Michael Lubliner, Senior Building Science Specialist WSU Energy Program Funding provided by the Northwest Energy Efficiency Alliance Technical support provided in Washington: Training (in-person, webinars, video) Phone and email inquiry


slide-1
SLIDE 1

Michael Lubliner, Senior Building Science Specialist WSU Energy Program

Funding provided by the Northwest Energy Efficiency Alliance

slide-2
SLIDE 2

Technical support provided in Washington:

  • Training (in-person, webinars, video)
  • Phone and email inquiry hotline support
  • Energy code compliance tools
  • Website with educational resources

WSU Energy Code website

  • Building department site visits
slide-3
SLIDE 3

Residential - Spend an hour on our web page!

  • WSU Energy Program
  • 360-956-2042
  • energycode@energy.wsu.edu
  • www.energy.wsu.edu/code
  • Mike Lubliner, Melinda Spencer,

Carolyn Roos

Non-residential

  • Evergreen Technology Consulting
  • Lisa Rosenow
  • 360-539-5300
  • com.techsupport@waenergycodes.com
  • http://waenergycodes.com
slide-4
SLIDE 4
  • Delivered 80 WSEC-R 2015 trainings to 2,100 attendees
  • Reply to over 2,000 hotline calls and emails annually
  • Participate in SBCC Energy & Mechanical TAGs
slide-5
SLIDE 5
  • Code change proposals – Spring 2019
  • Tech Advisory Groups (TAG) review proposals for

SBCC – Summer 2019

  • SBCC puts together model codes integrated with

proposed changes – Fall 2019

  • Public hearings & council vote – Winter 2019
  • Council & Legislative Approval – Winter 2020
  • Implementation – November 1, 2020 (new permits)
slide-6
SLIDE 6

45% energy savings (or 55% of the energy consumption in 2006)

slide-7
SLIDE 7
  • Residential buildings and associated sites, systems and

equipment

  • Maximum and minimum for residential construction in

each town, city and county

  • R3 - Single and townhomes
  • R2 - Multi-family 3 stories or

less above grade:

– Corridor style – “Garden” style (enter to each from outside)

slide-8
SLIDE 8
  • Chapter 1 - Scope and Administration
  • Chapter 2 - Definitions
  • Chapter 3 - General Requirements
  • Chapter 4 - Residential Energy Efficiency
  • Chapter 5 - Existing Buildings (challenging)
  • Chapter 6 - Reference Standards
  • Appendix A - Default Heat Loss U-Factors
  • Appendix RA/RB - R405 Optional Energy Measures
  • Appendix C - Exterior Design Conditions
slide-9
SLIDE 9
  • R401 - General
  • R402 - Building Envelope
  • R403 - Systems
  • R404 - Electrical Power & Lighting
  • R405 - Simulated Performance Alternative
  • R406 - Additional Energy Efficiency Credits
  • R407 - Certified Passive House (new)
slide-10
SLIDE 10
  • Air sealing of all joints and seams on all

ducts, air handlers and filter boxes (see IMC 603.9 or IRC M1601.4)

  • Duct testing performed and permanently

documented

  • Signed affidavit (duct tester’s

responsibility)

  • Test results must be recorded on

certificate for new construction (builder’s responsibility)

slide-11
SLIDE 11

Use RS-33 Duct Testing Standards

This and other resources are available on our website

www.energy.wsu.edu/Documents/Duct Testing Standards modified2015WSEC.pdf

slide-12
SLIDE 12
  • A permanent certificate shall be completed by the builder
  • r other approved party
  • Posted on a wall in the space where the furnace is located
  • a utility room or an approved location inside
  • The certificate shall list the R-values of insulation:

ceiling/roof, walls, foundation (slab, below-grade wall, and/or floor) and ducts outside conditioned spaces

  • U-factors for fenestration (see glazing worksheet)

.

slide-13
SLIDE 13
  • Types and efficiencies:

– HVAC – DHW service water heating – Appliances – Renewables

  • Test results and documentation:

– Ductwork air leakage by certified tester (per RS-33) – Envelope air leakage – Ventilation system flow rate testing and commissioning

  • The code official may require test documentation including:

– An electronic record of the time, date and location of the test, using a date-stamped smart phone photo or air leakage testing software

.

slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16

Duct Testing Test Result Calculator

slide-17
SLIDE 17
slide-18
SLIDE 18
  • Introduction to duct sealing and testing requirements for the

WSEC

  • Basic understanding of the purpose of duct sealing and testing
  • Discussion of benefits of moving ducts inside
  • Get you ready to take TEC/RETROTEC training on how to use

the testing equipment!

Note: This class does not provide qualification for ENERGY STAR, PTCS, tax credits or other Beyond Code programs

slide-19
SLIDE 19
  • Leaky and poorly insulated ducts typically raise heating

and cooling costs 20% to 40%

  • A conservative estimate is ducts waste over $10 billion in

energy in residential homes

  • HVAC ducts are “low-hanging WSEC-R fruit”
  • Design HVAC within the conditioned space?
  • Why drive a Tesla on flat tires?
slide-20
SLIDE 20
  • The hole needs to be connected to the outside
  • Heat loss is proportional to temperature and pressure

differences

  • Holes that see high pressures and high temperature

differences are most important for energy savings

  • In heating climates, this is the supply side near the air

handler

  • In cooling climates this is the return side near the air

handler

slide-21
SLIDE 21
  • Health and safety
  • Comfort
  • Energy savings
  • Building durability
  • Reduce greenhouse gases

in atmosphere

slide-22
SLIDE 22

105o – 140o

40o 40o 40o 40o

  • 68

+

40°

slide-23
SLIDE 23
  • Radon

Other soil gasses

+

slide-24
SLIDE 24

105o – 140o

+

68

68o-72o 68o-72o 68o-72o 68o-72o 68o-72o

  • 40°
slide-25
SLIDE 25

50o – 60o

+

68

68o-72o 68o-72o 68o-72o 68o-72o 68o-72o

  • 90°
slide-26
SLIDE 26
  • +

Return Air Pathway

slide-27
SLIDE 27
slide-28
SLIDE 28

Large Hole Unsealed Dovetail Connections

slide-29
SLIDE 29

Large hole where down drafting furnace connects to supply plenum

slide-30
SLIDE 30

Holes

slide-31
SLIDE 31
  • CFM: Cubic feet per minute
  • Pa: Pascals
  • Conditioned Floor Area (CFA): Square footage of all

heated areas

  • Manometer: Digital pressure-reading device
  • Duct Tester: Equipment used to pressurize ducts
  • Blower Door: Equipment used to pressurize (or

depressurize) a structure

slide-32
SLIDE 32
  • Airflow requires:
  • Driving force
  • (pressure or temperature

difference)

  • A hole
  • Air moves from high to low

pressure areas P1 + P2

  • P1- P2= P

Airflow  Hole size x P

slide-33
SLIDE 33

Perfect Duct

1 cfm (exfiltration)

1 cfm (infiltration)

1 cfm Perfect Duct System 1 cfm

slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36
  • Airflow in = airflow out, so

flow through fan = flow through leaks in system

  • CFM25 is an aggregation of all holes throughout the

entire duct system – that’s all!

  • It does not tell us where to find the holes
  • It does not tell us how much the ducts leak under

normal operating conditions

  • Without a blower door, it does not tell us how

much of the holes are connected to the outside

slide-37
SLIDE 37
  • Duct leakage to the
  • utdoors measures

effective duct leakage to the outside

  • Combines a blower door

with the duct blower

  • Total duct leakage

measures leakage to indoors and outdoors

Both tests provide cubic feet per minute (CFM) duct leakage numbers

slide-38
SLIDE 38

At rough-in:

  • Total leakage ≤ 4 CFM per 100 sf of conditioned floor

area @ 25 Pa for a complete system

  • Total leakage ≤ 3 CFM per 100 sf of conditioned floor

area @ 25 Pa if air handler has not been installed

slide-39
SLIDE 39

Post construction:

  • Total leakage test: ≤ 4 CFM per 100 sf
  • Leakage to exterior test: ≤ 4 CFM per 100 sf
  • Total leakage: ≤ 3 CFM per 100 sf buried duct
  • 2018 code (new)

Based on conditioned floor area @ 25 Pa

slide-40
SLIDE 40

Total leakage

  • House size: 2,240 sf
  • 2,240 x 0.04 = 90 CFM maximum

Leakage to exterior (requires a blower door)

  • House size: 2,240 sf
  • 2,240 x 0.04 = 90 CFM maximum
slide-41
SLIDE 41

Duct Testing Affidavit Test Result Calculator

slide-42
SLIDE 42

Exception:

Duct tightness test is not required if:

  • The air handler and all ducts are located within conditioned space
  • 10 feet of return ducts and 5 feet of supply ducts are allowed to

be outside of the conditioned space

slide-43
SLIDE 43
  • Duct tester
  • Manometer
  • Register blocks or “mask”

fan & rings

slide-44
SLIDE 44
  • Connect duct tester to furnace cabinet or return grill
  • Close/seal outside ventilation air openings
  • Block (seal) all registers
  • Remove furnace filter
  • Insert static pressure tap
  • Program manometer
slide-45
SLIDE 45

Seal registers to pressure test

slide-46
SLIDE 46
slide-47
SLIDE 47
  • 1. Insert static probe into duct
  • 2. Point toward air flow direction

Airflow

slide-48
SLIDE 48
slide-49
SLIDE 49
  • Meters measure pressures only
  • Most meters will convert pressures to flow rate
  • Attention to meter details is critical:

Garbage in = garbage out

Minneapolis DG-700

slide-50
SLIDE 50
slide-51
SLIDE 51

Color-coded connections

slide-52
SLIDE 52

Step 1: Seal all registers and grills Mask or foam blocks

Integrated fresh air duct sealed

Also: integrated fresh air duct sealed

slide-53
SLIDE 53

Step 2: Insert in Supply Side (in or near supply plenum)

slide-54
SLIDE 54

Step 3: Connect Duct Blower to System

Integrated fresh air duct sealed

slide-55
SLIDE 55
  • 1. Seal all registers and grills
  • 2. Seal fresh air duct and/or HRV
  • 3. Install static pressure tap in supply side
  • 4. Attach duct blower to system
  • 5. Set up pressure gauge
  • 6. Pressurize system to + 25 Pa
  • 7. Record air flow into system @ + 25 Pa
  • 8. Document set-up configurations
  • 9. Consider automated duct testing report with time/GPS
slide-56
SLIDE 56

and Yields duct leakage CFM to the exterior

slide-57
SLIDE 57

Seal and pressurize ducts to + 25 Pa Blower door pressurizes building to + 25 Pa

slide-58
SLIDE 58

Incorporates blower door

  • 1. Seal all registers and grills
  • 2. Seal fresh air duct and/or HRV
  • 3. Install static pressure tap in supply side
  • 4. Attach duct blower to system
  • 5. Install blower door and close up the house
  • 6. Set up pressure gauges
  • 7. Pressurize house to +25 Pa (blower door)
  • 8. Pressurize duct system to +25 Pa (duct blower)
  • 9. Record air flow into system @ +25 Pa
  • 10. Document set-up configurations
slide-59
SLIDE 59
slide-60
SLIDE 60

All joints, seams and connections shall be fastened and sealed

  • See IMC 603.9 or IRC M1601.3 for details
  • Closure systems must be installed

according to the manufacturer’s listing

  • Unlisted duct tape is not permitted as a

sealant on any metal ducts

slide-61
SLIDE 61

Duct tape may be used if:

  • Installed in accordance with mfg’s

installation instructions

  • Must contain detailed info specific to

application on ducts

  • Info must contain approved duct materials

and surface cleaning requirements Please let us know if you find this information from any manufacturer!

slide-62
SLIDE 62
slide-63
SLIDE 63

Mechanically fastened joint using “the right tool for the job” per UL flex duct listing using approved Panduit strapping gun!

slide-64
SLIDE 64
slide-65
SLIDE 65
slide-66
SLIDE 66
slide-67
SLIDE 67
slide-68
SLIDE 68
slide-69
SLIDE 69
slide-70
SLIDE 70
slide-71
SLIDE 71
slide-72
SLIDE 72
slide-73
SLIDE 73
slide-74
SLIDE 74
slide-75
SLIDE 75
slide-76
SLIDE 76
slide-77
SLIDE 77
slide-78
SLIDE 78
slide-79
SLIDE 79
slide-80
SLIDE 80
slide-81
SLIDE 81
slide-82
SLIDE 82
slide-83
SLIDE 83
slide-84
SLIDE 84
slide-85
SLIDE 85
slide-86
SLIDE 86
slide-87
SLIDE 87
slide-88
SLIDE 88
slide-89
SLIDE 89
slide-90
SLIDE 90
  • Attics, crawl spaces, garages require R-8
  • In slabs or underground require R-10
  • On a roof or exterior of a building require R-8 and

a weatherproof barrier

slide-91
SLIDE 91
  • Typical duct liner

requires 2.5 inches to meet code

  • Most duct liner is R-4

per inch & need additional insulation

slide-92
SLIDE 92
  • Installation of ducts in exterior walls, floors or ceilings

shall not displace required insulation

  • Unlined building cavities shall not be used as ducts
slide-93
SLIDE 93
  • Primary space conditioning systems in each dwelling

unit require a programmable thermostat

  • Heat pumps with supplemental electric resistance

heaters shall have strip heat lockout controls

  • Max. setting of 40oF
  • Set to 35oF or less at final inspection
slide-94
SLIDE 94

Duct testing is required when replacing HVAC equipment. This includes:

  • Air handler replacement
  • Outdoor condensing unit (AC or HP)
  • Cooling or heating coils
  • Furnace heat exchanger
slide-95
SLIDE 95
  • Testing must be completed by certified technician
  • Results provided to homeowner and building
  • fficial on affidavit
slide-96
SLIDE 96
  • Ducts with less than 40 lineal feet in unconditioned

spaces

  • Ducts that have been previously tested
  • Ducts containing asbestos
  • Ducts in additions less than 750 sf
slide-97
SLIDE 97
  • Habitat for Humanity
  • First WA ENERGY STAR
  • All ducts inside
  • 1,000 sf
  • All electric < $40/month
slide-98
SLIDE 98
slide-99
SLIDE 99
slide-100
SLIDE 100
slide-101
SLIDE 101
slide-102
SLIDE 102
slide-103
SLIDE 103
slide-104
SLIDE 104

Ducts between floors High-efficiency furnace inside the structure

slide-105
SLIDE 105

For floor/ceiling assemblies only - not for crawl spaces

slide-106
SLIDE 106
slide-107
SLIDE 107

Pressure difference

  • Stack effect
  • Wind effect
  • Temperature difference effect
  • Duct leakage effect
  • HVAC zone balance
slide-108
SLIDE 108

44

NCAT

Source: Residential Energy

slide-109
SLIDE 109

What does the energy code require?

  • Prescriptive air sealing
  • Testing of the air barrier
  • Maximum leakage targets
  • 2015 WSEC maximum = 5 ACH50

new/additions

  • 2018 may need 0.5 credit for 3 ACH50
  • 2018 may want 2.0 ACH50 w/HRV or

ERV 2020 for 1.5 - 2.0 credits

slide-110
SLIDE 110

Building envelope must have continuous air barrier Breaks or joints are sealed Air-permeable insulation is not an air barrier

VS.

slide-111
SLIDE 111
  • Air Barrier & Insulation table

R402.4.1.1

  • Include checklist of each building

component with: QA = who, what, when & how? = < ACH50

  • Cost-effective measure
  • The devil’s in the air barrier QA

details

slide-112
SLIDE 112
slide-113
SLIDE 113
slide-114
SLIDE 114

Existing house Addition Addition only = 5.0 ACH Addition + existing house = 7.0 ACH

slide-115
SLIDE 115

Duct Sealing for Comfort, Energy and Air Quality

http://www.energy.wsu.edu/videos/duct-sealing/

Sealing HVAC system ducts is a cost-effective energy efficiency action that also improves indoor air quality. Learn how ducts move air, where common leaks are, and how to fix leaks.

slide-116
SLIDE 116

Air Leakage in Homes: The Invisible Thief

http://www.energy.wsu.edu/videos/air-leakage-in-homes_part-01/

(presented in 7 chapters)

slide-117
SLIDE 117
slide-118
SLIDE 118
slide-119
SLIDE 119
  • Closed house condition
  • Blower door creates negative pressure
  • Measure house pressure + air flow out
  • Use - 50 Pascals pressure

High air flow @ 50 Pascals = large air leakage Low air flow @ 50 Pascals = small air leakage

slide-120
SLIDE 120

Measure the pressure in building Measure the volume of air out fan Calculate the leakage area Estimate air exchange

slide-121
SLIDE 121
  • Blower door
  • Fan
  • Panel
  • Frame
  • Manometer
  • Old version
  • New (WiFi) version

w/multiple doors

slide-122
SLIDE 122
  • Assemble frame, place nylon panel over frame,

secure in exterior door frame

  • Insert fan in panel
  • Connect tubing to manometer, fan and exterior
  • Properly program manometer
  • Depressurize to -50 Pa and record CFM
slide-123
SLIDE 123

Device Configuration select “REF” ports “Input” ports Device select Mode select

slide-124
SLIDE 124

BD 3 OPEN PR/ FL

Pa CFM

1

BD = Blower Door

slide-125
SLIDE 125

BD 3 OPEN PR/ FL

Pa CFM

1

slide-126
SLIDE 126

BD 3 OPEN PR/ FL

Pa CFM

1

slide-127
SLIDE 127

BD 3 OPEN PR/ FL

Pa CFM

1

slide-128
SLIDE 128
  • Close exterior windows and doors
  • Close fireplace and stove doors
  • Close dampers (depressurizing

the house sucks gravity dampers closed)

  • Plumbing traps must be filled with

water or blocked in some other manner

  • Open interior doors

Did I fill the plumbing traps?

slide-129
SLIDE 129
  • Open access hatches to conditioned

attics or crawl spaces

  • Exterior ventilation openings closed

and sealed

  • HVAC ducts and registers not sealed
  • HVAC, water heater OFF
slide-130
SLIDE 130

Pressure (in Pascals) Flow rate (CFM)

slide-131
SLIDE 131
  • Determine leakage rate of house with blower

door (CFM @ 50 Pascals)

  • Calculate to volume of the house (ft3)

ACH50 = (CFM x 60) ÷ volume

slide-132
SLIDE 132
  • 2,000 sf house
  • Volume = 16,000 ft3 (2,000 x 8)
  • Blower door CFM = 1,300 CFM
  • ACH50 = (CFM x 60) ÷ volume
  • ACH50 = (1,300 x 60) ÷ 16,000
  • ACH50 = 78,000 ÷ 16,000
  • ACH50 = 4.8
slide-133
SLIDE 133
  • Now that you understand the testing approaches and

requirements for WSEC-R, you need to learn how to use the equipment and become proficient using it

  • Spend 1-3 hours on these websites learning how to

use the equipment:

  • https://retrotec.com/
  • https://energyconservatory.com/
slide-134
SLIDE 134

www.energy.wsu.edu/ BuildingEfficiency/EnergyCode
