SLIDE 1
Missing proton energy fake data effect on deltaCP
DUNE LBL meeting May 13 2019
Cristóvão Vilela
This is what we have presented before
- Mass-squared bias: ~0.04e-3 eV*eV
- sinsq(theta_23) bias: ~0.025
- deltaCP bias: ~ 0.3 pi
2
Missing proton energy fake data effect on deltaCP DUNE LBL meeting - - PowerPoint PPT Presentation
Missing proton energy fake data effect on deltaCP DUNE LBL meeting - - PowerPoint PPT Presentation
Missing proton energy fake data effect on deltaCP DUNE LBL meeting May 13 2019 Cristvo Vilela This is what we have presented before Mass-squared bias: ~0.04e-3 eV*eV sinsq(theta_23) bias: ~0.025 deltaCP bias: ~ 0.3 pi 2
SLIDE 2
SLIDE 3
These are the spectra we have showed before
Background was not included on the nue samples (see next slide)
3
SLIDE 4
This is what the backgrounds look like
Also, new selection and binning
4
SLIDE 5
DeltaCP = 1.5 pi
5
SLIDE 6
DeltaCP = 1.2 pi
6
SLIDE 7
Fake data fit with latest analysis tools
Ignore error bars, look only at bias - these are just the gaussian-like uncertainties at the best-fit point
7
SLIDE 8
Same, without backgrounds
8
SLIDE 9
With th13 constrained
9
SLIDE 10
Appearance only, th13 unconstrained
10
SLIDE 11
All oscillation parameters fixed other than delta
11
SLIDE 12
All oscillation parameters fixed other than delta and th13
12
SLIDE 13
All oscillation parameters fixed other than delta and th23
13
SLIDE 14
All oscillation parameters fixed other than delta and dmsq32
14
SLIDE 15
15 years exposure all oscillation parameters fitted
7 years ND exposure
15
SLIDE 16
7 years exposure all oscillation parameters, NuFit constraint on all except deltaCP
16
SLIDE 17
Is this just a fluke?
- For a global energy scale transformation:
- From disappearance we get a biased mass-squared splitting:
○ Such that numu survival probability stays invariant ■ i.e., energy scale shift is absorbed by oscillation parameters
17
SLIDE 18
Is this just a fluke?
- Ignoring the solar term, can write the
deltaCP dependence as:
- with
- Now apply energy scale transformation and
use transformed :
○
- Appearance probability is invariant under:
○ and
- To first order, deltaCP measurements are
robust wrt energy scale in a joint LBL fit.
○ Disappearance parameter measurements are not.
18
SLIDE 19
So what about this?
arXiv:1507.08560
“Since the atmospheric parameters are fixed to their current best-fit values, and we are only interested in the δCP sensitivity,there is no need to include νμ and ̄ νμ disappearance channels in our analysis.”
19
SLIDE 20
Delta CP energy scale robustness - neutrinos
20
SLIDE 21
Delta CP energy scale robustness - antineutrinos
21
SLIDE 22
Delta CP energy scale robustness - neutrinos
True atmospheric mass splitting known.
22
SLIDE 23
Delta CP energy scale robustness - antineutrinos
True atmospheric mass splitting known.
23
SLIDE 24
Degeneracies
Neutrinos
- Disappearance parameters can
be degenerate with deltaCP. Made with Luke’s plotting tool.
24
SLIDE 25
Conclusions
- The missing proton fake data only induces a bias in delta CP if dmsq32 is
fixed at nominal.
○ Otherwise, there is a nearly perfect trade-off between biasing deltaCP and dmsq32 and the data prefer a biased dmsq32, which is not surprising given its significant effect in the disappearance samples.
- Our fake data biases dmsq32, not deltaCP
○ To make a case for deltaCP probably need fake data that’s (more) different from a global energy scale shift… ○ Need ideas on how to present this in the short term.
25
