 18

SLIDE 26

Implementation

SLIDE 27

Implementation

Mopsa A framework for the development of static analyzers by abstract interpretation, written in OCaml, that supports (for now) a subset

f C and Python.

Tests Focused on comparison with previous works:

Simon and King: 2 examples successfully analyzed
Allamigeon et al: 1 example successfully analyzed
Dor et al: 7 out of 9 example of Web2c successfully analyzed

(lack C features)

19

SLIDE 28

Example of successfully analyzed programs (1/2)

1 typedef struct { 2 char* f; 3 } s; 4 char buf [10]; 5 6 void init(s* x) { 7 x[1].f = buf; 8 } 9 int main () { 10 s a[2][2]; 11 s* ptr = (s*) &(a[1]); 12 init(ptr); 13 ptr = (s*) &(a[0]); 14 strcpy(a[1][1].f,"strcpy ok"); 15 strcpy(a[1][1].f,"strcpy not ok"); 16 }

Program 6: string in struct

From Allamigeon et al.
strcpy called on a string in

a struct itself in a matrix, and accessed by pointer manipulations.

no false positive, error

found at line 15.

20

SLIDE 29

Example of successfully analyzed programs (2/2)

1 char* insert_long (char* cp) 2 { 3

char tbuf[BUFSIZ ];

4

int i;

5

for (i=0;& buf[i]<cp ;++i)

6

tbuf[i] = buf[i];

7

strcpy (& tbuf[i],"(long)");

8

strcpy (& tbuf[i + 6], cp);

9

strcpy(buf , tbuf);

10

return cp + 6;

11 }

Program 7: insert long

From Dor et al., taken from

Web2c.

inserts "(long)" string in a

global variable buf at position pointed to by cp.

Modular relation inferred

for insert long: length of buf increased by 6 (under some conditions).

21

SLIDE 30

Conclusion

Modular static analysis of string manipulations in C programsa
